Haier HLPW028BXW User manual

Installation and User Manual
Instructions d’installation et
Guide de l’utilisateur
Instrucciones de instalación y
Manual del usuario
HLPW028BXW
Top-Load Clothes Washer
Laveuse à chargement par le haut
Lavadora de ropa con carga superior
Designed for
High-Eciency; use
HE detergent.
Conçue pour haute
ecacité; utiliser
un détergent HE.
Diseñada para un
alta eciencia; use
detergente HE (Alta
eciencia).
Part # 0030812994A
HAR # 0570001092 REV A

TABLE OF CONTENTS
WASHER SAFETY ................................................................................ 2
PARTS AND FEATURES ......................................................................... 5
INSTALLATION REQUIREMENTS ............................................................. 6
Tools and Parts ............................................................................. 6
Location Requirements ................................................................... 7
Water Supply Requirements ............................................................. 7
Drain System Requirements ............................................................. 7
Electrical Requirements .................................................................. 9
INSTALLATION INSTRUCTIONS ............................................................ 11
Step 1 - Unpack Washer ................................................................ 11
Step 2 - Install Bottom Cover .......................................................... 13
Step 3 - Install Casters .................................................................. 14
Step 4 - Connect and Secure the Drain Hose ...................................... 16
Step 5 - Connect the Water Hoses ................................................... 17
Step 6 - Level the Washer .............................................................. 20
Step 7 - Complete Installation ........................................................ 21
CONTROL PANEL AND FEATURES .......................................................... 22
Control Panel .............................................................................. 22
Cycle Guide ................................................................................ 23
WASHER USE ..................................................................................... 24
Step 1 - Prepare and Sort Laundry .................................................... 25
Step 2 - Add Fabric Care Products .................................................... 25
Step 3 - Load the Washer ............................................................... 27
Step 4 - Start the Washer ............................................................... 27
WASHER CARE ................................................................................... 27
Cleaning and Maintenance ............................................................. 28
Vacationing ................................................................................ 29
Moving or Storage Preparation ........................................................ 29
Reinstalling/Using Washer Again ..................................................... 30
TROUBLESHOOTING .......................................................................... 31
Error Codes ............................................................................... 31
Operation .................................................................................. 32
Water ....................................................................................... 32
Noise ....................................................................................... 33
Clothing .................................................................................... 34
LIMITED WARRANTY ........................................................................... 35
RECORD KEEPING .............................................................................. 36
1
ENGLISH

WASHER SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and
on your appliance. Always read and obey all safety messages.
DANGER
WARNING
CAUTION
This is the safety alert symbol.
This symbol alerts you to potential hazards that can
kill or hurt you and others. All safety messages will
follow the safety alert symbol and either the word
“DANGER,” “WARNING” or “CAUTION.”
These words mean:
An imminently hazardous situation. You
could be killed or seriously injured if you
don’t immediately follow instructions.
A potentially hazardous situation
which, if not avoided, could result in
death or serious bodily injury.
A potentially hazardous situation
which, if not avoided, may result in
moderate or minor injury.
All safety messages will tell you what the potential hazard is, tell you
how to reduce the chance of injury, and tell you what can happen if the
instructions are not followed.
2
ENGLISH

