Hangar 9 F-22 Raptor PTS User manual

Wingspan (with droops and tip extensions).................................52 in (1320.8 mm)
Wingspan (without droops and tip extensions)............................47.9 in (1216.66 mm)
Length..........................................................................................50.3 in (1277.62 mm)
Wing Area (with droops and tip extensions) ................................731 sq in (47.16 sq dm)
Wing Area (without droops and tip extensions) ...........................675 sq in (43.55 sq dm)
Weight..........................................................................................7.0–7.5 lb (3.18–3.40 kg)
Lockheed Martin and F-22 RAPTOR are either registered trademarks or trademarks of Lockheed Martin Corporation
in the USA and/or other countries, used under license by Horizon Hobby, Inc.
Assembly mAnuAl
F-22 Raptor ARF
Specifications

2
Table of Contents
Introduction.......................................................................3
ContentsofKit....................................................................3
UltraCoteCoveringColors...........................................................4
RequiredItems....................................................................4
OptionalPartsandAccessories .......................................................4
RequiredToolsandAdhesives........................................................4
RadioandPowerSystemsRequirements................................................5
WarrantyPeriod ...................................................................5
LimitedWarranty...................................................................6
DamageLimits....................................................................6
SafetyPrecautions .................................................................6
Questions,Assistance,andRepairs ....................................................7
InspectionorRepairs...............................................................7
WarrantyInspectionandRepairs.......................................................7
Non-WarrantyRepairs...............................................................7
Safety,Precautions,andWarnings.....................................................8
BeforeStartingAssembly............................................................8
UsingtheManual..................................................................8
Section1:AileronServoInstallation....................................................9
Section2:FixedFlapInstallation.....................................................14
Section3:FlapServoInstallation.....................................................19
Section4:EngineInstallation........................................................23
Section5:CowlingInstallation.......................................................26
Section6:LandingGearInstallation...................................................30
Section7:TailInstallation...........................................................33
Section8:RadioInstallation.........................................................35
Section9:WingInstallation.........................................................41
Section10:InstallingtheNACADroops................................................43
Section 11: Centering the Control Surfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Section 12: Checking the Control Surface Directions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Section 13: Checking the Control Throw Amounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Section14:AdjustingtheThrottle.....................................................49
Section15:BalancingYourF-22Raptor................................................50
Section16:FlightPreparations.......................................................52
Section 17: Maintaining Your F-22 Raptor ARF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .53
2007 Official AMA National Model Aircraft Safety Code. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

3
Contents of Kit
Introduction
Sophisticated sensors, unmatched close-in dogfighting skills and undetectable at long range. The F-22 Raptor™, the
U.S. Air Force's newest aircraft, is the most advanced stealth fighter in aviation technology. With the F-22 Raptor ARF,
beginners can learn to fly on a trainer that looks exciting. This revolutionary trainer sports red plastic NACA droops and
wing tip extensions that attach to the outer edge of the wing to provide extra stability. Once you’ve mastered the basics,
remove the droops and change the settings on the flap system to move up to the next level and enjoy sport aerobatics.
Progress from learning to fly to performing simple aerobatics with Hangar 9’s F-22 Raptor ARF.
The F-22 Raptor ARF is part of Hangar 9’s complete line of top-quality aircraft and accessories. Our Ready-To-Fly (RTF),
Almost-Ready-to-Fly (ARF), Progressive Trainer System (PTS™) and Plug-N-Play®(PNP®) trainer, performance and
scale airplanes are engineered and crafted to exacting standards and feature the finest components and materials, such as
our exclusive UltraCote®covering. Just as important, with every Hangar 9®product, you’ll get the service and technical
support you need to succeed.
E. HAN3831 Canopy Red/White
F. HAN3832 Landing Gear Set Complete
G. HAN3837 Cowling Red/White (uncut)
H. HAN3833 Spinner, 3-Blade
I. HAN3836 Spinner, 2-Blade
J. HAN3838 Wing Tube Set
K. HAN3839 NACA droops Red/White
Replacement Parts
A. HAN3826 Wing Set Red/White
B. HAN3827 Fuselage Red/White
C. HAN3828 Stabilizer Set w/Elevator
Red/White (2)
D. HAN3829 Fin Set w/Rudders Red/White (2)
F
A
B
C
D
G
E
H
I
J
K
K

