HAMPTON BAY Beacon Park FRS80937A-BA User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this chair. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
BEACON PARK 2-PACK CAPTAIN DINING CHAIR - BARE
Model # FRS80937A-BA
Item # 1003 955 289
1003 955 024
FRS80937AG-BA

2
Table of Contents
Table of Contents..........................................................2 Pre-Assembly ................................................................3
Planning Assembly .................................................................. 3
Hardware Included ................................................................
Package Contents ..................................................................
3
4
Assembly ........................................................................5
Care and Cleaning ....................................................... 9
WARNING: Do not place heavy objects on the chair.
WARNING: This chair unit is heavy, and may require
two adults for safe assembly.
CAUTION: Do not locate the product near any
heat source.
!
WARNING: Weight limit is 300 lbs (136.07 Kg) for each
chair.
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This chair was made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this product
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this product only for its intended use as described in
these instructions. Do not use attachments not recommended by
the manufacturer.
3. Do not move the chair while the chair is occupied. Failure
to obey this caution could result in injury.
4. Do not rock in the chair as you may fall and cause serious injury.
5. Please keep children outof the assembly area before assembly.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
AA
CC
BB
Part Description Quantity
M6x20 combination bolt 12+1
AA
M6x50 combination bolt
8+1
BB
Hex wrench 1
CC
Warranty
WHAT IS NOT COVERED
Contact the Customer Service Tea
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
m at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
3 YEAR FRAME LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for three years.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
Right arm 2
A
Left arm 2
B
Seat 2
C
Back 2
D
Seat cushion 2
E
B
C
D
E
A

1
l
5
Assembly
Attach the seat (C) to the left arm (B) using M6x20 combination bolts (AA).
Do not fully tighten all the bolts at this step.
CONNECTING THE SEAT TO THE LEFT ARM
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
B
C
AA
NOTE: Loosely tighten all bolts using the hex wrench (CC).

2
l
6
Assembly (continued)
Attach the seat (C) to the back (D) using M6x50 combination bolts (BB).
Attach the left arm (B) to the back (D) using an M6x20 combination bolt (AA).
Do not fully tighten all the bolts at this step.
CONNECTING THE SEAT AND THE LEFT ARM TO THE BACK
AA
BB
B
C
D
NOTE: Loosely tighten all bolts using the hex wrench (CC).

3
l
7
Assembly (continued)
CONNECTING THE SEAT AND THE BACK TO THE RIGHT ARM
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
Attach the seat (C) to the right arm (A) using M6x20 combination bolts (AA).
Attach the back (D) to the right arm (A) using an M6x20 combination bolt (AA).
Do not fully tighten all the bolts at this step.
AA
AA
A
B
D
C
NOTE: Loosely tighten all bolts using the hex wrench (CC).

8
4
l
Assembly (continued)
CONNECTING THE ARMS TO THE BACK
Connect the arms (A & B) to the back (D) using M6x50 combination bolts (BB).
Do not fully tighten the bolts at this step.
BB
D
A
B

Care and Cleaning
For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Keep the chair away from fire, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Store the chair in a dry, sheltered place when not in use.
Do not clean with abrasive materials, bleach, or solvents.
9
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance
5
l
Assembly (continued)
TIGHTENING THEBOLTS
Once all of the bolts are in place, fully tighten the bolts using the hex wrench (CC).
Place the seat cushion (E) to finish the assembly of the chair.
Ensure all connections are secure before use.
E

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Retain this manual for future use.
1-855-HD-HAMPTON
HAMPTONBAY.COM
Factory chair ID # FRS80937A
