1.0 Introduction
1.1 General
The Hall Research PGA-VHD is a handheld versatile multi-interface tester for video and audio. As a video
generator, it provides both VGA and HDMI outputs, and as an analyzer, it features an HDMI 2.0 input. The
product boasts a bandwidth of 18 Gbps (supporting 4K/60 4:4:4) and supports HDCP 2.2. An indispensible
tool for verification and troubleshooting of AV installations or for performing compatibility tests in the lab,
the PGA-VHD offers many advanced features at a cost effective price.
The battery operated PGA-VHD has a large color 4K display with touch screen function for user operation
and viewing status of outgoing and incoming video. The screen can also act as a 4K HDMI monitor
supporting virtually all HDTV and PC resolutions. The instrument can also be used as an analyzer for video
signal sources and displays. The PGA-VHD can perform “loop test” where quantitative information
concerning performance of cables, extenders, repeaters, and video splitters can be obtained.
The instrument is packaged and shipped in a rugged carrying case to protect your instruments from hostile
environments, shock, vibration, moisture and impact. Users will appreciate the built-in long lasting battery
operation, multitudes of video patterns including user’s own custom pattern uploadable via USB, touch panel
control, and access to advanced features such as HDCP analyzer and loop test in a single instrument. The
PGA-VHD supports 8-channel LPCM audio with selectable sample rate. The analyzer can also be used in pass-
through mode bypassing HDMI input to the connected display at the output.
1.2 Features
•Provides both VGA and HDMI outputs and an HDMI input
•HDMI input can be used as a display, source analyzer, or pass-thru loop mode
•Supports HDMI 2.0(a) on output and input with 18 Gbps Bandwidth
•Supports 4K2K/60 4:4:4 8bit and 4K2K60 4:2:0 16bit video signals
•High Dynamic Range Video with HDR 10 support
•Supports HDCP 2.2 (and 1.4)
•Large selection of output video patterns including user defined and patterns with moving objects
•Large 4.3” touch screen for display and control
•Screen image can be mirrored (duplicated) to the HDMI output (perfect for training)
•USB port for mouse control, loading custom patterns, or firmware update
•Analog (stereo) audio output
•Ethernet control using Telnet commands
•Scrambler supported for videos over 340MHz output
•EDID read and save option
•Rugged and durable housing with convenient carrying case
•Battery operation time of up to 4 hours under full load
NOTE
Fist time use:
Prior to switching on the PGA-VHD for the first time, you must plug the power supply to it. This will disable
the “shipping mode” and charge the device. We recommend leaving the product connected to the power
supply for 2 to 3 hours prior to using it with battery alone for the first time.

Video Generator/Analyzer
5
2.0 Package Contents
(1) Carrying Case
(1) Model PGA-VHD
(1) 12V DC Power Supply
(1) IEC Power Cord
(1) 6’ HDMI Cable
(1) 6’ VGA Cable
(1) User’s Manual
3.0 Configuration and Operation
3.1 Panel Description
Block Diagram
DC 12V: Connect the 12V 5A DC power supply supplied with the unit.
LAN: Connect the CAT5e/6 cable to this port to control the device using Ethernet TCP/IP protocol.
USB: Connect to a mouse for control or a flash drive for firmware update or loading custom patterns.
AUDIO OUT: Connect to speakers for analog audio output.
VGA OUT: Connect to a VGA display for simultaneous video output.
HDMI IN: Connect to this port to make the PGA-VHD act as a sink.
HDMI OUT: Connect to this port to make the PGA-VHD act as a source.
Touch Panel: Touch screen for user control.
Sturdy carrying case

PGA-VHD
6
3.2 General Operation
There are SIX major options on the Home Screen on the PGA-VHD.
Quick Select – Top Menu Bar
Output Type
Source Test
Sink Test
Loop Test
Settings (gear icon on the bottom right)
3.2.1 Quick Select Bar
There is a quick select menu bar at the top of the HOME screen so users can easily navigate from one setting
to another. PGA-VHD offers the users the convenience to change the output resolution, pattern and output
HDCP encryption all from one screen.
Home Screen – Showing the Top Menu Bar
Quick Select – Top Menu Bar
Menu Item
Description
1
Shows the current output resolution setting. Click on it to quickly jump to: Output
Settings/Signal Format/Resolution to select a different resolution.
NOTE
Navigating through Submenus:
The Quick Select items are clickable only when the main menu is shown. Once you have clicked into any
submenu, the Quick Select top line items are not clickable. To navigate back to the main menu, use the blue
back arrow button on the screen.

