ACTIV8 THREE ON
USER’S GUIDE
COMBINED RADAR OPENING AND ACTIVE INFRARED SAFETY SENSOR FOR ESCAPE ROUTE DOORS
2nd Radar Antenna
Cover
Push-Buttons
Radar motion sensor
Radar Antenna clip
Radar tilt angle indication
15°
30°
45°
IR-Presence sensor
IR-Prism
Main Connector
IR curtain adjustment screw
LED turns on LED flashing slowly LED flashing quickly Motion detection Presence detection Tip
LED display during normal function
GREEN LED Motion detection
RED LED Presence detection
Short flash after a motion or presence detection : Monitoring process active
ORANGE LED See chapter 5: Troubleshooting
1 Tips
Use the Remote-Control to
adjust the sensor.
Use the Spotfinder to locate
the safety curtains.
Avoid touching electronical
parts!
Avoid touching optical
parts!
Make sure the operator
cover is fixed properly and
electrically earthed.
Avoid vibrations!!! Do not cover the sensor! Avoid moving objects in
proximity to the sensor!
Avoid HF lamps and
fluorescent lighting in the
infrared field!
Avoid highly reflective
objects in the infrared field!
1 Description
3 Installation
2 Symbols

2/8
2 Mounting the sensor
Mount the sensor at a maximum height of 5cm from the bottom line
of the door operator. Use the mounting template to drill holes and position the sensor.
3 Wiring the sensor
{
To ensure a good water protection,
place the cable as shown above.
4 Radar motion sensing field : width
Sensitivity = 9 Sensitivity = 9
5 Radar motion sensing field : depth
15° 30° 45°
30°
45°
15°
0°
21 012
1
2
3
1
2
3
15
30
45
Sensitivity = 9
21 012
1
2
3
1
2
3
15
45
30
44
Sensitivity = 9
SENSOR DOOR CONTROLLER
12-24V AC/DC
Monitoring
Input Monitoring Output
(Beam transmitter)
Safety Input
(Beam receiver)
(keep door open)
Monitored Impulse
Input
(open door)
Sensor Power
Supply
Green
Brown
Yellow
White
Pink
Grey
Red
Blue
RADAR
IR

3/8
6 IR presence sensing field : width
2m
35cm
1m
35cm
Make sure to introduce the front
prism into the foreseen slides
in front of the lenses!
Above 3 m mounting height, use the narrow prism!
7 IR presence sensing field : depth (negative angle available)
+4° -4°
0°
The pin shown
here above
indicates the
angle adjusted.
To approach the
curtain to the
door, turn the
screw clockwise.
To tilt the curtain
out, turn the screw
counterclockwise.
min. 5cm
min. 5cm
0° -4°
Keep a minimum distance of 5cm
Åbetween the door and the first
curtain.
Use the Spotfinder (accessory)
to locate and adjust the position
of the curtains.
When mounting one sensor on each side of the door above a highly reflective threshold, select different frequencies
to avoid crosstalk between the sensors (see setting "Installation configuration" on p.5).
2 curtains of 24 overlapping spots
(
no holes between s
p
ots
)
2 curtains of 12 overlapping spots
(no holes between spots)

4/8
8 Remote Control adjustments (only when factory settings do not match)
Unlock the sensor to enter into adjustment
session (if no access code has been
entered)
RED LEDPress Unlock key
flashes slowly
To change the value of a parameter
(ex. Maximum duration of presence
detection)
RED LED RED LEDSelect parameter
to change flashes quickly
Enter new value
flashes slowly
… to change any other parameters
(ex. Output Configuration)
RED LED RED LEDSelect parameter
to change flashes quickly
Enter new value
flashes slowly
To check the value of a parameter (ex.
maximum duration of presence detection) …
RED LED GREEN GREEN GREEN GREEN RED LEDSelect parameter
to check flashes quickly
Press Question
Mark The number of green flashes indicate the value of this parameter flashes slowly
Lock the adjustment session and go back to
normal function
Press Lock key twice
8.a
Important Remote Control adjustments
Sensitivity
0(min) →9(max)
Factory value : 7
IR curtain
immunity
1♦normal
2 increased
3rain-mode
4snow-mode
5 snow-mode enhanced
Output configuration
Motion-Out Presence-Out
1♦Active Passive
2Passive Active
3Passive Passive
4Active Active
Number of IR
curtains
11 curtain
(safety curtain close to the door)
2♦2 curtains
32
nd curtain in dynamic mode
Unlock
Check values ?
Lock
Setup
launch a setup
launch an assisted setup
restore factory settings
Max. duration of
presence detection
030 seconds
1♦1 minute
22 minutes
35 minutes
410 minutes
520 minutes
660 minutes

