Hamilton Beach 1G730 User manual

English ...................... 2
Francais .................. 26
Espanol .................. 50
READ BEFORE USE
LIRE AVANT D’UTILISER
LEA ANTES DE USAR
Questions?
Please call us – our friendly
associates are ready to help.
USA: 1.800.851.8900
CAN: 1.800.267.2826
MEX: 01 800 71 16 100
Le invitamos a leer cuidadosamente
este instructivo antes de usar su
aparato.
Visit hamiltonbeach.com for
delicious recipes and to register
your product online!
Consultez hamiltonbeach.ca pour les
recettes délicieuses et pour enregistrer
votre produit!
Visite hamiltonbeach.com para recetas
deliciosas y para registro de su producto
en línea.
Quick Start
For Frying, refer to page 6.
For Steaming, refer to page 12.
For Boiling, refer to page 14. Meal Maker™
Multicooker
Multi-cuiseur Meal Maker™
Olla Multiuso Meal Maker™
840155100 nv10.qxd 5/24/07 9:30 AM Page 1

2
IMPORTANT SAFEGUARDS
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against risk of electric shock, do not immerse cord,
plugs, or heating element assembly in water or other liquid.
4. Close supervision is necessary when any appliance is used
by or near children.
5. Be sure handle is properly assembled to basket and locked into
place. See detailed assembly directions.
6. Unplug from outlet when not in use and before cleaning.
Allow to cool, before putting on or taking off parts and before
cleaning the appliance.
7. Do not operate any appliance with a damaged cord or plug,
or after the appliance malfunctions or has been damaged in
any manner. Call our toll-free customer service number for
information on examination, repair, or adjustment.
8. The use of accessory attachments not recommended or sold
by Hamilton Beach/Proctor-Silex, Inc. for use with this model
may cause injuries.
9. Do not use outdoors.
10. Do not let cord hang over edge of table or counter, or touch
hot surfaces.
11. Do not place on or near a hot gas or electric burner, or in a
heated oven.
12. Extreme caution must be used when moving multicooker
containing hot oil.
13. Always attach plug to appliance first, then plug cord in the
wall outlet. To disconnect, turn any control to OFF and remove
plug from wall outlet.
14. Do not use appliance for other than intended purpose.
15. Be sure handles are properly assembled to basket and locked
in place. See detailed assembly instructions.
16. To reduce the risk of injury, NEVER fill oil above MAX fill mark.
17. Always ensure removable pot is filled at least MIN level when
using oil.
18. Never leave appliance unattended while in use.
19. Always dry foods and remove ice before frying.
20. Always dry multicooker components thoroughly after cleaning
and before frying.
21. Always fry with lid in place.
22. Do not use refrigerated oil.
23. Never block vent on lid. Be aware of steam emitting from vent.
24. Escaping steam may cause burns to hands or fingers. Open
the lid carefully.
25. Always raise basket, rest on drain bracket, and allow food to
drain before removing lid or food basket.
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or
injury to persons, including the following:
SAVE THESE INSTRUCTIONS!
840155100 nv10.qxd 5/24/07 9:30 AM Page 2

3
OTHER CONSUMER SAFETY INFORMATION
This product is intended for household use only.
This product is only intended for the preparation, cooking,
and serving of foods. This product is not intended for use
with any non-food materials or products.
This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet only one way.
If the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not
attempt to modify the plug in any way.
WARNING: Serious hot-oil burns may result from a deep-fat
fryer being pulled off a countertop. Do not allow the cord to
hang over the edge of the counter where it may be grabbed
by children or become entangled with the user. Do not use
with an extension cord.
840155100 nv10.qxd 5/24/07 9:30 AM Page 3

4
Parts and Features
Removable Lid
Tilt & Hold™
Basket Hook
Removable
Pot
Base
Main
Basket
Handle
Helper
Handle
Food Basket
Heating Element
Assembly
Safe Release™ Cord
Boiling Rack
Ready to
Cook Light
Timer
Temperature
Control
Knob
Power
ON/OFF
Switch
Digital Timer Mechanical Timer
Heating
Element
Assembly
Adaptor
Cord Adaptor
Wire Loop
840155100 nv10.qxd 5/24/07 9:30 AM Page 4

