Haier HVTF48DPABS User manual

French Door Design Dual Compartment
Dual Zone Wine Cellar
Cave à vin compartiment double Dual Zone
Enfriador de vino con Compartimiento doble
Dual Zone
User Manual
Model # HVTF48DPABS
Guide de l’Utilisateur
Modéle # HVTF48DPABS
Manual del Usuario
Para Modelo de # HVTF48DPABS
Quality • Innovation • Style

IMPORTANT SAFEGUARDS
When using this appliance, always exercise basic safety
precautions, including the following:
1. Read all of the instructions before using this appliance.
2. Use this appliance only for its intended purpose as described in this
use and care guide.
3. This wine cellar must be properly installed in accordance with the
installation instructions before it is used. See grounding instructions in
the installation section.
4. Never unplug your wine cellar by pulling on the power cord. Always
grasp the plug firmly and pull straight out from the outlet.
5. Unplug your wine cellar before cleaning or before making any
repairs. Note: If for any reason this product requires service, we
strongly
recommend that a certified technician performs the service.
6. Repair or replace immediately, all electric power cords that have
become frayed or otherwise damaged. Do not use a cord that shows
cracks or abrasion damage along its length, the plug or the connector
end.
7. This wine cellar should not be recessed or built-in an enclosed
cabinet.
It is designed for freestanding installation only.
8. If your old wine cellar is not being used, we recommend that you
remove the door and leave the shelves in place. This will reduce
possibility of danger to children.
9. Do not operate your wine cellar in the presence of explosive fumes.
10. Do not store foods in wine cellar as interior temperature may
not be cool enough to prevent spoilage or may cause bacteria growth.
SAVE THESE INSTRUCTIONS
1
English

2
Thank you for using our Haier
product. This easy-to-use manual
will guide you in getting the best
use of your wine cellar.
Remember to record the model and
serial number. They are on a label
in back of the wine cellar.
Model number
Serial number
Date of purchase
Staple your receipt to your manual. You will need it to obtain
warranty service.
DANGER
Risk of child entrapment. Before you throw away your old wine
cellar, take off the doors. Leave the shelves in place so that
children may not easily climb inside.
English

Table Of Contents
PAGE
Important Safeguards ....................................................................1
Parts And Features ..........................................................................4
Installing Your Wine Cellar ............................................................5
Unpacking Your Wine Cellar ................................................................5
Leveling Your Wine Cellar ....................................................................5
Proper Air Circulation ..........................................................................5
Electrical Requirements ........................................................................6
Installation Limitations ..........................................................................6
Use of Extension Cords ........................................................................6
Wine Cellar Features And Use ............................................................7
Initial Set Up........................................................................................7
Temperature Adjustment ......................................................................7
Shelving ..............................................................................................8
Interior Light ........................................................................................8
Child Lock Temperature Control............................................................8
Door Handle Installation ......................................................................8
Proper Wine Cellar Care and Cleaning ........................................9
Cleaning and Maintenance ..................................................................9
Power Interruptions ..............................................................................9
Vacation and Moving Care ..................................................................9
Troubleshooting ............................................................................10
Warranty Information....................................................................11
3
English

1. LED Temperature Display
2. Temperature Adjustment (Up)
3. Temperature Adjustment (Down)
4. Interior Light Button
5. Stainless Steel Door Handle
6. Adjustable Leveling Legs (not shown)
7. Interior Shelves
8. Tinted Glass Door
4
5
English
6
7
Parts And Features
8
2
13
4

1. Remove all packaging material. This includes the foam base and all
adhesive tape holding the wine cellar accessories inside and outside.
2. Inspect and remove any remains of packing, tape or printed
materials before powering on the wine cellar.
• Your wine cellar has four leveling legs which are located in the
front and rear corners of your wine cellar.After properly placing your
wine cellar in its final position, you can level your wine cellar.
• Leveling legs can be adjusted by turning them clockwise to raise your
wine cellar or by turning them counterclockwise to lower your wine
cellar. The wine cellar door will close easier when the leveling legs
are extended.
• To assure your wine cellar works at the maximum efficiency it was
designed for, you should install it in a location where there is proper
air circulation, plumbing and electrical connections.
• The following are recommended clearances around the wine cellar:
Sides……………2" (50mm)
Top....................2" (50mm)
Back..................2" (50mm)
•Do not over fill your wine cellar for proper wine cooling.
Installing Your Wine Cellar
Unpacking Your Wine Cellar
Proper Air Circulation
Leveling Your Wine Cellar
5
English

