HAMPTON BAY FCS60610R-ST User manual

THANK YOU
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
CRESTRIDGE 7PC DINING SET
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Item #1004 441 320
Model #FCS60610R-ST

2
Table of Contents
Table of Contents............................... . . . . . 2
Important Safety Instructions....................... . . . 2
What is covered ................................... 3
What is not covered ............................. . . . 3
Warranty ............................... . . . . . . . . . . . 3
Pre-Assembly................................. . . . . . . 3
Planning Assembly ........................... . . . . . . 3
Hardware Included ........................... . . . . . . 4
Chair Package Contents . ......................... . . . 4
Table Package Contents . ......................... . . . 5
Care and Cleaning ............................... ....9
Chair Assembly. . . . . . ............................. . . .
Table Assembly. . . . . . ............................. . . .
6
8
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: THIS SET WAS MADE FOR THE EXPLICIT PURPOSE OF PROVIDING OUTDOOR FUNCTIONS AND IS NOT TO BE USED AS A TOY.
THIS PRODUCT IS INTENDED FOR NORMAL OUTDOOR USE. HOWEVER, THE MANUFACTURER RECOMMENDS STORING AND/OR COVERING THIS
PRODUCT WHEN ANY FORMIDABLE/SEVERE WEATHER IS APPROACHING.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
WARNING: DO NOT LOCATE THIS PRODUCT NEAR OPEN FLAMES. DO NOT USE THIS PRODUCT AS A SUPPORT. DO NOT SHAKE, LEAN OR CLIMB
ON THE PRODUCT. CHILDREN UNDER THE AGE OF 10, NEAR THE PRODUCT, SHOULD BE SUPERVISED BY A COMPETENT ADULT AT ALL TIMES.
THIS PRODUCT IS NOT INTENDED FOR COMMERCIAL USE AND WILL VOID THE WARRANTY.
WARNING: This table unit is heavy, and may require two
adults for safe assembly.
WARNING: Do not place heavy objects on the table.
WARNING: This chair unit is heavy, and may require two
adults for safe assembly.
WARNING: Never use this product as a support. Do not
shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the chair.
WARNING: Weight limit for the chair is 250 lbs (113.39 Kg)
for each seat.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a
cool and covered location.
CAUTION: Do not locate the product near any heat
sources.
1. Close supervision is necessary when this furnishing is used by
or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while it is occupied. Failure
to obey this caution could result in injury.
Save These Instructions .............................
Read All Instructions Before Use.......................
2
2
This table is not intended to support an umbrella. Umbrellas must
have a suitable base or stand.
4.

Pre-assembly
PLANNING ASSEMBLY
NOTE:
Warranty
YEAR FRAME AND 2 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
three
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
comercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.

Pre-assembly (continued)
HARDWARE INCLUDED
NOTE:
CHAIR PACKAGE CONTENTS
Part Description Quantity
M6x15 Combination Bolt
M6x30 Combination Bolt
38+2
24+1
AA
BB
M6x25 Bolt 12+1
CC
M6x25 Combination Bolt 2+1
DD
M8x30 Combination Bolt 12+1
EE
Hex Wrench 2
FF
Part Description Quantity
FF

Pre-assembly (continued)
TABLEPACKAGE CONTENTS
Part
Description Quantity

Chair Assembly
1
2
Attach the sling bucket (A) to the right arm (B) using M6x30 combination
bolts (BB) and an M8x30 combination bolt (EE), as shown below.
Attach the connector bar (D) to the right arm
(B) using M6x15 combination bolts (AA).
Insert the support bar (E) into the right arm (B).
Do not tighten all bolts at this step.
Attach the sling bucket (A) to the left arm (C) using M6x30 combination
bolts (BB) and an M8x30 combination bolt (EE), as shown below.
Attach the connector bar (D) to the left arm (C)
using M6x15 combination bolts (AA).
Insert the support bar (E) into the left arm (C).
Do not tighten all bolts at this step.
ABB
BB
B
E
AA EE
AA
D
EE AA AA
C
BB
BB
D
E

Chair Assembly (continued)
3
4Once all of the bolts are in place, fully tighten
all the bolts using the hex wrench (FF).

Table Assembly
1
2The
Attach the table legs (G) and the support tubes (H) to the table rim (F)
g(DD).

Table Assembly (continued)
3
Care Care and Cleaning
Do not clean with abrasive materials, bleach or solvents.
,
the bolts using the hex wrench (FF).

For certification use only
Factory Chair ID: FCS60610R
Factory Table ID: FTS61215
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
