HAMPTON BAY CYPRUS 220 635 User manual

220 635

Cyprus by Hampton Bay®

Ceiling Fan by Hampton Bay
Date Purchased
Store Purchased
ETL
Model No.
Serial No.
Vendor No.
UPC
Table of Contents
Safety Rules . . . . . . . . . . . . . . . . . . . . 1
Unpacking Y our Fan . . . . . . . . . . . . . . 2
Installing Y our Fan . . . . . . . . . . . . . . . 3
Installing the Light Kit. . . . . . . . . . . . . 8
Care of Y our Fan . . . . . . . . . . . . . . . . 10
Trouble shooting . . . . . . . . . . . . . . . . . 10
Specifications . . . . . . . . . . . . . . . . . . 11
Warranty Information . . . . . . . . . . . . 12
Thank you for purchasing our ceiling fan. This product has been
manufactured with the highest standards of safety and quality.
52 Cyprus
82598
845952000353
CF552C-CL056

Safety Rules - Read and Save These Instructions
WARNING
WARNING
To reduce the risk of electric shock, ensure electricity has been
turned off at the circuit breaker or fuse box before beginning.
All wiring must be in accordance with the National Electrical
Code “ANSI/NFPA 70-1999” and local electrical codes. Electrical
installation should be performed by a qualified licensed
electrician.
WARNING: To reduce the risk of electrical shock or fire, do not
use this fan with any solid-state fan speed control device. It will
permanently damage the electronic circuitry.
CAUTION: To reduce the risk of personal injury, use only the
screws provided with the outlet box.
The outlet box and support structure must be securely mounted and
capable of reliably supporting a minimum of 35 pounds. Use only
UL Listed outlet boxes marked “FOR FAN SUPPORT”.
The fan must be mounted with a minimum of 7 feet clearance from
the trailing edge of the blades to the floor.
Avoid placing objects in path of the blades.
To avoid personal injury or damage to the fan and other items, be
cautious when working around or cleaning the fan.
Do not use water or detergents when cleaning the fan or fan blades.
A dry dust cloth or lightly dampened cloth will be suitable for most
cleaning.
1.
2.
3.
4.
5.
6.
7.
8.
9.
After making electrical connections, spliced conductors should be
turned upward and pushed carefully up into outlet box. The wires
should be spread apart with the grounded conductor and the
equipment-grounding conductor on one side of the outlet box and
ungrounded conductor on the other side of the outlet box.
All set screws must be checked and retightened where necessary
before installation.
10.
11.
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE
BLADE ARMS (ALSO REFERRED TO AS FLANGES), WHEN
INSTALLING THE BRACKETS, BALANCING THE BLADES OR
CLEANING THE FAN. DO NOT INSERT FOREIGN OBJECTS IN –
BETWEEN ROTATING FAN BLADES.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL
INJURY, MOUNT FAN TO OUTLET BOX MARKED ACCEPTABLE FOR
FAN SUPPORT WITH THE SCREWS PROVIDED WITH THE OUTLET
BOX.
1

2
WARNING
DO NOT INSTALL OR USE FAN
IF ANY PART IS DAMAGED OR MISSING.
CALL TOLL FREE 1-877-262-7511
Unpacking Your Fan Unpack your fan and check the contents. You should have the following items:
14.
Loose parts bag containing:
A.Blade attachment hardware
(16 screws and paper washers)
B.Blade holder attachment hardware
(8 screws)
C.Pull chain fob(2)
D.Balancing kit(1)
E.Wire nut(3)
9. Compartment box cover(1)
10. Light kit(1)
11. Glass shade(3)
12. Bulbs(E12*40W) (3)
13. Bulbs(E12*15W) (4)
1. Fan blades(5)
2. Mounting bracket(1)
3. Canopy(1)
4. Canopy cover(1)
5. Downrod assembly(1)
6 Coupling cover(1)
7. Fan motor assembly(1)
8. Blade holders(5)
11
12
1
5
4
6
7
8
2
3
BA
CD
E
13
14
9
10