Video Generator/Analyzer
7
2
Shows the last pattern selected from the Default Patterns group (pattern names from Album
including user uploaded patterns are not shown on the Quick Select bar). Clicking on this button
will take you to: Output Settings/Video Pattern (Default patterns) screen where you can select a
different pattern
3
Use this button to enable the HDMI / VGA only resolutions on the quick select line. Notice that
both VGA and HDMI outputs are always active (VGA output is always RGBHV format
regardless of HDMI color space settings). The Purpose of this quick select button is to help get
you quicker to proper list of resolutions available from the quick select bar.
4
This button will take you to Sink Test/HDCP Selection page where you can select No HDCP, 1.4
or 2.2 HDCP.
3.2.2 Output Type/Output Settings
This button is used to set the signal type for the HDMI output and to define other parameters pertaining to
the outputs such as. color space, color depth, video resolution, video pattern, and audio formats.
Output Type
Output Type
Menu
Sub-Menu
Options
Description
Signal
Format
TYPE
HDMI
Select the digital video output type - Choose the color space
(RGB, YCbCr 4:4:4, 4:2:2, or 4:2:0), color depth (8 bit thru
16 bit) and HDR mode. Depending on the resolution setting,
not all color depths and color modes may be listed or
available.
DVI
The only color option for DVI output setting is RGB 8 bit.
RESOLUTION
TV
Select among SDTV/HDTV resolutions. Here you will be
making two selections: Resolutions and Frequency (refresh
rate). Depending on the resolution selected you get
different choices for the Frequency. For example when you
select 576p for output resolution you only get 50Hz, but for
720p output resolution you get 6 choices from 25 Hz to 60
Hz
PC
Select the PC resolutions. Selection method is slightly
different than that for TV explained above. Here, you don’t
select Resolution independent of Refresh rate, instead all
available refresh rates are shown as part of the resolution.
For example you have a choice for 1440x900 @ 60Hz, and

PGA-VHD
8
1440x900 @ 75Hz
Video
Pattern
DEFAULT
Pattern
Select the output pattern, enabling/disabling timer
duration and number of moving squares and their speed
Timer
Moving
Squares
ALBUM
Select the user defined pattern *
PCM
Audio
Tone
MUTE ON/OFF
Enable/ Disable MUTE on output audio
SINE WAVE
Content
Select the bits per sample (16~24 bits), sampling rate
(32~192 KHz) and audio decibel levels
Channel
Select the number of audio channels needed (from 2 to 7.1
channels).
Setting
Scrambling
AUTO
Auto enable Scrambling for video over 340 MHz bandwidth
(Per HDMI 2.0 specifications, scrambling of the digital data
is done prior to the TMDS encoding). Auto is default mode
and is recommended.
OFF
Turn off the scrambling for output video
*Selecting ALBUM under Video Pattern tab will activate the HDMI output mirroring function.Whatever is being shown on the
touch-screen is also sent to the HDMI output. This mirroring mode stays in effect even after you leave this screen so the HDMI
output will remain a duplicate of the screen on the device. This is a useful tool for training in a classroom setting on how to use
the instrument. To disable the output-mirroring mode just select a pattern from the Default group.
3.2.3 Source Test
In this mode you are using the PGA-VHD to test a video source such as STB, laptop, Blu-ray player, etc. You
can also use this mode to turn the PGA-VHD into a 4K compatible TV. Source tests include format, video,
audio, packet and HDCP analysis of the incoming video signal from the source.
Source Test – PGA-VHD as a Sink
Source Test
Menu Sub-Menu Description
Format
READ/ SAVE
Read and save the information from the VIDEO source such as timing
parameters, HSYNC , VSYNC, pixel clock, etc.

