Principle
Principle
s/o

52” Principle
Ceiling Fan by Hampton Bay
Brushed Nickel Finish
3 Blades (Black)
Full Function Thermostatic Remote
Control Included
Frosted Opal Glass
(7) 1-Watt LED Bulbs Included
QUESTIONS, PROBLEMS, MISSING PARTS:
Before returning to your local Home Depot, please call our
Customer Service Team at 1-877-527-0313 or visit www.homedepot.com.
Please reference your SKU (128 597 brushed nickel)
or UPC (082392 680435 brushed nickel).
Thank you for purchasing this Hampton Bay ceiling
fan. This product has been manufactured with the
highest standards of safety and quality. The nish
of this fan is weather resistant, but over time will
naturally weather and fade.
Safety Rules ...................................... 1
Unpacking Your Fan........................ 2
Installing Your Fan .......................... 3
Operating Your Fan ......................... 10
Operating Your Remote Control .... 11
Care of Your Fan.............................. 13
Troubleshooting................................ 13
Specications .................................... 14
Warranty Information..................... 15
Table of Contents
UL Model No. 52-UBN

Safety Rules ...................................... 1
Unpacking Your Fan........................ 2
Installing Your Fan .......................... 3
Operating Your Fan ......................... 10
Operating Your Remote Control .... 11
Care of Your Fan.............................. 13
Troubleshooting................................ 13
Specications .................................... 14
Warranty Information..................... 15
1. To reduce the risk of electric shock, insure electricity
has been turned off at the circuit breaker or fuse box
before beginning.
2. All wiring must be in accordance with the National
Electrical Code ANSI/NFPA 70-1999 and local electrical
codes. Electrical installation should be performed by a
qualied licensed electrician.
3. WARNING: To reduce the risk of re or electric shock,
this fan should only be used with fan speed control part no.
FAN-32R-ONELIGHT, manufactured by Chia Wei Electric
Co., Ltd.
4. CAUTION: To reduce the risk of personal injury, use only
the screws provided with the outlet box.
5. The outlet box and support structure must be securely
mounted and capable of reliably supporting a minimum of
35 pounds. Use only UL Listed outlet boxes marked “FOR
FAN SUPPORT.”
6. The fan must be mounted with a minimum of 7 feet
clearance from the trailing edge of the blades to the oor.
7. Avoid placing objects in path of the blades.
8. To avoid personal injury or damage to the fan and
other items, be cautious when working around or
cleaning the fan.
9. Do not use water or detergents when cleaning the fan or fan
blades. A dry dust cloth or lightly dampened cloth will be
suitable for most cleaning.
10. After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into
outlet box. The wires should be spread apart with the
grounded conductor and the equipment-grounding
conductor on one side of the outlet box and ungrounded con-
ductor on the other side of the outlet box.
11. Electrical diagrams are for reference only. Light kits that are
not packed with the fan must be UL Listed and marked suit-
able for use with the model fan you are installing. Switches
must be UL General Use Switches. Refer to the instructions
packaged with the light kits and switches for proper assembly.
12. All set screws must be checked and retightened where neces-
sary before installation.
Safety Rules 1.
READ AND SAVE THESE INSTRUCTIONS
TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE
BLADE BRACKETS (ALSO REFERRED TO AS “FLANGES”) DURING
ASSEMBLY OR AFTER INSTALLATION. DO NOT INSERT OBJECTS IN
THE PATH OF THE BLADES.
TO REDUCE THE RISK OF SHOCK, THIS FAN MUST BE INSTALLED
WITH AN ISOLATION WALL CONTROL/SWITCH.
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR PERSONAL
INJURY, MOUNT TO OUTLET BOX MARKED “ACCEPTABLE FOR
FAN SUPPORT OF 35LBS (15.9KG) OR LESS” AND USE MOUNTING
SCREWS PROVIDED WITH THE OUTLET BOX. OUTLET BOXES COM-
MONLY USED FOR THE SUPPORT OF LIGHTING FIXTURES ARE NOT
ACCEPTABLE FOR FAN SUPPORT AND MAY NEED TO BE REPLACED.
CONSULT A QUALIFIED ELECTRICIAN IF IN DOUBT.

