Hanhart PRIMUS User manual

1
BEDIENUNGSANLEITUNG & GARANTIE
Chronographen PRIMUS S. 17
DEUTSCH
MODE D’EMPLOI & GARANTIE
Chronographes PRIMUS p. 33
INSTRUCCIONES DE USO & GARANTIA
Cronógrafos PRIMUS p. 49
FRANÇAIS
ESPAÑOL
INSTRUCTION BOOK & GUARANTEE
Chronographs PRIMUS p. 3
ENGLISH

Operating Instructions
Chronographs Primus
Congratulations on your purchase of this
Hanhart chronograph from the Primus
collection. Your Hanhart chronograph was
intricately hand-crafted by highly qualified
watchmakers. To ensure that your chronograph
gives you the longest possible pleasure,
please note the following information and
hints.
Your Hanhart Guarantee Card will be
completed by your retailer at the time of
purchasing your watch.
We wish you much pleasure and thoroughly
enjoyable hours, minutes and seconds with
your Hanhart chronograph.
With best wishes,
Your Hanhart team

3
Operating Instructions
Chronographs Primus
Congratulations on your purchase of this
Hanhart chronograph from the Primus
collection. Your Hanhart chronograph was
intricately hand-crafted by highly qualified
watchmakers. To ensure that your chronograph
gives you the longest possible pleasure,
please note the following information and
hints.
Your Hanhart Guarantee Card will be
completed by your retailer at the time of
purchasing your watch.
We wish you much pleasure and thoroughly
enjoyable hours, minutes and seconds with
your Hanhart chronograph.
With best wishes,
Your Hanhart team
ENGLISH

Technical data and special features
•Modiedmechanicalchronographmovement
(bicompax, based on the ETA/Valjoux 7750
calibre)
•Automatic,powerreservemin.42hours
•28,000vibrationsperhour,4Hz
•28jewels
•RotorwithHanhartlogo
•Centrehourandminutehands,small
seconds at 9 o’clock
•Chronographminutescounterdisplay
at 3 o’clock
•Datedisplayat6o‘clock
•Casestainlesssteel,stainlesssteelblack
ADLC-coatedor18ct.rosegold
•Engravedserialnumber
•Redbutton(anodizedaluminium)
•Flutedbezel(PrimusDiverunidirectional
rotating) with inlaid red marking
(anodizedaluminium)
•Flexiblelugs(angleofinclination45˚-50˚)
•Screw-incrown
•Convex,internallyanti-reectivesapphire
glass

5
Technical data and special features
•Modiedmechanicalchronographmovement
(bicompax, based on the ETA/Valjoux 7750
calibre)
•Automatic,powerreservemin.42hours
•28,000vibrationsperhour,4Hz
•28jewels
•RotorwithHanhartlogo
•Centrehourandminutehands,small
seconds at 9 o’clock
•Chronographminutescounterdisplay
at 3 o’clock
•Datedisplayat6o‘clock
•Casestainlesssteel,stainlesssteelblack
ADLC-coatedor18ct.rosegold
•Engravedserialnumber
•Redbutton(anodizedaluminium)
•Flutedbezel(PrimusDiverunidirectional
rotating) with inlaid red marking
(anodizedaluminium)
•Flexiblelugs(angleofinclination45˚-50˚)
•Screw-incrown
•Convex,internallyanti-reectivesapphire
glass
ENGLISH

6
•Screw-downsapphireglassback,internally
anti-reective
•Super-LumiNova®coated, luminous
numerals, index marks and hands depending
on the model
•Water-resistantto10bar/100m
•Diameter44mm
•Caseheight15mm
Functions of your Hanhart chronograph
Datehigh-speedcorrectionisnotpossible
between8p.m.and2p.m.
INormalcourseposition
of the screw-in crown
II Hand-winding
III High-speed correction of the date
IIII Adjustment of the hour and minute hands
with second stop

