Halsey Taylor HydroBoost HTHBWF-HRFSER User manual

These water coolers are certified to
In-wall, recessed bottle filling station paired
with the bi-level Contour refrigerated fountain
Includes 3000 gallon capacity WaterSentry
Plus filtration system.
Quick fill rate is 1.1 gallons per minute. Includes
laminar flow to provide a clean fill with minimal
splash and easy maintenance. Equipped with
face design makes touchless operation intuitive.
automatic 20-second shut-off timer. User inter-
Keyplastic components are integratedwith silver
ion anti-microbial protection to inhibit growth of
moldandmildew.
Equipped with the HWF3000 WaterSentry Plus
®
Filter which is designed to reduce lead particles
and chlorine. Also reduces discoloration and
odors from incoming water. Features include the
Quick-Disconnect,1/4 turn installation and auto
inlet shut-off valve that closes when the filter is
removed.
Green, yellow, and red LEDs visually indicate
when filter maintenance is required. For service
replacement, order as:
55898C_3PK - Filter three pack.
Visually displays count of plastic bottles saved
from waste. (Based on 16 oz. bottles)
Manufactured from corrosion resistant, galvanized
steel. Open construction design for ease of installation.
Mounting frames can be shipped in advance for rough-
in installation.
Designed with hinged top and bottom stainless
steel panels for easy access and service.
NOTE: Continued product improvement makes
specifications subject to change without
notice. See Halsey Taylor website for most
current spec sheet.
HYDROBOOST Station with SolidLower Panel
MountingFrames (2)
HWF3000 WaterSentry®Plus Filter
Coolingunit - SJ8 (2)
HALSEY TAYLOR, 2222 CAMDEN COURT, OAK BROOK, ILLINOIS 60523
halseytaylor.com
JOB NAME:
ENGINEER/CONTRACTOR NAME:
APPROVAL:
DATE:
THIRD-PARTY CERTIFIED TO:
* UL399 & CAN/CSA 22.2 NO. 120
* NSF/ANSI 61 and 372
MODEL HTHBWF-HRFSER
NSF/ANSI 61 and 372.
HYDROBOOST BOTTLE FILLER
®
GENERAL
™
In-wall, recessed design with solid lower panel.
GREEN COUNTER
™
WATERSENTRY PLUS FILTRATION
®
55898C - Single replacement filter
55898C_12PK - Filter twelve pack.
55898C_24PK - Filter twenty-four pack.
55898C_48PK - Filter forty-eight pack.
FOUNTAIN
HALSEY TAYLOR DOUBLE BUBBLER
AUTOMATIC STREAM HEIGHT REGULATOR
Self-closingassemblyis locatedinside unit to prevent
PUSHBUTTON ACTIVATION
tampering. A constant stream height is automatically
maintained under line pressure that varies from 20 to
105 psi.
MOUNTING FRAMES
HydroBoost In-Wall Bottle Filler
with HRF-SER
®
FILTERED
Each HTHBWF-HRFSER is shippedin 7cartons
including:
HRF-SER Fountain
SUGGESTED SPECIFICATION
Model HTHBWF-HRFSER provides 8.0 gph
of 50ºF drinking water at 90ºF ambient and 80ºF
inlet water. Bottle filler shall be recessed design
and include electronic sensor activation with 20-
second automatic water shut-off. Shall provide
1.1 gpm flow rate with laminar flor to prevent
splashing. Shall include anti-microbial protected
plastic components to prevent mold and mildew.
Shall include WaterSentry Plus filter, certified to
NSF/ANSI 61 and 372 for lead reduction, with
visual monitor to indicate when replacement is
necessary. Shall include visual display of plastic
bottles saved from waste. Fountain shall be oval
design with self-closing pushbars and contoured
basin. Shall include water conservation bubbler
with auto stream height regulator. Shall include
SJ8 water chiller. Shall meet ADA guidelines for
reach ranges, when properly installed. Shall be
lead-free design which meets the Safe Drinking
Water Act and is certified to NSF/ANSI 61 & 372.
