HAMPTON BAY Barclay DQ546O User manual

Item # 1003517979
1003369652
Model # DQ546O
USE AND CARE GUIDE
Barclay 4PC Steel Conversation Set (Single Chair)
THANK YOU
Thank you for choosing Hampton Bay!
y through the purchase of this conversation set.We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs .
Questions, problems, missing parts? Before returning to the store
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Table of Contents
Table of Contents..........................................................2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Important Safety Instructions.......................................2
Save These Instructions ....... ........... ...................................... 2
Read All Instructions Before Use ............................................. 2
Pre-Assembly-Single Chair 3..........................................
Planning Assembly .................................................................. 3
Care and Cleaning-Single Chair....................................8
...5...............................................riahCelgniS-ylbmessA
stnetnoCegakcaP ....................................................................4
Hardware Included .................................................................. 3
Important Safety Instructions
When using a furnishing, basic precautions should always be followed,
including the following:
To reduce the risk of injury to persons:
a) Close supervision is necessary when this furnishing is used by,
or near children, or disabled persons.
b) Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
WARNING: Never use this product as a support. Do not shake, lean, or climb on the product at any time.
WARNING: Do not place heavy objects on the product.
CAUTION: Do not locate the product near any
heat source.
!
CAUTION: When not in use, secure the product in a
! cool and covered location.
This Single chair was made for the explicit purpose of providing outdoor
functions and is not to be used as a toy. This product is not intended for
inclement / severe weather in any form including, but not limited to: rain,
hail, sleet, snow and / or wind. The manufacturer recommends storing and
/ or covering this conversation set when formidable weather is approaching.
Do not locate the product near open flames. Children under the age of 10, near
the product, should be supervised by a competent adult at all times. This
product is NOT intended for commercial use and will void the warranty.
Warranty
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.HamptonBay.com.
2
YEAR LIMITED WA
RRANTY
WHAT IS COVERED
We warrant the single chair to be free of manufacturing defects to the original purchaser for two years.
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We

CC
3
Pre-Assem - Single Chairylb
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED - SINGLE CHAIR
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Part
Description
Quantity
AA
Bolt M6* 15
2
Quantity
BB
Bolt M6*35
Washer
6
DD
8
Hex Wrench 1
BB
AA
NOTE: Hardware not shown to actual size.
DD
CC

4
Pre-Assembly (continued)
Part
Description
Quantity
Right A
B
A
C
D
r tserm 1
B
A
Left Ar tserm 1
C
Back
1
PACKAGE CONTENTS
D Seat 1

1
l
5
Assembly-Single Chair
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Attaching the right armrest and left armrest to the seat
Attach the right armrest (A) using bolts (BB) and washers (CC). Loosely tighten using hex wrench (DD).
Repeat for the left armrest.
CC BB
B
A
D

2
l
6
Assembly (continued)
Attaching the back
Attach the back (C) to the seat (D) using bolts (BB) and washers (CC). Loosely tighten using the hex wrench (DD).
C
A
C
D
CC BB
B

l
7
Assembly (continued)
3Attaching the back (Continued)
Attaching the back (C) to the seat (D) using bolts (AA) and washers (CC). Loosely tighten using the hex wrench (DD).
C
CCAA
D
A
B

l
8
Assembly (continued)
4Checking the single chair
Fully tighten all bolts.
Ensure all connections are secure before use.
For best results, clean the chair with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt particles that
may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the chair in a dry, sheltered place when not in use.
Keep the chair away from , extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
Care and Cleaning-Single chair

Questions, problems, missing parts?Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
