HAMPTON BAY RTA699T User manual

THANK YOU
y through the purchase of this dining set. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
Item #:1003368601
Model #: RTA699T
USE AND CARE GUIDE
South Grove 5pc Cushion Firepit Set
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
HAMPTONBAY.COM
1-855-HD-HAMPTON

2
Warranty ........................................................................2
What is Covered ...................................................................... 2
What is Not Covered ................................................................ 2
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Warranty
Safety Informat oni
Safety Information .......................................................2
ProductCaution .................................................................... 2
Safety Warnings .................................................................... 2
Pre-Assembly ................................................................3
ChairPackageContents ....................................................... ... 4
Chair Assembly............................................................. 5
Care and Cleaning........................................................ 8
Table of Contents
Table of Contents..... .......... .............................. ............2
3 YEAR FRAME AND 3 YEAR FABRIC LIMITED WARRANTY
WHAT IS COVERED
We warrant the frames to be free of manufacturing defects to the original purchaser for 3 year.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.homedepot.com
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We
reserve theright to make substitutions with similar merchandise, if the model in question is no longer in production.
PRODUCT CAUTION
This set was made for the explicit purpose ofproviding outdoor functions and is not to be used as a toy. This productis intended fornormal
outdoor use; however, the manufacturer recommends storing and / or covering this set when any formidable/ severe weather is approaching.
hildren under
the age of 10, near the product, should be supervised by a competent adult at all times.
READ ALL INSTRUCTIONS BEFORE USE
WARNING: Weight limit for the chairs is 250 lb (113.39 kg)
for each seat.
WARNING: Do not place heavy objects on the chair.
WARNING: Please keep children out of the assembly
area before assembly.
CAUTION: When not in use, secure the product in a cool
and covered location.
!
To reduce the risk of injury to persons:
1. Close supervision is necessary when this furnishing is used
by or near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in
these instructions. Do not use attachments not recommended
by the manufacturer.

3
Pre-Assembly
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware notshown to actual size.
AA M6x14 BOLT 4+1
BB
CC
HH
AA
Part
Description Quantity
4+1
M8x1.25 JAM NUT
II
1 4 mm ALLEN KEY WRENCH
JJ
1 6 mm ALLEN KEY WRENCH
KK
1 10 & 13 mm ALLEN KEY WRENCH
4+1
4+1
M6x25 BOLT
M8x40 BOLT
DD
4+1
EE
8+1
d6.5xD13x1.0 WASHER
FF
2
d8.5xD17x1.6 WASHER
GG
2
50x50x4 WASHER
50x24x4 WASHER
BB CC DD EE
FF GG HH II JJ
KK
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

Part Description Quantity
A Seat Assembly 1
2
1
B Arm
C
1D
Base Assembly
1
E
Back Cushion
Seat Cushion
A
B
D
E
4
Pre-Assembly (continued)
CHAIR PACKAGE CONTENTS
C
B

5
Chair Assembly
1Connecting the chair arm to the chair seat assembly
Place the seat assembly (A) onto a non-abrasive surface, such as a carpet.
Fasten the arms (B) to the seat assembly (A) by using M6x25 bolts (BB) and d6.5xD13x1.0 washers (DD).
B
A
B
Loosely tighten all of the bolts using the hex wrench (II).NOTE:
BB
DD
DD BB
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

BB
A
l
6
Chair Assembly (continued)
2Connecting the chair arm to the chair seat assembly
Fasten the arms (B) to the seat assembly (A) by using M6x14 bolts (AA).
AA
AA
Loosely tighten all of the bolts using the hex wrench (JJ).NOTE:

l
7
Chair Assembly (continued)
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
3Connecting the chair base assembly to the chair support frame
Fasten the base assembly (C) to the ssat assembly (A) by using M8x40 bolts (CC), d8.5xD17x1.6 washers
(EE) , 50X24X4 washers (FF),50x50x4 washers (GG), M8x1.25 jam nuts (HH).
C
A
2 ) The labels marked “Front” on the base assembly ( C ) should
coincide with step 3 to ensure proper assembly.
1 ) Loosely tighten all of the bolts using hex wrenches (JJ and KK).NOTE:
CC
CC
EE
EE
GG
GG
FF FF
EE EE
HH HH
Front
Front
Front

l
8
Chair Assembly (continued)
4Tightening the bolts
Place cushions (E and F) onto the chair.
Once all of the bolts are in place, fully tighten the bolts.
Ensure all connections are secure before use.
D
E
Care and Cleaning
For best results, clean the set with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the set in a dry, sheltered place when not in use.
Keep the set away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet,
snow, or wind.

Retain this manual for future use.