a. Blade attachment hardware
(9 screws)
b. Mounting & Electrical Hardware
(1 hanger pin, 1 locking pin, 3 plastic
wire connectors, 1 rubber gasket)
c. Blade Balancing Kit
d. Blade Bracket Hardware
(6 screws and lockwashers)
6. Blades Brackets (3)
7. Blades (3)
8. Lower Housing
9. Glass
10. Transmitter (Hand Unit)
1. Mounting Plate (inside Canopy)
2. Downrod and Ball Assembly
3. Canopy
4. Decorative Motor Collar Cover
5. Fan Motor Assembly
2. Unpacking Your Fan
IMPORTANT: THIS PRODUCT AND/OR COMPONENTS ARE COVERED
BY ONE OR MORE OF THE FOLLOWING U.S. PATENTS: 5,947,436;
5,988,580; 5,971,573; 6,010,306; 6,039,541; 6,046,416 AND OTHER
PATENTS PENDING.
Unpack your fan and check the contents. You should have the following items:
1
6
2
3
4
57
8
9
10
ab
cd
REMOVE RUBBER PACKING MOUNTS IN THE
FAN MOTOR ASSEMBLY AND DISCARD BEFORE
INSTALLATION.

Installing Your Fan 3.
Tools Required
Phillips screw driver, straight slot screw
driver, adjustable wrench, step ladder, and
wire cutters.
Mounting Options
If there isn’t an existing outlet box, then read
the following instructions. Disconnect the
power by removing fuses or turning off
circuit breakers.
Secure the outlet box directly to the building
structure. Use appropriate fasteners and
building materials. The outlet box and its
support must be able to fully support the
moving weight of the fan (at least 35 lbs.)
Do not use plastic outlet boxes.
Figures 1, 2, and 3 are examples of different
ways to mount the outlet box.
Outlet Box
Note: You may need a longer downrod to
maintain proper blade clearance when install-
ing on a steep, sloped ceiling. The maximum
angle allowable is 30˚. If the canopy touches
downrod, remove the decorative canopy
bottom cover and turn the canopy 180˚ before
attaching the canopy to the mounting plate.
Outlet Box
To hang your fan where there is an existing
xture but no ceiling joist, you may need an
installation hanger bar as shown in Figure 4
(available at your Hampton Bay retailer).
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PERSONAL INJURY, MOUNT TO
OUTLET BOX MARKED “ACCEPTABLE FOR
FAN SUPPORT OF 35LBS (15.9KG) OR LESS”
AND USE MOUNTING SCREWS PROVIDED
WITH THE OUTLET BOX. OUTLET BOXES
COMMONLY USED FOR THE SUPPORT OF
LIGHTING FIXTURES ARE NOT ACCEPTABLE
FOR FAN SUPPORT AND MAY NEED TO
BE REPLACED. CONSULT A QUALIFIED
ELECTRICIAN IF IN DOUBT.
Figure 1
Figure 2
Figure 4
Figure 3