Video Generator/Analyzer
9
Video
Full Screen
Provides a small screen displaying the video from the source in Full
Screen
Displays the video information along with the source
Enables video pass through to the display.
Full Screen Info
Pass through
Audio
READ/ SAVE
Read and save the information from the AUDIO source such as
modulation scheme, channel information, sampling rate, etc.
Packet
REFRESH
Read the hexadecimal AVI info frame
HDCP
HDCP 1.4/ HDCP
2.2 Type-0
Enable HDCP (1.4/ 2.2) on PGA-VHD display on HDMI IN port from the
source
3.2.4 Sink Test
This option is for getting more information from the connected sink device (such as TV, Projector, or
Extender) – EDID and HDCP information regarding the connected sink are available here.
Sink Test – PGA-VHD acts as a Source
Sink Test
Menu
Sub-Menu
Description
EDID
READ/ SAVE
Read and save the EDID of a HDTV or other devices using EDID analyzer
Learn from RX
Learn EDID from the DUT that’s connected to the HDMI OUT to save it in the
HDMI IN port
Use Default
Use internal PGA-VHD EDID
HDCP
HDCP 1.4
HDCP 2.2
Select HDCP 1.4 or 2.2 for video output on HDMI OUT port
3.2.5 Loop Test
This section describes the cable or repeater loop test feature to evaluate the quality of the HDMI cables.
It is important to note that in this mode the system generates video with random pixel values at its output and it
expects to see the exact same pixel data values at the input. It tallies the number of errors. Therefore if the video

PGA-VHD
10
transport is using any encoding or compression techniques, the loop test will result in huge errors since pixels are
modified (and delayed) by the encoder. You can use loop test for cables or extenders that do not modify pixel
values in anyway, such as most HDBaseT products or Hall Research’s 4K Javelin optical HDMI cables.
Loop Test
Loop Test
Menu
Sub-Menu
Description
1920x1080@60
4Kx2K@30
4Kx2K@60
Time Duration
/ Time Elapsed
Evaluate the signal quality of HDMI cables and Device Under Test
(DUT) in 3 different resolutions FHD(1080p), UHD @ 30 and UHD
@ 60
It is recommended to run the test for at least 15 seconds for the results to be meaningful. You can use Loop Test to
compare the quality of different cables or their ability to handle UHD 30Hz or 60 Hz
3.2.6 Settings
This section shows the system settings to change the screen brightness, network settings, firmware update and
battery status.
System Settings
Settings
Menu
Sub-Menu
Description
Preferences
Screen
Brightness
Adjust the screen brightness at required levels
Beep
Enable/ Disable system sound

Video Generator/Analyzer
11
Factory Reset
Restore the device to factory default setting
Ethernet
DHCP
Set the network setting of PGA-VHD to either DHCP or Static IP
addressing
Static IP
Firmware
System
Update the firmware files using USB flash drive
ARM
FPGA
Pattern
Update and store customized patterns to the internal memory (up to
2 GB of storage)
Battery
Current Charge
Shows the battery status in percentage
Time Remaining
Shows the remaining charge on the battery. You can also lock the
battery (disconnect it from the circuit) in this screen. This is
referred to as Ship Mode. The PGA-VHD is in this mode when
purchased. In this mode the unit does not power up without the
power supply connected.
4.0 Using the PGA-VHD as a Video Generator
The PGA-VHD simultaneously provides HDMI and VGA outputs, they are both active and show the same
image. HDMI is the primary output (VGA output shows the same image and EDID functions apply to HDMI
output only).
Connect the desired video output to the “Sink” using the provided cables. Sink can be an HDTV, Projector,
Repeater, Splitter or a Video Switch.
PGA-VHD as Video Pattern Generator
Select Output Type from Main Menu. See section 3.2.2 for more details.
4.1 Signal Format
The following selections can be accessed under “Signal Format” option.
•Type – Switch between HDMI and DVI output format, select Color Space, Depth and HDR modes
NOTE
Both HDMI and VGA outputs are simultaneously active. You can select HDTV or VGA resolutions from
HDMI/VGA Quick Select option from top menu bar..

