HAMPTON BAY AERATRON User manual

Item #602-672
#602-676
Model #E503-WH
#E503-SL
AERATRON CEILING FAN
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 1／24页

2
Table of Contents
Table of Contents..........................................................2
Safety Information.........................................................2
Warranty.........................................................................3
Pre-Installation..............................................................3
Planning Installation ................................................................3
Tools Required .........................................................................3
Hardware Included...................................................................4
Package Contents ....................................................................5
Installation ..................................................................... 6
Operation..................................................................... 10
Care and Cleaning ...................................................... 11
Troubleshooting.......................................................... 11
Safety Information
1. All wiring must be in accordance with the National Electrical
Code ANSI/NFPA 70-1999 and local electrical codes.
Electrical installation should be performed by a
licensed electrician.
2. The outlet box and support structure must be securely
mounted and capable of reliably supporting a minimum of
35 lbs. (16 kg). Use only UL-listed outlet boxes marked “For
Fan Support.”
3. Do not operate the reversing switch while the fan blades are
in motion. You must turn the fan off and stop the blades
before you reverse the blade direction.
4. Avoid placing objects in the path of the fan blades.
5. Electrical diagrams are for reference only. Light kits that are
not packed with the fan must be UL-listed and marked
suitable for use with the model fan you are installing.
Switches must be UL General Use Switches. Refer to the
instructions packaged with the light kits and switches for
proper assembly.
6. After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into the
outlet box. The wires should be spread apart with the
grounded conductor and the equipment-grounding
conductor on one side of the outlet box.
WARNING: To reduce the risk of electric shock, ensure
electricity has been turned off at the circuit breaker or fuse
box before beginning.
WARNING: To reduce the risk of personal injury, do not
bend the blade brackets (also referred to as anges) during
assembly or after installation. Do not insert objects in the
path of the blades.
WARNING: To reduce the risk of or electric shock, do
not use this fan with any solid-state speed control device.
must be mounted with a minimum of 7 feet clearance from
the trailing edge of the blades to the or.
CAUTION: To reduce the risk of personal injury, the fan
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 2／24页

MOC.YABNOTPMAH3
.ecnatsissarehtrufrof3130-725-778-1tcatnocesaelP
Warranty
Pre-Installation
PLANNING INSTALLATION
Compare all parts with the Hardware Included and Package Contents sections in this manual. If any part is missing or damaged, do not
install this fan and contact the Customer Service Team at 1-877-527-0313 or visit www.HamptonBay.com.
TOOLS REQUIRED
Hammer
Safety
goggles
Phillips
screwdriver
Flathead
screwdriver
Wire cutters
Step
ladder
LIMITED LIFETIME WARRANTY
The supplier warrants the fan motor to be free from defects in workmanship and material present at time of shipment from the factory for a
lifetime after the date of purchase by the original purchaser. The supplier also warrants that all other fan parts, excluding any glass or
acrylic blades, be free from defects in workmanship and materialat the time of shipment from the factory for a period of one year after
the date of purchase by the original purchaser. We agree to correct such defects without charge or at our option replace with a comparable
or superior model if the product is returned. To obtain warranty service, you must present a copy of the receipt as proof of purchase. All
costs of removing and reinstalling the productare your responsibility. Damage to anypart, such as by accident, misuse, improper
installation, or by any accessories, is not covered by this warranty. Because of varying climatic conditions, this warranty does not
cover any changes in brass nish, including rusting, pitting, corroding, tarnishing, or peeling. Brass this type give their longest
useful life when protected from varying weather conditions. A certain amount of “wobble” is normal and should not be considered a defect.
Servicing performed by unauthorized persons shall render the warranty invalid. There is no other express warranty. The supplier hereby
disclaims any and all warranties, including but not limited to those of merchantability and for a particular purpose to the extent
permitted by law. The duration of any implied warranty which cannot be disclaimed is limited to the time period as in the express
warranty. Some states do not allow a limitation on how long an implied warranty lasts, so the above limitation may not apply to you. The
retailer shall not be liable for incidental, consequential, or special damages arising out of or in connection with product use or performance
except as may otherwise be accorded by law. Some states do not allow the exclusion of incidental or consequential damages, so the above
exclusion or limitation may not apply to you. This warranty gives legal rights, and you may also have other rights which vary from
state to state. This warranty supersedes all prior warranties. Shipping costs for any return of product as part of a claim on the warranty
must be paid by the customer.
Contact the Customer Service Team at 1-877-527-0313 or visit www.HamptonBay.com.
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 3／24页

