Hans Grohe Starck 10933 1 Series Installation guide

Installation Instructions / Warranty
QUATTRO FOUR WAY DIVERTER
Trim sets
Starck
10933XX1
Carlton
17933XX1
Carlton
17935XX1
Phoenix
17944XX1
Phoenix
17945XX1
Steel
35933801
Allegroh
36933XX1
Terrano
37933XX1
Terrano
37930XX1
Uno
38933XX1
Citterio
39920XX1
Citterio
39925XX1
Mondial/
Metris/
Elegance/
Sportive
15935XX1
Rough-in Ref. No.: 13932181

2
Sleeve and escutcheon assembly
1. Remove the cover
2. Seal around the rough-in with waterproof
bathroom sealant
3. Push the guide ring into the body of the rough-in,
only necessary for Starck10933XX1, Phoenix
17944XX1/17945XX1, Terrano 37930XX1/
37933XX1, Uno 38933XX1 and Citterio
39920XX1 / 39925XX1.
4. Install the trim sleeve and the escutcheon.

3
Handle assembly
Starck 10933XX1
Terrano 37930XX1 / 37933XX1
1. Push the handle onto the shaft.
2. Fix the screw.
3. Cover the hole by the plastic cap.
Carlton 17933XX1 / 17935XX1
Phoenix 17944XX1 / 17945XX1
1. Push the handle onto the shaft.
2. Fix the screw.
3. only Phoenix cross handle: Cover the hole by the
plastic cap.
Steel 35933801
Allegroh 36933XX1
Uno 38933XX1
Mondial / Metris / Elegance / Sportive15935XX1
1. Lock the screw by hand only three turns.
2. Snap on the handle.
3. Fix the screw.
4. Cover the hole by the plastic cap.

4
Citterio 39920XX1 / 39925XX1
1. Install the handle fixation and lock the screw.
2. Snap on the handle.
3. Fix the hollow set screw with a hex wrench 2 mm.
1 escutcheon Starck 94356XX0
escutcheon Starck/Carlton/Phoenix/Steel/Allegroh/Terrano/Citterio/Uno/
Mondial/Metris/Elegance/Sportive 13936XX0
2 handle Starck 10993XX1
2.1 screw-cover Starck 96540XX1
3 sleeve Starck/Carlton/Phoenix/Steel/Allegroh/Terrano/Citterio/Uno/
Mondial/Metris/Elegance/Sportive 96242XXX
sleeve Steel 96242XXX
4 cross handle Carlton 17993XX1
5 lever handle Carlton 17298XX1
6 handle Steel 35993801
6.1 screw-cover Steel/Allegroh/Uno/Mondial/Metris/
Elegance/Sportive/Phoenix cross handle 96541001
7 handle Allegroh
Mondial/Metris/Elegance/Sportive 36993XX1
8 cross handle Terrano 37995XX1
8.1 screw-cover Terrano 96542XX0
9 lever handle Terrano 37993XX1
9.1 screw-cover Terrano 96543XX0
10 handle Uno 38993XX1
11 lever handle Phoenix 96632XX1
12 cross handle Phoenix 96792XX1
13 lever handle Citterio 39993XX1
14 cross handle Citterio 39995XX1
XX = Color code: 00 chrome
09 chrome/gold
42 platin
80 steel
81 satinox
88 satin chrome
Extension Set 1 1/2" 92630000 (If needed, please order separately)
Spare parts

5
8
8.1
9
9.1
10
6.1
5
6
6.1 7
6.1
1
2
2.1
4
11
12
6.1
3
13 14

6