7
•Screw-downsapphireglassback,internally
anti-reective
•Super-LumiNova®coated, luminous
numerals, index marks and hands depending
on the model
•Water-resistantto10bar/100m
•Diameter44mm
•Caseheight15mm
Functions of your Hanhart chronograph
Datehigh-speedcorrectionisnotpossible
between8p.m.and2p.m.
INormalcourseposition
of the screw-in crown
II Hand-winding
III High-speed correction of the date
IIII Adjustment of the hour and minute hands
with second stop
ENGLISH

8
Winding the chronograph
Wind your Hanhart chronograph by hand
before wearing it for the first time or after the
movement has not run for a long period.
1. Firstreleasethescrew-incrownbyrotating
the crown in an anticlockwise direction.
The crown is now in position “II”.
2. Rotatethecrownthroughapproximately
40revolutionsinaclockwisedirectionto
wind the watch fully. The watch is protected
against overwinding. Please stop winding
when you feel resistance.
The movement of your Hanhart chronograph is
wound automatically by the movements of your
wrist. Your Hanhart chronograph has a power
reserveofatleast42hours.Whenyoutakeoff
your Hanhart chronograph (e.g. overnight) you
do not have to rewind it every time.
Setting the time and the date
1. Setthecrowninposition“III”.Rotatethe
crown in the clockwise direction until the
date display indicates one day before the
currentdate.Warning:Donotadjustthe
datebetween8p.m.and2a.m.Thiscould
result in damage to the movement.
2. Setthecrowntoposition“IIII”.Rotatethe
hands in the anticlockwise direction until
the date jumps ahead of the current day
(midnight).Setthewatchtothedesired
time of day by continuing to rotate the
hands in an anticlockwise direction.
3. The movement is stopped with the crown
in position “IIII”.Tosynchronizeyour
chronograph with an accurate time source
(e.g. a radio-controlled clock), stop the
watch when the seconds hand is at “60”.
You can now set the watch to the accurate
time. To restart the movement, push the
crown back into position “I”. Apply gentle
pressure to the crown in the direction of the
case, rotating it in a clockwise direction at
the same time.

9
Winding the chronograph
Wind your Hanhart chronograph by hand
before wearing it for the first time or after the
movement has not run for a long period.
1. Firstreleasethescrew-incrownbyrotating
the crown in an anticlockwise direction.
The crown is now in position “II”.
2. Rotatethecrownthroughapproximately
40revolutionsinaclockwisedirectionto
wind the watch fully. The watch is protected
against overwinding. Please stop winding
when you feel resistance.
The movement of your Hanhart chronograph is
wound automatically by the movements of your
wrist. Your Hanhart chronograph has a power
reserveofatleast42hours.Whenyoutakeoff
your Hanhart chronograph (e.g. overnight) you
do not have to rewind it every time.
Setting the time and the date
1. Setthecrowninposition“III”.Rotatethe
crown in the clockwise direction until the
date display indicates one day before the
currentdate.Warning:Donotadjustthe
datebetween8p.m.and2a.m.Thiscould
result in damage to the movement.
2. Setthecrowntoposition“IIII”.Rotatethe
hands in the anticlockwise direction until
the date jumps ahead of the current day
(midnight).Setthewatchtothedesired
time of day by continuing to rotate the
hands in an anticlockwise direction.
3. The movement is stopped with the crown
in position “IIII”.Tosynchronizeyour
chronograph with an accurate time source
(e.g. a radio-controlled clock), stop the
watch when the seconds hand is at “60”.
You can now set the watch to the accurate
time. To restart the movement, push the
crown back into position “I”. Apply gentle
pressure to the crown in the direction of the
case, rotating it in a clockwise direction at
the same time.
ENGLISH

10
Using the chronograph function
Simpletimerecording
Crown in position“I”
1 START
2 STOP
Readthetime
3 RESETTOZERO
If you would like to record a time with your
Hanhart chronograph, you should use the
button “A” for the start and stop functions. The
button “B” is used to reset the chronograph
after a measurement.
You start a time recording by pressing the
button “A”. You stop the time recording by
pressing the button “A” a second time. The
centre seconds hand and the chronograph
minutes counter display (at 3 o’clock) are used
to read the stopped time. Press the button “B”
toresetthehandstozero.
Donotforgettoscrewinthecrownagainonce
you have completed all the adjustments.
The water resistance of your chronograph can
only be guaranteed when the crown is screwed
in.