4
UltraCote®Covering Colors
• True Red HANU866 • White HANU870
• Black HANU874
Required Items
• Fuel (10%–15% nitro content) • Glow Plug Wrench (HAN2510)
• Glow Plug Igniter with Charger (HAN7101) • Glow Plug (HAN3001/3006)
• Manual Fuel Pump (HAN118)
or
• Start-Up Field Pack (HANSTART)
Optional Parts and Accessories
• Fieldmate Prebuilt Field Box (HAN117) • Mosfet Power Panel (HAN106)
• Metered Glow Driver w/Ni-Cd and Charger (HAN7101) • PowerPro 12V Starter (HAN161)
• Manual Fuel Pump (HAN118) • Double Vision Fast Field Charger (HAN114)
• Aluminum Transmitter Case for Single Tx (HAN124) • Digital Variable Load Voltmeter (HAN171)
• Long Reach Glow Plug Wrench (HAN2510) • 2-Cycle Sport Glow Plug (HAN3001)
• Transmitter Stand (HAN2525) • Angle Pro Throw/Incidence Meter (HAN192)
• Hangar 9 Straw Hat (HANP303) • Sealing Iron ( HAN101)
• Sealing Iron Sock (HAN141) • Heat Gun (HAN100)
• Covering Glove (HAN150) • Trainer Power System Propeller (EVOE100P)
Required Tools and Adhesives
• Felt-tipped pen • Adjustable wrench
• Pliers • Side cutters
• Threadlock (PAAPT42) • Medium sandpaper
• Drill • Paper towels
• 12-minute epoxy • Hobby knife
• Razor saw • Phillips screwdriver (small)
• Rubbing alcohol • Masking tape
• Z-bend pliers • Medium CA
• Ruler • Hobby scissors
• Rotary tool w/sanding drum • String
• Drill bit: 1/16-inch (1.5mm), 5/64-inch (2mm), 1/8-inch (3mm)

5
Radio and Power Systems Requirements
• 4-channel radio system (minimum) w/receiver
• ST47 Servo (JSP20050) (5) or equivalent
• 6-inch Servo Lead Extension (JRPA095) (2)
• Long Servo Arm (JRPA212) (2)
• Y-Harness (JSP98020)
• Receiver Battery (JSP91010)
• Receiver (JSP30060)
• Switch Harness (JSP98010)
Optional/Additional Radio Equipment for Flap Installation
• 5-channel radio system (minimum) w/receiver
• Long Servo Arm (JRPA212) (2)
• ST47 Servo (JSP20050)
• ST47 Reverse Servo (JSP20050R)
• Y-Harness (JSP98020)
Recommended JR®, JR SPORT™or Spektrum®Systems
• XP9303
• XP7202
• XP6102
• SX600
• DX7
Recommended Power Systems
• .46–.52 2-cycle engines
Recommended: Evolution®.52 NX (EVOE0520)
Warranty Period
Exclusive Warranty- Horizon Hobby, Inc., (Horizon) warranties that the Products purchased (the "Product") will be free
from defects in materials and workmanship at the date of purchase by the Purchaser.
JR XP6102
JR XP9303
Spektrum DX7
Evolution .52NX
EVOE0520
SX600

