Hannlomax HX-109CR User manual

PLL ALARM CLOCK RADIO With PROJECTOR
And USB PORT FOR CHARGING
Model : H -109CR
INSTRUCTION MANUAL
Note: Please read and follow these instructions before using your unit.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the anufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including a plifiers)
that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for
replace ent of the obsolete outlet.
10. Protect the power cord fro being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit fro the apparatus.
11. Only use attach ents/accessories specified by the anufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the anufacturer, or sold
with the apparatus. When a cart is used, use caution when oving the cart/apparatus
co bination to avoid injury fro tip-over.
13. Unplug this apparatus during lightning stor s or when unused for long periods of ti e.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been da aged in any way, such as power-supply cord or plug is da aged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or oisture, does not operate nor ally, or has been
dropped.
- 1 -
15. Grounding or Polarization – This product ay be equipped with a polarized alternating-current line plug (a plug having
one blade wider than the other). This plug will fit into the power outlet only one way. This is a safety feature. If you are
unable to insert the plug fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not defeat the safety purpose of the polarized plug.
16. Alternate Warnings – This product is equipped with a three-wire ground-type plug, a plug having a third (grounding)
pin. This plug will only into a grounding-type power outlet. This is a safety feature. If you are unable to insert the plug
into the outlet, contact your electrician to replace your obsolete outlet. Do not defeat the safety purpose of the
grounding-type plug.
17. Ventilation – Slots and openings in the cabinet are provided for ventilation and to ensure reliable operation of the
product and to protect it fro overheating, and these openings ust not be blocked or covered. The openings should
never be blocked by placing the product on a bed, sofa, rug, or other si ilar surface. This product should not be
placed in a built-in installation such as a bookcase or rack unless proper ventilation is provided or the anufacturer’s
instructions have been adhered to.
18. The MAINS plug or an appliance coupler is used as the disconnect device, the disconnect device shall re ain readily
operable.
19. 回: CLASS II apparatus with double insulation, and no protective earth provided.
20. Caution Marking and rating plate was located at botto enclosure of the apparatus.
21. WARNING : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or oisture.
22. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall
be placed on apparatus.
23. The ains plug is used as disconnect device. The ains plug of apparatus should not be obstructed OR should be
easily accessed during intended use. To be co pletely disconnect the power input, the ains plug or apparatus shall
be disconnected fro the ains.
24. Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
25. Excessive sound pressure fro earphones and headphone can cause hearing loss.
FCC NOTICE
This equip ent has been tested and found to co ply with the li its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
li its are designed to provide reasonable protection against har ful interference in a residential installation. This equip ent generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, ay cause har ful interference to
radio co unications.
However, there is no guarantee that interference will not occur in a particular installation. If this equip ent does cause har ful interference to
radio or television reception, which can be deter ined by turning the equip ent off and on, the user is encouraged to try to correct the
interference by one or ore of the following easures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equip ent and receiver.
– Connect the equip ent into an outlet on a circuit different fro that to which the receiver is needed.
– Consult the dealer or an experienced radio/TV technician for help.
This device co plies with part 15 of the FCC Rules. Operation is subject to the following two conditions :
(1) This device ay not cause har ful interference, and (2) this device ust accept any interference received, including interference that ay
cause undesired operation.
SPECIFICATIONS
Frequency Range: FM 87.5 – 108 MHz
Power Supply: AC 100V-240 ~ 60/50 Hz
Rated Output DC5V 1.5A
Back-Up Battery: 2 pc. UM4 ‘AAA’ size
Specifications are subject to change without prior notice.
- 2 -

