HAMPTON BAY Miramar User manual

Miramar
60 in Ceiling Fan
Owner’s Manual
Miramar
Ventilador de Techo de 1,52 m
Manual del Propietario
458 242

Miramar por Hampton Bay
®

60” Miramar
Ceiling Fan by Hampton Bay
Date Purchased
Store Purchased
UL Model No.
Serial No.
Vendor No.
UPC
Thank you for purchasing our ceiling fan. This product has been
manufactured with the highest standards of safety and quality.
Table of Contents
Safety Rules . . . . . . . . . . . . . . . . . . . . 1
Unpacking Your Fan . . . . . . . . . . . . . . 2
Installing Your Fan . . . . . . . . . . . . . . . 3
Installing the Light Kit . . . . . . . . . . . 10
Operating Your Transmitter . . . . . . . . . . . 11
Care of Your Fan . . . . . . . . . . . . . . . . 13
Troubleshooting . . . . . . . . . . . . . . . . . 13
Specifications . . . . . . . . . . . . . . . . . . 14
Warranty Information . . . . . . . . . . . . 15
792145353928
219032
458-242

Safety Rules - Read and Save These Instructions
1
To reduce the risk of electric shock, insure electricity has been turned off
at the circuit breaker or fuse box before beginning.
All wiring must be in accordance with the National Electrical Code
“ANSI/NFPA 70-1999” and local electrical codes. Electrical installation
should be performed by a qualified licensed electrician.
WARNING: To reduce the risk of electrical shock or fire, do not use this
fan with any solid-state fan speed control device. It will permanently
damage the electronic circuitry.
CAUTION: To reduce the risk of personal injury, use only the screws
provided with the outlet box.
The outlet box and support structure must be securely mounted and
capable of reliably supporting a minimum of 50 pounds. Use only UL
Listed outlet boxes marked “FOR FAN SUPPORT”.
The fan must be mounted with a minimum of 7 feet clearance from the
trailing edge of the blades to the floor.
Avoid placing objects in path of the blades.
To avoid personal injury or damage to the fan and other items, be
cautious when working around or cleaning the fan.
Do not use water or detergents when cleaning the fan or fan blades. A dry
dust cloth or lightly dampened cloth will be suitable for most cleaning.
After making electrical connections, spliced conductors should be turned
upward and pushed carefully up into outlet box. The wires should be
spread apart with the grounded conductor and the equipment-grounding
conductor on one side of the outlet box and ungrounded conductor on the
other side of the outlet box.
All set screws must be checked and retightened where necessary before
installation.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
WARNING
TO REDUCE THE RISK OF PERSONALL INJURY, DO NOT BEND THE
BLADE ARMS (ALSO REFERRED TO AS FLANGES), WHEN INSTALLING
THE BRACKETS, BALANCING THE BLADES OR CLEANING THE FAN.
DO NOT INSERT FOREIGN OBJECTS IN – BETWEEN ROTATING FAN
BLADES.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR PERSONAL
INJURY, MOUNT TO OUTLET BOX MARKED "ACCEPTABLE FOR FAN
SUPPORT OF 22.7 KG (50 LBS.) OR LESS" AND USE MOUNTING SCREWS
PROVIDED WITH THE OUTLET BOX.
ATTENTION
FAN INCLUDES A 190W LIMITER TO COMPLY WITH THE
DEPARTMENT OF ENERGY 2009 REGULATION. LAMPING THIS
PRODUCT OVER 190W WILL CAUSE THIS FAN TO NOT LIGHT. PLEASE
USE BULBS WITH A TOTAL WATTAGE UNDER THE 190W
REGULATION.

2
Unpacking Your Fan Unpack your fan and check the contents. You should have the following items:
Set of blades (5)
Canopy assembly
Ball/downrod assembly
Decorative top coupling cover
Decorative scroll
Decorative bottom coupling cover
1.
2.
3.
4.
5.
6.
Fan motor assembly
Set of blade arms (5)
Top glass housing
Light plate
Bottom glass shade
Transmitter+holder+2 mounting screws
60Watt candelabra bulb
15Watt candelabra bulbs (4)
7.
8.
9.
10.
11.
12.
13.
14.
Blade Attachment Hardware
(16 Screws with Fiber Washers)
Electrical Hardware
(3 Plastic Wire Nuts)
Decorative Scroll Mounting Hardware
(9 Screws)
Balance Kit
A.
B.
C.
D.
WARNING
DO NOT INSTALL OR USE FAN IF ANY
PART IS DAMAGED OR MISSING.
CALL TOLL FREE 1-877-902-5588.
1
3
6
9
10
11
12
13
14
7
8
4
5
2
A
D
B
C

