HAMPTON BAY 1000 000 000 User manual

THANK YOU
We appreciate the trust and condence you have placed in Hampton Bay through the purchase of this gazebo. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank
you for choosing Hampton Bay!
Item #1000 000 000
Model #XXXXXXX
USE AND CARE GUIDE
HOLDEN 10X10 HARD TOP GALVANIZED STEEL GAZEBO
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2
Table of Contents
Table of Contents..........................................................2
Safety Information.........................................................2
Warranty.........................................................................2
What is Covered .......................................................................2
What is Not Covered ................................................................2
Pre-installation ..............................................................3
Planning Installation ................................................................3
Tools required ..........................................................................3
Hardware Included...................................................................3
Package Contents ....................................................................4
Operation ....................................................................... 7
Care and Maintenance ............................................... 17
Service Parts ............................................................... 18
Model Type ............................................................................18
Safety Information
1.
2.
DANGER: This unit is heavy! Do not assemble this
WARNING: Do not leave the gazebo where there is a risk
CAUTION: Do not climb on top of the gazebo. Falling off
the gazebo can result in serious injury, possibly even death.
Warranty
Warning
WHAT IS NOT COVERED
We do not reimburse for transportation costs. This warranty does not cover the damage caused by commercial use, acts of nature,
re, freezing, and abusive use. Discoloration or fading of the nish or fabrics as a result of chemicals or spills is not covered.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www. Hamptonbay.com.
SET UP YOUR GAZEBO PROPERLY
口This unit is heavy. Do not assemble this item alone. 4 people are
recommended for safe assembly.
口Please read and understand this entire manual before attempting
to assemble, operate, or install the product.
口Keep all children, pets and other obstructions away from
assembly area.
口If any part is missing or damaged, do not attempt to assemble
the product.
口In order to avoid damage to the gazebo and its components
please use appropriate tools.
口Do not use the structure as support.
口Check all bolts on a regular basis to maintain the solidity of
the structure.
口Keep instructions for future use.
EXAMINE YOUR GAZEBO
口Examine occasionally to ensure there are no loose parts.
If loose parts are found, they should be retightened immediately.
2 YEAR WARRANTY FOR FRAME, 1YEAR WARRANTY FOR FABRIC
WHAT IS COVERED
We provide warranty to the original purchase for 2 year for frame and 1 year for fabric from the date of purchase, and the fabric and
frame will be replaced at no charge due to manufacturing defects.
Warning......................................................................2
of high wind, as possible damage will occur to the structure.
item alone.
WARNING: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC.
This tent meets the ammability requirements of CPAI-84. The fabric may burn if left in continuous contact with any ame source.
The application of any foreign substance to the tent fabric may render the ame-resistant properties ineffective.

3 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-installation
PLANNING INSTALLATION
NOTE: Tools and protective articles below
are not provided.
TOOLS REQUIRED
Safety goggles
Screwdriver
Level
HARDWAREINCLUDED
NOTE: Hardware not shown to actual size.
Part
Description
Quantity
AA
Bolt\Flat Washer (M6*15)
184
BB
Bolt\Plastic Washer (M6*25)
16
CC
Bolt\Plastic Washer (M6*35)
16
DD
Bolt\Flat Washer\Nut (M6*53)
4
EE
EE
Blot (M6*15)
32
FF Hanger 40
GG
Stake
16
HH
Fast Wrench
1
II
Allen Wrench
2
JJ
Wrench
1
To prevent damage, place all parts on a soft surface during assembly.
Tools required for assembly (not included): Allen wrench (included), hammer, screwdriver,stepladder, level
and other safety items such as gloves, safety goggles and hardhat.
Hammer Gloves Stepladder
Hardhat
AA
FF GG HH II JJ
BB CC DD EE

4
Pre-installation (continued)
PACKAGE CONTENTS
AI2
B
J
K
L1
L2
L3
L4
M1
M2
M3
M4
N1
N2
O1
O2
C
D1
D2
E
F
F1
G1
G2
H1
H2
I1

