Hans Grohe AXOR Edge 46431 7 Series Manual

INSTALLATION
ZH ⁄ 用户手册 ⁄ 组装说明 02
EN ⁄ Instructions for use ⁄ assembly instructions 03
Lesezeichen
中文 02
English 03
AXOR Edge
46430007 ⁄ 46431XX7

02
安装 (参见第页 04)
ZH
安全技巧
装配时为避免挤压和切割受伤，必须戴上手套。
本产品只允许作为洗浴、卫生和洁身之用。
必须避免让身体敏感部位 (如眼睛) 接触到莲蓬头
喷水。必须保持莲蓬头与人头之间有足够的距
离。
该产品不得作扶柄使用。必须安装单独的扶柄。
冷热水管间过大的压力差必须予以平衡。
安装提示
⁄ 安装前必须检查产品是否受到运输损害。 安装后
将不认可运输损害或表面损伤。
⁄ 管道和阀门必须根据通用标准进行安装、冲洗和
检查。
⁄ 请遵守当地国家现行的安装规定。
技术参数
工作压强： 最大 1 MPa
推荐工作压强： 0,1 - 0,5 MPa
测试压强： 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
热水温度： 最大 60°C
热力消毒: 70°C ⁄ 4 分钟
⁄ 自动防止回流
⁄ 该产品专为饮用水设计！
符号说明
请勿使用含有乙酸的硅胶！
调节 (参见第页 08)
热水温度调节。如果使用即热式喷头，则不
建议安装热水阀门。
保养 (参见第页 14)
单向阀必须在符合国家或当地的法律的情况
下按照EN 806-5定期检查 (至少一年一次) 。
大小 (参见第页 13)
流量示意图 (参见第页 13)
 手持花洒
 浴缸出水口
备用零件 (参见第页 16)
XX = 颜色代码
00 = 镀铬
33 = Polished Black Chrome
99 = Polished Gold-Optic
清洗 (参见第页 10)
操作 (参见第页 09)

03
ASSEMBLY (see page 04)
EN
SAFETY NOTES
Gloves should be worn during installation to prevent
crushing and cutting injuries.
The product may only be used for bathing, hygienic
and body cleaning purposes.
Do not allow the streams of the shower touch sensitive
body parts (such as your eyes). An adequate distance
must be kept between the shower and you.
The product may not be used as a holding handle. A
separate handle must be installed.
The hot and cold supplies must be of equal pressures.
INSTALLATION INSTRUCTIONS
⁄ Prior to installation, inspect the product for transport
damages. After it has been installed, no transport or
surface damage will be honoured.
⁄ The pipes and the fixture must be installed, flushed and
tested as per the applicable standards.
⁄ The plumbing codes applicable in the respective
countries must be observed.
TECHNICAL DATA
Operating pressure: max. 1 MPa
Recommended operating pressure: 0,1 - 0,5 MPa
Test pressure: 1,6 MPa
(1 MPa = 10 bar = 147 PSI)
Hot water temperature: max. 60°C
Thermal disinfection: 70°C ⁄ 4 min
⁄ Safety against backflow
⁄ The product is exclusively designed for drinking water!
SYMBOL DESCRIPTION
Do not use silicone containing acetic acid!
ADJUSTMENT (see page 08)
To adjust the hot water limiter. Using a hot water
limiter in combination with a continuous flow
water heater is not recommended.
MAINTENANCE (see page 14)
The check valves must be checked regularly
according to EN 806-5 in accordance with
national or regional regulations (at least once a
year).
DIMENSIONS (see page 13)
FLOW DIAGRAM (see page 13)
 Hand shower
 Bath Spout
SPARE PARTS (see page 16)
XX = Colors
00 = Chrome Plated
33 = Polished Black Chrome
99 = Polished Gold-Optic
CLEANING (see page 10)
OPERATION (see page 09)

04
15487187
1
2SW 17 mm 3SW 30 mm
4 5
1.
3.
SW 24 mm
(14 Nm)
1.
2.
2.
Montage

05
3.
1.
1.
6 7
2.
2.3.
8
SW 27 mm
9
10 11
SW 3 mm
(4 Nm) SW 3 mm
(4 Nm)
2.
SW 3 mm
(4 Nm)
1.
1.
2.
3. 4.
Montage

06
13 14
1615
1.
2.
3.
(1,5 Nm)
(1 Nm)
1.
2.
5.
6.
4.
12 1.
2.
3.
Montage

07
1.
2.
3. 1918
17
Montage

60 °C 10 °C 0,3 MPa
08
65
34
36°C
38°C
43°C
60°C
55°C
50°C
1 2
SW 3 mm
4 x
SW 3 mm
(5 Nm)
Justierung