5
How to Assemble
1 2 3
MAIN
HANDLE
567
Place base on stable, flat surface. Align #1 “spout” on pot with
#1 “notch” on base and insert
pot into base.
Slide heating element assembly
onto the adaptor on base. Push
all the way down to ensure
power connection.
Squeeze tines of handles together.
Main basket handle attaches to metal
bracket marked MAIN HANDLE.
Helper handle attaches to metal
bracket closest to wire loop (above).
Align tines with round holes on
metal brackets of basket. Release tines. They will spread and lock into metal brackets. Fill multicooker with cooking liquid. Refer to MAX and MIN fill
lines inside pot.
Heating element will not work unless multicooker is properly assembled.
Do not exceed maximum amount of food to be cooked in one batch.
4
MINIMUM Oil
18 cups/4.5 quarts/4.3 L
MAXIMUM Oil
21 cups/5.2 quarts/4.9 L
Never fill above MAX fill line.
Spout
Notch Wire
Loop
840155100 nv10.qxd 5/24/07 9:30 AM Page 5

6
8
Attach cord and make sure that it
is squarely seated for good
power connection.
9
To place lid on multicooker, align
#2 on lid with #2 on main basket
handle.
10
Set temperature control to
desired temperature.
11
Plug cord into outlet and push
ON/OFF switch ON. Ready Light
will come on when oil has
reached desired temperature.
12 13 14 15
When ready light is illuminated,
load basket with food AWAY FROM
POT, THEN tilt basket and place wire
loop on basket hook.
Place lid on on multicooker and
then carefully lower basket into
oil. Set Timer, if desired, per
Timer instructions.
When food is cooked, raise
basket with LID ON and place
wire loop on basket hook to drain.
How to Assemble and Fry
When drained, remove lid then
remove basket by tilting and
removing from basket hook.
840155100 nv10.qxd 5/24/07 9:30 AM Page 6

7
16 17
Carefully empty food from basket
away from pot to prevent food
particles from collecting in the oil.
Repeat frying as needed.
When finished frying, press
ON/OFF Switch to OFF and
unplug from outlet.
How to Assemble and Fry
840155100 nv10.qxd 5/24/07 9:30 AM Page 7

8
Digital Timer (on select models)
1 2
1
Mechanical Timer (on select models)
1. To set the timer, press timer button until the LCD display shows “00”.
Continue pressing the button to advance the timer by one minute per
press. To advance the timer faster, press and hold the button down.
2. The timer will start counting down the selected time shortly after
you stop pressing the button. During the countdown time, the
display will flash.
3. To reset Timer, hold button down until “00” is displayed.
4. The timer will beep when it reaches zero and will beep again after
30 seconds.
5. The timer will turn off automatically.
NOTES:
• The timer counts down and can be set for any time between 1-99 minutes.
• The timer DOES NOT turn off the multicooker.
1. To set the timer, turn the dial to desired cooking time.
2. The timer will count down and will ring when it reaches zero.
3. The timer will turn off automatically.
NOTES:
• The timer counts down. It can be set for any time between
1 to 60 minutes.
• The timer DOES NOT turn the multicooker off.
840155100 nv10.qxd 5/24/07 9:30 AM Page 8

9
2
Fill pot to MAX level with oil.
Never fill above MAX fill line. Place chicken in basket breast side up. Grasp BOTH handles and
carefully tilt basket and place wire
loop on basket hook.
3
To place lid on multicooker, align
#2 on lid with #2 on main basket
handle. Carefully lower basket into
oil.
Frying whole chickens
1
5
Place basket on dish or baking sheet
to lift chicken out. Do not turn bas-
ket over to empty. TIP: Insert tongs
into chicken cavity for a better grip.
Do not fry more than 2 chickens repeatedly. Allow multicooker to cool and adjust oil level to MAX.
CAUTION! Check for doneness using a meat thermometer until it reads 180ºF (82ºC).
Visit foodsafety.gov for more information.
4
When chicken is cooked, or to
check temperature, raise basket
with LID ON and place wire loop
on basket hook to drain.
WARNING! Burn Hazard.
To reduce the risk of burns from
hot oil, allow oil to drain from the
cavity inside chicken by tilting
food basket before removing it
from the pot.
840155100 nv10.qxd 5/24/07 9:30 AM Page 9