Installing Your Fan
WARNING
Outlet Box
Outlet Box
Outlet Box
Figure 2
Figure 1
Ceiling
Mounting
Plate
Provide Strong
Support
Recessed
Outlet Box
Figure 3
Figure 4
Tools Required
Mounting Options
Phillips screwdriver, straight slot
screwdriver, step ladder and wire cutters.
If there isn't an existing UL listed mounting
box, then read the following instructions.
Disconnect the power by removing fuses or
turning off circuit breakers.
Secure the outlet box directly to the building
structure. Use appropriate fasteners and
building materials. The outlet box and its
support must be able to fully support the
moving weight of the fan (at least 35 lbs). Do
not use plastic outlet boxes.
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PERSONAL INJURY, MOUNT FAN
ONLY TO AN OUTLET BOX MARKED ACCEPT-
AB L E FOR FAN SU PPORT A ND US E THE
MOUNTING SCREWS PROVIDED WITH THE
OUTLET BOX. OUTLET BOX COMMONLY USED
FOR THE SUPPORT OF LIGHTING FIXTURE MAY
NOT BE ACCEPTABLE FOR FAN SUPPORT AND
MAY NEED TO BE REPLACED. CONSULT A
QUALIFIED ELECTRICIAN IF IN DOUBT.
Figures 1~3 are examples of different ways to
mount the outlet box.
Note: You may need a longer downrod to
maintain proper blade clearance when
installing on a steep, sloped ceiling. The
maximum angle allowable is 18°. If the
canopy touches downrod, remove the
decorative canopy bottom cover and turn the
canopy 180° before attaching the canopy to
the mounting plate.
To hang your fan where there is an existing
fixture but no ceiling joist, you may need an
installation hanger bar as shown in Figure 4
(available at any Home Depot store).
3

Figure 11
Registration
slot
Hanging the Fan
REMEMBER to turn off the power. Follow the
steps below to hang your fan properly:
4
Figure 7
Downrod
Supply
wires
Figure 9
Figure 6
Outlet box
Mounting
bracket
Set
screws
1.
2.
4.
5.
6.
7.
Secure the mounting bracket to the ceiling outlet
box with the screws and washers provided with
Loosen the two set screws from the motor
Remove the hitch pin and lock pin from the
downrod assembly. Remove hanger ball from
downrod assembly by loosening set screw, removing
the cross pin, and sliding ball off rod. (Figure 8)
Carefully feed fan wires up through the downrod.
Thread the rod into the coupling. Next, line up holes
and replace lock pin and hitch pin. Tighten set screws.
Slip coupling cover, canopy cover and canopy onto
downrod. (Figure 10) Carefully reinstall hanger ball
onto downrod, make sure that cross pin is in correct
position, set screws are tighten and wires are not twisted.
Now lift motor assembly into position and place hanger
ball into mounting bracket. Rotate until the check
groove drops into the registration slot and seats firmly.
(Figure 11) Downrod should not rotate if this is done
your outlet box. (Figure 6)
assembly. (Figure 7)
(Figure 9)
correctly.
Cross pin
Hanger
ball
Downrod
Figure 8
Hitch pin
Lock pin
Set
screw
3. Figure 5
Upper housing
Screw
Glass housing
Light kit
Bulb
(E12*15W)
(included)
Motor assembly
Figure 10
Lead Wires
Ball/downrod
Assembly
Canopy
Lock Pin
Couping cover
Canopy cover
Hitch Pin
Tighten
Screws
Firmly
Remove one screw and loosen three screws on
the upper housing,take the upper housing away,
place four bulbs(E12*15W) into the light kit of
the motor assembly, tighten them firmly. Secure
the upper housing to the motor assembly by
tightening four screws previously removed and
loosened.(Figure 5)

