hanshow Nebular Series User manual

Hanshow Nebular Series Product Manual
V2.0.0
HS-ESL-EPDN0001
For more information, visit our website at: https://www.hanshow.com

HanshowNebular Series Product Manual
IHanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
STATEMENT
This document and all its contents contained remain the proprietary material of
Hanshow Technology Co., Ltd. (Hanshow) and are protected by Chinese laws and
applicable international conventions on copyrights. Any reproduction, transmission,
disclosure, revision, modification or use otherwise of this document or the whole or
part of its contents, in whatever form and by whatever means, is not permitted without
prior express written authorization from Hanshow. Offenders will be liable for any and
all damages caused by their offence hereof and will be subject to all remedies that
Hanshow is entitled to seek under applicable laws.

HanshowNebular Series Product Manual
IIHanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
ABOUT THE MANUAL
Thisdocument describes Nebular series, including features, specification, package
and precautions, etc.
Please read this manual carefully before using the device in first, retain the manual for
subsequent use or for the next owner. If the instructions contained in this manual are
insufficient to resolve issues that occur during device operation or maintenance,
please contact Hanshow Technical Customer Service Center (China: 400-0365-305;
Netherlands: 0800-022-5037; Belgium: 0800-71-335; France: 0800-91-7602; Thailand:
1800-011-185) directly, we will provide you with multi-channel technical services.
TARGET USERS
This document provides engineers with necessary data and related guidelines of
Nebular series. Users have to master the basic knowledge on communication and
network and so on. This manual is applicable for the below engineers:
Testing Engineer
Technical Support Engineer
After Sales Engineer
Installation Engineer

HanshowNebular Series Product Manual
IIIHanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
SYMBOL DESCRIPTION
Icon
Description
Information indicated with this icon should be paid special attention and attached
great importance by the reader.
Information indicated with this icon is the explanation on the formal text for the
readers to comprehend the text better.
[X-X]
It means special noun definition is provided here.
EXPLANATION OF TERMS
Acronym
Expanded form
Description
PriSmart
PriSmart Smart Retail System
Manage all store product data and issue price
update command, as well as support multi-
store management.
ESL-Working
ESL-Working System
Manage all the APs and ESLs in store, and
ESL-Working 3.0 and above supports multi-
store management.
ESL Controller
ESL Controller
Also called AP that is used for data
interaction between ESL-Working and ESL
Controller.
ESL
Electronic Shelf Label
Used for displaying product information like
promotion information, price and grade, etc.

Table of Contents
IVHanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
Table of Contents
1 Overview .................................................................................................................................................1
1.1 System architecture..........................................................................................................................1
1.2 Features ...........................................................................................................................................2
2 Product view............................................................................................................................................3
2.1 Product appearance .........................................................................................................................3
2.2 Dimensions.......................................................................................................................................5
3 Hardware performance ...........................................................................................................................9
3.1 Specifications ...................................................................................................................................9
3.2 NFC specification ...........................................................................................................................11
3.3 Identifying your ESLs......................................................................................................................11
3.4 Product nameplate .........................................................................................................................12
4 Packaging and accessories ..................................................................................................................13
4.1 Packaging.......................................................................................................................................13
4.2 Product accessories .......................................................................................................................14
5 Application scenarios ............................................................................................................................15
6 Precautions ...........................................................................................................................................16
6.1 Transportation considerations ........................................................................................................16
6.2 Precautions for use.........................................................................................................................16
7 FCC ID warning.....................................................................................................................................17
7.1 Warning for nameplate ...................................................................................................................17
7.2 Warning for product manual ...........................................................................................................17
8 IC STATEMENT....................................................................................................................................18

HanshowNebular Series Product Manual
1HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
1 Overview
The Nebular series isHanshow’s newest generation Electronic Shelf Labels (ESLs).
Theyadopte-ink screen to achievepage switching, light flashing,pricing and so
onbased on 2.4GHz wireless communication. With ultra-thin, extended life and high-
definition visual effects, theNebular series widely servestraditional retail, new retail,
department stores and fashion, pharmacies, culture and entertainment, etc.
1.1 System architecture
Hanshow ESL system includes ESLs, ESL Controller,ESL-Working,
PriSmart/ShopWeb, Database, Integrationserver, CloudMonitorand Handheld
Terminal (PDA), as shown inFigure 1-1. Specifically, theESLsare used for
electronicallydisplaying product informationsuch as name and price, and services
available for customers.
Figure 1-1Hanshow ESL system architecture