10
BATCH FRYING APPROXIMATE
FOOD SIZE TEMPERATURE COOKING TIME
Fish/Seafood (precooked) 1.5-2 lb / 675-900 g 375ºF (190ºC) 5 to 8 minutes
Chicken, Frozen (precooked) 2 lb / 900 g 375ºF (190ºC) 2 to 3 minutes
Chicken Pieces, Fresh 4 lb / 1.8 kg 375ºF (190ºC) 25-30 minutes
(180ºF / 82ºC internal temp)
Chicken, Whole 4.5-5.5 lb / 2-2.5 kg 375ºF (190ºC) 25-30+ minutes
(180ºF / 82ºC internal temp)
French Fries, Frozen 2 lb / 900 g 375ºF (190ºC) 3 to 5 minutes
French Fries, Fresh Basket 3/4 full 375ºF (190ºC) 15 minutes
Onion Rings, Frozen 1.5 lb / 675 g 375ºF (190ºC) 8 minutes
Egg Rolls, Frozen 12 375ºF (190ºC) 8 minutes
(170ºF / 77ºC internal temp)
• Fry foods listed below for the suggested amount of cooking time and until golden brown.
• For best results, fry a single layer of food for each batch.
• See “Tips for Frying with the Multicooker” for more information to obtain best results.
Frying Chart
Length of cooking time and temperature may vary based on batch size and weight. Follow package directions.
Visit foodsafety.gov for more information.
840155100 nv10.qxd 5/24/07 9:30 AM Page 10

11
Tips for Frying with the Multicooker
Selecting and Changing the Frying Oil
• Use a good quality vegetable or peanut oil.
• Frying foods in butter, margarine, olive oil, or animal fat is
NOT recommended because of low temperature smoke point.
• DO NOT mix two types of oil.
• Change oil regularly to maintain optimum frying and flavor
quality.
• Oil used for french fries can be used 10 to 12 times before
changing if the oil is filtered after each use. Oil used for food
that is high in protein (such as meat or fish) should be
changed more often.
• To filter oil, allow oil to completely cool. Cheesecloth or paper
towel may be used as a filter to strain oil.
• Always follow food package directions.
• DO NOT add fresh oil to used oil.
• Always change the oil if it starts to foam when heated, when
it has a strong smell or taste, or when it turns dark and/or
syrupy.
• Always change oil after frying 2 whole chickens.
Before Frying
• Excess water or ice particles can cause hot oil to splatter or
foam. Remove any excess water from fresh food by blotting
with a paper towel. Remove any ice chunks or build up from
frozen foods.
General Tips
• DO NOT use plastic utensils in hot oil.
• Season food AFTER frying.
• If food is not as crisp as desired, reduce batch size.
Disposing of Oil
• Pour cool oil into its original (resealable) empty plastic bottle.
Basket Usage with Freshly Battered Foods
• Freshly battered foods should be carefully placed directly
into the oil. First, lower the basket fully then carefully place
each piece of battered food into the hot oil. Use the basket
to remove fried battered foods.
WARNING! To reduce the risk of being burned by hot oil,
carefully place food in hot oil.
Storage
• Remove basket handles and store in basket. Place the
removable pot in base then attach the heating element
assembly. Place the boiling rack in the pot, the basket with
cord on the boiling rack and, finally, the lid on the pot.
• It is best to store all oils in the refrigerator or a cool, dark,
dry place for up to six months.
840155100 nv10.qxd 5/24/07 9:30 AM Page 11

12
2
Steaming with the Multicooker
1
Fill pot with desired amount of
water.
67
Load basket with food. Tilt basket
and place wire loop on basket hook
for steaming. Steam ONLY in food
basket. DO NOT use boiling rack
for steaming.
Attach cord.
To place lid on multicooker, align
#2 on lid with #2 on main basket
handle.
MINIMUM Water for STEAMING
(with basket on basket hook)
18 cups/4.5 quarts
(4.3 L)
4 5
Plug cord into outlet and push
ON/OFF switch ON. The ready light will NOT come on when water boils.
3
Set Temperature Control to 375ºF
(190ºC).
Do not steam on boiling rack—water level is insufficient to steam completely.
Always check water level after each batch and add water as necessary.
Water takes approximately 18-22
minutes to come to a full boil.
840155100 nv10.qxd 5/24/07 9:30 AM Page 12