1
P
ROJECTOR
ON/OFF
BUTTON
1
4
DISPLAY
2
P
ROJECTOR
180°
FLIP BUTTON
1
5
AL1 B
UZZER INDICATOR
3
MIN/

BUTTON
1
6
AL1 R
ADIO INDICA
TOR
4
HOUR
/

BUTTON
1
7
AL2 B
UZZER INDICATOR
5
DIMMER
BUTTON
1
8
AL2 R
ADIO INDICATOR
6
AL2/VOL
−
BUTTON
1
9
PM INDICATOR
7
AL1/VOL
+
BUTTON
20
DC IN JACK
8
CLK/MEM
BUTTON
2
1
AUX
-
IN JACK
9
SNOOZE/SLEEP
BUTTON
22
USB
CHARGING PORT
10
/
SOURCE
/AL.OFF
BUTTON
23
FM ANTENNA
11
PROJECTOR WHEEL
24
BATTERY COMPARTMENT
12
PROJECTOR LENS
25
SPEAKER
13
PROJECTION FOCUS KNOB
CONNECTING THE UNIT TO POWER
Plug one end of the AC adaptor into the DC power Input, and then plug the other end into AC wall outlet. Before switching
on the unit, ake sure that the voltage of your electricity supply is the sa e as that indicated on the rating plate.
BATTERY BACKUP
Insert two pieces UM-4 batteries into the battery co part ent. Be sure to observe the proper polarity (the "+" and "-" signs)
as indicated inside the battery co part ent.
In case of power failure or interrupted AC power, the current ti e and alar ti e settings, the stored radio stations are
preserved in the e ory of the unit by eans of battery back-up function.
SETTING THE CLOCK
1. When the unit is OFF, press and hold the CLK/MEM button for about 1 second, the ti e will begin to flash on the LED
display.
2. Press the HOUR// button to adjust the hour.
3. Press the MIN/ button to adjust the inute.
4. When the correct ti e is selected, press the CLK/MEM button again to confir .
SETTING THE ALARMS
1. When the unit is OFF, press the AL1/VOL+ or AL2/VOL− button. The ALARM ti e will begin to flash on the LED display.
2. Press the HOUR/ button to adjust the alar hour.
3. Press the MIN/ button to adjust the alar inute.
4. When the correct ti e is selected, press the AL1/VOL+ or AL2/VOL− button to confir .
5. Press the AL1/VOL+ or AL2/VOL− button to select the ALARM sound ode - buzzer or currently set radio station. The
alar buzzer or radio indicator will light up.
- 3 -
SNOOZE FUNCTION
1. Whenever the alar (radio or buzzer) activates, it can be te porarily suspended for a short period of 9 inutes by
pressing the SNOOZE/SLEEP button once.
2. The buzzer or radio will then auto atically activate again after the 9 inutes SNOOZE period has ended.
3. This procedure can be repeated for up to approxi ately one hour.
TURN OFF THE ALARM
When the Alar activate, press the /SOURCE/AL.OFF button to turn off the Alar .
LISTENING TO THE FM RADIO
1. Press the /SOURCE/AL.OFF button to select FM radio ode.
2. Press the HOUR/ button or MIN/ button step by step to tune to the desired radio stations.
3. Press and hold the HOUR/ button or MIN/ buttons for approx. 1 second, it will start to search the next radio station
in the direction of the search. The search operation si ply finds stations with strong signals. Stations with weak
reception can only be tuned in anually.
ANTENNA
For best reception, fully extend the FM wire antenna to receive FM stations.
SAVING A RADIO STATION TO THE MEMORY
1. Tune the radio to the desired station.
2. Press and hold the CLK/MEM button for approx. 1 second, the LED display will show P01 and flash, the radio station
will stored in the e ory..
3. Up to 10 FM radio stations can be stored in the e ory.
TO LISTEN TO A SAVED RADIO STATION
1. Press the /SOURCE/AL.OFF button to select FM radio odel
2. Press the CLK/MEM button to select the stored radio station.
SLEEP TO MUSIC FUNCTION
1. This function allows you to listen to the radio while you fall asleep.
2. Press the SNOOZE/SLEEP button, the display will show the default sleep ti e of 90 inutes
3. Press the SLEEP button again to adjust the desired sleep ti e.
4. The options are 90-80-70-60-50-40-30-20-10- in. or OFF
5. Now you can enjoy listening to the radio for the pre-set period of sleep ti e.
6. After this pre-set ti e has elapsed, the unit will switch off auto atically.
AU IN CONNECTION
1. Insert one side of the audio cable (requires 3.5 stereo plug, not supplied) into the line-out jack or phones jack on
your MP3 player or audio device and the other side to the aux-in jack on the unit.
2. Press the /SOURCE/AL.OFF button to select AUX ode, AUX will display in the LED display for a few seconds.
3. Turn on your MP3 player and follow the playback instruction.
4. To stop this function, si ply turned off your MP3 player.
CHARGE YOUR DEVICES
Connect the standard size end of a USB cable (not included) to the USB port on the unit and connect the other end to the
charging port of your device. The unit contains one USB port with 5V ~ 1A charging.
Remarks: So e devices ay not support USB charging or ay require a higher power rating than this product provides.
Observe the charging status on your device. Ensure your device is working properly before atte pting to charge. Charging
function ay not be supported for all phones or electronic devices
PROJECTION
1. Press the PROJECTION ON/OFF button to turn on the PROJECTION function.
2. The projector displays the ti e via a bright red projection light onto a wall, ceiling or any surface for viewing in a
darkened roo .
3. Rotate the Projector wheel to point the Projector lens to the desired direction. The projector lens can vertically swivel
180° so that you ay view the TIME fro different position. .
4. If the projected i age is out of focus, use the PROJECTION FOCUS knob to adjust the i age until the projection is in
focus.
5. To turn off the PROJECTION function, press the PROJECTION ON/OFF button again.
Notes
1. Do not stare into the lens directly.
2. The projector function cannot be used unless the clock has been set.
3. Certain walls and ceilings ay not display the projection properly.
4. Don’t rotate the projector wheel beyond its li its, it ay be da aged.
