MSA galaxy GX2 User manual

Operating Manual
GALAXYGX2
Automated Test System
Order No.: 10127150/00

WARNING
Read this manual carefully before using the instrument. The instrument will perform as designed
only if it is used and maintained in accordance with the manufacturer's instruction. Otherwise, it
could fail to perform as designed and persons who rely on this instrument for their safety could
sustain serious personal injury or death.
© MINE SAFETY APPLIANCES COMPANY 2012 - All Rights Reserved
This manual is available on the Internet at: www.msasafety.com
Manufactured by
MSA NORTH AMERICA
1000 Cranberry Woods Drive, Cranberry Township, PA 16066

MSA AUER
MSA
Contents
GALAXY GX2 3
US
Contents
1 Safety Regulations ................................................................................................................... 5
1.1 Correct Use ....................................................................................................................... 5
1.2 Product Warranty ............................................................................................................... 6
2 Introduction ................................................................................................................................ 8
2.1 Power Supply .................................................................................................................. 10
2.2 The Test Stand ................................................................................................................ 10
SD or SDHC Memory Card Slot ...................................................................................... 11
Test Stand Networked to a PC ........................................................................................ 11
Test Stand is Stand-Alone ............................................................................................... 12
USB Drives ...................................................................................................................... 12
2.3 Ethernet Interface ............................................................................................................ 13
2.4 Software Options ............................................................................................................. 13
2.5 Cylinder Holder (electronic) ............................................................................................. 14
2.6 Optional Printer ............................................................................................................... 15
2.7 Optional Multi-Unit Charger ............................................................................................. 15
2.8 Special Conditions for Use with Reactive Gases ............................................................ 16
3 Installation ................................................................................................................................ 17
3.1 Connect Units in a Bank .................................................................................................. 18
3.2 Connect a Test Gas Source Without a Cylinder Holder .................................................. 19
3.3 Network Test Stands ....................................................................................................... 19
3.4 Removing Gas Seal for Certain ALTAIR and ALTAIR Pro Instruments .......................... 20
3.5 Desktop Mounting ........................................................................................................... 21
3.6 Wall Mounting .................................................................................................................. 23
3.7 SD or SDHC Memory Card Option .................................................................................. 24
4 Setting Up the GALAXY GX2 .................................................................................................. 25
4.1 Initial Setup ...................................................................................................................... 25
4.2 Security Setup ................................................................................................................. 27
4.3 Home Screen .................................................................................................................. 27
4.4 General Setup ................................................................................................................. 29
4.5 GX2 Configuration ...........................................................................................................29
Backlight/Volume Setup .................................................................................................. 30
Test Setup ....................................................................................................................... 31
GX2 Setup ....................................................................................................................... 33
GX2 Gas Setup ............................................................................................................... 34
Network Setup (Optional) ................................................................................................ 38

GALAXY GX2
4
Contents MSA
US
4.6 Instrument Configuration .................................................................................................39
Instrument Setup .............................................................................................................40
Sensor Setup ...................................................................................................................42
Save Settings ..................................................................................................................44
Load/Delete Settings ......................................................................................................45
Update Settings ...............................................................................................................45
4.7 Cylinder Configuration .....................................................................................................46
Cylinder Setup .................................................................................................................47
Expiration Setup ..............................................................................................................48
5 Using the GALAXY GX2 .........................................................................................................49
5.1 Turning on the System .....................................................................................................49
5.2 Inserting the Instrument ...................................................................................................49
5.3 Running a Test ................................................................................................................50
5.4 Classic Mode ...................................................................................................................54
5.5 GALAXY GX2 Always Ready Feature .............................................................................55
5.6 E-mail Notification ............................................................................................................56
5.7 Overdue Calibration and Bump Notification .....................................................................56
6 Troubleshooting .......................................................................................................................57
6.1 Instrument Will Not Initiate a Bump or Calibration ...........................................................57
6.2 Instrument Fails Zero Calibration or Bump ......................................................................58
6.3 Instrument Fails Span Calibration or Bump .....................................................................58
6.4 Instrument Records Do Not Display ................................................................................58
6.5 Cylinder Data Does Not Display ......................................................................................59
6.6 Test Stand Yellow LED Blinking ......................................................................................59
6.7 System Error Messages ..................................................................................................61
7 Maintenance (Cleaning and Part Replacement) ....................................................................62
7.1 Corrective Maintenance ...................................................................................................62
7.2 Replacement Parts and Accessories ...............................................................................62
7.3 Fresh Air Filter Replacement ...........................................................................................66
7.4 O-Ring Seal Replacement (Cylinder Holder) ...................................................................67
7.5 Inlet Seal Replacement (ALTAIR 5/5X Gas Detector) .....................................................67
7.6 Rubber Insert Replacement (ALTAIR Gas Detector) .......................................................69
8 Technical Specifications .........................................................................................................70
9 Galaxy GX2 Default Parameters .............................................................................................71