13
9
Steaming
10
When drained, remove lid then
remove basket by tilting and
removing from basket hook.
8
When food is cooked, raise
basket with LID ON and place
wire loop on basket hook to drain.
When finished steaming, press
ON/OFF Switch to OFF and
unplug from outlet.
840155100 nv10.qxd 5/24/07 9:30 AM Page 13

14
7
To place lid on multicooker, align
#2 on lid with #2 on main basket
handle.
1
Fill pot with desired amount of
water.
Boiling with the Multicooker
MAXIMUM Water
for BOILING
(on boiling rack or in basket)
21 cups/5.2 quarts (4.9 L)
6
For larger quantities, place boiling
rack in pot on heater for boiling.
Basket may also be used for boiling.
Boiling with Boiling Rack
Always check water level after each batch and add water as necessary.
TO BOIL:
Follow Steps 2–5
in Steam Section
then proceed to Step 6.
2-5
Water takes approximately 18-22
minutes to come to a full boil.
8
When food is cooked, raise
basket with LID ON and place
wire loop on basket hook to drain.
9
When drained, remove lid then
remove basket by tilting and
removing from basket hook.
10
When finished boiling, press
ON/OFF Switch to OFF and
unplug from outlet.
840155100 nv10.qxd 5/24/07 9:30 AM Page 14

15
FOOD BATCH SIZE APPROXIMATE COOKING TIME
Fresh Broccoli or Cauliflower 2 lb / 900 g 6-8 minutes
Fresh Corn on the Cob 6-8 ears 6-8 minutes
Fresh Corn on the Cob 16-18 ears, standing, using boiling rack 10-15 minutes
Potatoes 3.5 lb / 1.575 kg 25-30 minutes
Hot Dogs 16 5 minutes
Eggs (do not bring water to boil before cooking) 24 30-45 minutes
Frozen Vegetables 2 lb / 900 g 6-8 minutes
NOTE: Temperature should always be set to MAX or 375ºF (190ºC) for Boiling.
Use Boiling Rack for larger quantities and adjust cooking time accordingly.
Boiling Chart with Multicooker Food Basket
FOOD BATCH SIZE APPROXIMATE COOKING TIME
Fresh Broccoli/Cauliflower 1 lb / 450 g 10 minutes
Fresh Carrots, sliced 2 lb / 900 g 15 minutes
Fresh Green Beans 1 lb / 450 g 8-10 minutes
Fresh Corn on the Cob 4-6 ears 10 minutes
Frozen Vegetables 2 lb / 900 g 10-15 minutes
Frozen Shrimp 2 lb / 900 g 5-8 minutes
Frozen Crab Legs 2 lb / 900 g 1-3 minutes
NOTE: Temperature should always be set to MAX or 375ºF (190ºC) for Steaming.
Length of cooking time and temperature may vary based on batch size and weight. Follow package directions.
Visit foodsafety.gov for more information.
Steaming Chart with Multicooker Food Basket
Bring water to a boil before cooking
unless otherwise instructed.
Bring water to a boil before cooking
unless otherwise instructed.
840155100 nv10.qxd 5/24/07 9:30 AM Page 15

16
Cleaning
34
1 2
5
For storage, release the handles
and store in basket. Additional
storage tips in Tips for Frying.
Pour cool oil into its original
container before cleaning pot.
OR
Wash food basket, handles and
boiling rack in hot, soapy water. Only the multicooker lid and pot
are dishwasher safe.
840155100 nv10.qxd 5/24/07 9:30 AM Page 16