3
Installing Your Fan
Tools Required
Mounting Options
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR PERSONAL INJURY, MOUNT TO OUTLET BOX
MARKED "ACCEPTABLE FOR FAN SUPPORT OF
22.7 KG (50 LBS.) OR LESS" AND USE MOUNTING
SCREWS PROVIDED WITH THE OUTLET BOX.
MOST OUTLET BOXES COMMONLY USED FOR
THE SUPPORT OF LIGHT FIXTURES ARE NOT
ACCEPTABLE FOR FAN SUPPORT AND MAY
NEED TO BE REPLACED. DUE TO THE
COMPLEXITY OF THE INSTALLATION OF THIS
FAN, A QUALIFIED LICENSED ELECTRICIAN IS
STRONGLY RECOMMENDED.
Figure 2
Figures 1~3 are examples of different ways to
mount the outlet box.
Outlet Box
Figure 1
To hang your fan where there is an existing fixture
but no ceiling joist, you may need an installation
heavy duty fan brace as shown in Figure 2
(available at any Home Depot store).
Figure 3
Heavy Duty Outlet Box for Fan
Heavy Duty Fan Brace
Provide Strong Support
Recessed
Outlet Box
Mounting bracket
opening must be
toward the top
If there isn't an existing UL listed mounting box,
then read the following instructions. Disconnect
the power by removing fuses or turning off circuit
breakers.
Secure the outlet box directly to the building
structure. Use appropriate fasteners and building
materials. The outlet box and its support must be
able to fully support the moving weight of the fan
(at least 50 lbs). Do not use plastic outlet boxes.
Note: You may need a longer downrod to
maintain proper blade clearance when installing
on a steep, sloped ceiling. The maximum angle
allowable is 25°. If the canopy touches downrod,
remove the decorative canopy bottom cover and
turn the canopy 180°before attaching the canopy
to the mounting plate.
Phillips screwdriver, straight slot screwdriver, step
ladder and wire cutters.

4
WARNING
FAILURE TO PROPERLY INSTALL COTTER
PIN AS NOTED IN STEP 5 COULD RESULT IN
FAN LOOSENING AND POSSIBLY FALLING.
Screws
Bottom
Decorative
Coupling
Cover
Screws
Scroll Coupling
Decorative Scroll
Figure 4
1.
2.
3.
4.
5.
Remove the decorative canopy bottom cover
from the canopy by turning the cover counter
clockwise. (Figure 5)
Remove the mounting bracket from the canopy
by removing the 1 of 2 screws from the bottom
of the mounting bracket and loosening the
other one a half turn from the screw head.
Next, turn the canopy counter clockwise to
removing the mounting bracket from the
canopy. (Figure 5)
Remove the clevis pin, cotter pin and set
screws from the scroll coupling. (Figure 6)
Route the wires and safety cable exiting from
the decorative scroll through the upper
coupling cover, canopy cover, canopy and then
through the ball/downrod assembly. (Figure 6)
Align the holes at the bottom of the downrod
with the holes in the scroll coupling on top of
the decorative scroll (Figure 6). Carefully
insert the clevis pin through the holes in the
collar and downrod. Be careful not to jam the
clevis pin against the wiring inside the
downrod. Insert the cotter pin through the hole
near the end of the clevis pin until it snaps into
its locked position, as noted in the circle inset
of Fig. 6.
6. Tighten two set screws firmly on the coupling
located at top of the decorative scroll. Slip the
upper coupling cover onto the coupling, The
decorative scroll assembly is now completed.
Installing the Decorative
Scroll Assembly
Installing the Downrod
Secure the decorative scroll to the scroll
coupling with two screws provided, repeat the
procedure with the remaining decorative
scrolls. (Figure 4)
Remove the screw from the bottom of scroll
coupling, installing the bottom decorative
coupling cover onto the scroll coupling and
securing with the screw provided. (Figure 4)
For packaging purpose, the decorative scroll is
packed disassembled, proceed the following steps
for proper decorative scroll assembly:
1.
2.
Figure 5
Ceiling
Mounting
Bracket
Ceiling Canopy
Canopy Bottom
Cover