MSA AUER
MSA
Safety Regulations
GALAXY GX2 5
US
1 Safety Regulations
1.1 Correct Use
WARNING
Read this manual carefully before using the instrument. The instrument will perform as designed
only if it is used and maintained in accordance with the manufacturer's instruction. Otherwise, it
could fail to perform as designed and persons who rely on this instrument for their safety could
sustain serious personal injury or death.
WARNING
(1) Do not use silicone-type lubricants in assembling the GALAXY®GX2 Automated
Test System and do not allow silicone vapors to be drawn into the flow system while in
operation. Silicone can desensitize the combustible gas sensor,thereby giving erroneously
low readings.
(2) Use the GALAXY GX2 System only in non-hazardous environments free of combustible
concentrations of gases and vapors.
(3) Use only genuine MSA replacement parts when performing any maintenance procedures
on the GALAXY GX2 System. Substitution of components can seriously impair
performance.
Failure to follow the above can result in serious personal injury or loss of life.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
LeprésentappareilestconformeauxCNRd'IndustrieCanadaapplicablesaux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si
le brouillage est susceptible d'en compromettre le fonctionnement.
This equipment has been tested and found tocomply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide rea-
sonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio fre-
quency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
NOTICE
This is a class A product in accordance with CISPR 22. In a domestic environment, this product
may cause radio interference, in which case the user may be required to take adequate measures.

GALAXY GX2
6
Safety Regulations MSA
US
FCC Warning Statements
Changes or modifications not expressly approved by the manufacturer could void the user's
authority to operate the equipment.
Industry Canada (IC) Warning Statements
The installer of this radio equipment must ensure that the antenna is located or pointed such that
it does not emit RF field in excess of Health Canada limits for the general population; consult
Safety Code 6, obtainable from Health Canada's website www.hc-sc.gc.ca/rpb.
L'installateur du présent matériel radio doit veiller à ce que le produit soit placé ou orienté de
manièreàn'émettreaucunchamp radioélectriquesupérieurauxlimitesfixées pour le grandpublic
par le ministère fédéral Santé Canada ; consultez le Code de sécurité 6 sur le site Web de Santé
Canada à l'adresse : www.hc-sc.gc.ca/rpb.
1.2 Product Warranty
The warranties made by Mine Safety Appliances Company with respect to the product are voided
if the product is not used and serviced in accordance with the instructions in this manual. Protect
yourself and others by following them. We encourage our customers to contact MSA regarding
this equipment prior to use or for any additional information relative to use or repairs.
This warranty does not cover filters, fuses, etc. Certain other accessories not specifically listed
here may have different warranty periods. This warranty is valid only if the product is maintained
and used in accordance with Seller's instructions and/or recommendations. The Seller shall be re-
leased from all obligations under this warranty in the event repairs or modifications are made by
persons other than its own or authorized service personnel or if the warranty claim results from
physical abuse or misuse of the product. No agent, employee or representative of the Seller has
any authority to bind the Seller to any affirmation, representation or warranty concerning this prod-
uct. Seller makes no warranty concerning components or accessories not manufactured by the
Seller, but will pass on to the Purchaser all warranties of manufacturers of such components.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED, IMPLIED OR
STATUTORY, AND IS STRICTLY LIMITED TO THE TERMS HEREOF. SELLER
SPECIFICALLY DISCLAIMS ANY WARRANTY OF MERCHANTABILITY OR OF FITNESS
FOR A PARTICULAR PURPOSE.
Exclusive Remedy
It is expressly agreed that Purchaser's sole and exclusive remedy for breach of the above warran-
ty, for any tortious conduct of Seller, or for any other cause of action, shall be the replacement at
Seller's option, of any equipment or parts thereof, which after examination by Seller is proven to
be defective. Replacement equipment and/or parts will be provided at no cost to Purchaser,
F.O.B. Seller's Plant. Failure of Seller to successfully replace any nonconforming equipment or
parts shall not cause the remedy established hereby to fail of its essential purpose.
ITEM WARRANTY PERIOD
GALAXY GX2 Test Stand,
Cylinder Holder and Multi Unit Charger 2 years from ship date
Optional Receipt/ Sticker Printer 1 year from ship date

