HAMPTON BAY 151-115-7D-V2-NF User manual

THANK YOU
USE AND CARE GUIDE
TOBAGO 7 PIECE WOVEN DINING SET - BARE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
HAMPTONBAY.COM
Item # 661 244
Model #151-115-7D-V2-NF
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
this 7 piece set. We strive
(1-pair Fully Woven Rocking Dining Chairs)

2
Table of Contents
Safety Information
DANGER: Please keep children out of the assembly area
during assembly.
IMPORTANT: Please check the tightness of bolts
periodically.
Warranty
Table of Contents.......................................................
Safety Information......................................................
Warranty .....................................................................
2 Year Frame and Weave Limited Warranty............
Pre-Assembly............................................................
Planning Assembly......................................................
Hardware Included.....................................................
Package Contents .....................................................
Assembly .................................................................
What Is Covered...........................................................
What Is Not Covered......................................................
2
2
2
2
2
2
3
3
3
4
5
2 YEAR FRAME AND WEAVE LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. Treat frame with one-step liquid wax for maximum protection against
UV light and salty, damp air. When not in use, store furniture in a cool, dry place. If your set includes cushions or mesh fabric, they may
be cleaned by hand with a mild solution of soap and water. Rinse cushion thoroughly and allow to drip dry. Do not machine wash or
tumble dry, as cushions may shrink. Do not use bleach or solvents on fabrics.
You may contact our customer service department with any questions by phone at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
Care Instructions...... ................................................ 2
Care Instructions
We warrant the frame and weave to be free of manufacturing defects to the original purchaser for two years.
..............

3 HAMPTONBAY.COM
Pre-Assembly
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA Bolt (M8x42) 8
BB Nut 8
CC Lock washer 8
DD Washer 8
EE
Washer plate
8
AA BB CC DD
EE
Please contact 1-855-HD-HAMPTON for further assistance.
PLANNING ASSEMBLY
It will take two people about 20 minutes to complete the assembly process.
FF GG HH
FF
GG
HH
Bolt cap
Nut cap
Spanner
16
16
2

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A2
B2
C
2
B
C
Seat and back
Seat pad
Chair base
A

5 HAMPTONBAY.COM
Assembly
1 Attaching the seat and back to the chair base
□
□
Attach the seat and back (B) to the chair base (A) from below the U-bar (A-1) with the bolts (AA) and one washer plate (EE) (see Fig. 1),
and above the U-bar (A-1) with one washer plate (EE), washers (DD), lock washers (CC) and nuts (BB) (see Fig. 2) using spanners (HH).
Please contact 1-855-HD-HAMPTON for further assistance.
IMPORTANT: Hand tighten bolts (AA) only. Do not fully
Place the chair base (A) upside down on a flat, smooth surface.
tighten bolts (AA) until the end of Step 2.
Fig. 2
A
EE
AA
BB
CC
DD
B
A
B
Fig. 1
EE
A-1
NOTE: You may need to loosen preinstalled bolts to allow for
proper alignment of the steel plates on Seat (B) and Base (A).

6
Assembly
2 Attaching the seat and back to the chair base (continued)
□
At the U-bar (B1) attach the chair base (A) to the seat and back (B) from under the U-bar (B-1) with bolts (AA), washer plate (EE) (see Fig. 3),
and with washer plate (EE), washers (DD), lock washers (CC) and nuts (BB) (see Fig. 4) using spanners (HH).
B-1
Fig. 3
EE
AA
BB
CC
DD
A
B
EE
Fig. 4
□Fully tighten all the bolts (AA) and nuts (BB).

Cover all the bolts (AA) and pre-installed bolts with bolt caps (FF).
Assembly
3 Attaching the bolt caps
4
□
□Place the seat pad (C) on the chair.
Placing the seat pad on the chair
7 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
□
Cover all the nuts (BB) and pre-installed nuts with nut caps (GG).
C
□Repeat step 1~4 for the other chair.
IMPORTANT: Please tie the hook and loops to the small
bar (1a) underneath the seat panel. Do not try to tie the hook
and loops to rear legs (1b) or other tubes (1c).
1a 1b
1c
FF
GG
AA
BB

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. – 6.00 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