IMPORTANT SAFETY
INSTRUCTIONS
WARNING: To reduce the risk of re, electrical shock, injury to
persons, or damage when using the washer, follow basic precautions,
including the following:
•Read all of the instructions before using this appliance.
•Use this appliance only for its intended purpose as described in this
user manual.
•Do not place articles that have been previously cleaned in, washed in,
soaked in, or spotted with gasoline, dry-cleaning solvents or other
ammable or explosive substances in the wash water. These
substances give o vapors that could ignite or explode.
•Close supervision is necessary if this appliance is used by or near
children. Do not allow children to play on, with, or inside this
appliance.
•Do not use the washer for commercial clothes washing.
•Under certain conditions, hydrogen gas may be produced in a hot-
water system that has not been used for 2 weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot water system has not been
used for such a period, before using a washing machine, turn on all
hot-water faucets and let the water ow from each for several
minutes. This will release any accumulated hydrogen gas. As the gas
is ammable, do not smoke or use an open ame during this time.
•This appliance must be properly installed and located in accordance
with the installation instructions before it is used.
•Do not store or install this appliance where it will be exposed to
temperatures below freezing or exposed to weather, which can cause
damage to the appliance.
•The appliance must be properly grounded to conform with all
electrical codes and ordinances. See “Electrical Requirements”
section.
•Keep the area around your appliance free from combustible materials
such as lint, paper, rags or chemicals.
•Do not add gasoline, dry-cleaning solvents, or other ammable or
explosive substances to the wash water. These substances give o
vapors that could ignite or explode.
•Do not reach into the appliance if the wash basket, tub or agitator is
moving.
•Do not tamper with the controls.
•Do not stand on top of the washer.
•If the power plug or power cord are damaged, contact your nearest
service center. Do not use a damaged power plug.
•To reduce the risk of electric shock, disconnect this appliance from
the power supply before attempting any maintenance or cleaning.
NOTE: Turning o power with the Power button does NOT
disconnect the appliance from the power supply.
3
ENGLISH

IMPORTANT SAFETY
INSTRUCTIONS
•Do not attempt to service, repair or replace any part of the appliance
unless specically recommended in this user manual or in published
user-repair instructions that you understand and have the skills to
carry out.
•Before the washer is removed from service or discarded, remove the
washer door or lid.
•Do not operate your appliance when parts are missing or broken.
•Do not operate this appliance unless all enclosure panels are properly
in place.
READ AND SAVE THESE
INSTRUCTIONS
State of California Proposition 65 Warnings:
WARNING: This product contains one or more chemicals known to the
State of California to cause cancer.
WARNING: This product contains one or more chemicals known to the
State of California to cause birth defects or other reproductive harm.
WARNING
Suffocation Hazard
Before you throw away your old appliance, remove the door or lid so
that children cannot hide or get trapped inside your old appliance.
Failure to follow these instructions can result in death or brain damage.
4
ENGLISH

PARTS AND FEATURES
m nl
a
b
c
d
e
fg
h
i
j
k
r
o
p
q
ATop Lid
BControl Panel
CCabinet
DCabinet Handle (2)
ELeveling Legs (2)
FDrain Port
GPower Cord (120 Volt / 60 Hz)
HAccess Panel
ICold Water Inlet Valve
JHot Water Inlet Valve
KWash Basket
LPowdered Detergent Dispenser
MPower Jet (2)
NOuter Tub Cover
OBalance Ring
PLint Filter (2)
QLiquid Bleach Dispenser
RPulsator
5
ENGLISH

HIGH-EFFICIENCY
•This washer uses a pulsator wash system to gently clean clothes using less water
and energy than a traditional agitator washer.
•Less water produces a concentrated water and detergent solution that
aggressively works to loosen soils.
•Use only High-Eciency detergent. An “HE” logo or the words “High-Eciency”
on the detergent label indicate that the detergent is the correct type to use in
this washer.
NOTE: Regular detergents will create excessive suds that can damage
washer components, reduce rinse performance, and lead to soap lm build-
up that creates mold and mildew. Follow the detergent manufacturer’s
instructions for the amount of HE detergent to use.
INSTALLATION REQUIREMENTS
TOOLS AND PARTS
Gather the required tools and parts before starting installation.
TOOLS NEEDED
•Pliers
•Large Adjustable Wrench
•Flat-blade Screwdriver
•Phillips Screwdriver
•Tape Measure
•Carpenter's Level
PARTS SUPPLIED
•Drain Hose Clamp
•Drain Hose Hook
•Drain Hose
•Water Hoses (2)
(at washers
pre-installed)
•Cable Ties (2)
•Bottom Cover
(with screw) •Caster Kit •Faucet Adapter
6
ENGLISH