Shall be certified to UL399 and CAN/CSA 22.2
No. 120 electrial requirements.
®
®
Features contoured basin and softly rounded corners
and edges.
Self-closing, vandal-resistant pushbutton does not
require grasping or twisting.
Exclusive one-piece, chrome-plated two-stream mound-
building bubbler with non-removable anti-squirt feature
and integral hood insures a satisfying drink of water.
™

Printed in the U.S.A.
Specifications and measurements are subject to change without notification.
Please visit halseytaylor.com for most current version.
FILTER LOCATION
(OPTIONAL)
1/4" O.D. TUBE CONNECT
(CHILLER WATER OUTLET)
3/8" O.D. TUBE CONNECT
(CHILLER WATER INLET)
SHUT OFF VALVE BY OTHERS
BACK WALL LINE
FINISHED FLOOR
1-1/4" (32MM)
WASTE TUBE
FURNISHED
ELECTRICAL
INLET
FINISHED FLOOR
STANDARD HEIGHT
20 3/8"
( 518mm )
20 7/16"
( 519mm )
19 3/4"
( 502mm )
17 3/8"
( 441mm ) 1 3/16" ( 30mm )
1 3/16"
( 30mm )
8 1/8"
( 206mm )
9 3/8"
( 238mm )
1 1/8"
( 29mm )
3"
( 79mm )
18 3/4"
( 476mm )
4"
( 102mm )
12" *
( 305mm )
MINIMUM
DEPTH
25 1/4"
( 641mm )
27"
( 681mm )
38 7/8"
( 987mm )
2 7/8"
( 73mm )
25 7/8"
( 657mm )
3 1/2"
( 89mm )
4 1/2"
( 116mm)
1 1/8"
( 29mm )
11"
( 279mm )
DOUBLE STUD OR 3" (76mm)
BETWEEN MOUNTING FRAMES
IF PLACED NEXT TO ANOTHER
FOUNTAIN OR WALL
* 7" minimum depth
for non-refrigerated models
FILTER LOCATION
(OPTIONAL)
1/4" O.D. TUBE CONNECT
(CHILLER WATER OUTLET)
3/8" O.D. TUBE CONNECT
(CHILLER WATER INLET)
SHUT OFF VALVE BY OTHERS
BACK WALL LINE
FINISHED FLOOR
1-1/4" (32MM)
WASTE TUBE
FURNISHED
ELECTRICAL
INLET
FINISHED FLOOR
ANDARD HEIGHT
20 3/8"
( 518mm )
20 7/16"
( 519mm )
19 3/4"
( 502mm )
17 3/8"
( 441mm ) 1 3/16" ( 30mm )
1 3/16"
( 30mm )
8 1/8"
( 206mm )
9 3/8"
( 238mm )
1 1/8"
( 29mm )
3"
( 79mm )
18 3/4"
( 476mm )
4"
( 102mm )
12" *
( 305mm )
MINIMUM
DEPTH
25 1/4"
( 641mm )
27"
( 681mm )
38 7/8"
( 987mm )
2 7/8"
( 73mm )
25 7/8"
( 657mm )
3 1/2"
( 89mm )
4 1/2"
( 116mm)
1 1/8"
( 29mm )
11"
( 279mm )
DOUBLE STUD OR 3" (76mm)
BETWEEN MOUNTING FRAMES
IF PLACED NEXT TO ANOTHER
FOUNTAIN OR WALL
* 7" minimum depth
for non-refrigerated models
40"
1016mm
4 1/2
114mm
18 3/4"
476mm 5 1/8"
130mm
BACK OF WALL TO
BE 12" (305mm)
MIN DEPTH
8"
203mm
TO FLOOR LINE
FLOOR LINE
WOOD OR STEEL
FRAME SHOWN
(NOT PROVIDED)
ELECTRICAL INLET
LOCATION ON CHILLER
1"
25mm
CHILLER SHELF
P/N 27638C
HOOK RODS (2)
P/N 101567443730
SCREWS OR BOLTS
(NOT PROVIDED)
5/16" SCREWS OR BOLTS
(10 REQ'D-NOT PROVIDED)
FRAME
INSTALL (2) SCREWS
(P/N 111008343890) IN FRAME
BEFORE INSTALLING IN OPENING
MFWS100
DOUBLE STUD OR 3 INCHES (76 mm)
BETWEEN MOUNTING FRAMES
IF PLACED NEXT TO ANOTHER
FOUNTAIN OR WALL
Supply water - 105 psi maximum
Minimum 40 psi supply line pressure required
in special circumstances when both sides of
bilevel are in use simultaneously to ensure
adequate stream height. Does not apply to
non-refrigerated units.