HanshowNebular Series Product Manual
2HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
1.2 Features
The features of Nebular series are as follows:
Nebular ESLs come in 8 ESL sizes:1.54”, 2.13”, 2.66”, 2.9”, 3.5”, 4.2”, 5.83”and
7.5”.
Display colors include: BWR (Black-White-Red) orBWY (Black-White-Yellow)
display (OnlyBW(Black-White) display for freezer ESLs).
Operating frequency band:2402MHz ~ 2480MHz.
IP68 waterproof and dustproofdesign.
Built-in LED indicator: 7-colordisplayassists in product location, promotion
reminder,out-of-stockreminder, lowpower reminder, etc.
Embedded NFC chip:Supports operations from NFC-enabled devices such as
mobile phone, PDA and remote controlforbinding/unbinding, flashing,page
switching and so on.
The freezer ESLs come in three sizes:2.13”, 2.66”and3.5” thatfunction in
temperature -25℃~ 0℃.
Nebular ESLs supportmultiple functions, including binding/unbinding, updating,
instantflashing, multi-page storage, page switching, geolocation, temperature
collection,NFC function and so on.
SupportsAES-128 encryption.
SupportsOTA(Over-The-Air) upgrade.

HanshowNebular Series Product Manual
3HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
2 Product view
This chapter describes Nebular series’ appearance and composition.
2.1 Product appearance
Figure 2-1shows Nebularfamily.
Figure 2-1Nebular family

HanshowNebular Series Product Manual
4HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
Each section of Nebular and its relative descriptionis shown in Figure 2-2 and Table
2-1.




Figure 2-2 Key area of Nebular
Table 2-1Each area description of Nebular
No.
Name
Description
1
LED indicator
Supports 7-color flashing.
2
Display area
Supports BWR or BWY display on E-ink screen.
Displaytext, images, barcode, QR code and others.
Product informationdisplay such as name, price, origin, unit,
grade, phone number, barcode, QR code, etc.
Supportscustomizable display position and fontsize.
Supports 8-pagestorage and page switchfunctionality.
3
Nameplate
Product information mark, including Model, S/N and certifications.
4
Barcode area
18-digit barcode used for product binding and maintenance.

HanshowNebular Series Product Manual
5HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
2.2 Dimensions
This sectioncoversthe dimensions of Nebular series.
Figure 2-31.54”dimension
Figure 2-4 2.13” dimension

HanshowNebular Series Product Manual
6HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
Figure 2-52.66”dimension
Figure 2-62.9”dimension

HanshowNebular Series Product Manual
7HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
Figure 2-73.5” dimension
Figure 2-84.2”dimension

HanshowNebular Series Product Manual
8HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
Figure 2-9 5.83” dimension
Figure 2-107.5”dimension

HanshowNebular Series Product Manual
9HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
3 Hardware performance
This chapter consists of:
Specifications
NFCspecification
Identifying your ESLs
Product nameplate
3.1 Specifications
Table 3-1lists the Nebular specifications.
Table 3-1Nebular specifications
Name
1.54”
2.13”/
2.13” Freezer
2.66”/
2.66” Freezer
2.9”
3.5”/
3.5” Freezer
4.2”
5.83”
7.5”
Dimensions
(mm*mm*mm)
46.7*35.8
*10.0
69.7*33.2*7.8
82.3*40.3*7.8
89.5*40.7
*7.8
105.8*52.0
*9.2
100.1*88.0
*9.5
132.8*112.2
*9.8
178.1*125.7
*10.8
Active display area
(mm*mm)
27.0*27.0
48.6*23.7
60.1*30.7
67.6*29.6
79.7*38.2
84.8*63.6
118.8*88.2
163.2*97.9
Weight (g)
15.9
23.8
31.0
33.1
47.5
79.6
159.5
225.7
Size (inch)
1.5
2.13
2.66
2.9
3.5
4.2
5.83
7.5

