SCWT14A-WC-Q*1D
97321C (7/98)PAGE 1
HALSEY TAYLOR OWNERS MANUAL
USES HFC-134A REFRIGERANT
FIG. 1
SEE FIG.4
25
17
33
11
18
16
12,13,14,15
19
21
26
27
32
3, 4
7
2, 30 - SEE FIG.5
5, 6
28, 29
31
22

SCWT14A-WC-Q*1D
PAGE 297321C (7/98)
FIG. 2
E = INSURE PROPER VENTILATION BY MAINTAINING 4" (102mm) (MIN.) CLEARANCE FROM CABINET LOUVERS TO WALL.
ASEGURE UNA VENTILACIÓN ADECUADA MANTENIENDO UN ESPACIO E 4" (102mm) (MÍN.) DE HOLGURA ENTRE LA REJILLA DE VENTILACIÓN DEL MUEBLE YLAPARED ASSUREZ-VOUS UNE BONNE VENTILATION EN GARDANT 4" (102mm) (MIN.) ENTRE LES ÉVENTS DE LENCEINTE ET LE MUR.
F = POWER CORD 4' (1219mm) LONG
CABLE ELÉCTRICO DE 4' (1219mm) PIE, DE LARGO CORDON DALIMENTATION 4' (1219mm)
G = WALL SCREW HOLES
AGUJEROS DE TORNILLOS DE PARED TROUS DE VIS DU MUR
H = 2 X 4 BLOCKING
BLOQUEO DE 2 X 4 BLOC 2 X 4
FINISHED FLOOR PISO ACABADO PLANCHER FINI
LEGEND/LEYENDA/LÉGENDE A = RECOMMENDED WATER SUPPLY LOCATION 3/8 O.D. UNPLATED COPPER TUBE CONNECT STUB OUT 1-1/2 IN. (38mm)
FROM WALL SHUT OFF BY OTHERS
SE RECOMIENDA UBICAR ELTUBO CORTO DE CONEXIÓN AL TUBO DE COBRE SIN CHAPAR DE 3/8" DE DIÁM. EXT. A 1-1/2"
(38 mm) FUERA DE LA LLAVE DE PASO EN LA PARED COLOCADA POR TERCEROS.
EMPLACEMENT RECOMMANDÉ D'ALIMENTATION EN EAU PAR TUBE EN CUIVRE NON PLAQUÉ DE 3/8 PO. (9,5 mm) D.E.
CONNECTANT UNE TUYAUTERIE DE 1-1/2 PO. (38 mm) DEPUIS LE ROBINET D'ARRÊT FOURNI PAR D'AUTRES.
B = RECOMMENDED LOCATION FOR WASTE OUTLET 1-1/4 O.D. DRAIN
UBICACIÓN RECOMENDADAPARA EL DRENAJE DE SALIDADEAGUA, DE 1¼ DE DIÁMETRO. EMPLACEMENT RECOMMANDÉ POUR LE DRAIN DE D.E. 1-1/4" DE SORTIE DEAU.
C = 1-1/4 TRAP NOT FURNISHED
PURGADOR DE 1¼ NO PROPORCIONADO SIPHON 1-1/4 NON FOURNI
D = ELECTRICAL OUTLET LOCATION
UBICACIÓN DE LA TOMA DE ELECTRICIDAD EMPLACEMENT DE LA PRISE DE COURANT

SCWT14A-WC-Q*1D
97321C (7/98)PAGE 3
PUSH BUTTON VALVE ADJUSTMENT
FIG. 3
ADJUST THIS SCREW TO ELIMINATE VALVE
LEVER "FREE PLAY" OR CONTINUOUS FLOW
FROM BUBBLER
STREAM HEIGHT
ADJUSTMENT SCREW
FIG. 4
2
23
8
9
10
1,20,24
CORRECT STREAM HEIGHT
FIG. 5

SCWT14A-WC-Q*1D
PAGE 497321C (7/98)
ITEM NO. PART NO. DESCRIPTION
15005C
51544C
10-15075-31-550
10-14534-31-640
10-26399-31-640
16-02705-08-640
17-14037-42-590
26860C
26861C
26862C
31513C
35762C
31027C
35766C
19-42439-01-550
19-26684-51-550
45688C
66229C
40136C
50986C
60-14181-51-550
66506C
55880C
61314C
66202C
75494C
55996C
55913C
55885C
15008C
70682C
See Color Table
See Color Table
See Color Table
Nut-Regulator Retaining
Bubbler
Push Button Stem
Cap Push Button
Drain Plug
Strainer Plate
Basin
Regulator Lever
Pivot Bracket
Regulator Retaining Bracket
Cold Control
Compressor Service Pak
Overload/Relay Assy
Relay Cover
Electrical Shield
Power Cord
Precooler
Heat Exchanger
Water Temperature Valve
Regulator Holder
Condenser Assy
Evaporator
Regulator Mounting Bracket
Regulator
Drier
Check Valve
Strainer
Adaptor-Drain W/O Holes
Nut 1-1/4 Slip Joint
Nipple - Bubbler
Tee - 1/4
Side Panel - Right
Side Panel - Left
Front Panel
Platinum (PV)
Almond (AV)
Slate (SV)
Stnlss Stl (SS)
401536248410
26912C
401536248440
401536242830
401536348410
26908C
401536348440
401536342830
401507448410
26904C
401507448440
401507442830
FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.323.0620
2222 CAMDEN COURT
OAK BROOK, IL 60523
630.574.3500
PRINTED IN U.S.A.
RIGHT PANEL FRONT PANELCOLOR LEFT PANEL
*INCLUDES RELAY & OVERLOAD. IF UNDER WARRANTY, REPLACE
WITH SAME COMPRESSOR USED IN ORIGINALASSEMBLY.
NOTE: All correspondence pertaining to any of the above water coolers or
orders for repair parts MUST include Model No. and Serial No. of cooler,
name and part number of replacement part.
ITEMIZED PARTS LIST
1
2
3
4
5
6
7
8
9
10
11
12*
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
NS
FIG. 6
CONDENSER WATER VALVE ADJUSTMENT
The condenser water valve is factory preset for a condenser water outlet temperature of 95° to 105° F.
If actual temperature varies greatly from this, readjust water flow rate at the valve using the following procedures.
1. START UP COMPRESSOR
This can be accomplished by depressing the cooler push button (See Fig. 1 - Item 4). Keep water
running during the entire readjustment procedure.
2. ADJUSTMENT CONDENSER WATER VALVE
Adjust valve by rotating adjustment stem. Rotating stem clockwise will decrease water flow.
Counterclockwise rotation will increase water flow. Increasing water flow will result in a lower
condenser outlet temperature, while decreasing water flow will result in a higher outlet temperature.
Proper adjustment is attained when condenser outlet temperature is 95° to 105° F.
WIRING DIAGRAM
This drawing is merely for illustrating the
components of the electrical system.
