Hanwei AT6000 User manual

AT6000 Alcohol Tester
HENAN HANWEI ELECTRONICS CO.,LTD Tel: [phone] / 80 Fax: [phone]

Henan Hanwei Electronics Co.,Ltd www.hwsensor.com
AT6000 Alcohol Tester for Personal Use
Preface
Reminding Before your testing.
Alco Smart Breath tester should be used only to give an indication of the possible presence of
alcohol in the breath/blood. You should not rely upon it as the sole basis to determine intoxication
or whether it is safe to drive a vehicle, operate equipment, or engage in dangerous activities.
Everyone has different body responds to alcohol consumption and his testing result only as
reference, not a subject standard for consequent decision.
The manufacture, importer or distributor takes no responsibility whatsoever for the use of this
product for any reason. This product must not be used as a tool for determining whether a person is
able to operate a motor vehicle or device legally or safely. The intake of any alcohol will impair
reflexes and judgment to operate motor vehicle.
Before your testing, please view the manual carefully and follow the instruction strictly.
General Introduction
AT6000 breath alcohol tester is kind of tester designed to measure concentration result of the
breathed alcohol in the human body. This device adopts advanced NM Hot-wire alcohol sensor which
has excellent sensitivity and reproducibility, fashion and portable design make it more convenient for
personal use. When the alcohol content exceeds the preset limited level, this device would send an
audio and video warning to remind your safety.
Main Feature:
Advanced NM Hot-wire alcohol sensor
Quick response
SMD assembling, stable performance
Smart MCU control
Direct testing process LCD indication
Digital LCD display with light blue backup
Portable and fashion design
Audio warning beyond pre-set limit
Sensor Fault Self checking
Battery saved design, low voltage indication
Technical Data
Sensor type: NM Hot-wire alcohol sensor
Detection Range: 0.001.00mg/L (0.000.20%BAC; 0.002.00g/L; 0.002.00‰BAC)
Alarming Level: 0.24mg/L (0.05%BAC, 0.50g/L; 0.50‰BAC)
Accuracy: ±5% F.S
Response Time: 5s Warm-upTime: 20s
Resume Time: ≤20s
Working Voltage: DC4.5V3×AAABatteries; Working Current: ≤120mA
Working Environment: Temperature -1050Relative Humidity ≤95% No Dews
Display: 3 digits LCD display with light blue backup
Dimension: 103×65×27mm (L×W×H), ≤64 g Battery excluded
Battery expectancy time: ≥200Times
E-mail: [e-mail] Fax:[phone]

Henan Hanwei Electronics Co.,Ltd www.hwsensor.com
1. Structure and Function Guide
1.1 Structure Guide picture 1:
1.2. Function Guide
Digital Indication:
8.8 8 Alcohol content
20s Countdown Warm-up Countdown
“C” on the LCD ready for blow
000 flash working mode conversion
FFF sensor fault
2. Operation Instruction
2.1. Slide down the battery compartment on the back side, insert 3pcs AAA 1.5V batteries inside
according to battery polarity indication and close it.
2.2. Press the switch button last for 1S, the tester would be on with a buzzer brief ringing, ‘Wait’
flashes and Warm-up of 20 sec begin, the fig on the LCD Countdown from 20-0, please wait now.
Until “Wait” disappears, tester will send out a ring, meantime “BLOW” and “C” gliding, also the small
car icon twinkles, now the test could begin.
2.3. Have a deep breath before testing, and blow directly to gas entry until a buzzer ringing, “000”
1 Mouthpiece
2 Buzzer hole
3 Switch Button
4 Input for external power
5 LCD Screen
6 Vent hole
6
5
2
4
3
1
Picture 1
Excessive drinking
Low Battery Indication
Excessive drinking
Testing Result
Warm-up
Test Testing result
Blow
Picture 2
Indication unit
E-mail: [e-mail] Fax:[phone]

Henan Hanwei Electronics Co.,Ltd www.hwsensor.com
twinkles for 4S on the screen, at the same time the “BLOW” disappear and ‘TEST’ shown.
2.4. Tester will send out a ring after testing process finished, the LCD screen would give the readout
of temporal alcohol concentration (If the testing result is lower than preset level, only the car icon
twinkles; If the testing result is higher than preset level, the buzzer ringing continuously, at the same
time the “Hi” and “No Driving” icon twinkles), this result would be keep on the screen for 10 sec, then
cut off the power supply automatically with two buzzer ringing.
2.5. If a new testing needed, press the switch button again and repeat the above step 4.24.4.
3. Notification
3.1. Avoid any fall or strong shock.
3.2. If noise gas with high concentration existed, may the tester won’t work normally.
3.3. If testing is done under low voltage, certain error will be existed between the real value.
3.4. To ensure the testing result, please wait 10 min to take the testing after your drinking.
3.5. Please operate it strictly according to this instruction. If long time not use, when you first begin a
new testing, the first two times testing result may be unreliable, just begin testing from the third time,
otherwise the result will also not be accurate.
3.6. Do not keep the tester in the environment of Corrosive gas (Chlorine etc) for use or deposit, also
in other bad surroundings.
3.7. Under normal detections, sensor life could be more than two years.
3.8. After Long time use, there may be dirt on the tester, please use clean cloth to wipe off. Do not
use any hard object or the solvent with any Corrosive ingredient.
Remarks: Common Fault and Solving solutions
Fault Possible reason Solution
Incorrect battery
installation
Insert battery correctly
according to polarity
Low battery seriously New battery replacement
NO display on LCD
Circuit fault Contact distributor
not complete Warm-up Waiting complete Warm-upNo response to
detection gas Circuit fault Contact distributor
FFF display then power off Sensor fault Contact distributor
Low voltage display then power off Low battery seriously New battery replacement
To keep the continuous improvement of the products, we reserve the right to improve design without prior notice.
Hanwei
Electronics Co.,Ltd
2006.06
E-mail: [e-mail] Fax:[phone]