5
Pre-installation (continued)
PACKAGE CONTENTS
P1
T1
P2
T2
U
V
W
X
Q1
Q2
Q3
R
S1
S2

6
Pre-installation (continued)
PACKAGE CONTENTS
Part
Description
Quantity
A
Post
4
B
4
C
Base
4
D1
Left Lintel
4
D2
Right Lintel
4
E
Connector
8
F
Lintel Cover
4
F1
Corner Connector
4
G1
Connector 4
G2
Top Connector
4
H1
Left Support Bar
4
H2
Right Support Bar
4
I1
Long Top Bar
4
I2 Short Top Bar 4
J
Big Top Connector
1
K
Small Top Bar
4
L1
Center Connector
1
L2
Small Top Cover
1
L3
Finial 1
L4
Hook
1
M1
#1 Roof Borders
4
Part
Description
Quantity
M2
#2 Roof Borders
4
M3
#3 Roof Borders
4
M4
Short Bar Connector
4
N1
#1 Roof Supports
4
N2
#2 Roof Supports
4
O1
#3 Roof Supports
4
O2
#4 Roof Supports
4
P1
Connector
4
P2 Sliding Tube 8
Q1
Small Top Roof Cover
4
Q2
Big Top Panel Cover
4
Q3
Connector
4
R
Small Top Panel
4
S1
#1 Roof Panel 4
S2
#5 Roof Panel
4
T1
#2 Roof Panel
4
T2
#4 Roof Panel
4
U
#3 Roof Panel
4
V Air Vent 1
W
Mosquito Net
4
X
Spacer
16
Base Cover

A
A
B
C
AA
AA
B
D2
D2
D1
D1
E
EF
F
7 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation
1
Installing the Post
□Insert the Base Cover (B) into Post (A), attach Post (A) to
the Base (C) with Bolt (AA).
2
Inserting the Lintel
□Insert the Right Lintel (D2) into the Lintel Cover (F), insert the
Connector (E) into the Lintel (D2/D1).
NOTE: Please take note of the direction of lintel cover and
Lintel (D1/D2).

A
EE EE
A
A
A
A
D1
D1
D1 D1
D1
D2
D2
D2
D2
D2
D1
D1
D1
D2
D2
G1
G1
D2
AA AA
FF
F
AA AA
8 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
3
Installing the Lintel and Connector
□Connect the Lintel (D1/D2) with the Connector (E) by bolt
(AA), at the same time, connect the Connector (G1) and
the Connector (E) by Bolt (AA) in the upper side.
4
Installing the Lintel and Post
□Attach the Right Lintel (D2) and the Left Lintel (D1) to Post (A) by
Bolt (EE).
NOTE: Please take note of Connector’s direction.

A
A
A
D1
D1
D2
D2
D2
D1
AA AA
AA
A
A
D1
D1
F1
D1
D2
D2
D2
A
A
A
A
H2
H2
H1
H1
9 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
5
Installing the Support Bar
□Attach the Left Support Bar (H1) to the Left Lintel (D1) and Post (A)
by Bolt (AA); attach the Right Support Bar (H2) to the Right Lintel
(D2) and Post (A) by Bolt (AA).
6
Installing the Corner Connector and Lintel
□Attach the Corner Connector (F1) to the Lintel (D1/D2) by Bolt (AA).

AA
AA
G2
G2
I1
I1
I1
10 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
7
Installing the Top Connector and Long Top Bar
□Attach the Top Connector (G2) to the Long Top Bar (I1) by Bolt (AA).
8
Installing the Long Top Bar
□Attach the Long Top Bar (I1) to the Big Top Connector (J) by
Bolt (AA).
Attach the Top Connector (G2) located below the Long Top Bar (I1) to
Post (A) by Bolt (AA).
□
Connect the other corners in the same way.
□
J
AA
AA
AA
AA
A
A
J
I1 I1
I1
I1
I1
G2
A

AA
AA
I2
I2
I2
I2
D1
D1
AA
D2
D2
G1
P1
J
J
I2
K
K
K
DD
DD
L4
K
K
KL1
L1
L4
11 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
9
Installing the Short Top Bar
□Attach the Short Top Bar (I2) to the Big Top Connector (J) by
Bolt (AA).
Connect the Connector (P1) and Connector (G1) to the end of Short
TOP Bar (l2) by Bolt (AA).
□
Connect other sides in the same way.
□
10
Installing the Center Connector and Small Top Bar
□Screw the Hook (L4) to the Center Connector (L1).
□Connect the Small Top Bar (K) with the Center Connector (L1)
by bolts (DD).

K
J
I1
M3
M3
M3
R
R
R
AA AA
AA
KM3
M3
K
AA
12 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
11
Installing the Small Top Bar and Big Top Connector
□Attach the Small Top Bar (K) to the Big Top Connector (J)
by Bolt (AA).
12
Installing the Small Top Panel and Roof Border
□Attach the Small Top Panel (R) to the Small Top Bar (K) by Bolt
(AA). Assemble the others In the same way.
Attach #3 Roof Borders (M3) to the edge of the roof as shown by Bolt (AA).
□
NOTE: To avoid destroying the nish, please handle
it with care.