4.
each section of the instructions will note the
different procedures to follow for the two types
of installation.
Standard Ceiling Mounting
1. Remove the canopy ring from the canopy
by turning the ring to the right until it un-
locks (Figure 5).
Hanging the Fan
REMEMBER to turn off the pow-
er. Follow the steps below to hang your
fan properly.
NOTE: This ceiling fan is supplied with two
types of hanging assemblies; the standard
ceiling installation using the downrod with
ball and socket mounting, and the “close-to-
ceiling” mounting. The “close-to-ceiling”
mounting is recommended in rooms with
less than 8-foot ceilings or in areas where
additional space is desired from the oor
to the fan blades. When using standard
downrod installation, the distance from the
ceiling to the bottom of the fan blades will be
approximately 12 inches. The “close-to-ceil-
ing” installation reduces the distance from
the ceiling to the bottom of the fan blades to
approximately 8 inches.
Once you have decided which ceiling
installation you will use, proceed with the
following instructions. Where necessary,
Turn Canopy Ring to Remove
Figure 5
Figure 7
2. Remove the mounting plate from the canopy
by loosening the four screws on the top of
the canopy. Remove the two non-slotted
screws and loosen the slotted screws. This
will enable you to remove the mounting
plate (Figure 6).
3. Route the wires exiting the top of the fan
motor through the decorative motor collar
cover then the canopy ring. Make sure the
slot openings are on top. Route the wires
through the canopy and then through the
ball/downrod assembly (Figure 7).
Tighten
Screws
Pin in
Locked
Position
Locking
Pin
Hanger Pin
Motor Collar
Cover
Downrod/Ball
Assembly
Canopy Ring
Canopy
Motor Wires
Hook
Ceiling
Mounting
Plate
Mounting Screws
(Supplied With
Outlet Box)
UL Listed
Outlet Box
Slide Mounting
Plate Over
Screw Heads
120V Wires
WHEN MOUNTING THE FAN ON A SLOPED
CEILING, THE STANDARD BALL/DOWNROD
MOUNTING METHOD MUST BE USED. THE
MOUNTING PLATE MUST BE MOUNTED SO
THAT THE SLOT OPENINGS ARE ON THE
LOWER SIDE BY SLIDING THE MOUNTING
PLATE FROM THE TOP DOWN. FOR A GREATER
MOUNTING ANGLE, REMOVE THE DECORA-
TIVE CANOPY BOTTOM COVER (FIGURE 8).
Remove
Loosen But
Do Not Remove
Figure 6

4. Loosen, but do not remove, the set screws
on the collar on the top of the motor
housing.
5. Align the holes at the bottom of the down-
rod with holes in the collar on top of the
motor housing (Figure 7). Carefully insert
the hanger pin through the holes in the col-
lar and downrod. Be careful not to jam the
pin against the wiring inside the downrod.
Insert the locking pin through the hole near
the end of hanger pin until it snaps into its
locked position as noted in the circle inset
of Figure 7.
6. Retighten the set screws on the collar on top
of the motor housing.
7. Proceed to “Installing the Fan” section.
5.
“Close-to-Ceiling” Mounting
1. Remove the canopy ring from the canopy
by turning the ring to the right until it
unlocks (Figure 5).
2. Remove the mounting plate from the cano-
py by loosening the four screws on the top
of the canopy. Remove the two non-slotted
screws and loosen the slotted screws. This
will enable you to remove the mounting
plate (Figure 6).
FAILURE TO COMPLETELY TIGHTEN THE
THREE SCREWS IN STEP 7 COULD RESULT IN
THE FAN LOOSENING AND POSSIBLY FALLING.
FAILURE TO PROPERLY INSTALL THE SET
SCREWS AS NOTED IN STEP 6 COULD RESULT
IN FAN LOOSENING AND POSSIBLY FALLING.
Figure 8
Canopy
Bottom
Cover
Figure 9
Figure 10
Motor
Collar
Screw and
Lockwasher
(3 of 6 screws)
Collar
Screw and
Lockwasher
(3 Screws)
Ceiling
Canopy Canopy
Ring
Rubber
Gasket
3. Remove the decorative canopy bottom cov-
er from the canopy by depressing the three
studs (Figure 8).
4. Remove three of the six screws and lock-
washers (every other one) securing the mo-
tor collar to the top of the fan motor housing
(Figure 9).
5. Place the rubber gasket over the remaining
three screws, route the wires exiting the top
of the fan motor through the canopy ring
(make sure the slot opening are on top),
then proceed to place the ceiling canopy
over the collar at the top of the motor.
(Figure 10).
6. Align the mounting holes with the holes in
the motor and fasten, using the three screws
and lock-washers removed in step 4 (Figure
10).
7. Tighten the mounting screws securely.

