HAMPTON BAY SF103-18H User manual

USE AND CARE GUIDE
ELECTRIC FIREPLACE INSERT
C US
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING!
IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY,
AN ELECTRICAL SHOCK OR FIRE MAY RESULT
CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
IMPORTANT INSTRUCTIONS
PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE
20-10-326 2018-04-20
Model # SF103-18H
Item # 1003132247
# 1003054957
# 1003063474
# 1003063475
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday - Friday
855-HD-HAMPTON HAMPTONBAY.COM
THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this electric log insert. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home
improvement needs. Thank you for choosing Hampton Bay!

2
Table of Contents
Table of Contents....................................2
Safety Information...................................3
Warranty ..........................................6
What is covered ...................................6
What is not covered................................6
Pre-Installation .....................................7
Installation.........................................9
Operation.........................................10
Maintenance ......................................11
Care and Cleaning ..................................12
Troubleshooting....................................13
Service Parts ......................................14
IMPORTANT: Read all instructions and warnings carefully before starting installation.
Failure to follow these instructions may result in a possible electric shock, injury to persons, re hazard and will void the warranty.
Please read the Installation & Operating Instructions before using this appliance.
PRODUCT DAMAGE MAY OCCUR.
Never attempt to disassemble or alter the product in any way not instructed by this manual.
CAUTION

3
HAMPTONBAY.COM
Please contact 855-HD-HAMPTON for further assistance.
Safety Information
Please read and understand this entire manual before attempting to assemble, operate or install the product.
□Read all instructions before using this appliance.
□This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this
appliance. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 ft. (914 mm) from
the front of this appliance and keep them away from the sides and rear.
CAUTION: Extreme caution is necessary when any heater
is used by or near children or invalids and whenever the
heater is left operating unattended.
□If possible, always unplug this appliance when not in use.
□Do not operate any heater with a damaged cord or plug or after the appliance malfunctions, has been dropped or damaged in any
manner.
□Any repairs to this appliance should be carried out by a qualied service person.
□Under no circumstances should this appliance be modied. Parts having to be removed for servicing must be replaced prior to
operating this appliance again.
□Do not use outdoors.
□This heater is not intended for use in bathrooms, laundry areas and similar indoor locations. Never place this appliance where it
may fall into a bathtub or other water container.
□Do not run the cord under carpeting. Do not cover the cord with throw rugs, runners or the like. Arrange the cord away from trafc
areas and where it will not be tripped over.
□To disconnect this appliance, turn the controls to the off position, then remove the plug from the outlet.
□Connect to properly grounded outlets only.
□This appliance, when installed, must be electrically grounded in accordance with local codes, with the current CSA C22.1 Canadian
Electrical codes or for USA installations, follow local codes and the National Electric Code, ANSI/NFPA No. 70.
□Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause an electric shock, re, or
damage to the appliance.
□To prevent possible re, do not block air intakes or exhaust in any manner. Do not use on soft surfaces, like a bed, where
openings may become blocked.
□This appliance has hot and arcing or sparking parts inside. Do not use it in areas where gasoline, paint, or ammable liquids are
used or stored. This appliance should not be used as a drying rack for clothing, nor should Christmas stockings or decorations be
hung on or near it.
□Use this appliance only as described in this manual. Any other use not recommended by the manufacturer may cause re, electric
shock, or injury to persons.
□Avoid the use of an extension cord because of the risk of overheating the cord and the risk of re. Extension cords are for temporary
use only. If an extension cord must be used, it must be UL/CSA certied, rated at 15A (875W), 125V maximum with 14 AWG
minimum and constructed of two carrying conductors with ground. A heavy duty extension cord with the shortest length possible
for the connection is recommended and must not be longer that 50 ft. (15.2 m). Do not coil or cover the extension cord.
□“SAVE THESE INSTRUCTIONS FOR FUTURE USE”

4
Safety Information (continued)
WARNING: Electrical outlet wiring must comply with local
building codes and other applicable regulations to reduce
the risk of re, electrical shock and injury to persons.
WARNING: Do not use this replace if any part of it has
been under water. Immediately call a qualied service
technician to inspect the replace and replace any part of
the electrical system which has been under water.
ELECTRICAL CONNECTION
DANGER
A 15-Amp, 120-Volt, 60 Hz circuit with a properly grounded outlet is required. Preferably, the item will be on a
dedicated circuit, as other appliances on the same circuit may cause the circuit breaker to trip or the fuse to blow
when the heater is in operation. The unit comes standard with a 6 ft. (1.8 m) long three wire cord, exiting the right side
of the item. Plan the installation to avoid the use of an extension cord. Extension cords are for temporary use only. If an
extension cord must be used, it must be UL/CSA certied, rated at 15A (1875W), 125V maximum with 14 AWG minimum
and constructed of two current carrying conductors with ground. A heavy duty extension cord with the shortest length
possible for the connection is recommended and must not be longer than 50 ft. (15.2 m). Do not coil or cover the
extension cord.
POLARIZED PLUG
This product is equipped with a polarized plug (one blade is wider than the other blade). To reduce the risk of electrical
shock, this plug will fit into a polarized outlet only one way. This is a safety feature. If you are unable to insert the plug into
the electrical outlet, try reversing the plug. If the plug still does not fit, contact a qualified electrician.

5
REMOTE CONTROL
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modications to this unit not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This Product can expose you to chemicals including Di(2-ethylhexyl)
phthalate (DEHP) which is known to the State of California to cause
cancer and developmental harm.
For more information go to www.p65Warnings.ca.gov
WARNING
DO NOT mix old and new batteries.
DO NOT use rechargeable silver oxide cell batteries with remote control unit.
DO NOT mix alkaline, standard (Carbon-Zinc), or rechargeable (Nickel-Cadmium) batteries.
DO NOT dispose of batteries in re. Improper disposal may cause batteries to leak or explode.
Safety Information (continued)
HAMPTONBAY.COM
Please contact 855-HD-HAMPTON for further assistance.
WARNING