5
Remove the set screws, clevis pins and cotter
pins from the decorative scroll assembly,
place the decorative scroll in the top plate of
motor assembly, align the screw holes at the
bottom of decorative scroll with holes in the
top plate of fan motor assembly and then
secure with the set screws and clevis pins,
insert the cotter pin through the hole near the
end of the clevis pin until it snaps into its
locked position. Repeat the procedure for the
remaining decorative scrolls. NOTE: Make
sure the three rods are evenly set on the plate
of the motor assembly.
Snap together the wire connection plugs from
decorative scroll assembly and fan motor
assembly. (Figure 7)
Remove the nut and washers from the top plate
of motor assembly and then place the looped
end of the safety cable from the decorative
scroll between the two washers and secure with
nut provided. (Figure 7)
1.
2.
3.
Connection
Plugs
Figure 7
Decorative
Scroll Cotter Pin
Clevis
Pin
Screws with
Washers
Safety Cable
Top Plate
Washer Nut
Motor Wires
Ball/Downrod
Assembly
Ceiling Canopy
Canopy Cover
Scroll Coupling
Upper Decorative
Coupling Cover
Cotter Pins
Tighten Screw
Firmly
Clevis Pin
Figure 6
Pin in Locked
Positioon
Attaching the Fan Motor
Assembly

6
Figure 9
Groove
Tab
WARNING
THE TAB IN THE RING MUST REST IN THE
GROOVE OF THE HANGER BALL AS FIGURE 9.
FAILURE TO PROPERLY SEAT THE TAB IN
THE GROOVE COULD CAUSE DAMAGE TO
WIRING.
Figure 8
Ceiling
Mounting
Bracket
120V
Wires
Washers
Tab
UL Listed
Outlet Box
Posts in the
Outlet Box
Mounting
Screws (Supplied
with Electrical Box)
Figure 10
Safety Cable
Ceiling
Mounting
Bracket
Installing Fan to the
Electrical Box
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR OTHER PERSONAL INJURY.
MOUNT FAN ONLY TO AN OUTLET BOX OR
SUPPORTING SYSTEM MARKED ACCEPTABLE
FOR FAN SUPPORT AND USE THE MOUNTING
SCREWS PROVIDED WITH THE OUTLET BOX.
WARNING
Pass the 120-volt supply wires through the
center hole in the ceiling mounting bracket as
shown in Figure 8.
Install the ceiling mounting bracket to the
outlet box; be sure to align the holes in the
hanger bracket with the post holes in the outlet
box and secure with screws and washers
provided by the outlet box. (Fig. 8)
Security tighten the two mounting screws.
Carefully lift the fan assembly up to the ceiling
mounting bracket and seat the hanger ball in
the mounting bracket socket. Make sure the tab
on the mounting bracket socket is properly
seated in the groove in the hanger ball (Figure
9). This will help to balance the ceiling fan.
Secure the safety cable to the building structure
as shown in Figure 10.
1.
2.
3.
4.
5.

7
Making the Electrical
Connections
Connect the fan supply (black) wire to the
black household supply wire as shown in
Figure 11.
Connect the neutral fan (white) wire to the
white neutral household wire.
Connect the fan ground wire (green) to the
household ground wire.
After connecting the wires, spread them apart
so that the green and white wires are on one
side of the outlet box and the black wires are on
the other side.
Turn the connecting nuts upward and push the
wiring into the outlet box.
1.
2.
3.
4.
5.
REMEMBER to disconnect the power.
If you feel you do not have enough electrical
wiring knowledge or experience, have your fan
installed by a licensed electrician.
Follow the steps below to connect the fan to your
household wiring. Use the wire nuts supplied with
your fan. Secure the wire nuts with electrical tape.
Make sure there are no loose strands or
connections.
Figure 11
SUPPLY CIRCUIT
Ground
Conductor
Outlet Box
Green Ground
Lead
Ground to
Downrod
BLACK
WHITEWHITE
BLACK
GREEN
WARNING
CHECK TO SEE THAT ALL CONNECTIONS ARE
TIGHT, INCLUDING GROUND, AND THAT NO
BARE WIRE IS VISIBLE AT THE WIRE NUTS.
EXCEPT FOR THE GROUND WIRE.
WARNING
ELECTRICAL DIAGRAMS ARE FOR REFER-
ENCE ONLY. OPTIONAL USE OF ANY LIGHT
KIT SHALL BE UL LISTED AND MARKED
SUITABLE FOR USE WITH THIS FAN.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK. DO NOT USE THIS FAN WITH ANY
SOLID-STATE SPEED CONTROL DEVICE.

