Hans Grohe Axor Carlton 17133 1 Series User manual

Carlton
17133XX1 Carlton
17233XX1
Terrano
37133XX1
Terrano
37134XX1
Installation / Warranty

2
3
Carlton
17133XX1/17233XX1
Terrano
37133XX1
Terrano
37134XX1

2
3
Technical data
Hole size in deck:
Spout
Minimum: 1 1/4"
Maximum: 1 5/8"
Valve
Minimum: 1 1/8"
Maximum: 1 1/4"
Operating pressure: max. 147 psi
Recommended operating press.: 14.7 - 72.5 psi
Test pressure: 232 psi
Hot water temperature: max. 176° F
Recommended hot water temp.: 149° F
Assembly
1. Flush pipe lines thoroughly.
2. Mount spout and valves onto lavatory.
3. Screw pop-up rod onto the pop-up rod exten-
ding from faucet.
4. Connect flex hose with valves.
5. Attach handle trim and connect pop-up assem-
bly. The hot water supply should be connected
to the left and the cold on the right.
6. Turn on angle stops and check function of
faucet.
7. Check all connections for leakage.
Major pressure differences between cold
and hot water in supply should be avoi-
ded and balanced.

4
5
Spare parts
1 Handle for cold water 17291XXX
2 Handle for warm water 17292XXX
3 Stop unit for cold water 96765000
4 Stop unit for warm water 96766000
5 Aerator 13085000
6 Lift rod 94028XXX
7 Tube 94071001
8 Fixation cpl. 94138000
9 Handle for cold water 37291XXX
10 Handle for warm water 37292XXX
11 Aerator 96336XXX
12 diverter knob 96335XXX
13 Fixation cpl. 13961000
14 Spout 96521XXX
15 Lift rod 94083XXX
16 Fixation cpl. 96016000
XXX = Color code:
Carlton - 000 chrome
- 090 chrome/gold
- 930 polished brass
Terrano - 000 chrome
- 810 satinox
4
13
12
10
9
11
16
7
15
11
14
1
3
2
6
5
7
8
7
3
4

4
5
Cleaning Recommendation for Hansgrohe Products
Modern faucetry and shower products utilize a combination of materials to comply with the needs of the
market with regard to design and functionality.
To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper
treatment is not covered under the Hansgrohe warranty.
Cleaning Materials for Faucets and Showers
• To remove lime scale, use only products made specifically for that purpose. Always follow the
manufacturer’s instructions when using.
• Do not use cleaners that contain hydrochloric, formic, acetic, or phosphoric acids, as these will
cause considerable damage to finishes and to plastic components.
• Never mix cleaning materials.
• Never use cleaners containing abrasives. Do not use abrasive cleaning cloths, pads, or sponges.
Cleaning Procedures
• Clean your faucets and shower products as and when required. Regular cleaning will prevent
scale buildup and water spotting.
• Follow the label instructions. Do not allow any cleaner to remain on the product for longer than
necessary.
• When using spray cleaners, spray first onto a sponge or cloth – do not spray directly onto the
product.
• After cleaning, rinse thoroughly with clear water to remove any cleaner residue.
Important
• Soap and shampoo residue can also cause damage to the product. Rinse well with clean water
after use.
• If the surface is already damaged, harsh cleaning materials will cause further damage.

6
7
Limited Lifetime Consumer Warranty
This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. („Hans-
grohe“). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United
States after March 1, 1996, and installed in either the United States or Canada.
WHO IS COVERED BY THE WARRANTY
This warranty extends to the original consumer purchaser only.
WHAT IS COVERED BY THE WARRANTY
This warranty covers only your Hansgrohe manufactured product. Hansgrohe warrants this product against
defects in material or workmanship as follows: Hansgrohe will repair at no charge for parts only or, at its
option, replace any product or part of the product which proves defective because of improper workman-
ship and/or material, under normal installation, use, service and maintenance. If Hansgrohe is unable
to provide a replacement and repair is not practical or cannot be timely made, Hansgrohe may elect to
refund the purchase price in exchange for the return of the product.
LENGTH OF WARRANTY
Replacement or repaired parts of products will be covered for the term of this warranty as stated in the
following two sentences. If you are a consumer who purchased the product for use primarily for personal,
family, or household purposes, this warranty extends for as long as you own the product and the home
in which the product is installed. If you purchased the product for use primarily for any other purpose,
including, without limitation, a commercial purpose, this warranty extends only (i) for 1 year, with respect
to Interaktiv and Retroaktiv products, and (ii) for 5 years, with respect to AXOR, ShowerPower and Pharo
products.
THIS WARRANTY DOES NOT COVER, AND HANSGROHE WILL NOT PAY FOR:
A. Conditions, malfunctions or damage not resulting from defects in material or workmanship.
B. Conditions, malfunctions or damage resulting from (1) improper installation, improper maintenance,
misuse, abuse, negligence, accident or alteration, or (2) the use of abrasive or caustic cleaning agents
or „no rinse“ cleaning products, or the use of the product in any manner contrary to the product
instructions.
C. Labor or other expenses for the disconnection or return of the product for warranty service, or for
installation or reinstallation of the product.
D. Accessories or related products not manufactured by Hansgrohe.
TO OBTAIN WARRANTY SERVICE
Contact your Hansgrohe retailer, or write to Technical Service at:
Hansgrohe Inc.
1492 Bluegrass Lakes Parkway
Alpharetta GA 30004
Or, call Hansgrohe toll-free at [phone].

6
7
In requesting warranty service, you will need to provide
1. The sales receipt or other evidence of the date and place of purchase.
2. A description of the problem.
3. Delivery of the product or the defective part, postage prepaid and carefully packed and insured, to
Hansgrohe Inc. 1492 Bluegrass Lakes Parkway, Alpharetta, Georgia 30004, Attention: Technical
Service, if required by Hansgrohe.
When warranty service is completed, any repaired or replacement product or part will be returned to you
postage prepaid.
EXCLUSIONS AND LIMITATIONS
REPAIR OR REPLACEMENT (OR, IN LIMITED CIRCUMSTANCES, REFUND OF THE PURCHASE
PRICE) AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE PUR-
CHASER. HANSGROHE NEITHER ASSUMES NOR AUTHORIZES ANY PERSON TO CREATE
FOR IT ANY OBLIGATION OR LIABILITY IN CONNECTION WITH THIS PRODUCT.
HANSGROHE SHALL NOT BE LIABLE TO PURCHASER OR ANY PERSON FOR ANY INCI-
DENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGES, ARISING OUT OF BREACH OF THIS
WARRANTY OR ANY IMPLIED WARRANTY (INCLUDING MERCHANTABILITY).
Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may have other rights which vary from State to
State.
You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply
before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
PRODUCT INSTRUCTIONS AND QUESTIONS
Upon purchase or prior to installation, please carefully inspect your Hansgrohe product for any damage or
visible defect. Prior to installing, always carefully study the enclosed instructions on the proper installation
and the care and maintenance of the product. If you have questions at any time about the use, installa-
tion, or performance of your Hansgrohe product, or this warranty, please call or write to us at the toll-free
number and address printed above.