10
Washer
G
AA BB CC DD EE FF GG HH
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 4／24页

A
A
B
B
C
C
D
D
E
E
F
F
G
G
3
1
1
1
1
1
1
Fan blade
Blade arm base
Blade arm cover
Mounting bracket
Transmitter with holder
Receiver
Fan motor
H
H
1Upper housing
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 5／24页

AA
AA
C
A
A
B
Attaching the blades to the blade
arm
Attach each fan blade (A) to the blade arm base (B)
using the blade screws (AA). Tighten securely with
a Phillips screwdriver.
Attach the blade arm cover (C) using the blade screws
(AA). Tighten securely with a Phillips screwdriver.
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 6／24页

3 4
1
D
CC
DD
F
D
G
EE
FF
7
Attach the mounting bracker (D) to the outet box using the
washers (CC), star washers (DD), lockwashers (EE), and
mounting bracket screws (FF). Tighten securely with a
Phillips screwdriver.
Seat the hanger ball portion of the motor (G) in the
mounting bracket (D) socket. Ensure that the tab on
the mounting bracket (D) socket is properly seated
in the groove on the hanger ball.
Slide the receiver (F) into position in the space between
the hanger ball portion of motor (G) and the mounting
bracket (D).
HAMPTONBAY.COM
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 7／24页

5 6
KK JJ
II
II
II
JJ
KK
2
2
F
1
GG
GG
G
1
H
GG
H
GG
1
8
Making the electrical connections
Connect the 9 pin connector (2) from the fan motor (G) to
the 9 pin connector (2) from the receiver (F).
from the fan motor (G).
Connect the green ground wire (II) from the receiver (F)
to the green wire (II) from the outlet box (1) using a wire
connecting nut (HH).
Connect the white wire (JJ) from the receiver (F) to the white
wire (JJ) from the outlet box (1) using a wire connecting
nut (HH).
Connect the black wire (KK) from the receiver (F) to the black
wire (KK) from the outlet box (1) using a wire connecting
nut (HH).
Ensure the upper housing (H) screw covers (1) are in
the full open position.
Raise the upper housing (H) up to the ceiling and slide
the slotted hole in the upper housing (H) through the
loosened upper housing screw (GG), and twist the upper
housing (H) to lock it in place on the screw (GG). Tighten
all three screws (GG) securely with a Phillips screwdriver,
and close all three screw covers (1).
Attaching the upper housing to
the fan motor
Remove one of the preassembled upper housing
screws (GG) from the fan motor (G). Loosen, but do
not remove, the other two upper housing screws (GG).
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 8／24页

9
H
GBB
1
7Attaching the fan blade assembly to the fan motor
Slip the fan blade assembly onto the fan motor (G), insert the blade
Rotate the screw cover (1) to hide the screw head.
NOTE:
screw (BB) from falling out, should it become loose.
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 9／24页

10
Press the "Forward" or "Reverse" button on the transmitter
(E) to control the direction of the blades.
PROGRAMMING THE TRANSMITTER AND RECEIVER
TRANSMITTER BUTTON DESCRIPTION
Set the transmitter (E) dip switch to the desired setting.
Switch on the main power to activate the receiver.
Within 3 minutes after the power is turned on, press and hold
the transmitter’s “ON/OFF” button for 5 seconds.
Press any transmitter (E) button to check for proper functioning.
Fan Speed Buttons: Press the up or down arrow to turn the
fan on or change the speed setting.
ON/OFF Button: Press this button to turn the fan off or on.
For code changes, repeat this procedure.
1.
2.
E
Battery Compartment Door
E
1
3
2
4
NOTE: The dip switch on thereceiver doesnot need to be
manipulated.
NOTE: The receiver (F) will issue four short tones to indicate
a successful code match. Afterwards, the fan will automatically
retum to the original speed indicated on the LCD screen.
NOTE: The transmitter and receiver will retain the code for
futureuse(alsoifswitched off).
Remove the battery compartment door and battery from the
transmitter (E), revealing the dip switch.
Forward Button: Press this button to turn the fan in the
forward direction (for warm weather).
Reverse Button: Press this button to turn the fan in the
reverse direction (for cool weather).
3.
4.
DPA12122006 新版 SIZE:216x280mm 80g模糙纸 24P 单黑色 骑马钉 2013-4-17 第 10／24页
