HAMPTON BAY FCS80198CST User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item #1001 845 561
Model #FCS80198CST
USE AND CARE GUIDE
BELLEVILLE 7-PIECE C-SPRING DINING SET
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Questions, problems, missing parts? Before returning to the store,

2
Table of Contents
Table of Contents..........................................................2
Warranty.........................................................................2
What is Covered.......................................................................2
What is Not Covered ................................................................2
Pre-Assembly
Planning Assembly
Hardware Included
Chair Package Contents
Chair Assembly
Care and Cleaning
Warranty
2 YEAR FRAME AND 2 YEAR LIMITED FABRIC WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for two years, and a two year limited warranty for the fabric.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
commercial use, hardware, acts of nature, fire, freezing, and abusive use. In addition, purchased parts are not covered under this warranty.
We reserve the right to make substitutions with similar mercha
stretching of sling material that may occur over two years time under normal usage.
ndise, if the model in question is no longer in production. We do not cover
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft,
non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
complete the assembly of this product.
HARWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA M6x20 combination bolt
BB
CC
12+1
32+1
M6x30 combination bolt
M6x25 bolt 12+1
DD M6x15 combination bolt 8+1
Table Package Contents ...........................................................4
TableAssembly
........................................................9
............................................................ 7
............................................................ 5
...........................................................3
...................................................................2
...................................................................2
.................................................................2
Part Description Quantity
EE Hex wrench 3

HAMPTONBAY.COM3
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly (continued)
CHAIR PACKAGE CONTENTS
Part Description Quantity
A
Chair back 6
B
Right arm 6
C
Left arm 6
D
Back bar 6
A
C
B
D

4
Pre-Assembly (continued)
TABLE PACKAGE CONTENTS
Part Description Quantity
E
Tile 15
F
Stamped metal 1
G
Table rim 1
H
Leg connector 1
E
G
I
H
ITable leg 4
F

Chair Assembly
1
Connecting the chair back to the chair arms
Attach the chair back (A) to the right arm (B) using M6x20 combination bolts (AA) and M6x30 combination bolts (BB), as shown below.
Place the back bar (D) into the right arm (B).
Repeat this step for the left arm (C).
HAMPTONBAY.COM5
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE: Loosely tighten all bolts using the hex wrench (EE).

6
Chair Assembly (continued)
2
Securing the back bar
Attach the back bar (D) to the chair arms (B and C) using the M6x25 bolts (CC).
Tighten all of the bolts. Check and ensure the chair is tightly assembled and stable before use.
CC
B
D
C

Table Assembly
1
Connecting the table legs
Place the table rim (G) upside down on a soft surface.
Attach each of the table legs (I) to the table rim (G) with M6x20 Combination bolts (AA).
HAMPTONBAY.COM7
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE: Loosely tighten all bolts using the hex wrench (EE).

Table Assembly (continued)
2
Connecting the leg connector to the table legs
Align the holes of the leg connector (H) with the holes on the inside of each table leg (I).
Attach the leg connector (H) to the table legs (I) using M6x15 combination bolts (DD).
8
NOTE: Tighten all bolts using the hex wrench (EE).

Table Assembly (continued)
3
Adding the tiles
Turn the table right side up.
Ensure all connections are secure.
Carefully place the tiles (E) and stamped metal (F) onto the table rim (G).
NOTE: The stamped metal (F) can be replaced by the
tile (E) if desired.
FE
9
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
For best results, clean the frames with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that
may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the set in a dry, sheltered place when not in use.
ng conditions, and inclement weather such as rain, hail, sleet, snow, or wind.

call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
NOTPMAH-DH-558-1
HAMPTONBAY.COM
Retain this manual for future use.
Questions, problems, missing parts? Before returning to the store,
