HAMPTON BAY PN68351C User manual

LISMORE SUN LOUNGER
Item # XXXXXXXXXX
Model # PN68351C
THANK YOU
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this lounger. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!

2
THREE YEAR FRAME AND TWO YEAR SLING LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HAMPTONBAY.com.
READ ALL INSTRUCTIONS BEFORE USE
SAVE THESE INSTRUCTIONS
Table of Contents ............................................................................2
Important Safety Instructions .......................................................2
Warranty .........................................................................................2
3 Year Frame and 2 Year Sling Limited Warranty.................2
What Is Covered ...................................................................2
What Is Not Covered ............................................................2
Care & Cleaning ..............................................................................2
Pre-Assembly ............................................................................3
Planning Assembly...................................................................3
Hardware Included...................................................................3
Package Contents ...................................................................4
Assembly ....................................................................................5
Operation ....................................................................................7
We warrant the frame to be free of manufacturing defects to the original purchaser three years and sling fabric for two years.
Table of Contents
Important Safety Instructions
WARNING: Please keep your fingers clear while switching
positions of the chaise lounge back.
IMPORTANT: Please check the tightness of the bolts
periodically.
Warranty
When using a furnishing, basic precautions should always be followed, including the following:
Read all the instructions before using this furnishing.
To reduce the risk of injury to persons:
a) Close supervision is necessary when this furnishing is used by or near children, or disabled persons, if applicable.
b) Use this furnishing only for its intended use as described in these instructions.
Do not use attachments not recommended by the manufacturer.
c ) Do not move the chaise while it is occupied. Failure to obey this caution could result in injury.
Care & Cleaning
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. Treat the frame with one-step liquid wax for maximum protection
against UV light and salty, damp air. When not in use, store the furniture in a cool, dry place.

3
PLANNING ASSEMBLY
HARDWARE INCLUDED
It will take two people about 30 minutes to complete the assembly process.
AA BB CC DD
EE
AA Bolt (M6×20)
Plain washer (6.5x18×1)
Cap (Ø17.9×4.7)
16
16
CC 2
DD 2
Sleeve nut (M6×62)
Wheel (Ø99×25)
EE
FF
2
FF GG HH
LL
MM NN 00 PP
JJ KK
II
Plain washer (Ø10.5x18×5) 2
GG 2
HH
4
Bolt (M8×18)
Bushing bolt ((M6×30), (Ø6.2xØ10x11))
Support piece (Ø21×35)
Plain washer (8.5x18×1)
Plain washer (Ø12.5x25×3)
Hex wrench (4×98)
Hex wrench (5×58)
II
4
JJ
KK
LL
MM
NN
OO
PP
Headless-bolt (M6×45)
Cap (Ø18×4.2)
Sleeve nut (M6×20) 2
2
2
2
2
1
4
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
Part Description Quantity
BB
NOTE: Hardware is not shown to actual size.

4
PACKAGE CONTENTS
AB
C D
EF
G
Pre-Assembly(continued)
Part Description Quantity
A
Back panel
1
B
Left armrest 1
C
1
D
Leg frame
E
2F
Seat panel 1
Right armrest
Cross bar
1
1G Cross bar

5
1Attaching the leg frame to the seat panel
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
2 3
Attaching the first wheel Attaching the cap
□
4Attaching the second wheel
Attach the seat panel (B) to the leg frame (A) with the bolts (AA) and the plain washers (BB) using the hex wrench (OO),
and make sure it is on a flat surface.
Attach one wheel (EE) to the right armrest (C) with
a sleeve nut (DD), a plain washer (FF), a headless-bolt (GG)
and a sleeve nut (HH) using the hex wrench (OO).
Attach one wheel (EE) to the left armrest (D) with a sleeve
nut (HH), a headless-bolt (GG), a plain washer (FF) and
a sleeve nut (DD) using the hex wrench (OO).
□
□Cover the wheel by hand with the cap (CC).
5Attaching the cap
□Cover the wheel by hand with the cap (CC).
□
Assembly
x 2 x 4
x 2 x 4
AA
BB
DD
EE FF GG
HH
CC
HHGG FF
EE DD
OO
OO
OO
OO
D
C
8x
100%
100%
100%
AB
CC
OO

Assembly (continued)
6
6Attaching the armrests, the seat panel and the back panel
□
□
□
Attach the left armrest (D) and the right armrest (C) to the seat panel (B) with the bolts (JJ) and the plain washers (KK).
Attach the left armrest (D) and the right armrest (C) to the back panel (E) with the plain washers (NN).
Hand tighten only.
7Attaching the cross bars to the armrests
□
□
□
Attach the assembled frame to the cross bars (F) with the bolts (AA) and the plain washers (BB).
Attach the assembled frame to the cross bar (G) with the bushing bolts (LL).
Hand tighten only.
EJJKK
D
C
NN
LL
BB AA
G
F
4x
80%
80%
80%
2x
2x
B
8x

Assembly (continued)
Operation
1Using the lounger
□
7HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
WARNING:
Never try to move the lounger when it is occupied.
NOTE:
You can lock the back onto the cross bar (G) in three different positions.
Before using, confirm the back is firmly locked in place.
OO
II
OO
PP
8Tightening the bolts and caps
□
□
To make sure the lounge will be level, make any necessary adjustments before tightening all the bolts with the wrenches (OO) (PP).
Cover all the bolts by hand with the bolt caps (II).
100%
100%
100%
4x
2x
8x
4x
G

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