Tuck connections neatly into ceiling outlet
box.
Slide the canopy up to mounting bracket and
place the key hole on the canopy over the
screw on the mounting bracket, turn canopy
until it locks in place at the narrow section of
the key holes. (Fig. 12)
Align the circular hole on canopy with the
remaining hole on the mounting bracket,
secure by tightening the two set screws. Note:
Adjust the canopy screws as necessary until the
canopy and canopy cover are snug.
1.
2.
3.
Install 4 x 15W bulbs (provided) into the
sockets of the top plate on the top of motor
(Fig. 13).
Remove 1 of the 4 screws from the glass
housing and keep it for future use. Loosen the
other 3 screws. (Do not remove). Hold up the
top glass housing to ceiling fan assembly. Get
through the three screws on glass housing into
the three key holes located on the bottom of
motor housing, twist clockwise to set glass
housing firmly with motor housing. Secure by
tightening the 3 screws previously loosened
and the one previously removed. (Fig. 13)
1.
2.
Finishing the Fan
Installation
WARNING
MAKE SURE THE TAB ON THE MOUNTING
BRACKET PROPERLY SITS IN THE GROOVE IN
THE HANGER BALL BEFORE ATTACHING THE
CANOPY TO THE BRACKET BY TURNING THE
HOUSING UNTIL IT DROPS INTO PLACE.
8
Attaching the Top Glass
Housing
Motor Housing
Top Glass
Housing
Screws
Figure 13
Figure 12
Outlet Box
Ceiling
Mounting
Bracket
Screw
Screw
Canopy
Canopy
Bottom Cover
E12/15W
Bulbs
Top Plate

9
Attaching the Fan Blades
Attach blades to blade arms using three screws
with fiber washers. (Fig. 14) Start a screw into
the blade arm, do not tighten. Repeat for the 2
remaining screws and washers.
Tighten each screw securely starting with the
center screw. Make sure the blade is straight.
Repeat steps for the remaining blades.
Fasten the blade assemblies to the motor
housing by lining up the slots of the blade arms
with the tabs on the motor housing, then
tighten the two screws and washers already
installed in the blade arms. (Fig. 15)
1.
2.
3.
Figure 15
WARNING
TO REDUCE THE RISK OF PERSONAL INJURY,
DO NOT BEND THE BLADE ARMS WHILE
INSTALLING, BALANCING THE BLADES, OR
CLEANING THE FAN. DO NO INSERT FOREIGN
OBJECTS BETWEEN ROTATING FAN BLADES.
Figure 14
Blade Balancing
Most fan wobble problems are caused when
blade levels are unequal. Check this level by
selecting a point on the ceiling above the tip of
one of the blades. Measure from a point on the
center of each blade to the point on the ceiling.
Measure this distance as shown in Figure 16.
Rotate the fan until the next blade is positioned
for measurement. Repeat for each blade.
Measurements deviation should be within 1/8˝.
Run the fan for 10 Minutes.
Use the enclosed Blade Balancing Kit if the
blade wobble is still noticeable.
2.
3.
Check that all blade and blade bracket screws
are secure.
1.
The following procedure should correct most fan
wobble. Check after each step.
Figure 16
Touching Ceiling
Screws with
Fiber Washers
Blades
Blade Arm
Motor
Tab
Slot Blade Arm
Screw