PGA-VHD
12
•Resolution – Choose among HD and PC output resolutions
Select HDMI or DVI output format
Then select color parameters
Select resolution and refresh Rates
Both HDTV and PC (VGA or DVI) resolutions can be selected.
Some TV resolutions (such as 480i, 1080i, ) may not be
available (grayed-out). This occurs when the Quick Select is set
for VGA. If you want all resolutions available, go back to main
menu and change Quick Select from VGA to HDMI
4.2 Video Pattern
PGA-VHD is able to output default and user definable custom video patterns (Album). Select “DEFAULT” to
select among default patterns.
Enabling Timer shows a running timer on the
output screen. Hit RESET to reset displayed time
to 0:0:0 (or any other start time you want to set)
Enable Moving Squares and select up to 5
moving squares. Each square has a different
pre-assigned color.
4.2.1 Steps to update user defined patterns using USB flash memory
•Create a folder by the name: usr_pic on the root directory of the USB flash drive with your desired images
in JPG format. Images should ideally be 3840x2160 pixels. But the device accepts smaller images.
•From Main Menu, select the Settings Icon (gear symbol) Firmware Pattern
•Check the free space in the PGA-VHD disk storage displayed on this screen. The maximum total size for
custom patterns is 2 GB.
•Touch the “Update” option to update the patterns and wait for completion. Then reboot the device.
NOTE
Default choice also allows display of a timer on the output screen as well as enabling moving squares.
In Album mode timer or moving squares are not displayed. This mode enables the output mirroring feature
where the HDMI output is an exact duplicate of the instrument’s video screen, This is useful for
demonstrations and training purposes. To disable mirroring, select any pattern from default choices.
To go to the next image touch right edge of the screen, for previous image touch the left edge, and for going
back to gallery touch the center of the screen.

Video Generator/Analyzer
13
4.3 Select Output Audio
The audio settings can be changed in the “PCM Audio Tone” tab. The bit depth, sampling rate, decibel level and
number of audio channels can be selected.
4.4 TMDS Scrambling Setting
Auto enable Scrambling for video over 340 MHz bandwidth. Per HDMI 2.0 specifications, scrambling of the
digital data is done prior to the TMDS encoding. Auto is default mode and is recommended.
5.0 Source Test (PGA-VHD acts as Sink)
The PGA-VHD can be used to display the video from any HDMI or DVI source. It can also detect and display
the video format, audio format, packet data, and HDCP status of the signal received from the source.
Note that the source signal can be from an original video source (laptop, DVD player, etc), or it could be the
signal that is passed through a repeater, scaler, switcher, etc.
Also, for testing a switcher, scaler, or other device, you can use the PGA-VHD’s own output as the source.
Source Test – Connection alternatives for Source Test
5.1 Format Analysis
In Format Tab, read and save the information from the VIDEO source such as timing parameters, HSYNC,
VSYNC, pixel clock, etc.
TMDS Scrambler Setting
Output Audio Settings
Content Settings
Channel Settings
Source Test tabs

PGA-VHD
14
The information shown can be saved in (.dat) and (.txt) format. Plug a USB flash to the analyzer and click on
Save. Files are instantly created and saved on the USB flash device.
Source Test - Format Analysis
5.2 Video Analysis
In Video tab, a small screen displaying the video from the source is provided to monitor the incoming video
from the source. In Full Screen, the video information along with the source information is displayed.
The Pass through option enables video pass through for the video coming into the PGA-VHD’s HDMI IN to
the display via HDMI OUT.
Source Test - Video Analysis Full Screen w/ Info
5.3 Audio Analysis
In Audio tab, read and save the information from the AUDIO source such as modulation scheme, channel
information, sampling rate, etc. The information can be read and saved in (.dat) and (.txt) format in the USB
flash drive
Source Test - Audio Analysis

Video Generator/Analyzer
15
5.4 Packet Information
In this tab, the AVI info frame packet information of video source can be read and saved in (.dat) and (.txt)
format in the USB flash drive
Source Test - Packet Information
5.5 HDCP Selection
Show the HDCP standard (none, 1.4 or 2.2) for the incoming video on HDMI IN port of the PGA-VHD.
Source Test - HDCP Selection
6.0 Sink Test (PGA-VHD as Source)
This option is used for testing the EDID and HDCP of the connected SINK
HDCP encryption can be enabled on the HDMI OUT to test HDCP authentication with the sink device.
Use the following procedures to make the physical connections from the PGA-VHD from the source device
under test.
Sink Test - PGA-VHD Acting as Video Generator
6.1 Sink EDID
The PGA-VHD can read the EDID data from the downstream device displayed (analyzed) and saved on a USB
flash memory. It can also "Learn" the sink's EDID and use it for its own HDMI input

