HAMPTON BAY TOBAGO 151-101-5MOD-V5 User manual

THANK YOU
USE AND CARE GUIDE
TOBAGO 5 PIECE MODULAR SECTIONAL
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
HAMPTONBAY.COM
Item # 1000 054 283
Model #151-101-5MOD-V5
8.00 a.m. - 6.00 p.m., EST, Monday - Friday
1-855-HD-HAMPTON
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
this 5 piece modular sectional. We strive
YOW SKU # 661 248

2
Table of Contents
Safety Information
DANGER: Please keep children out of the assembly area
during assembly.
IMPORTANT: Please check the tightness of bolts
periodically.
Table of Contents....................................................
Safety Information...................................................
Warranty ........................................................................19
2 Year Frame, Weave and Fabric Limited Warranty
Pre-Assembly (Left Arm Chair Section).....................3
Planning Assembly/ Hardware Included / Package Contents...3
What Is Covered..............................................................19
What Is Not Covered.........................................................19
2
2
Before using, wipe with a clean, dry cloth. Do not use bleach or solvents. Treat frame with one-step liquid wax for maximum protection against
UV light and salty, damp air. When not in use, store furniture in a cool, dry place. If your set includes cushions or mesh fabric, they may
be cleaned by hand with a mild solution of soap and water. Rinse cushion thoroughly and allow to drip dry. Do not machine wash or
tumble dry, as cushions may shrink. Do not use bleach or solvents on fabrics. When clening the tabletop make sure to use a soft clean cloth
that does not bleed color.
You may contact our customer service department with any questions by phone at 1-855-HD-HAMPTON or visit www.hamptonbay.com.
Care Instructions...... ................................................ 2
Care Instructions
.................19
Pre-Assembly (Armless Chair Section)......................4
Planning Assembly/ Hardware Included / Package Contents...4
Pre-Assembly (Right Arm Chair Section)...................5
Planning Assembly/ Hardware Included / Package Contents...5
Pre-Assembly (Table)...................................................6
Planning Assembly/ Hardware Included / Package Contents...6
Pre-Assembly (Ottoman).............................................7
Planning Assembly/ Hardware Included / Package Contents...7
Assembly (Left Arm Chair Section).................................8
Assembly (Armless Chair Section).................................11
Assembly (Right Arm Chair Section)..............................14
Assembly (Table)............................................................. 17
Assembly (Ottoman)........................................................18
Assembly (3-Seat Sofa)...................................................19
Since the faux wood table top is sensitive to heat, we recommend the following precautions:
Do not expose the table top in sunlight when ambient temperature is above 70 º C (158 º F).
Keep the table away from fire and flame source.
Do not barbecue on the table, do not use a stove on the table.
Do not place hot dishers or utensils directly on the tabletop without tablemat or coasters.
Do not put wine glasses on the table directly as wine glass may produce a magnifying glass effect, which could possibly burn a small portion of
the surface of the table.
Minor scratches can be buffed out with steel wool or 600 grit sand paper. Be sure to sand the surface in the direction of the grain.
Heavy scratches can be filled using working crack fillers and puddies.
You can wipe the faux wood surface with a damp cloth. If needed, mild soap or dish detergent can be used.
Never use petroleum or oil based products such as solvents or harsh cleaners.
SPECIAL CARE INSTRUCITONS ABOUT THE TABLE TOP
Special Care Instructions about The Table Top.........................2

3 HAMPTONBAY.COM
Pre-Assembly (Left Arm Chair Section)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA 12
BB 12
CC 12
DD
Washer (D6)
Wrench 1
AA BB CC DD
Please contact 1-855-HD-HAMPTON for further assistance.
PLANNING ASSEMBLY
It will take two people about 20 minutes to complete the assembly process.
Bolt cap
Bolt (M6x35)
PACKAGE CONTENTS
Part Description Quantity
A 1
B 1
C1
B C
Back panel
Seat panel
Side panel
A
0.300
F
E
D
D1
E1
F1
Seat cushion
L-shaped panel
Back cushion
The whole set includes one left arm chair section, one armless chair section, one right arm chair section, one table
and one ottoman. Please lay out all parts prior assembly to verify all parts are included.
HH
HH Plastic clamp 1