10
Installing the Light Kit
Remove 1 of 4 screws from the mounting ring
and keep it for future use. Loosen the other 3
screws. (Do not remove)
Connect the white wire connector from the
light kit and fan, follow the same procedure
with the black wire connectors. (Fig. 17)
Place the key holes on the light plate over the 3
screws previously loosened from the mounting
ring, turn light plate until it locks in place at the
narrow section of the key holes. Secure by
tightening the 3 screws previously loosened
and the one previously removed. (Fig. 17)
Install 60W candelabra bulb (included). (Fig.
18)
1.
2.
3.
4.
Raise the glass shade up against the light plate,
place looped end of the safety cable over the
hook located on the light plate. Install the glass
shade onto the light plate with 4 screws
provided. Be sure to tighten all screws. (Fig. 18)
Restore power and your light kit is ready for
operation.
5.
6.
CAUTION
BEFORE STARTING INSTALLATION, DISCON-
NECT THE POWER BY TURNING OFF THE
CIRCUIT BREAKER OR REMOVING THE FUSE
AT FUSE BOX. TURNING POWER OFF USING
THE FAN SWITCH IS NOT SUFFICIENT TO
PREVENT ELECTRIC SHOCK.
Figure 17
Mounting Ring
Light Plate
Screws
Wire Connection
Plugs
Figure 18
Screws
Hook
Safety Cable
Light Plate
Bulb
Bottom Glass
Shade
NOTE
LIGHT BULBS HAVE NO WARRANTY; CAN BE
PURCHASED AT ANY HOME DEPOT STORE.

11
Interior Bulb Replacement
REMEMBER to turn off the power
1.
2.
3.
Remove the 2 screws from the light cover from
the top decorative housing as shown in Fig. 19.
Replace the defective bulb (15W, 120V AC
CANDELABRA base).
Place the light cover back to the top decorative
housing and secure the screws in position.
1.
2.
The receiver frequency selector is located on
the top of the motor assembly plate as show in
Fig. 20.
The transmitter frequency selector is located in
the battery compartment as show in Fig. 21.
Each frequency selector has 4 switches, you
may use any number of possible combinations
but you must set each switch in the transmitter
to match the same switch in the receiver. Figure 21
Frequency
Switch
Figure 19
Screws
Motor
Housing
Light Cover
Bulbs
Figure 20
Code
Switch
Operating Your Transmitter
Installing the Battery:
Install 9 volt battery (not included), to prevent
damage to transmitter, remove the battery if not
used for long periods. (Figure 22)
Figure 22
9Volt
Battery

1212
"LO. MED, HI" buttons:
These three buttons are used to set the fan
speed as follows:
LOW=Low speed,
MED= Medium speed
HI=High speed
"OFF" button:
This button turns the fan off.
The "U/L" button turns the upper light ON or
OFF and also controls the brightness setting.
The "D/L" button turns the bottom light ON or
OFF and also controls the brightness setting.
Press and release the button to turn the light
ON or OFF. Press and hold the button to set the
desired brightness. The light button has an
auto-resume, it will stay at the same brightness
as the last time it was turned off.
"REV" Button: This button is used to change
the direction of the rotation of the blades;
forward for warm weather or reverse for warm
weather.
1.
2.
3.
4.
Restore power to the ceiling fan and test for
proper operation.
Figure 23
LO
MED
HI
OFF
U/L
D/L
REV
Speed settings for warm or cool weather depend
on factors such as the room size, ceiling height,
number of fans, etc.
Warm weather - (Counter-Clockwise direction)
A downward air flow creates a cooling effect.(Fig.
24) This allows you to set your air conditioner on
a higher setting without affecting your comfort.
Cool weather - (Clockwise direction) An upward
airflow moves warm air off the ceiling area. (Fig.
25) This allows you to set your heating unit on a
lower setting without affecting your comfort.
NOTE
TO OPERATE THE REVERSE FUNCTION ON
THIS FAN, PRESS THE "REV" BUTTON WHILE
THE FAN IS RUNNING.
Figure 24
Figure 25