5/8
8.b
Launch a setup (to take a reference picture)
Unlock the sensor to enter into adjustment
session
RED LEDPress Unlock key
flashes slowly
To launch an assisted setup
Ærecommended after mechanical
adjustments of the IR sensor module.
Ærecommended once after the first
installation
Press Setup key followed
by 0
RED/GREEN LED
alternating
The sensor performs a door opening and closing cycle to check
the influence of the door leaves to the safety curtains.
See Troubleshooting if RED LED flashes quickly after setup.
To launch a setup
Ærecommended after change of
parameters by remote control
Press Setup key twice RED/GREEN LED
alternating
The sensor only takes a new reference picture.
LED display during sensor assisted setup
RED/GREEN
LED
alternating
Setup-process active: the sensor learns its environment.
After finishing the setup process, the sensor shows the following behavior:
RED LED flashing quickly The sensor ‘sees’ the door movement and can not finish its setup.
RED LED continuously on The sensor signals a faulty IR monitoring.
ORANGE LED continuously on The sensor encounters a signal saturation
(ex. due to a highly reflective floor).
No LED turns on The sensor successfully finished its setup.
8.c
Additional Remote Control adjustments
Hold time
0♦(0.5s) →9(9s)
Detection mode
1bidirectional mode
2♦unidirectional mode
3unidirectional mode with MTF
External
Monitoring Enable
0 monitoring disabled (OFF)
1♦monitoring enabled (ON)
Safety output
redirection
F1
0♦no redirection
1transfer presence detection to
motion output
2motion output activated if motion
and presence detection
Installation
Configuration
Mounting
Height
Pulse
Frequency
1♦Low Low
2 High Low
3 Low High
4 Hi
g
h Hi
g
h
Immunity
1sismo
2♦normal
3Increased

6/8
TÜV Requirements in
Germany
To be TÜV compliant for the German market, please make sure to adjust the sensor as follows:
Number of IR curtains 2
Max. duration of presence detection 1 or higher (min. 1minute)
External Monitoring Enabled 1 (ON)
Sensitivity (size of detection field) Min. 1.5m depth
IR curtain immunity 1 to 3
High mounting height
(>3m)
If the sensor is installed higher than 3m above the floor, make sure to use the narrow prism
(see chapter “3 Installation” § 6). Also, set the sensor to “High Mounting”:
or
Installation Configuration High Mounting Height
Rain/Snow
If the sensor is exposed to rain or snow, use the URC (Universal Rain protection Cover)
Set the sensor to presetting 3 or 4 to increase the immunity of the sensor. You can reduce the influence of rain and snow
even more when selecting the RAIN or SNOW mode for the IR curtain immunity:
RAIN mode
SNOW mode
SNOW mode enhanced
Setup
Assisted Setup (~14sec) Sensor checks the influence of the door leaves to the IR
curtains (performs a door open/door close cycle)
Standard Setup (~4sec) Sensor only learns its environment
After adjusting the sensor for the first time, it is recommended to launch an “Assisted Setup”. Refer to chapter “3
Installation” § 8.2 for more information about the LED display)
If the IR sensor module “sees” the door movement, move the curtains out of the door leaves.
Access Code
The access code is recommended to set sensors close to each other with remote control. The access code can be
composed of 1 to 4 digits (factory values or no access code : 0 or 0000). No code is required to unlock during the first minute
after powering.
Overlapping
IR-curtains
Overlapping IR-curtains from sensors installed side-by-side may cause disturbances due to crosstalk (interferences).
Select different frequencies on each sensor to avoid crosstalk (see setting "Installation configuration" on p.5).
Attention: avoid curtains that are overlapping by more than 30cm (at 2,2m mounting height, using the wide prism).
No monitoring on IR
curtain
If no monitoring of the IR sensor module is required, but the product you use has the monitoring enabled by default, set the
“Monitoring” parameter to “0”:
External Monitoring Enabled 0 (= OFF)
Only one single
Impulse input on door
controller
If your door controller has only one single impulse input for motion impulse (open the door) and no safety input (keep the
door open), use the “Safety Output Redirection” to transfer the safety detection (IR sensor module) to the motion impulse
output and connect only the motion output to your door controller:
Safety Output Redirection 1 (= transfer presence detection to the motion output)
PULSE monitoring of
safety sensor (beams) If your door controller monitors its safety sensors using PULSE (ex. RECORD, ATS, DORMA ES-90 EM2/EM3), make
sure you have a PULSE compatible product (ACTIV8 THREE PULSE).
Check the wiring Push the left push button to release the outputs. The door should close and the LED should switch off.
4 Installation Tips