N1
O1 O2
N2
CC
Q1
Q1
Q1
K
L3
L3
L2
L2
N1/O1 N2/O2
AA
AA
AA
I2 I2
I1 I1
AA
13 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
13
□Attach the Small Top Roof Cover (Q1) to the Small Top Bar (K)
by Bolt (CC).
□Attach the Small Top Cover (L2) to the Center Connector (L1)
by Finial (L3).
14
Installing the Roof Supports
Installing the Small Top Center and Small Top Cover
□Attach #1 Roof Supports (N1) to the Long Top Bar (I1) and the
Short Top Bar (I2) by Bolt (AA). Attach #2 Roof Supports (N2)
to the Short Top Bar (I2) and the Long Top Bar (I1) by Bolt
(AA). Attach #3 Roof Supports (O1) and #4 Roof Supports (O2)
to the Long Top Bar (I1) and the Short Top Bar (I2) in the same
way.
NOTE: To avoid destroying the nish, please handle
it with care.
NOTE: To avoid destroying the nish, please handle
it with care.

Note: Don't tighten
the screws firstly
untill all roof borders
are installed.
Assembled by 2 persons
NOTE: Don't tighten the screws rstly untill all roof borders
are installed.
P2
P2
P2 AA
I1
I2
P1
P2
AA AA M1
M2
M2
M4
U
U
S2
S2
S1
S1 T1
T1
T2
BB
BB
XO1/O2
BB
S1
M1
14 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
15
Installing the Sliding Tube
□Insert one end of the Sliding Tube (P2) into the Connector (P1),
attach the other end of the Sliding Tube (P2) to the Long Top
Bar (l1) by Bolt (AA).
16
Installing the Big Top Panel
□
□
□
□
□
□
Install the Roof Panels starting from left to right. Slide #1 Roof Panel
(S1) into position. Then overlap #2 Roof Panel (T1) as shown and slide
it into position. Attach #1 Roof Panel (S1) and #2 Roof Panel (T1) to
#3 Roof Supports (O1) by Bolt (BB) and Spacer (X).
Slide #3 Roof Panel (U) into position. Attach #3 Roof Panel (U) and #2
Roof Panel (T1) to #3 Roof Supports (O1) by Bolt (BB) and Spacer (X).
Slide #4 Roof Panel (T2) into position. Attach #4 Roof Panel (T2) and #3
Roof Panel (U) to #4 Roof Supports (O2) by Bolt (BB) and Spacer (X).
Slide #5 Roof Panel (S2) into position. Attach #5 Roof Panel (S2) and
#4 Roof Panel (T2) to #4 Roof Supports (O2) by Bolt (BB) and Spacer (X).
Repeat on each side.
Tighten all bolts (BB).
Attach #1 Roof Borders (M1) and #2 Roof Borders (M2) to the edge of the
roof as shown witha Bolt (AA). Attach the Short Bar Connector (M4) as
shown with Bolt (AA).
●Assembled by 2 persons.
●Make sure each screw installed on this step is attached to
a Spacer (X).
●Do not tighten the screws until all roof panels nish
installation. If tighten them from the beginning, you will
not be able to install all the roof panels properly.
NOTE: To avoid destroying the nish, please handle
it with care.

CC
CC
Q2
I1
Q3
15 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
17
Installing the Big Top Cover and Connector
□Attach the Big Top Panel Cover (Q2) to the Long Top Bar (I1) by
Bolt (CC).
□Attach the Connector (Q3) to the Big Top Connector (J) by Bolt (AA).
18
Installing the Small Air Vent
□Put the Air Vent (V) inside of the frame and attach the Air Vent (V)
to the Long Top Bar by using the velcro straps.
AA
J
Fig 26
S2
KV
NOTE: To avoid destroying the nish, please handle
it with care.

16 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Operation (continued)
19
Installing the Mosquito Net and Fixing the Gazebo
Hang the Mosquito Net (W) onto the Sliding Tube (P2) by
Plastic Ring (FF).
□
□
Adjust position of gazebo and anchor posts to the ground by inserting
the Stakes (GG) into each hole in each Base Plate.
FF
P2
W
A
B
GG

17
Care and Maintenance
□ For cleaning, use a mild detergent solution, rinse with water, and allow to air dry.
Do not use acetone, abrasive, or other special detergents as they would be harmful to
the product’ s nish.
□ Due to the nature of steel, surface oxidation (rusting) will occur if this protective coating
is scratched. This is a natural process. To minimize this condition, it is recommended
that care be taken when assembling and handling the product in order to prevent the
paint from being scratched.

18 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Service Parts
MODEL TYPE
AA
FF
BB
CC
DD
EE
Part
Description
Quantity
AA
Bolt\Flat Washer (M6*15)
2
BB
Bolt\Plastic Washer (M6*25)
2
CC
Bolt\Plastic Washer (M6*35)
2
DD
Bolt\Flat Washer\Nut (M6*53)
1
EE
EE
Blot (M6*15)
2
FF Hanger 2

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