5
SUPPLY CIRCUIT
Ground
Conductor
Outlet Box
Green
Ground
Lead
Ground to
Downrod
BLACK
WHITEWHITE
BLACK
BLUE
GREEN
WHITE
BLUE
BLACK WHITE
Figure 12
Diagram indicates optional light kit wiring.
Making the Electrical
Connections
Remember
Follow the steps below to connect the fan to
your ceiling wiring. Use the wire nuts
supplied with your fan. Secure the
connectors with electrical tape. Make sure
there are no loose strands or connections.
to shut off the power.
1. Connect the fan supply (black) wire and
light supply (blue) wire to the black ceiling
supply wire. (Figure 12)
2. Connect the neutral fan (white) wire t o
the w hite neutral wire from the ceiling.
(Figure 12)
3. Connect the fan ground wire (green) and
the mounting bracket ground wire (green) to
the ground wire from the ceiling. (Figure
12)
4. After connecting the wires, spread them
apart so that the green and white wires are
on one side of the outlet box and the black
and the blue wires are on the other side.
LIGHT KITS ARE AVAILABLE AT YOU HAMPTON
BAY RETAILER. THE FAN IS ALREADY WIRED TO
SUPPORT THE LIGHT KIT OPTION.
5. Turn the wire nuts upward and push the wiring into the
outlet box. Figures 13 and Figures 14 illustrate the wiring
connections for optional wall control (available at your
Hampton Bay Retailer, the wire color out of wall control
may vary, see wall control's installation manual for correct
wire connections)
NOTE
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR
OTHER PERSONAL INJURY. MOUNT FAN ONLY ON AN
OUTLET BOX OR SUPPORTING SYSTEM MARKED
ACCEPTABLE FOR FAN SUPPORT.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK.
DO NOT USE THIS FAN WITH ANY SOLID-STATE SPEED
CONTROL DEVICE.

SUPPLY CIRCUIT
Ground
Conductor
Outlet Box
Green
Ground
Lead
Ground to
Downrod
BLACK
WHITE
WHITE
BLACK
BLUE
GREEN
Figure 14
Diagram indicates optional light kit wiring.
Light
Fan
WHITE
BLUE
BLACK WHITE
SUPPLY CIRCUIT
Ground
Conductor
Outlet Box
Green
Ground
Lead
Ground to
Downrod
BLACK
WHITE
WHITE
BLACK
BLUE
GREEN
Figure 13
Diagram indicates optional light kit wiring.
Light Switch
WHITE
BLUE
BLACK WHITE
Finishing the Installation
1. Tuck connections neatly into ceiling outlet box.
2. Remove one screw from the mounting bracket
and loosen the other screw around 1/4″.
3. Align the canopy up to ceiling and over the loose
screw. Place the canopy into key hole and rotate
canopy clockwise. (Figure 15)
4. Secure the canopy by using previous removed
and loosened screw.
5. Place the canopy cover to the canopy and rotate
canopy cover clockwise until it is locked into right
position.(Figure 15)
MAKE SURE TAB AT BOTTOM OF HANGER
BRACKET IS PROPERLY SEATED IN GROOVE OF HANGER
BALL BEFORE
ATTACHING CANOPY TO BRACKET. FAILURE
TO PROPERLY SEAT TAB IN GROOVE COULD CAUSE
DAMAGE TO ELECTRICAL WIRING.
WARNING
Figure 15
6
Outlet box
Mounting
bracket
Canopy
Screw
Canopy
cover
Lead Wires
Ball/Downrod
Assembly

7
The following procedure should correct most
fan wobble issues. Check after each step.
1. Check that all blades and blade holder
screws are secure.
2. Most fan wobble problems are caused
when blade levels are unequal. Check this
level by selecting a point on the ceiling above
the tip of one of the blades. Measure this
distance as shown in Figure 18. Rotate the fan
until the next blade is positioned for
measurement. Repeat for each blade. The
distance should be equal within 1/8".
If all blade levels are not equal, you can
adjust the blade level with the following
procedure.
3. Use the enclosed Blade Balancing Kit if the
blade wobble is still noticeable. (Please refer
to the introduction provide in the blade
balancing kit, which is individually packed.)
4. If the blade wobble is still noticeable,
interchanging two adjacent (side by side)
blades can redistribute the weight and
possibly result in smoother operation.
Touching
ceiling
Figure 18
Figure 17
Attaching the Fan
Blades
1. Attach the blades to the blade holders
using three screws and paper washer as
shown in Figure 16. Start a screw into the
blade holder, do not tighten. Repeat for
the 2 remaining screws and washers.
2. Tighten each screw securely starting
with the center screw. Make sure the blade
is straight.
3. Remove the plastic blocks before
installing the blade holder to the bottom
motor housing, discard the plastic blocks
but keep the screws. (Figure 17).
4. Fasten the blade assemblies to motor
hou sin g by tig h ten ing the scr e ws
previously removed from the motor
housing and the screws from the loose
parts bag(B). (Figure 17)
Figure 16
Blade holder
Blade
Screws
paper
Washer
Motor housing
Blade holder
Screw
