SCWT8A-CB-Q*1P
98962C (Rev. C - 04/16)
USES HFC-134A REFRIGERANT
OWNER'S MANUAL

PAGE 2
SCWT8A-CB-Q*1P
98962C (Rev.C - 04/16)
Uses HFC-134A refrigerant
Note: Danger! Electric shock hazard. Disconnect power before servicing unit.
FIG. 1
2, 3, 38
4
31 - SEE FIG. 6
40
34
12
7
39
18
31
37
22
21
29
13
920
6
10, 11, 30
8
16
1-SEE FIG. 4
14,15
32
SEE FIG. 3
36
33
35
17
19
16

PAGE 3
SCWT8A-CB-Q*1P
98962C (Rev. C - 04/16)
FIG. 2
FINISHED FLOOR PISO ACABADO PLANCHER FINI
LEGEND/LEYENDA/LÉGENDE A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB OUT 1-1/2 IN. (38mm)
FROM WALL SHUT OFF BY OTHERS
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4” O.D. DRAIN C = 1-1/4 TRAP NOT FURNISHED D = ELECTRICAL OUTLET LOCATION E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL. F = POWER CORD 4' (1219mm) LONG G = WALL SCREW HOLES H = 2 X 4 BLOCKING

PAGE 4
SCWT8A-CB-Q*1P
98962C (Rev.C - 04/16)
PUSH BUTTON VALVE ADJUSTMENT
FIG. 4
1
5
24
26
25
23,27,28 CORRECT STREAM HEIGHT
FIG. 3
ADJUST THIS SCREW TO ELIMINATE VALVE
LEVER "FREE PLAY" OR CONTINUOUS FLOW
FROM BUBBLER
STREAM HEIGHT
ADJUSTMENT SCREW
Faucet Assembly Instructions
1. Place the faucet spout through the chrome cover with the smaller diameter end toward the faucet outlet.
2. Place the chrome collar over the faucet spout with the smaller diameter toward the bigger diameter chrome cover in step no. 1.
3. Place the faucet spout end down inside the same diameter hole in the brass connector.
4. Hold the chrome collar and cover up so you can get to the faucet set screw, turn the faucet spout so it goes toward the drain on the cooler.
5. Tighten the faucet set screw gradually until faucet wil not rotate.
6. Lower the chrome collar and the chrome cover down to basin.
7. Place the chrome cover so the set screw is toward the rear of the faucet.
8. Tighten set screw until cover will not pivot.
9. Place handle on faucet with the slot toward the front of the faucet, slide the slot into the brass pin.
10. Hold handle in snug toward faucet making sure it is seated into the brass pin, and then tighten the handle set screw until
handle will not come off the brass pin.
11. Removal of the handle is exactly opposite of the assembly process.
Faucet Spout
Chrome Cover
Chrome Collar
Faucet Spout
Set Screw
Handle Set
Screw
Cover Set Screw
FIG. 5

PAGE 5
SCWT8A-CB-Q*1P
98962C (Rev. C - 04/16)
DESCRIPTION
98533C
102639931640
160270508640
28724C
55880C
98724C
98773C
36322C
0000000238
75589C
75588C
45897C
98776C
101453431640
101507531550
98775C
402672943730
1000002162
20282C
66703C
98778C
36219C
15005C
26860C
26861C
26862C
50986C
61314C
55996C
55913C
98311C
56092C
70793C
1000001994
56278C
28719C
28439C
100147140560
See Color Table
See Color Table
See Color Table
KIt - Bubbler Assy
Drain Plug
Strainer Plate
Basin Replacement
Bracket-Regulator Mounting
Kit - Evaporator Replacement
Kit- Cold Control/Screws
Compressor Serv. Pak
Kit - Elect/Relay/Overload/Cover
Gasket
Nut - Slip Joint 1-1/4
Drain Tube
Kit - Condenser/Drier
Cap Push Button
Push Button Stem
Kit - Fan Motor/Shroud/Blade/Nut
Back Panel
Kit - 1/4" Union (3-pack)
Fan Motor Bracket
Drier
Kit - Heat Exchanger/Drier
Power Cord
Regulator Retaining Nut
Regulator Lever
Pivot Bracket
Regulator Retaining Bracket
Regulator Holder
Regulator
Strainer
Adaptor-Drain W/O Holes
Kit - Hot Tank Assy Replacement
Poly Tubing (Cut To Length)
Elbow - 1/4 x 90°
Kit - Tee - 1/4 (3-Pak)
Fitting - 1/4 Snap Connect
Bracket - Clamp
Bracket - Hot Tank Mounting
Drain Gasket
Side Panel - Right
Side Panel - Left
Front Panel
Platinum (PV)
Stainless Steel (SS)
401536248410
401536242830
401536348410
401536342830
401507448410
401507442830
2222 CAMDEN COURT
OAK BROOK, IL 60523
630.574.3500
PRINTED IN U.S.A.
RIGHT PANEL
ITEM 39
FRONT PANEL
ITEM NOT
SHOWN
COLOR LEFT PANEL
ITEM 40
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY, REPLACE
WITH SAME COMPRESSOR USED IN ORIGINAL ASSEMBLY.
NOTE: All correspondence pertaining to any of the above water coolers or
orders for repair parts MUST include Model No. and Serial No. of cooler,
name and part number of replacement part.
ITEMIZED PARTS LIST
1
2
3
4
5
6
7
*8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
NS
WIRING DIAGRAM
This Drawing is merely for illustrating the
components of the electrical system.
PART NO.
ITEM
NO.
FOR PARTS CONTACT YOUR LOCAL DISTRIBUTOR OR VISIT OUR WEBSITE WWW.HALSEYTAYLOR.COM
FIG. 6
PART OF
ITEM 31