HENAN HANWEI ELECTRONICSCORPLIMITED
www.hwsensor.com
E
-
mail:hwsensor@1
63.com
Alcohol
concentration
Short ofVolt
Warmup, pleasewait
Higherthan preset level
Readyforblow
Alcohol
concentration
Units
Digital
results
ALCNose
AT-126 BreathAlcohol Tester
Reminding Beforeyourtesting
AlcoNoseBreathtestershouldbeusedonlytogivean indication ofthepossiblepresenceofalcoholinthebreath/blood.
You shouldnot relyupon it asthesolebasistodetermineintoxication orwhetherit issafetodriveavehicle, operate
equipment, orengageindangerousactivities.
Everyonehasdifferent bodyrespondstoalcoholconsumption and histesting result onlyasreference, not asubject
standardforconsequent decision.
Themanufacture, importerordistributortakesno responsibilitywhatsoeverfortheuseof
thisproductforanyreason.Thisproductmustnotbeusedasatoolfordetermining whetheraperson isabletooperatea
motorvehicleordevicelegallyorsafely.Theintakeofanyalcoholwill impairreflexesand judgment tooperatemotorvehicle.
MainFeatures:
AdvancedNMhot-wirealcoholsensor;
Quick response;
SMDassembling, stableperformance;
MCU control;
Cartoon and LCD indication, backup light
Portableand small design
NoTouchHealthydesign;
Sensorfault self-checking;
Batterysaveddesign, lowVolt warning.
MainTechnical Info:
SensorType: Hot-wirealcoholsensor
Detection Range: 0.00 1.00mg/L(0.00 0.20%BAC；0.00 2.00g/L)
Alarming Level: 0.24mg/L(0.05%BAC; 0.5g/L)
Working Volt: DC3V（2×AAAbatteries）Batteryusing time: ≥60 times
Using Environment: Tem：0℃ 45℃RelativeHum：≤93%NoDews
ResponseTime: ＜8SWarm-Up: ＜18S
Indication Manner: 3digitalLCD withcartoon indication
Dimension: l×b×h, 103×37×19 mm ≤45 g
StructureandfunctionDirection
3.2Function Direction,
shownasFig1：

HENAN HANWEI ELECTRONICSCORPLIMITED
www.hwsensor.com
E
-
mail:hwsensor@1
63.com
LCD indication：
Operation instruction:
4.1Openthebatteryroomintheback, packed2pcs ofAAAbatteriesaccording totheirpolarityand closeit。
4.2Press theOn/Off switchlasting 1S, backuplightwouldbeon followingwithabrief ringing,thenshown(10.9.8 ……0)
countdown,also “WAIT”shownontheupperofLCD screen,nowthetestersisinWarm-up status,pleasewait.After
10SW-Upfinished, witharinging, meantimeshown “BLOW”, and “C”, nowyou can start thetesting.
4.3Takeadeepbreath,thenblowtothegasentryslowlywith3-4cmintervaluntilabuzzerringing forstop,now “000”
flashedintheLCD screenand result comesout.
4.4Theend, testing result wouldremain8S, afterthat thetesterwouldcut off thepowerwithabuzzerring.
4.5 If anewtesting needed, press the “On/Off”switchagain, thenfollowing theabove4.2 –4.4stepsinstruction.
5. Gobletindication
Above0.08%BAC0.05%BAC 0.08%BAC0.02%BAC 0.05%BAC0%BAC 0.02%BAC
6. Notification
6.1Avoidanystrong shock and drop tokeepthetesterincarefulpackageordeposit.;
6.2Donot wipeit withanycleaning agent, If noisegasexist, thenormaltesting wouldbedisturbed;
6.3Avoiding short of Volt batteriesusedintesting, theresult wouldbenot accurateand you needreplacenewbattery;
6.4It’sbettertotaketesting after10Minsof drinking formoreaccurateresults;
6.5 Afterlongtimestorage,If theinitialalcoholleveloftheLCDisonhighLevel, Pleaseopenandcloseittimestostabilize
until thelevelis0.00 inunit.
8.88 Breathedalcoholconcentration
10S/ 18Scount down Warm-Up
3Scount down Lowbattery
“C”shownincircleReady, pleaseblow
“000”showninflashTurning working manner
FFF Sensorfault
