Haier HWM85-1482 User manual

User Manual HWM85-1482

Elements
2
Thanks for purchasing a Haier Product
Please read these instructions carefully before using this appliance. The instruction contain important
information which will help you get the best out of the appliance and ensure safe and proper installation,
use and maintenance
Keep this manual in a convenient place so you can always refer to it for the safe and proper use of the
appliance.
If you sell the appliance, give it away, or leave it behind when you move house, make sure you also pass on
this manual so that the new owner can become familiar with the appliance and safety warnings.
Accessories
Check the accessories and literature in accordance with this list:
1x Use & care manual
1x Base Cover
1X Drain hose bracket
1x Inlet Hose
5x Blanking Plugs

Index
3
..................................................................................................................................................4
Before Use .............................................................................................................................................7
Functions ..............................................................................................................................................10
Maintenance .........................................................................................................................................18
Trouble-Shooting ..................................................................................................................................20
Technical Data ................................................................................. .................................................23
After Sales Service .................................................................................................................................24
Legend
Yes
No
Optional
Caution
Attention

Cautions
4
Before switching the appliance on for the first time
Do…
Make sure that the transport bolts are removed.
Use a separate earthed socket for the power supply.
Make sure that the plug is accessible.
Hold the plug and not the electric cable when unplugging the mains
supply.
Make sure that the fuse in the power circuit is rated for 10Amps.
Keep away from heat sources and direct sun light to prevent plastic and rubber components from
aging.
Make sure that the power cord is not caught under or in the appliance and avoid damage to the
power cable.
Check that hose joints and connections are firm and no water can leak. If joints are loose or
there is leakage, turn off the water supply and refit. Do not use the washing machine until the
hoses are properly fixed.
Do Not…
Touch or use the appliance when barefoot or with wet or damp hands or feet.
Use flammable detergent or dry cleaning agent.
Use any flammable sprays in close vicinity to the appliance.
Remove or insert the plug in presence of flammable gas.
Allow children or infirm persons to play with the appliance or packing materials.
Install the appliance outdoors in a damp place, or in an area which may be prone to water
leaks such as under or near a sink unit. In the event of a water leak allow the machine to dry
naturally.
Place the washing machine directly on a carpet.

Cautions
5
During daily use of the appliance
Do…
Pull up zips and fix loose threads to prevent the items from being entangled. If necessary, put
small items into a laundry bag or pillow case.
Turn off the machine after each wash program and switch it off at the mains to save electricity and
for safety. Wipe clean the lower part of the porthole of any remaining water.
Keep the door slightly open when the washing machine is not in use to prevent formation of odours.
The power cord must be replaced by the manufacturer, service agent or qualified persons, if it is
damaged.
Ensure that the appliance is not used by people with reduced physical, sensory or mental
capabilities, lack of experience and knowledge without supervision or instruction by a person that
responsible for their safety.
Supervise children to ensure that they do not play with the appliance.
Do not…
Touch the washer glass door during the washing process, it gets hot on the 60°C & 90°C cycles.
Place heavy objects or sources of heat or damp on top of the appliance.
Hot wash foam rubber or sponge-like materials.
Open the detergent distribution drawer during the wash cycle.
Force the washer door pen, the door is fitted with a self-lock device and will open shortly after the
washing procedure is ended.
Open the washer door if the water level is visibly over the porthole.
Cover the washing machine with a cover so that may keep dampness in.

Cautions
6
Saving Tips
Achieve the best use of energy, water, detergent and time by using the recommended maximum
load size
Do not exceed the detergent dosages indicated in the manufacturer’s instructions.
The Eco-Ball –a special system in the outlet- will prevent detergent loss from the drum to avoid
detergent loss into the environment.
Use “Prewash” for heavily soiled laundry only. Save detergent, time, water and energy consumption
by not selecting “Prewash” for slightly too normal soiled laundry.
Save energy and time by selecting a high spin speed to reduce the water content in laundry before
using a tumble dryer.
Choose a proper washing temperature. Modern detergents can wash with very good result already
in lower temperature than 60°C. Only y use higher temperature than 60°C for heavily soiled laundry.

Before Use
7
Description
This diagram may be slightly different from the layout of the washing machine you have just purchased.
Unpacking the washing machine
Remove all the packing materials prior to use, including the
polystyrene base. Upon opening the package, water drops may be
seen on the plastic bag and the porthole. This is normal phenomenon
resulting from water tests in the factory.

Before Use
8
Installation
Fitting the base cover
Before removing the transportation bolts, please
fix the base cover to the bottom of the washing
machine. Lay down the machine (fig1) screw off
the feet and adjust the base cover with the four
holes corresponding to the screw holes of the
feet. Then screw the feet back on through the
cover and fix it securely to the bottom of the
machine (fig2).
The base keeps out any dampness and reduces
the noise
Removing the transportation bolts
The transportation bolts are designed for clamping,anti-
vibration components inside the washing machine during the
transportation process
Remove the back cover. Fig 1.
Remove the four bolts on the rear side and take out the
synthetic stabilisers from within the machine Fig 2
Replace the back cover. Fig 3.
Fill the holes left by the bolts with blanking plugs. Fig 4.
When replacing the back cover, ensure the convex
surface is facing outwards, and insert the back
cover between the gaps as shown in Fig. 5.
Keep the transportation bolts and synthetic
stabilisers in a safe place for later use
Adjusting the feet
There are adjustable feet under the bottom of the washing machine.
Before use, they should be adjusted so that the machine is level. This will
minimize vibrations and noise during use. It will also reduce wear and tear. We
recommend using a spirit level to level the appliance. The floor should be as
stable and flat as possible.

9
Before use
Inlet Hose
Connect the nut on the inlet hose to the connector on
the water valve (fig1).
Apply inlet hose to a water tap with cold, fresh water
(fig2).
Use the hose-set supplied with the appliance.
Old hose-sets should not be reused.
Drain Hose
Use the drain hose bracket to keep the end of the drain
hose retained and prevent the outflow of water (fig1). Do
not extend the length of the drain hose; if an extended
hose is required, please consult a serviceman.
The height of the drainage outlet must be 80-100 cm. Fix
the drain hose to the clip at the back of the washing
machine to prevent it from dropping off (fig2).
The drain hose should not be submerged in water and should be securely fixed and leak-
free. If the drain hose is placed on the ground or if the pipe is at a height of less than
80cm, the washing machine will continuously drain while being filled (self-siphoning).
Connecting to the power supply
Before connecting to the power supply, check:
The socket is adequate for the maximum power of the washing
machine (For safety, fuses in the power circuit should be rated
for no less than 10A).
The voltage should meet the requirement.
The power outlet should be capable of accepting the washing
machine plug.
Connect the machine to an earthed socket outlet.

Functions
10
