HAMPTON BAY D11034-7PC-R User manual

Model #D11034-7PC-R
THANK YOU
USE AND CARE GUIDE
FALL RIVER 7PC DINING SET
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this dining set. We strive to
continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your
home improvement needs. Thank you for choosing Hampton Bay!
YOW sku # 587 608 / 587 610
HAMPTONBAY.COM
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday
9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON

Table of Contents
Table of Contents
Safety Information
Warranty
Pre-installation
Planning Installation
........................................................ 3
Table Package Contents
Assembly
Care and Cleaning
Safety Information
WARNING: Do not sit or stand on the table top.
WARNING: Do not place heavy items on the table top.
WARNING: An umbrella base must be used at all times.
Warranty
2 YEAR FRAME AND FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frame and fabric to be free of Manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer's responsibility for freight and packaging charges to and from our service center.
This warranty does not cover commercial use, hardware, acts of nature, fire, freezing and abusive use.
In addition, purchased parts are not covered under this warranty. We reserve the right to make substitutions
with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
Umbrella should not be used in the event of wind, rain, hail,
sleet, snow or any other inclement weather.
2
Dining Chair Package Contents
Swivel Dining Chair Package Contents
What is Not Covered
What is Covered
............................................2
............................................2
..........................................................2
...... .................................................2
.................................................3
...............................................3
.................................................2
............................................................7
............................................4
...............................5
.....................6
...........................................10
Hardware Included ................................................... 3
Tools Required
THIS IS A RESIDENTIAL WARRANTY AND DOES NOT APPLY FOR COMMERCIAL USE.
For a copy of our full limited warranty, please contact our customer service team below.

Pre-installation
PLANNING INSTALLATION
PLEASE READ COMPLETE INSTRUCTION MANUAL PRIOR TO ASSEMBLY!
Identify all parts packed in the carton against the parts list. Remove all protective
materials and place the parts on a nonabrasive surface to avoid scratching.
NOTE: More than one person may be required to
complete the assembly of this product.
HARDWARE INCLUDED
NOTE: Tools not shown to actual size.
AA
3
BB
CC DD
FF GG
Allen Wrench (Incl uded) Hex Wrench (Incl uded) Socket Wrench (Incl uded)
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
TOOLS REQUIRED
Part Description Quantity
AA M6*35 He x bolt 24
12
8
12
BB
CC
DD
EE 56
44
12
M6 Hex bo lt cap
FF
GG
M6 Socket hex bo lt cap
M6*25 Socket hex bolt
M6*20 Hex bolt
M6*15 Hex bolt
Washer
EE

Pre-installation (continued)
TABLE PACKAGE CONTENTS
Part Description
B
C
A
Quantity
A
B
C
4
4
1
1
Table leg
Connector ring
Table top

DINING CHAIR PACKAGE CONTENTS
Part Description Quantity
D Seat frame
E Lumbar pillow
F Seat cushion
5
4
4
4
D
J
E
J Arm 8
F
Pre-installation (continued)
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

SWIVEL DINING CHAIR PACKAGE CONTENTS
6
E
F
J
G
H
Part Description Quantity
F Seat cushion
G
H Base 2
2
2
I Stem bracket 2
E Lumbar pillow 2
I
Pre-installation (continued)
J Arm 4
Seat frame

Assembly
Attaching the table legs Attaching the connector ring
□Place the table top (A ) on a soft, flat non-abrasive
surface. Attach the table legs (C) to the table top (A)
using the hex bolts (DD) and washers (EE).
NOTE: Do not fully tighten the bolts.
Attach the connector ring (B) to the table legs (C) using hex
bolts (DD) and washers (EE). Tighten all bolts. Then cover
bolt heads with covers (FF).
□
2
DD
EE
1
A
DD EE
FF
7
Positioning the table
□Turn the table over and set it down on its legs.
The table is now ready for use.
3
B
C
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE: Please ensure all the bolts are assembled
correctly and use the socket wrench to tighten.
C
□

□Attach the back of the arm (J) to the seat frame (D)
using a washer (EE) and socket hex bolt (BB) .
NOTE: Do not fully tighten the bolts.
4
8
EE BB
GG
AA
EE
J
E
F
□Ensure all bolts are aligned and assembled correctly.
5Adding the bolt caps and cushions
Assembly (continued)
Attaching the arms
□Attach the front of the arm (J) to the seat frame (D)
using washers (EE) and hex bolts (AA).
□Repeat these instructions to attach the other arms
to the seat frames.
FF
□Tighten all socket hex bolts (BB) with the allen wrench.
Attach the socket hex bolt caps (GG).
□Tighten all hex bolts (AA) with the hex wrench.
Attach the hex bolt caps (FF).
□Place the seat cushion (F) and lumbar pillow (E) onto
the chairs.

Attaching the arms Attaching the stem bracket
□Place the seat frame (G) on a soft , flat non-abrasive
surface.
Attach the back of the arm (J) to the seat frame (G)
using a washer (EE) and socket hex bolt (BB).
Attach the front of arm (J) to the seat frame (G) using
washers (EE) and hex bolts(AA).
□
Attach the stem bracket (I) to the seat frame (G) using the
washers (EE) and hex bolts (CC) .
Ensure all bolts are aligned and assembled correctly.
□
7 6
9
E
F
CC
EE
FF
JG
EE BB GG
AA
EE
FF
I
H
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
□
Connecting the base and seat
Place the base (H) on a flat surface and align the stem
under the seat frame (G) with the hole on the base. Push
down firmly to lock the seat frame (G) and base (H) together.
□
8 Adding the seat cushions
Place the seat cushions (F) and lumbar pillows (E) onto the chairs.
□
9
Ensure all bolts are aligned and assembled correctly.
Tighten all socket hex bolts (BB) with the allen
wrench. Attach the socket hex bolt caps (GG).
Tighten all hex bolts (AA) with the hex wrench.
Attach the hex bolt caps (FF).
Repeat these instructions to attach the other
arms to the seat frames.
□
□
Assembly (continued)
Tighten all hex bolts (CC) with the hex wrench.
Attach the hex bolt caps (FF).
□
G
G

Care and Cleaning
Do not allow water to build up in frames. This will cause corrosion and possible freezing damage in cold climates. .
□Use a mild soap and water for normal cleaning. DO NOT use janitorial or alcohol based cleaners. Some cleaners may be
□Rinse with clean water and dry with a soft, absorbent cloth towel.
□Treat frames with a liquid wax for maximum protection against UV rays and/or salty, damp air.
□
marked as natural, but some ingredients may cause discoloration or have an adverse reaction to your finish.
10

Retain this manual for future use.