6.
Making the Electrical
Connections
REMEMBER to disconnect the power. If
you feel you do not have enough electrical
wiring knowledge or experience, have your fan
installed by a licensed electrician.
NOTE: See Operating Your Remote Control on
Page 11 for details, or follow the instructions
packed with the receiver.
Follow the steps below to connect the fan
to your household wiring. Use the wire
connecting nuts supplied with your fan. Se-
cure the connectors with electrical tape.
Make sure there are no loose strands or
connections (Figure 12).
1. Using supplied wire nut, connect the
green ground wire from the downrod and
the green ground wire from the mounting
plate to the ground household supply wire
(Figure 12).
2. Using supplied wire nut, connect the fan
supply (black) wire to the black household
supply wire (Figure 12).
3. Using supplied wire nut, connect the fan
neutral (white) wire to the white neutral
household supply wire (Figure 12).
4. After connecting the wires, spread them
apart so that the green and white wires are
on one side of the outlet box and the black
wire is on the other side.
Figure 11
Installing Fan to
the Outlet Box
1. Pass the 120-volt supply wires through the
center hole in the ceiling mounting plate as
shown in Figure 7.
2. Install the ceiling mounting plate on the out-
let box by sliding the mounting plate over
the two screws provided with the outlet box
(Figure 7). When using close-to-ceiling
mounting, it is important that the mount-
ing plate be level. If necessary, use leveling
washers (not included) between the mount-
ing plate and the outlet box. Note that the
at side of the mounting plate is toward the
outlet box (Figure 7).
3. Securely tighten the two mounting screws.
4. Carefully lift the assembly up to the ceil-
ing mounting plate. If using close-to-ceil-
ing mounting, hang the fan on the hook
provided by utilizing one of the holes at
the outer rim of the ceiling canopy (Fig-
ure 11). If using standard mounting, seat
WHEN MOUNTING THE FAN ON A SLOPED
CEILING, THE STANDARD BALL/DOWNROD
MOUNTING METHOD MUST BE USED. THE
MOUNTING PLATE MUST BE MOUNTED SO
THAT THE SLOT OPENINGS ARE ON THE
LOWER SIDE BY SLIDING THE MOUNTING
PLATE FROM THE TOP DOWN.
the hanger ball in the mounting plate
socket. Make sure the tab on the mount-
ing plate socket is properly seated in
the groove in the hanger ball.
WHEN USING THE STANDARD BALL/DOWN-
ROD MOUNTING, THE TAB IN THE RING AT THE
BOTTOM OF THE MOUNTING BRACKET MUST
REST IN THE GROOVE OF THE HANGER BALL.
FAILURE TO PROPERLY SEAT THE TAB IN THE
GROOVE COULD CAUSE DAMAGE TO WIRING.
THE HOOK AS SHOWN IN FIGURE 11 IS ONLY
TO BALANCE FAN WHILE ATTACHING WIRING.
FAILURE TO HANG AS SHOWN IN FIGURE 11
MAY RESULT IN HOOK BREAKING, CAUSING
THE FAN TO FALL. HOOK MUST PASS FROM
INSIDE TO OUTSIDE OF CANOPY.