HanshowNebular Series Product Manual
10HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
Name
1.54”
2.13”/
2.13” Freezer
2.66”/
2.66” Freezer
2.9”
3.5”/
3.5” Freezer
4.2”
5.83”
7.5”
Resolution (pixel)[3-
1]
200*200
296*144
360*184
384*168
384*184
400*300
648*480
800*480
DPI[3-1]
188
155
153
144
123
120
138
126
Display color
BWR, BWY
Viewing angle
Nearly 180 degree
Battery life[3-2]
10 or15 years
Page switch
8 pages
Battery
specification
650mAh
1030mAh
1030mAh
1030mAh
1030mAh
1350mAh
2*1030mAh
2*1030mAh
Protection level
IP68
Operating
temperature[3-3]
0℃~40℃
0℃~40℃/
-25℃~0℃
0℃~40℃/
-25℃~0℃
0℃~40℃
0℃~40℃/
-25℃~0℃
0℃~40℃
0℃~40℃
0℃~40℃
Storage
temperature[3-3]
0℃~40℃
0℃~40℃
0℃~40℃
0℃~40℃
0℃~40℃
0℃~40℃
0℃~40℃
0℃~40℃
Humidity(%RH)
30~70
Note:
[3-1]: The resolution and DPI may be subject to slight variations.
[3-2]: Battery life is calculated based onthe following scenarios:The battery life is 10 yearsif updated twice a day for the
following sizes:1.54”/2.13” Freezer/2.66”Freezer/3.5”Freezer.The life is 15 yearsif updated twice a day for the following
sizes:2.13”/2.66”/2.9”/4.2”/5.83”/7.5”.

HanshowNebular Series Product Manual
11HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
[3-3]:Room-temperature ESLs operate within 0 ℃~ 40 ℃,however
temperatures below 10℃ may impact the ESL lifespan. Freezer ESLs
operate within -25℃~ 0℃.
3.2 NFCspecification
NFC specifications are shown in Table 3-2.
Table 3-2NFCspecifications
Name
Standard
Data format
Memory
Communication
distance
NFC
ISO/IEC 14443 Type A
NFC NDEF
200 byte storage space,
and write configurable
1cm
3.3 Identifying your ESLs
You can identify your ESLs from the followingNebular naming rules:
Nebular-XXXY-Z
Product Family
Nebular Series
Display Size
154: 1.5 inch
213: 2.13 inch
266: 2.66 inch
290: 2.9 inch
350: 3.5 inch
420: 4.2 inch
583: 5.83 inch
750: 7.5 inch
Function Suffix
N: NFC function
Display Type
R: Black/White/Red
Y: Black/White/Yellow
F: Freezer tag
Figure 3-1Naming rules for Nebular series

HanshowNebular Series Product Manual
12HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
3.4 Product nameplate
Take Nebular-266R-N as an example, the nameplateofNebular-266R-N is shown in
Figure 3-2.
Figure 3-2Nameplate of Nebular
Note: Each ESL has the unique S/N number. See the real.

HanshowNebular Series Product Manual
13HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
4 Packaging and accessories
This chapter describes Nebular series’ packaging and required accessories.
4.1 Packaging
Nebular family packaging and the specific ESLquantity is shown in Figure 4-1.
Figure 4-1Nebular familypackaging

HanshowNebular Series Product Manual
14HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
4.2 Product accessories
Common accessories of Nebular series are shown in Table 4-1.
Table 4-1Common accessories of Nebular series
Rail
Table stand
T-hook
Basket clip

HanshowNebular Series Product Manual
15HanshowCopyright Reserved ©
Hanshow Technology Co., Ltd.
5 Application scenarios
Nebular series are available to various zones and shelves of hypermarket,
supermarket and retail stores.The ESLs are applicable to areas with different fixtures:
Shelves
Hooks
Fences
Tables
