HAMPTON BAY ANSELMO D6051-7PC User manual

Item #
Model # D6051-7PC
THANK YOU
USE AND CARE GUIDE
ANSELMO 7-PIECE DINING SET
Questions, problems, missing parts? Before returning to the store call
Hampton Bay Customer Service
8 a.m. - 6 p.m., EST, Monday-Friday
1-877-527-0313
HAMPTONBAY.COM
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this dining set. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Hampton Bay!
554-936

2
Table of Contents
Table of Contents..........................................................2
Warranty.........................................................................2
Pre-Assembly ................................................................2
Planning for Successful Assembly...........................................2
Hardware Included...................................................................3
Sling Swivel Dining Chair Package Contents...........................4
Sling Dining Chair Package Contents.......................................5
Table Package Contents ..........................................................6
Swivel Chair Assembly................................................. 7
Dining Chair Assembly................................................. 8
Table Assembly............................................................. 9
Care and Cleaning ...................................................... 11
Warranty
1 YEAR FRAME / 1 YEAR FABRIC AND TABLE TOP WARRANTY
We warrant the frame, fabric and tabletop to be free of manufacturing defects to the original purchaser for one year and the fabric for one
year.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-877-527-0313 or visit www.hamptonbay.com.
Pre-Assembly
PLANNING FOR SUCCESSFUL ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-
abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
complete the assembly of this product.

Pre-Assembly (continued)
HARDWARE INCLUDED
3 HAMPTONBAY.COM
Please contact 1-877-527-0313 for further assistance.
NOTE: Hardware not shown to actual size.
Part Description Quantity
A
A
M8 x 23 Hex bolt 8
BB M6 x 15 Hex bolt 30
CC M6 x 25 Hex bolt 24
DD M8 nut 8
EE M6 washe
r
54
FF M8 washe
r
8
GG Hex wrench 1
HH Open wrench 2
BB CC EE FF
GG HH
DDAA

4
Pre-Assembly (continued)
SLING SWIVEL DINING CHAIR PACKAGE CONTENTS
B
D
A
C
Part Description Quantity
A
Chair back 2
B Chair base 2
C Chair seat 2
D Stem bracket 2

Pre-Assembly (continued)
SLING DINING CHAIR PACKAGE CONTENTS
5 HAMPTONBAY.COM
Please contact 1-877-527-0313 for further assistance.
E
F
Part Description Quantity
E Chair back 4
F Chair seat 4

6
Pre-Assembly (continued)
TABLE PACKAGE CONTENTS
M
L
G
K
J
H
Part Description Quantity
G Table rim 1
H Table leg 4
J Leg connector 2
K Table brace 1
L Table glass 4
M Stone top 1

Swivel Chair Assembly
1Connecting the chair seat to the
stem bracket 2Connecting the chair base to the chair seat
□Place the seat (C), upside down on a flat surface, align the
arrows on the seat (C) and stem bracket (D) so they are
facing in the same direction.
□Attach the stem bracket (D) to the seat (C) by inserting bolts
(AA) and washers (FF) and nuts (DD) and using the Hex
wrench (GG).
NOTE: The arrow labels on the seat (C) and stem bracket (D)
must be facing in the same direction to ensure proper
assembly.
□Place the base (B) on a flat surface and align the stem
under the seat (C) with the hole on the base (B).
□Push down firmly to lock the seat (C) and base (B)
together.
B
C
D
FF
C
DD
A
A
7 HAMPTONBAY.COM
Please contact 1-877-527-0313 for further assistance.

8
Swivel Chair Assembly (continued)
3Connecting the chair seat to the
chair back
□Attach the chair back
(
A
) to the seat C) by inserting bolts
(
CC
)
and washers (EE) through the holes on the left side of the
seat (C) and back (A), and using the Hex wrench (GG) to
tighten.
□Repeat this step for the right side.
A
CC
EE
C
NOTE: Repeat steps 1-3 for the remaining chair.
Dining Chair Assembly
1Connecting the chair seat to the
chair back
□Place the chair back (E) to the seat (F) by inserting bolts
(
CC
)
and washers (EE) through the holes on the back (E), left and
right side of the seat.
□Use the Hex wrench (HH) to tighten.
NOTE: Repeat step 1 for the remaining chairs.
CC
E
F
EE

Table Assembly
1Connecting the table legs 2Connecting the leg connector to
the table legs
□Remove the table glass (L) and stone top (M) and set both
in a safe place and in a vertical position until the table is
completely assembled.
□Turn the table rim (G) upside down and place on a at
surface.
□Attach the table legs (H) to the table rim (G) by inserting
bolts (BB) and washers (EE) through the pre-drilled holes in
the table rim (G) and into the table legs (H).
NOTE: Hand tighten the bolts only. Do not fully tighten.
□Attach the leg connector (J) to the table legs (H) by
inserting bolts (BB) with washers (EE) through the pre-
drilled holes in the leg connector (J) and into the table
legs (H).
9 HAMPTONBAY.COM
Please contact 1-877-527-0313 for further assistance.
H
J
BB
EE
BB
H
G
EE

10
Table Assembly (continued)
3Connecting the table brace to leg
connectors and table top 4Placing the table glass and stone top on the table rim
□Attach the table brace (K) to the leg connector (J) and table
rim (G) using the bolts (BB) and washers (EE).
□Tighten all bolts (BB) using the hex wrench (HH).
NOTE: Tighten each bolt a few turns at a time, alternating
between bolts in a cross-corner pattern (X). This ensures that
the table is level by placing equal amounts of pressure on all
bolt joints. Do not overtighten the bolts.
□Turn the table over so it is right side up.
□Carefully place the table glass (L) into the table rim (G).
□Carefully place the stone top (M) into the table rim (G).
BB
EE
K
G
J
BB
EE
M
L
G