LOCATION REQUIREMENTS
IMPORTANT: Do not install or operate the washer where it will be exposed to
temperatures below 32°F (0°C). Water remaining in the washer will freeze and
cause damage to the washer.
•The washer must be installed on a solid oor to minimize vibration during the
spin cycle. A concrete oor is the best.
•The oor should be level with maximum slope of 1" (25 mm) under entire washer.
•A suitable location is protected from direct sunlight and heat sources such as
radiators, baseboard heaters, or cooking appliances.
•Do not install on carpeting.
•The location must have a grounded electrical outlet located within 4 ft. (1.2 m) of
power cord on the back of the washer.
•Hot and cold water faucets must be present within 3 ft. (0.9 m) of the hot and
cold connections on the washer.
•This appliance must be operated at room temperature.
PRODUCT DIMENSIONS
21²⅓₂"
(55.0 cm)
22¹⁄₁₆"
(56.0 cm)
37⅝"
(95.6 cm)
WATER SUPPLY REQUIREMENTS
•A water heater must supply hot water with a temperature of at least 120°F
(49°C).
•The water pressure should be between 20 and 120 psi (138 to 827 kPa).
DRAIN SYSTEM REQUIREMENTS
IMPORTANT:
•Do not lay the drain hose on the ground. A portion of the drain hose must
be kept higher than the water line inside the wash basket or the ll water will
run out of the drain hose and the washer will not work correctly.
•The end of the drain hose cannot be immersed in water for the washer to
work properly.
7
ENGLISH

a
a
AWater Line
WALL
•Fasten the drain hose to the water hose as shown.
FLOOR STANDPIPE
For the drain hose, the height of the standpipe drain should be between 39" and 60"
(99 cm and 153 cm) from the bottom of the washer.
The standpipe drain requires a minimum diameter standpipe of 2" (5 cm). The
minimum carry-away capacity can be no less than 17 gal. (64 L) per minute.
•Fasten the drain hose to the standpipe tightly, as shown.
39" – 60"
(99 cm – 153 cm)
8
ENGLISH

LAUNDRY TUB
The laundry tub must have a minimum capacity of 20 gal. (76 L). For the drain hose,
the height of the sink rim should be between 39" and 48" (99 cm and 122 cm) from
the bottom of the washer.
•Fasten the drain hose to the laundry tub leg tightly, as shown.
39" – 48"
(99 cm – 122 cm)
ELECTRICAL REQUIREMENTS
WARNING
Electrical Shock Hazard
The washer must be connected to a properly grounded 120 volt, 60 Hz.,
AC only, 15- or 20-amp, fused electrical supply. A time-delay fuse or
circuit breaker is recommended.
Failure to do so could result in death, fire or electric shock.
•If you are in doubt the electric supply provided meets the above requirements,
contact a licensed electrician.
9
ENGLISH

WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove the ground prong from the power cord plug.
Do not use an adapter.
Do not use an extension cord.
Failure to do so can result in death, fire or electrical shock.
•A 120 volt, 60 Hz., AC only, 15- or 20-amp, fused electrical supply is required. A
time-delay fuse or circuit breaker is recommended. It is recommended that a
separate circuit breaker serving only this appliance be provided.
•This washer is equipped with a power supply cord having a 3 prong grounding
plug.
•The power cord must be plugged into a mating, 3 prong outlet, grounded in
accordance with local codes and ordinances. If a mating outlet is not available,
contact a licensed electrician to have one installed.
•If codes permit and a separate ground wire is used, it is recommended that a
qualied electrician determine that the ground path is adequate.
•Do not ground to a gas pipe.
•Check with a qualied electrician if you are not sure the washer is properly
grounded.
•Do not have a fuse in the neutral or ground circuit.
10
ENGLISH

