HAMPTON BAY FRS50421U-ST-1 User manual

Item # 1001 073 619
Model #
FRS50421U-ST-1
Questions,problems,missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
THANK YOU
We appreciate the trust and con dence you have placed in Hampton Bay through the purchase of this table. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing Hampton Bay!
USE AND CARE GUIDE
FRANKLIN ESTATES KD 5-PIECE DINING SET-TABLE

2
Table of Contents
Planning Assembly .................................................................. 3
Hardware Included .................................................................. 3
Care and Cleaning.......................................................... 8
5
4
WARNING: This table unit is heavy, and may require
two adults for safe assembly.
CAUTION: When not in use, secure the product in a cool
and covered location.
!
CAUTION: Do not place heavy objects on the table top.
!
Table of Contents..........................................................2 Pre-Assembly ................................................................ 3
Package Contents
Assembly
..................................................................
..................................................................
Important Safety Instructions ................................... 2
Save These Instructions ........................................................2
Read All Instructions Before Use .............................................. 2
Warranty .........................................................................3
What is Covered .......................................................................3
What is Not Covered .................................................................3
Important Safety Instructions
SAVE THESE INSTRUCTIONS
WARNING: This table was made for the explicit purpose of providing outdoor functions and is not to be used as a toy.
This product is intended for normal outdoor use; however, the manufacturer recommends storing and / or covering this set
when any formidable / severe weather is approaching.
W
product. Children under the age of 10, near the product, should be supervised by a competent adult at all times. This product is
NOT intended for commercial use and will void the warranty.
READ ALL INSTRUCTIONS BEFORE USE
!
CAUTION: Do not locate the product near
any heat source.
Please keep children out of the assembly area before assembly.
To reduce the risk of injury to persons:
1. Close supervision is necessary when this product is used by or
near children, or disabled persons, if applicable.
2. Use this furnishing only for its intended use as described in these
instructions. Do not use attachments not recommended by the
manufacturer.
3.

3
PLANNING ASSEMBLY
Read all instructions before assembly.
To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard.
NOTE: More than one person may be required to
assemble this product.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part
Description
Quantity
AA M6x20 combination bolt 16+1
BB
Hex wrench 1
AA BB
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
Warranty
2 YEAR FRAME WARRANTY
WHAT IS COVERED
We warrant the frame to be free of manufacturing defects to the original purchas
er
for two years.
WHAT IS NOT COVERED
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit www.Homedepot.ca.
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty. We
reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.

4
Pre-Assembly (continued)
PACKAGE CONTENTS
Part Description Quantity
A Table top 1
B Table leg 1 1
C Table leg 2 2
D Metal sheet 1
A
B
C
D
E
E Table ring 1

5
1
l
Assembly
Connecting the table leg 1 to the table top
Place the table top (A) upside down on a soft surface.
Attach the table leg 1 (B) to the table top (A) using M6x20 combination bolts (AA).
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
NOTE : Loosely tighten all the bolts using the hex wrench (BB).
AA
A
B

6
2
l
(continued)
Assembly
Connecting the table leg 2 to the table top
Attach the table leg 2 (C) to the table top (A) using M6x20 combination bolts (AA).
Do not fully tighten all the bolts at this step.
NOTE : Loosely tighten all the bolts using the hex wrench (BB).
AA
AA
C
Connect the table legs 2 (C) to the table leg 1 (B) using M6x20 combination bolts (AA).

7
3
l
(continued)
Assembly
Connecting the metal sheet to the table legs
Attach the metal sheet (D) to the table legs (B & C) using M6x20 combination bolts (AA).
Do not fully tighten all the bolts at this step.
NOTE : Loosely tighten all the bolts using the hex wrench (BB).
HOMEDEPOT.CA
Please contact 1-855-HD-HAMPTON for further assistance.
AA
D
C
B

8
Assembly (continued)
4
Attaching the table ring
Once all of the bolts are in place, fully tighten the bolts.
Turn the table right side up and cover the center hole with the table ring (E).
Ensure all connections are secure before use.
Care and Cleaning
For best results, clean the table with a damp cloth and dry thoroughly. This will help prevent mildew by removing dirt
particles that may accumulate.
Do not clean with abrasive materials, bleach, or solvents.
Store the table in a dry, sheltered place when not in use.
Keep the table away from re, extreme heat, freezing conditions, and inclement weather such as rain, hail, sleet, snow, or wind.
E

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service.
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HOMEDEPOT.CA
Retain this manual for future use.
For certification use only
Factory ID # FTS81019J