Electrical Requirement
•Make sure there is a suitable power Outlet (115 volts, 15 amps
outlet) with proper grounding to power the wine cellar.
• Avoid the use of three plug adapters or cutting off the third grounding
in order to accommodate a two plug outlet. This is a dangerous prac-
tice since it provides no effective grounding for the wine cellar and
may result in shock hazard.
• Do not install your wine cellar in any location not properly insulated
or heated e.g.garage etc.
• Select a suitable location for the wine cellar on a hard even
surface away from direct sunlight or heat source e.g. radiators,
baseboard heaters, cooking appliances etc. Any floor unevenness
should be corrected with the leveling legs located on the front and
rear bottom corners of the wine cellar.
• Your wine cellar is designed for free-standing installation only. It is
not designed for built-in application.
• Avoid the use of an extension cord because of potential safety haz-
ards under certain conditions. If it is necessary to use an extension
cord, use only a 3-wire extension cord that has a 3-blade grounding
plug and a 3-slot outlet that will accept the plug.The marked rating
of the extension cord must be equal to or greater than the electrical
rating of the appliance.
Install Limitations
6
English
Use of Extension Cord

•Your wine cellar has an electronic temperature control in front of the
unit. The two individual temperature zones maintain their own
temperature with the dual controls. The cooling temperature ranges
from 46˚ F to 64˚ F. This makes it ideal for white wines and reds
wine in either of the compartments. Please note that the actual
cabinet temperature in a thermal electric unit is dependent on the
ambient temperature. If the ambient temperature is too high then the
cabinet temperature may not reach the preset range.
• To raise or lower the temperature simply press the “Temp tDOWN”
or “Temp sUP” button.
• The LED display will show the actual cabinet temperature while it is
running.
•The set temperature will be displayed for several seconds once it is
set. After that it will revert back to the actual cabinet temperature.
Wine Cellar Features And Use
Initial Setup
When turned on, the LED will display the internal temperature. If the temperature
is not set it will operate at 54˚ F in each compartment.
Temperature Adjustments:
7
English

•The shelves are designed to have air movement around the bottles to
keep the wine cool. Either of the chambers can fit 24 bottles. Making
a total bottle capacity of 48.
• To complement the look of your wine collection, a soft light has been
built into the wine cellar. Simply push the "Light" button and the light
comes on, push again for off. For maximum energy efficiency, leave
light off when not viewing your collection.
• Your wine cellar has a child lock function for the temperature control.
This function is controlled by the light button. To lock the set
temperature simply keep the light buton pressed in for 5 seconds. To
un lock it, press it for another 5 seconds.
• The wine cooler comes with 2 metal stainless steel handles. One for
each side. To install simply screw them to the door with the supplied
screws.
Shelving
8
English
Interior Light
Door Handle
Handle Screw
Screw Cover
Door Handle
Door
Child Lock Temperature Control

Warning: To avoid electric shock always unplug your
wine cellar before cleaning. Ignoring this warning
may result in death or injury.
Caution: Before using cleaning products, always read and
follow manufacturer’s instructions and warnings to
avoid personal injury or product damage.
General:
• Prepare a cleaning solution of 3-4 tablespoons of
baking soda mixed with warm water.Use sponge or
soft cloth, dampened with the cleaning solution, to
wipe down your wine cellar.
• Rinse with clean warm water and dry with a soft
cloth.
•Do not use harsh chemicals, abrasives, ammonia,
chlorine bleach,concentrated detergents, solvents or
metal scouring pads. SOME of these chemicals may
dissolve, damage and/or discolor your wine cellar.
• Clean door gaskets every three months according to
general instructions. Gaskets must be kept clean and
pliable to assure a proper seal.
• Petroleum jelly applied lightly on the hinge side of
gaskets will keep the gasket pliable and assure a
good seal.
Proper Wine Cellar Care and Cleaning
Cleaning and Maintenance
Door Gaskets:
9
English
•Occasionally there may be power interruptions due to thunderstorms
or other causes. Remove the power cord from ACoutlet when a
power outage occurs. When power has been restored, replug power
cord to AC outlet.
• For long vacations or absences, unplug the wine cellar and clean the
wine cellar and door gaskets according to "General cleaning" section.
Leave doors open, so air can circulate inside.
• When moving always move the wine cellar vertically. Do not move
with the unit lying down, as possible damage to the unit
could occur.
Power Interruptions
Vacation and Moving Care