4
Pre-Assembly (Armless Chair Section)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA 6
BB 10
CC 10
Washer (D6)
AA BB CC
PLANNING ASSEMBLY
It will take two people about 20 minutes to complete the assembly process.
Bolt cap
Bolt (M6x35)
EE
EE
Bolt (M6x48) 4
PACKAGE CONTENTS
Part Description Quantity
B1 1
C1 1
D1 1
C1 D1
Back panel
Seat panel
B1
0.300
F
E
E1
F1
Seat cushion
U-shaped panel
Back cushion
0.300
HH
HH Plastic clamp 2

5 HAMPTONBAY.COM
Pre-Assembly (Right Arm Chair Section)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
AA 12
BB 12
CC 12
Washer (D6)
AA BB CC
Please contact 1-855-HD-HAMPTON for further assistance.
PLANNING ASSEMBLY
It will take two people about 20 minutes to complete the assembly process.
Bolt cap
Bolt (M6x35)
PACKAGE CONTENTS
Part Description Quantity
A2 1
B2 1
C 1
B2 C
Back panel
Seat panel
Side panel
A2
比例0.300
F
E
D2
D2 1
E1
F1
Seat cushion
L-shaped panel
Back cushion
HH Plastic clamp 1
HH

6
Pre-Assembly (Table)
NOTE: Hardware not shown to actual size.
PLANNING ASSEMBLY
It will take two people about 10 minutes to complete the assembly process.
HARDWARE INCLUDED
Part Description Quantity
Washer
Bolt cap
FF
CC
12
12
FF
BB
CC
Bolt (M6x20) 12
BB
PACKAGE CONTENTS
Part Description Quantity
GTable top 1
HTable leg 4
GH

7
Pre-Assembly (Ottoman)
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part Description Quantity
I I
Bolt (M6x18)
4
BB
Bolt (M6x40) 4
CC
Washer 8
Bolt cap 8
GG
II
BB CC GG
PLANNING ASSEMBLY
It will take two people about 10 minutes to complete the assembly process.
PACKAGE CONTENTS
Part Description Quantity
I1
J2
K 1
J K
Side panel
Seat panel
I
Seat pad
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.

8
Assembly (Left Arm Chair Section)
1 Attaching the side panel to the back panel
□
□
Hook the side panel (A) into the back panel (B) as shown below.
IMPORTANT:Do not fully tighten bolts (AA)
Stand the back panel (B) on a flat, smooth surface.
until the end of Step 3.
2Attaching the seat panel
□
□Attach the seat panel (C) to the back panel (B) and the side panel (A) with washers (BB) and bolts (AA) using the wrench (DD).
Place the frame upside down on a flat, smooth surface.
IMPORTANT:Do not fully tighten bolts (AA)
until the end of Step 3.
Attach the side panel (A) to the back panel (B) with washers (BB) and bolts (AA) using the wrench (DD).
A
B
A
B
BB
AA
DD
B
C
A
BB
AA
DD

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
9
Assembly (Left Arm Chair Section)
3 Attaching the L-shaped panel
□
Attach the L-shaped panel (D) to the side panel (A), the seat panel (C) and the back panel (B) with washers (BB) and bolts (AA) using
the wrench (DD).
□Fully tighten all the bolts (AA) when all of them are in place.
A
C
B
D
DD
AA
BB
D
A
BC
BB
AA
DD
BB
AA
DD
BB
AA DD

Assembly (Left Arm Chair Section)
10
5 Placing the cushions
□
Place the cushions (E and F) on the sectional chair.
D
B
A
C
CC
4 Covering the bolts
□Cover all the bolts (AA) with bolt caps (CC).
□
Adjust the foot glides to stabilize the sectional chair.
F
E

11 HAMPTONBAY.COM
Assembly (Armless Chair Section)
1 Attaching the seat panel to the back panel
□
□
Please contact 1-855-HD-HAMPTON for further assistance.
IMPORTANT:
Do not fully tighten the bolt (AA)
Place the back panel (B1) upside down on a flat smooth surface.
until the end of Step 3.
2Attaching the U-shaped panel
□Align the U-shaped panel (D1) to the seat panel (C1) and the back panel (B1) .
Attach the seat panel (C1) with a washer (BB) and a bolt (AA) using the wrench (DD).
DD BB
AA
B1
C1
B1
C1
D1