PGA-VHD
16
Sink Test - EDID Report
The “Learn from RX” option caused the PGA-VHD to use the EDID of the connected sink for its own HDMI
input's EDID. Select “Use Default” to revert and use the internal factory default PGA-VHD EDID.
Sink Test - Source learns EDID from UHD TV
6.2 HDCP Encryption applied to the output Video
In HDCP tab under SINK option, Test the HDCP of the downstream devices such as SINK or an AV receiver by
enabling the HDCP 1.4 or HDCP 2.2 Type 0 or Type 1 encryption. This will enable the HDMI OUT of the PGA-
VHD to output patterns with HDCP encryption in the above two SINK configurations.
Sink Test – Output HDCP Selection
7.0 Cable or Repeater LoopTest
This option is used to evaluate the signal quality of HDMI cables or device under test (DUT) using one of 3
resolutions FHD(1080p), UHD @ 30, or UHD @ 60.
It is recommended to run the test for at least 15 seconds for the results to be meaningful. You can use Loop Test to
compare the quality of different cables or their ability to handle UHD 30Hz or 60 Hz.
See Section 3.2.5 for more details.

Video Generator/Analyzer
17
Loop Test - Connection Examples
Procedure for Loop Test:
Select Loop Test from the HOME screen.
Set the “Time Duration” for the test.
Touch the “START” button to evaluate the signal transmission quality. Do not touch any buttons for at
least 3 seconds after starting test.
Let the PGA-VHD complete the test, or terminate Test by pressing “STOP”.
8.0 Settings
The Settings selection (gear icon) consists of system adjustments, firmware and network setup.
8.1 Preferences
Screen Brightness: Adjust the screen brightness in required levels in percentage.
Beep: Enable/ Disable system sound.
Factory Reset: Select this option to restore the device to factory default setting.
8.2 Network Setting
The PGA-VHD has Ethernet (TCP/IP) control accessibility via Network settings under the “Settings” icon on the
HOME screen.
Connect the Ethernet port of the PGA-VHD with the PC or an external control system. The user has the option to
select either the DHCP or Static IP addressing.
Network Settings
As shipped from the factory (or after restoring factory defaults), the PGA-VHD IP address is set for DHCP and
the IP address will be assigned by the router.

PGA-VHD
18
Setting the IP address
(A) DHCP - Default
In order to use the DHCP feature, you must have a compatible DHCP ROUTER OR SWITCH that will assign the
IP addresses to the end devices.
Use DHCP radio button to automatically assign IP address to the pattern generator in the network. A
DHCP router has to be connected to the network.
Click “Update” and Reboot the device.
(B) Setting STATIC IP
If your network doesn’t support DHCP server function: Then you have to change the IP addresses
manually in the fields below.
Static IP: Select Static IP radio button and enter the IP address manually.
Subnet Mask: Enter the subnet mask as assigned by your network administrator.
Gateway: Enter gateway IP address for the device and the PC.
Click “Update” to confirm the settings.
Reboot the device.
8.3 Firmware
The Firmware section can be found in “Settings” icon on the HOME screen. The firmware upgrade on PGA-
VHD can be completed through the USB port by updating the System and ARM files.
We do not recommend the user to change any settings in this tab. If you have any questions regarding firmware
update, contact Hall Research for more information
Procedure for Firmware Upgrade
Before updating the firmware on the PGA-VHD, make sure the files are in the root directory of the USB drive.
When both the ARM and System files are to be updated, update the ARM first and then the System file.
•Make sure the arm.dat, system.dat, or FPGA.dat file is in the root directory.
•Connect the USB flash drive to the PGA-VHD.
•Select Settings Firmware"Arm", “System”, or "FPGA" radio button
•Touch Update to initiate update. Wait for 10~15 seconds. Do not remove the USB while updating.
•There will be a message prompting the user to reboot the device upon completion of the update.
8.4 Battery
This section shows the battery status and time remaining for the PGA-VHD before it needs charging.
Depending on screen brightness, a fresh full battery lasts about 4 hours and it can be fully charged in 2 hours.
NOTE
Network Setting
Before changing the network setting from DHCP to Static IP, select Static IP, touch “update” and then, reboot
the device to enter the complete IP configuration..