GROUNDING INSTRUCTIONS
For a grounded, cord-connected washer:
The washer must be grounded. In the event of a malfunction or
breakdown, grounding will reduce the risk of electric shock by providing a
path of least resistance for electric current. The washer is equipped with
a cord having an equipment-grounding conductor and a grounding plug.
The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
Check with a qualied electrician or serviceman if you are in doubt
whether the washer is properly grounded.
Do not modify the plug provided with the washer; if it will not t the
outlet, have a proper outlet installed by a qualied electrician.
For a permanently connected washer:
The washer must be connected to a grounded metal, permanent wiring
system, or an equipment-grounding conductor must be run with the
circuit conductors and connected to the equipment-grounding terminal
or lead on the washer.
INSTALLATION INSTRUCTIONS
We recommend that your new washer be installed by a qualied appliance
technician. If you feel that you have the skills to install the washer, please read the
installation instructions carefully before installing.
IMPORTANT:
•If, after completing these steps, you are unsure that the washer is properly
installed, contact a qualied appliance technician.
•If your washer was just delivered and the outside temperature was below
freezing, do not operate until the washer warms up to room temperature.
STEP 1 - UNPACK WASHER
WARNING
Suffocation Hazard
To avoid danger of suffocation, keep plastic bag and other packing
material away from babies and children. Do not use this bag in cribs,
carriages and playpens. The plastic bag could block nose and mouth
and prevent breathing. This bag is not a toy.
Failure to follow these instructions can result in death or brain damage.
11
ENGLISH

WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
1. Remove all packing materials. This includes the foam base, molded plastic
support and all adhesive tape holding the washer accessories inside and
outside.
IMPORTANT: Failure to remove the packing base will cause the washer to
not operate properly and will void your warranty.
•Open the lid to access the wash basket brace. Pull up on the basket brace to
remove.
NOTE: Save the wash basket brace to use when moving the washer in
the future.
a
AWash Basket Brace
•Using two or more people, lift the washer o of the packing base and the
molded plastic support.
NOTE: It is possible for the plastic support, under the U bracket, to
remain attached to the bottom of the washer. Make sure it is removed
with the foam base.
b
a
APlastic Support
BFoam Base
2. Inspect the washer, and remove any remnants of packaging, tape or printed
materials before using the washer.
12
ENGLISH

3. Properly dispose of /recycle all packing material.
STEP 2 - INSTALL BOTTOM COVER
WARNING
Electrical Shock Hazard
Install bottom cover.
Lock all four casters prior to operating washer.
Failure to do so can result in death, electric shock or personal injury.
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before operating.
Failure to do so can result in death or electrical shock.
1. Lay folded blankets or towels on the oor to create an incline.
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
2. Using two or more people, lay the washer onto its side so that the top of the
washer is higher than the base, and the drain outlet is facing upward.
13
ENGLISH

ab
ADrain Outlet
BTop of Washer
3. With the side of the bottom cover that is marked FRONT/UP toward the interior
and front of the washer, align the edges of the cover with the track in the
bottom of the washer.
4. From the front of the washer, slide the bottom cover fully into the track making
sure the edges of the cover are behind the tabs.
NOTE: When the cover is completely inserted into the track behind the
tabs, the hole for the screw will be ush and aligned with the hole in the
cabinet bottom.
a
c
bc
ABottom Cover
BScrew Hole
CTabs
5. Using the screw (provided), fasten the bottom cover to the cabinet base.
6. If installing casters, continue with STEP 3 - INSTALL CASTERS (OPTIONAL). If
not installing casters, using two or more people, stand the washer upright.
STEP 3 - INSTALL CASTERS
(Optional)
NOTE: If you later decide to install casters, you must rst lay the washer on its
side. See “STEP 2 - INSTALL BOTTOM COVER” for instructions on how to
correctly lay the washer on its side.
1. Using a at blade screwdriver, pry the rubber pads from the bottom of all four
washer legs.
14
ENGLISH

a
ARubber Pad
2. Install casters on the adjustable front legs.
•Unscrew the two front leveling legs from the base of the washer.
•Using the hex key (provided), thread a caster insert into each leveling leg.
•Screw the caster/spacer assembly into the inserts and then reinstall the
two front leveling legs.
a c d e
b
ACaster
BLock
CSpacer
DCaster Insert
ELeveling Leg
3. Install casters on the xed rear legs.
•Using the hex key (provided), thread the caster inserts into the rear washer
legs.
•Screw the caster/spacer assembly into the inserts.
a c d
b
ACaster
BLock
CSpacer
DCaster Insert
4. Using the wrench (provided), completely tighten all casters.
15
ENGLISH

