HAMPTON BAY L-GZ019PST-C User manual

THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this grill gazebo. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank
you for choosing Hampton Bay!
Item # 0000 000 000
Model #L-GZ019PST-C
USE AND CARE GUIDE
TIKI GRILL GAZEBO
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday-Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM

2 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Table of Contents
Table of Contents................................................................... 2
Safety Information................................................................. 2
Warranty................................................................................ 2
What is Covered .......................................................................2
What is Not Covered ................................................................2
Pre-Assembly ........................................................................3
Planning Assembly...................................................................3
Hardware Included...................................................................3
Package Contents ....................................................................4
Assembly ...............................................................................6
Care and Cleaning..................................................................9
Safety Information
1. Some parts may contain sharp edges. Wear protective
gloves.
2. When assembling and using this product, basic safety
precautions should always be followed to reduce the risk of
personal injury and damage to equipment. Please read all
instructions before assembly and usage.
DANGER: This unit is heavy! Do not assemble this item
alone.
WARNING: Do not leave the gazebo where there is a risk of
high wind, as possible damage will occur to the structure.
WARNING: Keep all flame and heat sources away from this
gazebo fabric. This Gazebo is made with fabric that meets
CPAI-84 specifications for flame resistance. It is not fire
proof. The fabric will burn if left in continuous contact with
any flame source. The application of any foreign substance
to the gazebo fabric may render the flame-resistant
properties ineffective.
Warranty
2 YEAR WARRANTY
WHAT IS COVERED
This limited warranty is extended to the original purchaser and applies to defects in materials and workmanship of your item provided the
item is maintained with care and used only for personal, residential purposes. The item is warranted to be free from defects in material or
workmanship for a period of 2 years.
WHAT IS NOT COVERED
We do not reimburse for transportation of delivery costs, or compensate the individual or any outside party for assembling or disassembling
the product.
Contact the Customer Service Team at 1-855-HD-HAMPTON or visit HAMPTONBAY.COM.
Production Number : XXXXXXXX
CAUTION: Do not climb on top of the gazebo. Falling off the
gazebo can result in serious injury, possibly even death.
NOTICE: For outdoor use only.

3 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly
PLANNING ASSEMBLY
Before beginning assembly of this product, make sure all parts are present. Compare parts with the Hardware Included
and Package Contents lists. If any part is missing or damaged, do not attempt to assemble the product. Contact
customer service for replacement parts.
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
AA BB CC DD
FF ZZ
Part Part No Description Quantity Additional
AA H02020C11 Bolt M6*20 24 3
BB H19001C11 M6 Flat Washer 32 4
CC H02035C11 Bolt M6 *35 4 1
DD H14001C11 M6 Nut 4 1
FF P12401C01001 “7” Shape Stake 6*230mmΦ12 0
ZZ H00001C12 Wrench M6 2 0

4 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly (continued)
PACKAGE CONTENTS
A
1
A
2
B
C
D
K
F
G
H
J
E

5 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Pre-Assembly (continued)
Part Part No Description Quantity
A1 P11101B01102 Post 1 2
A2 P11102B01102 Post 2 2
B P11001C01102 Long Frame 2
C P11002C01102 Short Frame 2
D P10301C01102 Slant Beam For Big Roof 4
E P10101C01102 Top Connector 2
F P10201B01102 Slant Beam For Small Roof 4
G P1231C01102 Table Top 2
H P12601
A
01102 Hook 1
J P00102L06007 Small Canopy 1
K P00103L06007 Big Canopy 1

6 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly
1 Attaching the Post and Long Frame 2 Attaching the Post and Short
Frame
Connect the Long Frame (B) and the Post (A1 and A2) together
using Bolts (AA) and Washers (BB).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
Connect the Short Frame (C) and the Post (A1 and A2) together
using Bolts (AA) and Washers (BB).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
3 Assembling the Big Roof 4 Assembling the Slant Beam for
Small Roof
Connect the Top Connector (E) and Slant Beam For Big Roof (D)
as pictured, then connect the Slant Beam For Big Roof (D) and
the Post (A1 and A2) using Bolts (CC), Washers (BB) and Nuts
(DD).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
Connect the Top Connector (E) and Slant Beam For Small Roof (F)
as pictured.
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
A
1
A
2
BB
A
A
B
A
1
A
2
B
BB
AA
C
C
A2
A
1
A1 A2
C
E
F
E
F
E
D
A2
A
1
DD
BB
E
D
A2
A1
D
BB
CC

7 WWW.HAMPTONBAY.COM
.ecnatsissarehtrufrofNOTPMAH-DH-558-1tcatnocesaelP
Assembly (continued)
5 Attaching the Small Canopy 6 Attaching the Big Canopy to the
Big Top
 Put the Small Canopy (J) onto the assembled small top, aligning
the corners as pictured.
NOTE: To avoid destro ish, do not put the parts on
the ground directly.
Put the Big Canopy (K) onto the assembled big top.
NOTE: To av ish, do not put the parts on
the ground directly.
7 Attaching the Small Roof and Hook 8 Attaching the Big Canopy
Connect the small top and big top together, then attach the
Hook (H) to the big top.
NOTE: To avoid destro ish, do not put the parts on
the ground directly.
Align the corners of Big Canopy (K) as pictured.
NOTE: To av ish, do not put the parts on
the ground directly.
K
H
E
F
D
F
J
F
J

8 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly (continued)
9 Attaching the Table Top 10 Securing the Gazebo
Attach the Table Top (G) onto the Post using Bolts (AA) and
Washers (BB).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
Secure the gazebo using the Stakes (FF).
NOTE: To avoid destroying the finish, do not put the parts on
the ground directly.
FF
A
A
A
ABB
BB
G
G
G

9 WWW.HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Care and Cleaning
□Before using, clean the gazebo completely with a soft dry towel.
□Do not put your gazebo in wet conditions where there is a risk of rust developing.
□When not in use, store in a cool, dry area.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8 a.m. - 7 p.m., EST, Monday- Friday, 9 a.m. - 6 p.m., EST, Saturday
1-855-HD-HAMPTON
WWW.HAMPTONBAY.COM
Retain this manual for future use.