17
POTENTIAL PROBLEM
Fried food does not have
a golden brown color
and/or is not crispy.
Multicooker gives off
a strong, unpleasant odor.
Unit does not heat.
PROBABLE CAUSE
• The selected temperature is too low or the food has not been fried long enough.
Check food package or Frying Chart for correct temperature or preparation time.
Allow oil in multicooker to preheat before frying.
• There is too much food in the basket. Never fry too much food at one time. See the food
package, Frying Chart, or recipe for correct frying amount. The food pieces may be too
thick to fry adequately.
• Volume of oil is too low.
• The oil isn’t fresh. Change the oil. Filter oil regularly to keep it fresh longer.
• When frying food with a high moisture content (such as chicken, fries, etc.), change oil
frequently.
• The type of oil is not suitable for deep-frying food. Use good quality frying oil. Do not mix
two different types of oil.
• Ensure cord is properly attached to the multicooker socket.
• Ensure cord is plugged into electrical outlet.
• Ensure Power ON/OFF Switch is set to ON.
• Heating Element Assembly not correctly assembled. Make sure the Heating Element
Assembly is properly installed on the base. See “How to Assemble” section.
• The pot is not properly installed on base.
• Press Reset on Heating Element/Control Panel by inserting a small pointed item
(such as a paper clip) into the opening labeled RESET. Make sure the multicooker has
the recommended amount of oil in pot.
• Make sure multicooker has the recommended amount of water (max or min) in the pot.
If below this level, water may boil off and control will turn heater off. Press the RESET
button.
Troubleshooting
840155100 nv10.qxd 5/24/07 9:30 AM Page 17

18
POTENTIAL PROBLEM
During frying, the oil spills
over the edge of the
multicooker.
The oil foams too much
during frying.
PROBABLE CAUSE
• There is too much oil in the multicooker. Make sure that the oil does not exceed the
maximum level mark.
• Basket/food immersed too quickly. Carefully raise basket out of the oil.
• The food contains too much liquid. Dry food thoroughly before placing it in the multicooker.
See How to Use the Multicooker.
• When frying food with a high moisture content (such as chicken, fries, etc.), change oil
frequently.
• There is too much food in the frying basket. Do not fry more food at one time than the
quantities indicated on the food package or the Frying Chart.
• The food contains too much liquid. Dry food thoroughly before placing it in the multicooker.
• When frying food with a high moisture content (such as chicken, fries, etc.), change oil
frequently.
• The type of oil is not suitable for deep-frying food. Use good quality frying oil. Do not mix
two different types of oil.
• Basket/food immersed too quickly. Carefully raise basket into the air.
• The use of refrigerated oil may cause excessive splattering. Use room temperature oil.
• Oil pot has not been cleaned properly. See instructions in the “Cleaning” section.
Troubleshooting
840155100 nv10.qxd 5/24/07 9:30 AM Page 18

19
POTENTIAL PROBLEM
Condensation forms on
viewing window.
Oil film buildup on
oil pot.
Steamed foods take
longer than stated time.
READY light does
not illuminate.
PROBABLE CAUSE
• Water vapor from the food collects on window. When unit is cold, wipe a small amount
of oil on inside of viewing window to prevent condensation buildup.
• Use plastic scouring pad to clean.
• Temperature setting not set to MAX.
• Insufficient time allowed to Preheat or Reheat (Oil).
• Light will NOT illuminate when Steaming/Boiling (Water).
Troubleshooting
840155100 nv10.qxd 5/24/07 9:30 AM Page 19

20
Whole Chicken Recipes
Teriyaki Fried Chicken
1 (4 lb/1.8 kg) whole chicken
1 15 oz (450 ml) bottle teriyaki sauce/marinade
1. Remove giblets, neck from chicken. Rinse and pat dry. Place chicken in large ziplock freezer bag or other container.
2. Pour teriyaki sauce over chicken and close bag or container.
3. Refrigerate for 8 hours or overnight, turning once or twice.
4. Place multicooker basket on baking-pan or cookie sheet. Remove chicken from marinade and place in basket breast up.
5. Follow instructions in Frying Whole Chickens section.
Serves 4-6
Lemon Rosemary Fried Chicken
1 (4 lb/1.8 kg) whole chicken
1/2 fresh lemon
3 sprigs fresh rosemary
3 fresh garlic cloves
2 bay leaves
Salt and freshly ground pepper
1. Remove giblets, neck from chicken. Rinse and pat dry and place on baking pan or cookie sheet.
2. Sprinkle salt and pepper over outside of chicken and inside cavity.
3. Smash garlic cloves slightly with side of knife and place inside chicken cavity.
4. Place lemon half, rosemary and bay leaves in chicken cavity with garlic.
5. Place multicooker basket on baking-pan or cookie sheet. Place chicken in basket breast side up.
6. Follow instructions in Frying Whole Chickens section.
Serves 4-6
840155100 nv10.qxd 5/24/07 9:30 AM Page 20
