PAGE 1 97588C (Rev. M - 5/04)
4420 FOUNTAIN
Halsey Taylor Fountains are among the easiest to install Fountains on the
market today. To assure you install these models easily and correctly,
PLEASE READ THESE SIMPLE INSTRUCTIONS BEFORE STARTING THE
INSTALLATION. CHECK YOUR INSTALLATION FOR COMPLIANCE WITH
PLUMBING, ELECTRICAL, AND OTHER APPLICABLE CODES. After install-
ation, leave these instructions with the Fountain for future reference.
Halsey Taylor Owners Manual
Model 4420
Bi-Level Tubular Fountain
IMPORTANT
ALL SERVICE TO BE PERFORMED BY AN AUTHORIZED SERVICE PERSON
IMPORTANT! INSTALLER PLEASE NOTE.
THE GROUNDING OF ELECTRICAL EQUIPMENT SUCHAS TELEPHONE, COMPUTERS, ETC. TOWATER LINES
IS A COMMON PROCEDURE. THIS GROUNDING MAY BE IN THE BUILDING OR MAY OCCUR AWAY FROM THE
BUILDING. THIS GROUNDING CAN CAUSE ELECTRICAL FEEDBACK INTOAFOUNTAIN, CREATING AN ELEC-
TROLYSIS WHICH CAUSES AMETALLIC TASTE OR AN INCREASE IN THE METAL CONTENT OF THE WATER.
THIS CONDITION IS AVOIDABLE BY USING THE PROPER MATERIALS AS INDICATED. ANY DRAIN FITTINGS
PROVIDED BY THE INSTALLER SHOULD BE MADE OF PLASTIC TO ELECTRICALLY ISOLATE THE FOUNTAIN
FROM THE BUILDING PLUMBING SYSTEM.
INSTALLER

PAGE 297588C (Rev. M - 5/04)
4420 FOUNTAIN
LEGEND
A = 3/8" O.D. UNPLATED COPPER TUBE CONNECT - SHUT OFF VALVE BY OTHERS
B = ACCESS PANEL ( 8" X 10" )
C = REMOVABLE BOTTOM COVER

PAGE 3 97588C (Rev. M - 5/04)
4420 FOUNTAIN
FIG. 2
NOTE: WATER FLOW
DIRECTION
BUILDING WATER INLET
SERVICE STOP
(NOT FURNISHED)
1/4" O.D. TUBE
WATER INLET
TO COOLER
3/8" O.D. UNPLATED
COPPER TUBE CONNECT
COLD WATER SUPPLY
FIG. 1
TROUBLE SHOOTING AND MAINTENANCE
Actuation of Quick Connect Water Fittings: Fountain is provided with lead-free connectors which utilize an o-ring
water seal. To remove tubing from the fitting, relieve water pressure, push in on the gray collar while pulling on the
tubing.(see Fig. 1) To insert tubing, push tube straight into fitting until it reaches a positive stop,
approximately 3/4".
1. This fountain is to be mounted on a smooth, flat, finished surface with adequate support structure. NOTE: Mounting structure must be
capable of supporting 300 lb. load on fountain.
2. Refer to rough-in for plumbing.
3. Install shut-off valve on water supply. (Valve not furnished)
4. Locate and install fountain using 3/8" minimum screws or bolts. (Screws or bolts not furnished)
5. Connect water supply and fountain drain. Connect drain waste "Tee" to fountain drain tubes. Connect outlet of "Tee" to drainage
system. Water connection and drain must comply with local codes.
6. Turn on water supply and check all connections for leaks.
CAUTION: This fountain is rated for inlet water pressure of 20-105 PSI. Apressure reducing regulator should be used if the inlet water
supply exceeds 105 PSI. Any damage caused by reason of connecting this product to supply line pressures lower than 20
psig or higher than 105 psig is not covered by warranty.
7. Water supply 3/8" O.D. unplated copper tube. Waste 1-1/4" IPS. Contractor to supply waste trap and service stop valve in
accordance with local code.
8. Connecting lines to be made of unplated copper and should be thoroughly flushed to remove all foreign matter before being connected
to fountain. This fountain is manufactured in such a manner that it does not in any way cause taste, odor, color, or sediment problems.
9. Connect fountain to supply line with a shut-off valve and install a 3/8" unplated copper water line between the valve and the cooler.
Remove any burrs from outside of water line. Push the tubes straight into the fittings until they reach a positive stop, approximately
3/4" (See Fig. 2). DO NOT SOLDER TUBES INSERTED INTO THE STRAINER AS DAMAGE TO THE O-RINGS MAY RESULT.

PAGE 497588C (Rev. M - 5/04)
4420 FOUNTAIN
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
2222 CAMDEN COURT
OAK BROOK, IL 60523
630.574.3500
PRINTED IN U.S.A.
ITEM NO. PART NO.
100147140560
28308C
101570540560
15005C
15009C
28091C
40045C
40551C
45392C
45464C
45825C
45832C
45833C
45476C
45662C
45663C
50986C
56121C
55913C
56092C
55996C
61313C
66346C
70022C
70682C
28467C
75535C
100322740560
75588C
75589C
70023C
75596C
ITEMIZED PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
NS
Drain Gasket
Washer
Drain Gasket
Regulator Retaining Nut
Nipple Assy. - Bubbler
Nameplate Insert
Hex Nut 1-5/16"
Tailpipe
Bubbler
Drain Plug 1-1/2"
Fountain Body
Access Panel
Bottom Cover
Drain Tube
Push Button
Push Button Sleeve
Regulator Holder
Drain Elbow 1-1/4"
Drain Adaptor
Poly Tubing (Cut To Length)
In - Line Strainer
Regulator
Drain Tube
Set Screw #6-32 x .31"
Tee - 1/4"
Basin
Pinned Torx Screw 1/4-20 x .75"
Washer
Slip Joint Nut 1-1/4"
Gasket
Set Screw #6-32 x .12"
Paint Touch-up (Pen)
DESCRIPTION
9
28
10
26
5
6
3
4, 17, 22
716, 24, 31
15
1
18
26
10
1
3
30
29
19
8
29
23
13
27
20
25
14
20
11
12, 27
21
Touch-up Paint
For minor scratches a Touch-up Paint Stick is available. For
repairing large defects, off-the-shelf aerosol paint from your local
hardware store can be used. Listed are two suggested
brandnames.
 Brandname: X-O
XO-11 Hunter Green
 Brandname: Ace Hardware
Rust Stop / Machine & Implement
International Green
30
2
FIG. 3
9
28
5
See Fig. 3
