HAMPTON BAY HDP00007 User manual

THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this light xture. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
STRATTON 3 LIGHT SEMI-FLUSH
Item # 1005 889 664
Model # HDP00007
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Safety Information .................................. 2
Warranty .......................................... 2
Pre-Installation ..................................... 3
Planning Installation ............................... 3
Tools Required .................................... 3
Hardware Included................................. 3
Package Contents ................................. 4
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation ....................................5, 6, 7
Care and Cleaning .................................. 7
Troubleshooting .................................... 7
Safety Information
□Consult a qualied electrician with any electrical questions
you may have. IMPORTANT: Inspect the wire insulation for any cuts,
abrasions, or exposed copper that may have occurred
during shipping. If there is a defect in the wire, do not
continue the assembly process. Please call our Customer
Service Team at 1-855-HD-HAMPTON.
Warranty
3-YEAR LIMITED WARRANTY
WHAT IS COVERED
The manufacturer warrants this lighting xture to be free from defects in the materials and workmanship for a period of three (3) years
from date of purchase. This warranty applies only to the original consumer purchaser and only to products used in normal use. If this
product is found to be defective, the manufacturer’s only obligation, and your exclusive remedy, is the repair or replacement of the
product at the manufacturer’s discretion, provided that the product has not been damaged through misuse, abuse, accident, modications,
alterations, neglect or mishandling. This warranty shall not apply to any product that is found to have been improperly installed, assembled,
or used in any way not in accordance with the instructions supplied with the product. This warranty shall not apply to a failure of the
product as a result of an accident, misuse, abuse, negligence, alteration, faulty installation, or any other failure not relating to faulty material
or workmanship.
WHAT IS NOT COVERED
This warranty shall not apply to the nish on any portion of the product due to weathering, as this is considered normal wear. The
manufacturer does not warrant and specically disclaims any warranty, whether expressed or implied, other than the warranty contained
herein. The manufacturer specically disclaims any liability and shall not be liable for any consequential or incidental loss or damage,
including but not limited to, any labor or expense costs involved in the replacement or repair of the product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.

3 HAMPTONBAY.COM
Pre-Installation
PLANNING INSTALLATION
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. Inspect each part for defects that
may have occurred during shipping. Keep your receipt and these instructions for proof of purchase.
TOOLS REQUIRED
Safety
goggles
Phillips
screwdriver
Flathead
screwdriver
Pliers
Wire
strippers
Wire
cutters
Ladder Electrical
tape
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA BB CC DD EE FF GG
Part Description Quantity
AA Wire nut 3
BB Cross bar 1
CC Outlet box screw 2
DD Lock nut 3
EE Ground screw 1
FF Nipple 1
GG Finial 1
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE: This light xture requires the use of three 120V, 60Hz,
60-Watt max., medium-base type S21 (ST64) bulbs (included).
Do not exceed the recommended wattage.

4
Pre-Installation (continued)
PACKAGE CONTENTS
Part Description Quantity
A
A
B
C
D
B
C
D
Fixture body
3
1
Arm
1
Column assembly
3
Bulb

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
A
A
B
B
C
DD
BB
FF
C
Hook
Hook
Loop
Loop
1
2
3
4
5
Assembly Installation
1
Assembling the light fixture
□Carefully unpack the xture, lay out all parts on clean
surface.
This xture can be assembled up or down.
Pull the excess cord through the arm (B).
Pull the excess cord through top of the canopy assembly (A).
Attach the hooks of arms (B) to the loops of canopy
assembly (A).
Attach the other hooks of arms (B) to the loops of the xture
body (C).
□
□
□
□
1
Installing the cross bar
DANGER: Ensure the power is off at the main fuse box
prior to beginning installation.
□
□
□
Turn off the switch at the wall.
Turn the power off at the main fuse box.
Install the cross bar (BB) with nipple (FF) and lock nuts (DD) to
the outlet box using two outlet box screws (CC).
CC

6
Installation (continued)
3
Hanging the light fixture
□Push all excess wires into the outlet box.
□Raise the canopy (A) to the ceiling and secure in
place by screwing the lock nut (DD) onto the nipple (FF),
and then screw the nial (GG) to end of the nipple (FF).
House wire
black
(or red, or blue)
(HOT)
House wire
white
(NEUTRAL)
Fixture wire
smooth
(HOT)
Fixture wire
ribbed
(NEUTRAL)
Fixture wire
ground wire
(GROUND)
Ribbed line
House wire
green
(or bare wire,
or green & yellow)
(GROUND)
Install the xture bare copper ground wire (1) under the
ground screw (EE) on the cross bar (BB).
Connect the xture bare copper ground wire (1) to the green
(or bare, or green & yellow) supply ground wire (2) in the
outlet box using a wire nut (AA).
Connect the ribbed xture wire (3) to the white supply wire
(4) in the outlet box using a wire nut (AA).
Connect the smooth xture wire (5) to the black (or red, or
blue) supply wire (6) in the outlet box using a wire nut (AA).
2
Connecting the wires
□
□
□
□
6
4
3
2
EE
AA
5
BB
FF
A
DD
GG
1

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
7
4
Assembling the bulbs
□
□
Prior to installing the bulbs, inspect sockets for silica
packet. If packet is present, then remove and throw
away. Do not expose it to children or pets.
Install three 120V, 60Hz, 60-Watt medium-base type S21 (ST64)
bulbs (D) (included) into the sockets of the light xture.
Installation (continued)
Care and Cleaning
Troubleshooting
□Clean the light xture with a soft, dry cloth. Do not use any cleaners with chemicals, solvents, or harsh abrasives.r
Problem Possible Cause Solution
The bulb will not light. □The bulb is burned out. □Replace the light bulb.
□The power is off. □Ensure that the power supply is turned on.
□There is a faulty wire connection. □Check the wiring.
□The circuit breaker is off. □Ensure that the circuit breaker is set in the
on position.
The fuse blows or a circuit breaker
trips when the light is turned on.
□There is an exposed wire.
□There are too many items on one circuit.
□Discontinue use of the light xture.
Unplug other items on the circuit.
r
□Contact a qualied electrician or
call the Customer Service Team at
1-855-HD-HAMPTON.
□
Socket
D

Retain this manual for future use.