Video Generator/Analyzer
19
9.0 TELNET Ethernet Protocol: TCP/IP Port (6133)
PGA-VHD offers communication and control via Telnet. The user can obtain information from the unit such
as output resolution, pattern, audio and video data from a remote location.
•Commands are in ASCII format.
•Each command has to be terminated by <CR> and responded with <CR>.
•Commands are case sensitive. Use uppercase characters.
•Unknown command respond with “Invalid Command”.
Set Output Resolution
Command: S OUTPUT 0~55
Response: S OUTPUT 0~55
Res 0x 1x 2x 3x 4x 5x
0
720x480i60
1920x1080i60
1920x1080p23
1366x768p60
3840x2160p59
4096x2160p50
1
720x576i50
1920x1080i59
640x480p60
1400x1050p60
3840x2160p50
4096x2160p30
2
720x480p60
1920x1080i50
640x480p75
1600x1200p60
3840x2160p30
4096x2160p29
3
720x576p50
None
800x600p60
1440x900p60
3840x2160p29
4096x2160p25
4
1280x720p60
1920x1080p59
800x600p75
1440x900p75
3840x2160p25
4096x2160p24
5
1280x720p59
1920x1080p50
1024x768p60
1680x1050p60
3840x2160p24
4096x2160p23
6
1280x720p50
1920x1080p30
1024x768p75
1680x1050pRB
3840x2160p23
7
1280x720p30
1920x1080p29
1280x1024p60
1920x1080pRB
1920x1080p60
8
1280x720p29
1920x1080p25
1280x1024p75
1920x1200pRB
4096x2160p60
9
1280x720p25
1920x1080p24
1360x768p60
3840x2160p60
4096x2160p59
Example:. Res = 21 for 640x480p60
Get Output Resolution
Command: R OUTPUT 0~55
Response: OUTPUT 0~55
Set Output Mode
Command: S MODE 0~4
Response: S MODE 0~4
Index
0
1
2
3
4
Mode
DVI
RGB
YCbCr
4:4:4
YCbCr
4:2:2
YCbCr
4:2:0
Default Pattern
Command: S PATTERN 0~47
Response: S PATTERN 0~47
NOTE
YCbCr 4:2:0 is available only for 4K2K59.94/60

PGA-VHD
20
Default Pattern
Value
Default Pattern
Value
Default Pattern
Value
SMPTE Bar
0
TV Bar 100%
1
TV Bar 75%
2
Checkfield
3
EQ
4
PLL
5
Ramp Red H 1
6
Ramp Green H 1
7
Ramp Blue H 1
8
Ramp Red H 2
9
Ramp Green H 2
10
Ramp Blue H 2
11
Ramp Black to Red V
12
Ramp Green V 1
13
Ramp Blue V 1
14
Ramp Red V 2
15
Ramp Green V 2
16
Ramp Blue V 2
17
Stair Red 1
18
Stair Red 2
19
Stair Green 1
20
Stair Green 2
21
Stair Blue 1
22
Stair Blue 2
23
Stair White 1
24
Stair White 2
25
Red 100
26
Green 100
27
Blue 100
28
White 100
29
Gray 70
30
Gray 40
31
Black
32
Noise
33
Circle 1
34
Circle 2
35
Moire
36
V Stripe Red
37
V Stripe Green
38
V Stripe Blue
39
H Stripe Red
40
H Stripe Green
41
H Stripe Blue
42
Chess 1
43
Chess 2
44
Multi Burst
45
CZP
46
Overscan
47
User Defined Pattern
Command: S USERPATTERN 0~29
Response: S USERPATTERN 0~29
User Pattern
Value
User Pattern
Value
User Pattern
Value
Philips
0
Checker3x3
1
Checker6x6-1
2
Checker6x6-2
3
White75
4
White50
5
White25
6
Ramp W-1
7
Ramp W-2
8
Ramp W-3
9
Ramp W-4
10
Graybar32 R-1
11
Graybar32 G-1
12
Graybar32 B-1
13
Graybar32 W-1
14
Graybar32 R-2
15
Graybar32 G-1
16
Graybar32 B-2
17
Graybar32 W-2
18
Graybar32 R-1
19
Graybar64 G-1
20
Graybar 64 B-1
21
Graybar64 W-1
22
Graybar64 R-2
23
Graybar64 G-2
24
Graybar64 B-2
25
Graybar64 W-2
26
User can add…
27
User can add…
28
User can add…
29
Set Audio Mute
Command: S MUTE 0~1
Response: S MUTE 0~1
Mute
Off
On
Value
0
1
Get Audio Mute Status
Command: R MUTE
Response: MUTE 0~1
Set Audio Bit Depth
Command: S AUDIOBIT 0~2
Response: S AUDIOBIT 0~2
Audio Bit Depth
24bits
20bits
16bits
Value
0
1
2