11
Using the chronograph function
Simpletimerecording
Crown in position“I”
1 START
2 STOP
Readthetime
3 RESETTOZERO
If you would like to record a time with your
Hanhart chronograph, you should use the
button “A” for the start and stop functions. The
button “B” is used to reset the chronograph
after a measurement.
You start a time recording by pressing the
button “A”. You stop the time recording by
pressing the button “A” a second time. The
centre seconds hand and the chronograph
minutes counter display (at 3 o’clock) are used
to read the stopped time. Press the button “B”
toresetthehandstozero.
Donotforgettoscrewinthecrownagainonce
you have completed all the adjustments.
The water resistance of your chronograph can
only be guaranteed when the crown is screwed
in.
ENGLISH

12
Aggregate time recording
Crown in position“I”
1 START
2 STOP
Readthetime
3 RESTART
4 STOP
Readthetime
5 RESTART
6 STOP
Readthetime
 RESETTOZERO
You start a time recording by pressing the
button “A”. You interrupt the time recording
by pressing the button “A” a second time. You
then continue the time recording by actuating
the button “A”oncemore,andsoon.Stopped
times are added together in this way. Press the
button “B”toresetthehandstozero.
Using the unidirectional rotating bezel
(Primus Diver)
TheunidirectionalrotatingbezelonyourPrimus
Diver,withitsprecisionratchet,isforthemeas-
urementofdivetime.Forsafety,thebezelcan
only turn counter-clockwise. If it is accidentally
moved, it will indicate a longer elapsed dive
time.Atthestartofadive,turnthebezelsothat
thezeromarkisinfrontoftheminutehand(V1).
The minute hand will always show the number
of minutes that have elapsed since the dive
started(V2). 30 minutes have elapsed since the
start of the dive.
Important point
ThePrimusDiverisnotadiver’swatchfor
scuba diving. You should not wear the Primus
Diverforscubadivingunlessyouuseaprofes-
sional diving computer at the same time.

13
Aggregate time recording
Crown in position“I”
1 START
2 STOP
Readthetime
3 RESTART
4 STOP
Readthetime
5 RESTART
6 STOP
Readthetime
 RESETTOZERO
You start a time recording by pressing the
button “A”. You interrupt the time recording
by pressing the button “A” a second time. You
then continue the time recording by actuating
the button “A”oncemore,andsoon.Stopped
times are added together in this way. Press the
button “B”toresetthehandstozero.
Using the unidirectional rotating bezel
(Primus Diver)
TheunidirectionalrotatingbezelonyourPrimus
Diver,withitsprecisionratchet,isforthemeas-
urementofdivetime.Forsafety,thebezelcan
only turn counter-clockwise. If it is accidentally
moved, it will indicate a longer elapsed dive
time.Atthestartofadive,turnthebezelsothat
thezeromarkisinfrontoftheminutehand(V1).
The minute hand will always show the number
of minutes that have elapsed since the dive
started(V2). 30 minutes have elapsed since the
start of the dive.
Important point
ThePrimusDiverisnotadiver’swatchfor
scuba diving. You should not wear the Primus
Diverforscubadivingunlessyouuseaprofes-
sional diving computer at the same time.
ENGLISH