12
Attaching the U-shaped panel (continued)
□
Secure the U-shaped panel (D1) to the back panel (B1) and the seat panel (C1) with washers (BB) and bolts (AA and EE) using the wrench (DD).
□Fully tighten all the bolts (AA and EE) when all the bolts are in place.
AA
BB
DD
B1
D1
C1
AA
BB
DD
B1
D1
C1
BB
EE
DD
Assembly (Armless Chair Section)
3

Assembly (Armless Chair Section)
13 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
5 Placing cushions
□
Place the seat cushion (E) and the back cushion (F) on the armless chair section.
4 Covering the bolts
□Cover all the bolts (AA and EE) with bolt caps (CC).
□Adjust foot glides to stabilize the armless chair section.
CC
E
F

14
1 Attaching the side panel to the back panel
□
□
Hook the side panel (A2) into the back panel (B2) as shown below.
IMPORTANT:Do not fully tighten bolts (AA)
Stand the back panel (B2) on a flat, smooth surface.
until the end of Step 3.
2Attaching the seat panel
□
□Attach the seat panel (C) to the back panel (B2) and the side panel (A2) with washers (BB) and bolts (AA) using the wrench (DD).
Place the frame upside down on a flat, smooth surface.
IMPORTANT:Do not fully tighten bolts (AA)
until the end of Step 3.
Attach the side panel (A2) to the back panel (B2) with washers (BB) and bolts (AA) using the wrench (DD).
A2
B2
A2
B2
BB AA DD
B2
C
A2
BB AA DD
Assembly (Right Arm Chair Section)

HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Assembly (Right Arm Chair Section)
15
3 Attaching the L-shaped panel
□
Attach the L-shaped panel (D2) to the side panel (A2), the seat panel (C) and the back panel (B2) with washers (BB) and bolts (AA) using the
wrench (DD).
□Fully tighten all the bolts (AA) when all of them are in place.
A2
C
B2
D2
DD AA BB
D2
A2
B2
C
BB
AA
DD
BB
AA
DD
BB
AA DD

Assembly (Right Arm Chair Section)
16
5 Placing cushions
□
Placing the cushions (E and F) on this chair section.
D2 B2
A2
C
CC
4 Covering the bolts
□Cover all the bolts (AA) with bolt caps (CC).
□Adjust the foot glides to stabilize this chair section.
F
E

Assembly (Table)
HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
1 Attaching table legs
□Attach the table legs (H) to the table top (G) with washers (BB)
and bolts (FF). Fully tighten the bolts (FF) with the wrench (DD).
□Place the table top (G) upside down on a flat, smooth surface.
H
G
DD
FF
BB
2 Attaching bolt caps
CC
□Cover all bolts (FF) with bolt caps (CC).
FF
3 Stabilizing the table
□Turn the table upright.
□Adjust the foot glides to stabilize the table.
17

18
Assembly (Ottoman)
1 Attaching side panels to the seat panel 2 Covering the bolts
□
□
□
□Cover all the bolts (II and GG) with bolt caps (CC).
Attach side panels (J) to the seat of seat panel (I) with
washers (BB) and bolts (II and GG) using the wrench (DD).
Completely tighten all the bolts (II and GG).
Place the seat panel (I) upside down on a flat, smooth suraface.
3 Placing the seat pad
GG
BB
J
J
I
IIBB
CC
CC
DD
DD
□
Turn the ottoman upright.
K
□
Place the seat pad (K) on the ottoman.

Use plastic clamps (HH) to secure the left arm chair section and the right arm chair section to the armless chair section to form
a 3-seat sofa. See diagram below. Secure cushions to the 3-seat sofa with hook and loop strips.
Assembly (3-Seat Sofa)
HH
19 HAMPTONBAY.COM
Please contact 1-855-HD-HAMPTON for further assistance.
Warranty
2 YEAR FRAME/ WEAVE/ FABRIC LIMITED WARRANTY
WHAT IS COVERED
WHAT IS NOT COVERED
It remains the customer’s responsibility for freight and packaging charges to and from our service center. This warranty does not cover
s warranty.
We reserve the right to make substitutions with similar merchandise, if the model in question is no longer in production.
We warrant the frame, weave and fabric to be free of manufacturing defects to the original purchaser for two years.

Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8.00 a.m. – 6.00 p.m., EST, Monday-Friday
1-855-HD-HAMPTON
HAMPTONBAY.COM
Retain this manual for future use.