7.
EACH WIRE NUT (WIRE CONNECTOR) SUP-
PLIED WITH THIS FAN IS DESIGNED TO ACCEPT
UP TO ONE 12 GAUGE HOUSE WIRE AND TWO
WIRES FROM THE FAN. IF YOU HAVE LARGER
THAN 12 GAUGE HOUSE WIRING OR MORE
THAN ONE HOUSE WIRE TO CONNECT TO THE
FAN WIRING, CONSULT AN ELECTRICIAN FOR
THE PROPER SIZE WIRE NUTS TO USE.
Black (Motor) White (Neutral)
Green (Ground)
Outlet Box
Fan
Black (Hot) White (Neutral)
Figure 12
Finishing the Fan
Installation
STANDARD CEILING MOUNTING
1. Align the locking slots of the ceiling canopy
with the two screws in the mounting plate.
Push up to engage the slots and turn clock-
wise to lock in place. Immediately tighten
the two mounting screws rmly.
2. Install the remaining two mounting
screws into the holes in the canopy and
tighten rmly.
3. Install the decorative canopy ring by
aligning the ring’s slots with the screws
in the canopy. Rotate the ring counter-
clockwise to lock in place.
4. You may now proceed to attaching the
fan blades.
CLOSE-TO-CEILING MOUNTING
1. Carefully unhook the fan from the mount-
ing bracket and align the locking slots of
the ceiling canopy with the two screws in
the mounting plate. Push up to engage the
slots and turn clockwise to lock in place.
Immediately tighten the two mounting
screws rmly.
WHEN USING THE STANDARD BALL/DOWN-
ROD MOUNTING, THE TAB IN THE RING AT
THE BOTTOM OF THE MOUNTING PLATE MUST
REST IN THE GROOVE OF THE HANGER BALL.
FAILURE TO PROPERLY SEAT THE TAB IN THE
GROOVE COULD CAUSE DAMAGE TO WIRING. LOCKING SLOTS OF CEILING CANOPY ARE
PROVIDED ONLY AS AN AID TO MOUNTING.
DO NOT LEAVE FAN ASSEMBLY UNATTENDED
UNTIL ALL FOUR CANOPY SCREWS ARE EN-
GAGED AND FIRMLY TIGHTENED.
2. Install the remaining two mounting screws
into the holes in the canopy and tighten
rmly.
3. Install the decorative canopy ring by align-
ing the ring’s slots with the screws in the
canopy. Rotate the ring counter-clockwise
to lock in place.
4. You may now proceed to attaching the fan
blades.
Attaching the
Fan Blades
1. Attach blade to blade bracket using the
screws supplied (Figure 13). Start a screw
into the bracket. Repeat for the two remain-
ing screws.
2. Tighten each screw securely.
3. Insert the blade/blade bracket assembly
through the hole in the side of the center y-
wheel, align the 2 screw holes in the blade
bracket with the screw holes in the center
ywheel and secure with screws and lock-
washers supplied (Figure 14).
4. Repeat steps 1-3 for the remaining blades.
5. Turn the wires upward and push the wires
into the outlet box.

8.
Screws Blade
Blade Bracket
Flywheel
Blade
Blade Bracket
Screws
Lockwashers
Figure 13
Figure 14
Figure 15
BLADE BALANCING
All blades are grouped by weight. Because nat-
ural woods vary in density, the fan may wobble
even though the blades are weight matched.
TO REDUCE THE RISK OF PERSONAL INJURY,
DO NOT BEND THE BLADE HOLDERS WHILE
INSTALLING, BALANCING THE BLADES, OR
CLEANING THE FAN. DO NOT INSERT FOREIGN
OBJECTS BETWEEN ROTATING BLADES.
Installing the Light Kit
and Glass Bowl
CAUTION - To reduce the risk of electrical
shock, disconnect the electrical supply circuit
to the fan before installing light kit.
1. Loosen, but do not remove, three of the
four mounting screws on the black bracket
below the fan motor assembly; remove the
other mounting screw (Figure 16).
Lower Housing
Mounting Screw
Mounting
Screw
Red
White
Figure 16
The following procedure should correct most
fan wobble. Check after each step.
1. Check that all blade and blade brackets are
secure.
2. Most fan wobble problems are caused when
blade levels are unequal. Check this level
by selecting a point on the ceiling above
the tip of one of the blades. Measure from
a point on the center of each blade to the
point on the ceiling. Measure this distance
as shown in Figure 15. Rotate the fan until
the next blade is positioned for measure-
ment. Repeat for each blade. Measurement
deviations should be within 1/8”. Run the
fan for 10 minutes.
3. Use the enclosed Bladed Balancing Kit if
the blade wobble is still noticeable.