14
Maintenance and servicing of your Hanhart
chronograph
With your Hanhart chronograph from the
Primus collection, you have acquired a first
class precision timepiece.
To ensure that you have lasting enjoyment from
your chronograph, we recommend that every
veyearsyoutakeyourwatchtoanauthorized
Hanhart retailer for a careful service. If
necessary, he will send it to our Hanhart
customer service centre.
If your Hanhart chronograph has a leather
strap, we advise you not to wear it in water.
However, if the leather strap does happen
to come into contact with sea water or
chlorinated water, you should rinse it
thoroughly under a running tap and leave it to
dry naturally (not using a heater!). By the way:
Your leather strap is made from top-quality
calfskin, and darkening is a normal reaction in
a natural product.
We generally recommend that you wash
your chronograph thoroughly under running
tap water after contact with sea water or
chlorinated water.
International guarantee conditions
With your Hanhart chronograph, you have
acquired an outstanding example of the
watchmaker’s art: If any faults arise, in spite of
our rigorous inspections and quality standards,
weprovideyouwitha2-yearguaranteeagainst
material and manufacturing defects.
The following are not covered by the guarantee:
• Damageto/wearoutofleatheror
rubber straps
• Damagetosapphireglasses
• Damagecausedbydeliberatedestruction,
violence
• Damagecausedbyrepairsundertakenby
retailer, customer service centres or watch-
 makersnotauthorizedbyHanhart

15
Maintenance and servicing of your Hanhart
chronograph
With your Hanhart chronograph from the
Primus collection, you have acquired a first
class precision timepiece.
To ensure that you have lasting enjoyment from
your chronograph, we recommend that every
veyearsyoutakeyourwatchtoanauthorized
Hanhart retailer for a careful service. If
necessary, he will send it to our Hanhart
customer service centre.
If your Hanhart chronograph has a leather
strap, we advise you not to wear it in water.
However, if the leather strap does happen
to come into contact with sea water or
chlorinated water, you should rinse it
thoroughly under a running tap and leave it to
dry naturally (not using a heater!). By the way:
Your leather strap is made from top-quality
calfskin, and darkening is a normal reaction in
a natural product.
We generally recommend that you wash
your chronograph thoroughly under running
tap water after contact with sea water or
chlorinated water.
International guarantee conditions
With your Hanhart chronograph, you have
acquired an outstanding example of the
watchmaker’s art: If any faults arise, in spite of
our rigorous inspections and quality standards,
weprovideyouwitha2-yearguaranteeagainst
material and manufacturing defects.
The following are not covered by the guarantee:
• Damageto/wearoutofleatheror
rubber straps
• Damagetosapphireglasses
• Damagecausedbydeliberatedestruction,
violence
• Damagecausedbyrepairsundertakenby
retailer, customer service centres or watch-
 makersnotauthorizedbyHanhart
ENGLISH

16
PleasecontactanauthorizedHanhartretailer
if you require a repair or service. He will send
your chronograph to a Hanhart customer
service centre or he will carry out the
necessary service operations by arrangement
with our watchmakers.
This guarantee is only valid in conjunction with
the Hanhart Guarantee Card. You will receive
your international Hanhart Guarantee Card at
the time of purchasing your chronograph. It
must be completed and dated by the retailer.
Please keep your Guarantee Card in a safe
place.
Bedienungsanleitung
Chronographen Primus
HerzlichenGlückwunschzumKaufdieses
Hanhart-ChronographenausderKollektion
Primus. Ihr Hanhart-Chronograph wurde von
hochqualiziertenUhrmacherninkunstvoller
Handarbeitgefertigt.DamitSiemöglichst
langeFreudeanIhremChronographenhaben,
beachtenSiebittediefolgendenInformationen
und Hinweise.
IhreausgefüllteHanhart-Garantiekarte
erhaltenSiebeimKaufderUhrvonIhrem
Fachhändler.
WirwünschenIhnenvielFreudeundeinmalig
schöneStunden,MinutenundSekundenmit
Ihrem Chronographen von Hanhart.
Herzlichst,
Ihr Hanhart Team