Hydroboost station equipped with electric
cord and three-prong molded rubber plug for
use with 15-amp minimum receptacle.
For the cooling unit, a junction box for a (3)
wire , 10 amp branch circuit is provided.
Rated at 115 volt, 60 Hz, single phase.
MODEL HTHBWF-HRFSER
OPERATING PRESSURES: ELECTRICAL
SIDE VIEW
FRONT VIEW / WALL LAYOUT
HydroBoost In-Wall Bottle Filler
®
* Rated for Indoor Use Only

Printed in the U.S.A.
HRF-SER
(CONTINUED)
MODEL HTHBWF-HRFSER
A = 3/8” O.D. TUBE CONNECT (CHILLER WATER INLET) SHUT OFF VALVE BY OTHERS
B
B = 1/4” O.D. TUBE CONNECT (WATER OUTLET)
C = 1-1/4” TRAP
D = ELECTRICAL INLET
FRONT VIEW
TOP & SIDE VIEW
C
D
WALL OPENING
IMPORTANT: It is necessary to create a wall
opening 37 1
/2" W x 37 3/4" H and 4 1 /2" above
the floor line.
MOUNTING INSTRUCTIONS
Refer to rough-in for location of plumbing and
electrical sources. The support frame is to be
installed first. The shelf for the water chiller
should be assembled to the wall frame, and
then place chiller into position. Hang upper
fountain panel to hanger on frame. Fountain is
to be attached to panel and wall frame. Water
service lines, waste lines and electrical are
assembled as required. The bottom panel
is attached last, after a final check for leaks
and correct functions of fountains and chiller.
(For details see the installation instructions.)
OPERATING PRESSURES:
Supply water - 105 psi maximum
Minimum 40 psi supply line pressure required
in special circumstances where both sides of
bilevel are in use simultaneously to ensure
adequate stream height. Use of water filter in
this situation is not recommended.
ELECTRICAL DATA
Junction box for a (3) wire 10 AMP branch
circuit. Standard 120 volt, 60 HZ, single phase.

Printed in the U.S.A.
HRF-SER MOUNTING FRAME
(CONTINUED)
MODEL HTHBWF-HRFSER
1. Cut a rectangular wall opening 37-1/2” (953 mm) W x
37-3/4” (959 mm) H and 4-1/2” (114 mm) above the
floor line (see Figure 6). The dimensions are required
to obtain proper rim and bubbler heights for
compliance with ANSI standard A117.1.
2. Reinforce the wall openingon all sides to adequately
support the water fountain. This reinforcement must
support up to 150 lbs. static load and provide a
means for securing the frame assembly in place.
NOTE:Building construction must allow for
adequate air flow on both sides, top and
back of chiller. A minimum of 4” (102 mm) on
both sides and top is required. See chiller
installation for additional instructions.
3. Install plumbing and electrical rough-ins. Ajunction
box for a (3) wire, 10 amp branch circuit is provided on
the inside of the chiller. (Standard 120 Volts, 60 Hz,
and single phase.)
4. Remove frames and related hardware from
packaging. Release the two shelf rods by cutting
cable ties. Attach the two frames together through the
upright supports with (4) 5/16” x 3/4” (19 mm) long
bolts and nuts (provided). Tighten securely.