6
Limited Warranty
(a) This warranty is limited to the original Purchaser ("Purchaser") and is not transferable. REPAIR OR REPLACEMENT
AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PURCHASER. This warranty covers only
those Products purchased from an authorized Horizon dealer. Third party transactions are not covered by this warranty.
Proof of purchase is required for warranty claims. Further, Horizon reserves the right to change or modify this warranty
without notice and disclaims all other warranties, express or implied.
(b) Limitations- HORIZON MAKES NO WARRANTY OR REPRESENTATION, EXPRESS OR IMPLIED, ABOUT NON-
INFRINGEMENT, MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE OF THE PRODUCT. THE
PURCHASER ACKNOWLEDGES THAT THEY ALONE HAVE DETERMINED THAT THE PRODUCT WILL SUITABLY MEET
THE REQUIREMENTS OF THE PURCHASER’S INTENDED USE.
(c) Purchaser Remedy- Horizon's sole obligation hereunder shall be that Horizon will, at its option, (i) repair or (ii)
replace, any Product determined by Horizon to be defective. In the event of a defect, these are the Purchaser's exclusive
remedies. Horizon reserves the right to inspect any and all equipment involved in a warranty claim. Repair or replacement
decisions are at the sole discretion of Horizon. This warranty does not cover cosmetic damage or damage due to acts of
God, accident, misuse, abuse, negligence, commercial use, or modification of or to any part of the Product. This warranty
does not cover damage due to improper installation, operation, maintenance, or attempted repair by anyone other than
Horizon. Return of any goods by Purchaser must be approved in writing by Horizon before shipment.
Damage Limits
HORIZON SHALL NOT BE LIABLE FOR SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, LOSS OF PROFITS OR
PRODUCTION OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCT, WHETHER SUCH CLAIM
IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. Further, in no event shall the liability of
Horizon exceed the individual price of the Product on which liability is asserted. As Horizon has no control over use,
setup, final assembly, modification or misuse, no liability shall be assumed nor accepted for any resulting damage or
injury. By the act of use, setup or assembly, the user accepts all resulting liability.
If you as the Purchaser or user are not prepared to accept the liability associated with the use of this Product, you are
advised to return this Product immediately in new and unused condition to the place of purchase.
Law: These Terms are governed by Illinois law (without regard to conflict of law principals).
Safety Precautions
This is a sophisticated hobby Product and not a toy. It must be operated with caution and common sense and requires
some basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury
or damage to the Product or other property. This Product is not intended for use by children without direct adult
supervision. The Product manual contains instructions for safety, operation and maintenance. It is essential to read
and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in order to operate correctly
and avoid damage or injury.

7
Questions, Assistance, and Repairs
Your local hobby store and/or place of purchase cannot provide warranty support or repair. Once assembly, setup or
use of the Product has been started, you must contact Horizon directly. This will enable Horizon to better answer your
questions and service you in the event that you may need any assistance. For questions or assistance, please direct your
email to [e-mail], or call 877.504.0233 toll free to speak to a service technician.
Inspection or Repairs
If this Product needs to be inspected or repaired, please call for a Return Merchandise Authorization (RMA). Pack
the Product securely using a shipping carton. Please note that original boxes may be included, but are not designed
to withstand the rigors of shipping without additional protection. Ship via a carrier that provides tracking and insurance
for lost or damaged parcels, as Horizon is not responsible for merchandise until it arrives and is accepted
at our facility. A Service Repair Request is available at www.horizonhobby.com on the “Support” tab. If you do not
have internet access, please include a letter with your complete name, street address, email address and phone number
where you can be reached during business days, your RMA number, a list of the included items, method of payment
for any non-warranty expenses and a brief summary of the problem. Your original sales receipt must also be included
for warranty consideration. Be sure your name, address, and RMA number are clearly written on the outside of the
shipping carton.
Warranty Inspection and Repairs
To receive warranty service, you must include your original sales receipt verifying the proof-of-purchase
date. Provided warranty conditions have been met, your Product will be repaired or replaced free of charge. Repair or
replacement decisions are at the sole discretion of Horizon Hobby.
Non-Warranty Repairs
Should your repair not be covered by warranty the repair will be completed and payment will be
required without notification or estimate of the expense unless the expense exceeds 50% of the retail
purchase cost. By submitting the item for repair you are agreeing to payment of the repair without notification. Repair
estimates are available upon request. You must include this request with your repair. Non-warranty repair estimates will
be billed a minimum of ½ hour of labor. In addition you will be billed for return freight. Please advise us of your preferred
method of payment. Horizon accepts money orders and cashiers checks, as well as Visa, MasterCard, American Express,
and Discover cards. If you choose to pay by credit card, please include your credit card number and expiration date. Any
repair left unpaid or unclaimed after 90 days will be considered abandoned and will be disposed of accordingly. Please
note: non-warranty repair is only available on electronics and model engines.
Electronics and engines requiring inspection or repair should be shipped to the following address:
Horizon Service Center
4105 Fieldstone Road
Champaign, Illinois 61822
All other Products requiring warranty inspection or repair should be shipped to the following address:
Horizon Product Support
4105 Fieldstone Road
Champaign, Illinois 61822
Please call 877-504-0233 with any questions or concerns regarding this product or warranty.