WARNING
Electrical Shock Hazard
Install bottom cover.
Lock all four casters prior to operating washer.
Failure to do so can result in death, electric shock or personal injury.
5. Lock each caster by pressing down on the caster lever.
WARNING
Excessive Weight Hazard
Use two or more people to move and install washer.
Failure to do so can result in back or other injury.
6. Using two or more people stand the washer upright.
STEP 4 - CONNECT AND SECURE THE DRAIN HOSE
1. Enlarge the opening by squeezing the ends of the drain hose clamp together.
Slide the clamp over the end of the drain hose, and onto the exible section of
the hose.
2. Fit the drain hose rubber end over the plastic drain port on the washer.
3. Squeeze the ends of the clamp to enlarge the opening, and then slide the drain
hose clamp over the connection of the drain hose rubber end and drain port.
Release the clamp to tighten.
4. Place the drain hose (hook end) in a wall drain pipe, standpipe or laundry tub.
NOTE: The drain hose will shake when water is being pumped out of the
washer.
5. Secure the drain hose in place by fastening it to a water hose, the standpipe, or
a leg on the laundry tub. See “Drain System Requirements” for illustrations.
6. Check all hose connections to ensure the connections are tight.
16
ENGLISH

STEP 5 - CONNECT THE WATER HOSES
Depending on your model, the water hoses provided will be either Style 1 or Style 2.
Follow the instructions specic to the style of water hoses provided.
IMPORTANT: Use only new hoses when installing the washer. The water hoses
must have coarse thread connectors on one end (to connect to the household
water supply), and ne thread connectors on the other end (to connect to the
washing machine).
NOTE:
•Periodically inspect hoses for cracks, cuts, leaks or wear. Replace with new
hoses every 5 years.
•Hot water needs to be set at a temperature of at least 120ºF - 140ºF. (49ºC-
60ºC) for the soap to dissolve and to avoid soap residue remaining on
clothes.
1. Check that a at washer is present and rmly in place in each end of the water
inlet hoses.
Style 1
a
Style 2
a
AWasher
2. Thread the white end of the inlet hose by hand onto the COLD water inlet valve
on the back of the washer until rmly hand tightened.
IMPORTANT:
•Do not connect the gray end of the inlet hose to the washer. You will
damage the threads and it will leak.
•To avoid damage to the hose couplings, do not overtighten.
Style 1 - Using pliers, tighten the connection an additional two-thirds turn
(MAXIMUM). Do not use excessive force.
Style 2 - Do not use pliers to tighten the connection.
NOTE: To avoid damage to the washer inlet valves, do not use plumber’s
tape or sealants on the valve threads.
Style 1
Cold Water
Hot Water
a
Style 2
Cold Water
Hot Water
a
AWhite End Only
3. Determine installation type.
17
ENGLISH

•If you wish to install the washer in a xed location, follow the instructions in
the “OPTION 1 - FIXED” section.
•If you wish to install the washer in a temporary location, skip to the
instructions in the “OPTION 2 - PORTABLE” section.
OPTION 1 - FIXED
1. First thread the white end of the second inlet hose onto the HOT water valve on
the back of the washer until rmly hand tightened. Then, thread the gray ends
of the inlet hoses onto the HOT and COLD water faucets by hand until rmly
hand tightened.
Style 1 - Using pliers, tighten the three connections an additional two-thirds
turn (MAXIMUM). Do not use excessive force.
Style 2 - Do not use pliers to tighten the connections.
IMPORTANT:
•Make sure that one hose connects the Hot water faucet to the Hot
water inlet valve and the other hose connects the Cold water faucet to
the Cold water inlet valve.
•To avoid damage to the hose couplings and plastic washer inlet valve
threads, do not overtighten.
NOTE: To avoid damage to the faucet do not use thread seal tape or
sealants on the valve threads.
Style 1
a
Style 2
a
AGray End Only
2. Turn on the hot and cold water faucets and check for leaks. If there is any
leaking, check for loose connections and tighten.
OPTION 2 - PORTABLE
1. Remove the aerator from your faucet nozzle.
2. Examine the faucet to determine if it has internal or external faucet threads.
Internal threads - Keep the rubber washer (A) in place.
External threads - Remove the rubber washer (A) before threading the faucet
connector onto the faucet.
18
ENGLISH