09
关 ⁄ close开 ⁄ open
热 ⁄ hot
max. 1,45 m
冷 ⁄ cold
1.
2.
Bedienung

10
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
⁄
Hansgrohe
Hansgrohe
www.hansgrohe-int.com/guarantee
QUICKCLEAN
QuickClean
Reinigung
QUICK
CLEAN
QUICK
CLEAN

11
CLEANING RECOMMENDATION FOR
HANSGR
OHE PRODUCTS
T
oday, modern sanitary and kitchen tapware, showers,
accessories,
washstands, tubs and radiators consist of very
differ
ent materials to comply with the needs of the market
w
ith regard to design and functionality.
T
o avoid damage and reclamations, it is necessary to
consider
certain criteria when cleaning.
W
ITH REGARD TO CARING FOR THE
HANSGR
OHE PRODUCTS, THE FOL-
LO
WING MUST IN PRINCIPLE BE
HE
EDED:
⁄ Only use cleaning material which is explicitly provided
for this type of application.
⁄ Never use cleaning materials, which contain hydrochlo-
ric acid, formic acid, chlorine pale lye or acetic acid, as
they cause considerable damage.
⁄ Phosphorus acidic cleaners are only conditionally
applicable.
⁄ Mixing cleaning agents is not permitted, generally.
⁄ Never use cleaning materials or appliances with an
abrasive effect, such as unsuitable cleaning powders,
sponge pads or micro fibre cloths.
⁄ The instructions of the cleaning agent manufacturers
have to be followed absolutely.
⁄ Cleaning has to be carried out with a specified cleaner
dosage, contact time, object-related and adapted to the
needs.
⁄ The building up of calcifications has to be removed by
cleaning regulary.
⁄ When using spray cleaners, spray the cleaning solution
onto a soft cloth or sponge, never directly onto the
Hansgrohe products, as the atomised spray could enter
openings and gaps in the Hansgrohe products and
cause damage.
⁄ After cleaning rinse thoroughly with clean water to
remove any cleaner residue.
⁄ The use of steam cleaners is not permitted. The high
temperatures can damage the products.
Important
Residues of toiletries such as liquid soaps, shampoos and
shower gels, hair dyes, perfumes, aftershave and nail
varnish can also cause damage.
Here too: Carefully rinse with water after use to remove
residues.
Likewise, do not store any cleaning agents or chemicals
under the products, for example in a vanity unit, as the
vapours may damage the products.
The damage of already damaged surfaces will deteriorate
under the effect of the cleansers.
Components with damaged surfaces must be
exchanged, otherwise there could be an injury
danger.
Damage caused by improper treatment will not be covered
by our guarantee.
WARRANTY
Hansgrohe guarantees to the consumer that this product is
free of production faults. If evertheless any defect is
detected within 5 years from date of purchase, Hansgrohe
will remedy this defect free of charge. You will find the
conditions and details of this guarantee at
www.hansgrohe-int.com/guarantee. Please contact your
contracting party to claim your rights under this guarantee.
This guarantee does not affect the customer‘s rights under
the respective national legislation.
QUICKCLEAN
The QuickClean cleaning function only needs a small
manual rub over to remove the lime scale from the spray
channels.
Reinigung
QUICK
CLEAN
QUICK
CLEAN

12
3
5 6
> 1 min
21
4
94246000

13
AXOR Edge
46430007 ⁄ 46431XX7
bar
4,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
5,0
0,45
0,00
0,05
0,10
0,15
0,20
0,25
0,30
0,35
0,40
0,50
5,50,55
6,00,60
036912151821242730
MPa
00,1 0,2 0,3 0,4 0,5
Q = l/min
Q = l/sec
1
2
AXOR Edge
46430007 ⁄ 46431XX7
1
2
44
72
72
108
7260 216
110190
33
230
210
230
266
65
172
145
Maße ⁄ Durchflussdiagramm

14
1.
2.
21
3 4
5 6
1. 2.
Wartung

15
78
10
1.
2.
3. 11
9
Wartung

16
98119000
(9x2)
98397000
(22x1,2)
98217000
(9x2,5)
98189000
(14x2,5)
98183000
(23x2,5)
92602000
(20x2)
93584XX0
93583XX0
93585000 (46430007)
93586XX0 (46431X X 7)
96775000
93592000
97660000
93590XX0
93587XX0
98447000
95704000
95704000
95704000
M6x8 98388000
(24x2)
98193000
(32x2)
98200000
(52 x1, 5)
96942000
94246000
93339000
28532XX7
93582XX0
93591XX0
93506XX0
96456000
93185000
95008000
AXOR Edge
46430007 ⁄ 46431XX7
Serviceteile

17

18

19

AXOR ⁄ Hansgrohe SE
Auestraße 5–9
77761 Schiltach
Deutschland
[e-mail]
axor-design.com 10 ⁄ 2 021 9.06723.52