13
WARNING
MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX
BEFORE YOU ATTEMPY ANY REPAIRS. REFER TO THE SECTION,
“MAKING ELECTRICAL CONNECTIONS”.
Because of the fan's natural movement, some
connections may become loose. Check the
support connections, brackets, and blade
attachments twice a year. Make sure they are
secure. (It is not necessary to remove fan from
ceiling.)
Clean your fan periodically to help maintain its
new appearance over the years. Do not use
water when cleaning. Use only a soft brush or
lint-free cloth to avoid scratching the finish.
The plating is sealed with a lacquer to
minimize discoloration or tarnishing. Do not
use water when cleaning. This could damage
the motor, or the wood, or possibly cause an
electrical shock.
You can apply a light coat of furniture polish to
the wood blades for additional protection and
enhanced beauty. Cover small scratches with a
light application of shoe polish.
There is no need to oil your fan. The motor has
permanently lubricated sealed ball bearings.
1.
2.
3.
4.
Here are some suggestions to help you maintain
your fan.
Check main and branch circuit fuses or breakers.
Check line wire connections to the fan and switch wire connections in
the switch housing.
Check to make sure the dip switches from the transmitter and receiver
are set to the same frequency.
Make sure all motor housing screws are snug.
Make sure the screws that attach the fan blade bracket to the motor hub
is tight.
Make sure wire nut connections are not rattling against each other or
the interior wall of the switch housing.
Allow a 24-hour "breaking-in" period. Most noises associated with a
new fan disappear during this time.
If using ceiling fan light kit, make sure the screws securing the
glassware are tight. Check that the light bulb is also secure.
Make sure there is a short distance from the ceiling to the canopy. It
should not touch the ceiling.
Make sure your ceiling box is secure and rubber isolator pads are used
between mounting bracket and outlet box.
This unit is equipped with a wattage limiting device. Lamping in excess
of 190 watts will disable your ceiling fan's light kit. To reset your light
kit you must turn the power off and relamp, keeping the wattage under
190 watts. Restore power to your ceiling fan and continue normal
operation.
Do not connect the fan with a wall mounted variable speed control(s).
Make sure the dip switches are set correctly.
1.
2.
3.
1.
2.
3.
4.
5.
6.
7.
1.
1.
2.
Fan will not start
Fan sounds noisy
Lights shut off and
will not come back
on.
Remote control
Care of Your Fan Troubleshooting
PROBLEM SOLUTION

14
Specifications
FAN SIZE SPEED VOLTS AMPS WATTS RPM CFM N.W. G.W. C.F.
60” 120 19.40 kgs
(42.68 lbs)
21.50 kgs
(47.3 lbs) 5.21’
LOW
MED.
HIGH
0.3
0.5
0.7
15
40
88
50
95
140
1200
3850
6500
These are approximate measures. They do not include Amps and Wattage used by the light kit.

15
The Hampton Bay warrants the fan motor to be free from defects in workmanship and material present at time
of shipment from the factory for a period of lifetime after the date of purchase by the original purchaser.
Hampton Bay also warrants that all other fan parts, excluding any glass or acrylic blades, to be free from
defects in workmanship and material at the time of shipment from the factory for a period of one year after the
date of purchase by the original purchaser. We agree to correct such defects without charge or at our option
replace with a comparable or superior model if the product is returned to Hampton Bay. To obtain warranty
service, you must present a copy of the receipt as proof of purchase. All costs of removing and reinstalling the
product are your responsibility. Damage to any part such as by accident or misuse or improper installation or
by affixing any accessories, is not covered by this warranty. Because of varying climatic conditions this
warranty does not cover any changes in brass finish, including rusting, pitting, corroding, tarnishing or peeling.
Brass finishes of this type give their longest useful life when protected from varying weather conditions. A
certain amount of “wobble” is normal and should not be considered a defect. Servicing performed by
unauthorized persons shall render the warranty invalid. There is no other express warranty. Hampton Bay
hereby disclaims any and all warranties, including but not limited to. Those of merchantability and fitness for
a particular purpose to the extent permitted by law. The duration of any implied warranty which cannot be
disclaimed is limited to the time period as specified in the express warranty. Some states do not allow
limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The retailer
shall not be liable for incidental, consequential, or special damages arising out of or in connection with product
use or performance except as may otherwise be accorded by law. Some states do not allow the exclusion of
incidental or consequential damages, so the above exclusion or limitation may not apply to you. This warranty
gives specific legal rights, and you may also have other rights which vary from state to state. This warranty
supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty must
be paid by the customer.
Hampton Bay Lifetime Limited Warranty
(lifetime warranty on motor)
You must present a copy of the original
purchase receipt to obtain warranty
service.
Ceiling Fan Parts & Service Department
2919 E. Philadelphia Street
Ontario, Ca 91761
Attach receipt here for easy
location