7/8
SYMPTOMS POSSIBLE CAUSES CORRECTIVE ACTION
Red LED flashing quickly after an assisted
setup.
The sensor ‘sees’ the door movement and
can not finish its setup.
Adjust the position of the IR curtains.
Orange LED permanently ON after an
assisted setup.
The sensor encounters a signal saturation. Use the wide-field prism and/or slightly increase the IR curtains angle
(turning the screw counterclockwise).
Red LED permanently ON after an assisted
setup.
The sensor fails the IR test. Cut and restore the power supply.
Launch a new assisted setup.
If the LED still stays ON, replace the sensor.
Orange LED ON The sensor encounters a signal saturation. Use the wide-field prism and/or slightly increase the IR curtains angle
(turning the screw counterclockwise).
Launch an assisted setup.
Orange LED flashes The sensor signals an internal fault. Cut and restore the power supply.
If the orange LED lights up again, replace faulty sensor.
Red LED ON The sensor detects a presence. Wait the time set in “maximum duration of presence detection” setting
or launch an assisted setup (with the remote control or right push
button).
Unwanted presence detection The sensor is not placed properly
and/or the front face is not properly fixed.
Fasten the sensor firmly and/or
check whether the front face prism is placed into the foreseen slides
(see section 6) and not in the sensor cover.
Door keeps recycling open-closed. The sensor is disturbed by the door motion
because it sees the door or because of
vibrations.
Green LED signals a motion detection : increase the radar angle
Red LED signals infrared detection : increase the IR curtains angle
(turning the screw counterclockwise).
The door is not closing.
LED OFF
On-Off switch at door control is in wrong
position or is faulty.
Check to insure that On-Off switch for door is in the ON or
AUTOMATIC position.
Improper output configuration on the sensor. Check the output configuration setting on each sensor.
Faulty sensor monitoring of the door
controller.
Check if the monitoring mode is ON or PULSE depending on the door
controller. Check the wiring.
After a power on, there is no LED-signal,
even during a motion detection.
The motion output is active and the presence
output is fixed.
The sensor’s monitoring input is not correctly
supplied.
Check the wiring and the power supply (voltage and polarity) of the
monitoring input.
Disable the monitoring of the sensor if the door operator cannot monitor
the sensor.
The door closes slowly.
LED OFF
Faulty sensor monitoring of the door
controller.
Check if the monitoring mode is ON or PULSE depending on the door
controller. Check the wiring.
The presence detection is disturbed by the
rain (red LED)
Increase the immunity of the curtains (immunity 3 up to 5)
The radar detection is disturbed by the rain
(green LED).
Check whether the unidirectional mode is selected and the MTF
function is disabled. Increase the radar immunity.
The sensor does not unlock when access
code is entered.
Improper code being entered. Cut and restore power supply. No code is required to unlock during the
first minute after powering. Press on “unlock”, then on “lock” and
introduce a new access code.
The sensor does not respond to the remote
control.
1. Batteries in the remote control are dead or
not installed properly.
2. Remote control badly pointed.
1. Check to insure that the batteries are installed correctly or replace
batteries.
2. Point the remote control towards the sensor.
5 Troubleshooting

8/8
Supply voltage : 12V (– 5%) to 24V (+10%) AC/DC
Mains frequency : 50 - 60 Hz
Power consumption : < 3 W
Mounting height : 1.8m to 4m
Sensitivity of the monitoring input : 10-30V DC
Delay of the output activation after stimulation : < 1ms
3-color LED : RED (presence detection) – GREEN (motion detection) – ORANGE (signal saturation, error)
Temperature range : -25°C to +55°C
Degree of protection : IP54
Norm conformity : R&TTE 1999/5/EC; EMC 89/336/EEC; TÜV; BS
Dimensions : 262 mm (L) x 55 mm (H) x 44 mm (D)
Weight : 250 g
Housing material : ABS + LURAN S
Minimum length of cable : ±2.6 m
Range of Remote Control : 5m
MOTION SENSOR PRESENCE SENSOR
Detection mode Motion
Minimum detection speed: 5 cm/s (measured in sensor axis)
Presence
Response time: < 128ms
Technology Microwave and microprocessor
Transmitter frequency: 24.175 GHz
Transmitter radiated power: < 20 dBm EIRP
Transmitter power density: < 5 mW/cm²
Focused active infrared and self-monitored microprocessor
Spot diameter (standard): 0.1m max
Number of spots: 24 or 12 spots by curtain
Number of curtains: 2
Detection field Width Depth
Wide 4 m 2 m
Narrow 2 m 2,5 m
Width Depth
Wide 2 m 0,35 m
Narrow 1 m 0,35 m
Angle From 15° to 50° in elevation (adjustable) From - 4° to + 4° (adjustable)
Output specification Free of potential current source
State “No detection”: current source ON
Max. open circuit voltage: 6.5V
Output voltage available at 10mA: 3V min.
Typical load: up to 3 optocouplers in series
State “Detection”: current source OFF
Leakage current: <100µA
Open-circuit remained voltage: <500mV
Transistor (optocoupled transistor)
Max. output current: 100 mA
Max. switching power: 42 V DC
Output holdtime 0.5s to 9s (adjustable) 0,1/1s (fixed)
Sensing field dimensions given at 2.2m mounting height.
Specifications are subject to changes without prior notice.
Remote Control Spotfinder ACA ABA
6 Technical Specifications
7 Accessories (sold individually)
42.0166 / V2 – 02.04
Parc Scientifique du Sart Tilman – Allée des Noisetiers, 5 B-4031 Angleur – Belgium - TEL [phone] - FAX [phone] – e-mail : [email protected] - http://www.beasensors.com