17
PleasecontactanauthorizedHanhartretailer
if you require a repair or service. He will send
your chronograph to a Hanhart customer
service centre or he will carry out the
necessary service operations by arrangement
with our watchmakers.
This guarantee is only valid in conjunction with
the Hanhart Guarantee Card. You will receive
your international Hanhart Guarantee Card at
the time of purchasing your chronograph. It
must be completed and dated by the retailer.
Please keep your Guarantee Card in a safe
place.
Bedienungsanleitung
Chronographen Primus
HerzlichenGlückwunschzumKaufdieses
Hanhart-ChronographenausderKollektion
Primus. Ihr Hanhart-Chronograph wurde von
hochqualiziertenUhrmacherninkunstvoller
Handarbeitgefertigt.DamitSiemöglichst
langeFreudeanIhremChronographenhaben,
beachtenSiebittediefolgendenInformationen
und Hinweise.
IhreausgefüllteHanhart-Garantiekarte
erhaltenSiebeimKaufderUhrvonIhrem
Fachhändler.
WirwünschenIhnenvielFreudeundeinmalig
schöneStunden,MinutenundSekundenmit
Ihrem Chronographen von Hanhart.
Herzlichst,
Ihr Hanhart Team
DEUTSCH

Technische Daten und Besonderheiten
•UmgebautesmechanischesChronographen-
werk(bicompax,basierendaufKaliberETA/
Valjoux 7750)
•AutomatischerAufzug,Gangreserve
mind.42Stunden
•28‘000HalbschwingungenproStunde,4Hz
•28Steine
•SchwungmassemitHanhart-Logo
•Stunden-undMinuten-Anzeigeausder
Mitte,kleineSekundebei9Uhr
•Chronographen-Minutenzählerbei3Uhr
•Datumsanzeigebei6Uhr
•GehäuseEdelstahl,EdelstahlschwarzADLC-
beschichtetoderRoségold18ct.
•GravierteSeriennummer
•RoterDrücker(Alueloxiert)
•KannelierteLünette(PrimusDivereinseitig
drehbar)mitroterMarkierung(Alueloxiert)
•FlexibleBandanstöße
(Neigungswinkel45˚-50˚)
•VerschraubteKrone
•Konvexes,innenentspiegeltesSaphirglas

19
Technische Daten und Besonderheiten
•UmgebautesmechanischesChronographen-
werk(bicompax,basierendaufKaliberETA/
Valjoux 7750)
•AutomatischerAufzug,Gangreserve
mind.42Stunden
•28‘000HalbschwingungenproStunde,4Hz
•28Steine
•SchwungmassemitHanhart-Logo
•Stunden-undMinuten-Anzeigeausder
Mitte,kleineSekundebei9Uhr
•Chronographen-Minutenzählerbei3Uhr
•Datumsanzeigebei6Uhr
•GehäuseEdelstahl,EdelstahlschwarzADLC-
beschichtetoderRoségold18ct.
•GravierteSeriennummer
•RoterDrücker(Alueloxiert)
•KannelierteLünette(PrimusDivereinseitig
drehbar)mitroterMarkierung(Alueloxiert)
•FlexibleBandanstöße
(Neigungswinkel45˚-50˚)
•VerschraubteKrone
•Konvexes,innenentspiegeltesSaphirglas
DEUTSCH

20
•VerschraubterGehäusebodenmitinnen
entspiegeltemSaphirglas
•MitSuper-LumiNova®beschichtete, lumines-
zendierendeZiffern,IndexeundZeigerjenach
Modell
•Wasserdichtbis10bar/100m
•Durchmesser44mm
•Gehäusehöhe15mm
Funktionen Ihres Hanhart-Chronographen
DieDatums-Schnellkorrekturistnichtmöglich
zwischen20Uhrund2Uhr.
INormaleGangstellungderverschraubten
 Krone
II Handaufzug
III SchnellkorrekturdesDatums
IIII ZeiteinstellungderUhrmitSekundenstopp
 undDatumsschaltungumMitternacht