8
Safety, Precautions, and Warnings
This model is controlled by a radio signal that is subject to interference from many sources outside your control. This
interference can cause momentary loss of control so it is advisable to always keep a safe distance in all directions around
your model, as this margin will help to avoid collisions or injury.
• Always operate your model in an open area away from cars, traffic, or people.
• Avoid operating your model in the street where injury or damage can occur.
• Never operate the model into the street or populated areas for any reason.
• Never operate your model with low transmitter batteries.
• Carefully follow the directions and warnings for this and any optional support equipment (chargers, rechargeable
battery packs, etc.) that you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Moisture causes damage to electronics. Avoid water exposure to all equipment not specifically designed and protected
for this purpose.
Before Starting Assembly
Before beginning the assembly of the F-22 Raptor ARF, remove each part from its bag for inspection. Closely inspect
the fuselage, wing panels, rudder, and stabilizer for damage. If you find any damaged or missing parts, contact the place
of purchase.
If you find any wrinkles in the covering, use a heat gun or sealing iron to remove them. Use caution while working around
areas where the colors overlap to prevent separating the colors.
Using the Manual
This manual is divided into sections to help make assembly easier to understand, and to provide breaks between each
major section. In addition, check boxes have been placed next to each step to keep track of each step completed. Steps
with a single box () are performed once, while steps with two boxes () indicate that the step will require
repeating, such as for a right or left wing panel, two servos, etc. Remember to take your time and follow the directions.
HAN100 – Heat Gun
HAN150 – Covering Glove
HAN101 – Sealing Iron
HAN141 – Sealing Iron
Sock

9
Items Required
• Wing (left and right)
•#2 x 3/8-inch screw (8)
• Aileron servo hatch (left and right)
• Wire pushrod keeper (2) • Clevis w/retainer (2)
• Pushrod wire, 4 3/4-inch (121mm) (2)
• 3/8 x 3/4 x 3/4-inch (9.5 x 19 x 19mm)
servo mounting block (4)
Tools Required
• 12-minute epoxy • Felt-tipped pen
• Drill • Hobby knife
• Side cutters • String
• Servo extension, 6-inch (152mm) (2)
• Drill bit: 1/16-inch (1.5mm) 5/64-inch (2mm)
• Phillips screwdriver (small)
• Long Servo Arm (JRPA212) (2)
Step 1
Install the recommended servo hardware (grommets and
eyelets) supplied with the servo. Use the instructions
provided with your servos or radio system that detail the
installation of the grommets and eyelets.
Step 2
Attach a 6-inch (152mm) servo extension to the
servo lead. Use either string or a commercially
available connector to prevent the two from
unplugging during flight.
Step 3
Position the servo onto the hatch so the servo arm is
centered in the notch. Once satisfied, mark the location for
the servo mounting blocks using a felt-tipped pen.
Note: Check to make sure your servo does
not hang off one end of the servo hatch.
If so, reposition the servo. Having the
servo fully on the hatch is more important
than having the servo arm centered.
Section 1: Aileron Servo Installation

10
Step 4
Locate two 3/8 x 3/4 x 3/4-inch (9.5 x 19 x 19mm) servo
mounting blocks. Use 12-minute epoxy to glue the blocks
to the hatch. Let the epoxy fully cure before proceeding to
the next step.
Step 5
Remove the standard servo arm on the servo and
replace it with a long servo arm. Place the aileron servo
between the mounting blocks and use a felt-tipped pen
to mark the location of the four servo mounting screws.
Note the servo must not touch the hatch in order to
isolate engine vibration.
Note: Before mounting the aileron servo,
make sure the servo arm is installed correctly
on the servo. This is done by moving the
servo from each end point to determine the
center position of the servo. With the radio off,
secure the servo arm in the center position.
Check the operation of the servo to determine
if the two end positions of the arm are equal.
If not, reposition the arm as necessary.
Step 6
Remove the servo and use a 1/16-inch (1.5mm) drill bit to
pre-drill the holes for the servo mounting screws marked
in the previous step.
Step 7
Use the screws supplied with the servo to mount it to the
servo mounting blocks.
Section 1: Aileron Servo Installation