MSA AUER
MSA
Safety Regulations
GALAXY GX2 7
US
Exclusion of Consequential Damage
Purchaser specifically understands and agrees that under no circumstances will seller be liable to
purchaser for economic, special, incidental or consequential damages orlosses of any kind what-
soever, including but not limited to, loss of anticipated profits and any other loss caused by reason
ofnonoperationofthe goods.Thisexclusionis applicabletoclaimsforbreachof warranty, tortious
conduct or any other cause of action against seller.

GALAXY GX2
8
Introduction MSA
US
2 Introduction
Congratulations on purchasing the GALAXY GX2 Automated Test System, the next generation
Test Stand and instrument management system from MSA. This system is used exclusively with
the ALTAIR®family of gas detectors. This manual uses the terms instrument and gas detector
to represent that entire line of ALTAIR gas detection instruments.
Inthismanualthe user will learn to installandconfiguretheGALAXYGX2 Test Stand and optional
attachments,andtest gasdetectors.Maintenance,Troubleshooting,and TechnicalSpecifications
sections are also provided.
The Test Stand uses a sophisticated internal processor and simple to use touch screen display
for the configuration of calibration parameters and gas detector settings, and for gathering instru-
ment data.
Each Test Stand and optional attachments can be wall or desk mounted to serve the needs of the
user. Constructed of durable composite polymers, this equipment is designed for normal indoor
applications and operates within a broad temperature range of 0º to 40ºC in non-condensing hu-
midity atmospheres.
The principal components of the GALAXY GX2 include the Test Stand and optional electronic or
non-electronic Cylinder Holder, Multi-Unit Charger, and Receipt/ Sticker Printer. These compo-
nents[Fig. 1]aredesignedtobeattached(excludingtheprinter),toavoidaccidentalseparation
during operation.
Fig. 1 The GALAXY GX2 Automated Test System

MSA AUER
MSA
Introduction
GALAXY GX2 9
US
TheTest Standisastandaloneunitthat can accommodateone gas detectorofthe ALTAIR family.
However, each Test Stand contains the plumbing and electronic ports to simultaneously connect
a total of 10 Test Stands and four Cylinder Holders (electronic or non-electronic).
For applications where multiple Cylinder Holders are connected, the Test Stand Expanded Sole-
noid option must be ordered. This option allows the Test Stand to open and close up to four Cyl-
inder Holder valves for gas detectors that may require multiple cylinders for test purposes. For
example, an ALTAIR 5/5X with the standard 4 sensors plus a toxic sensor likely requires two gas
cylinders.
The electronic Cylinder Holder is designed to read a Radio Frequency Identification (RFID) tag
embedded in a plastic ring on MSA test gas cylinders. The RFID tag contains cylinder parameters
that are necessary for successful calibration operations, providing the customer with an excep-
tionally easy setup experience. Gas cylinder information is automatically populated without user
intervention when using the RFID-tagged gas cylinders.
If MSA test gas cylinders are not used, the non-electronic version of the Cylinder Holder is avail-
able. This configuration [Fig. 2] requires the user to manually enter cylinder parameters.
Fig. 2 Non-electronic Cylinder Holder and Test Stand.
A USB port is provided on the Test Stand that may be used with the Digital Secure USB key to
change instrument settings via the touch screen. This function allows for convenient fleet
management capabilities. The port may also be used for an optional Receipt/ Sticker Printer, to
print calibration/bump stickers or paper receipts after an instrument test.
The primary functions of the Test Stand are to calibrate and bump the ALTAIR family of gas de-
tectors. For a detailed definition of these processes, please refer to:
http://www.safetyequipment.org/userfiles/File/calibration_statement-2010-Mar4.pdf
In the following sections of this manual the user will learn how to install the GALAXY GX2
Automated Test System, set up its functionality, and performinstrumenttests. Thehardware,soft-

GALAXY GX2
10
Introduction MSA
US
ware, and configuration options anticipate the user's needs and provide superb efficiency in this
next generation Automated Test System.
GALAXY GX2 System Features and Options
The GALAXY GX2 automatically identifies the type of gas detector inserted into the Test Stand.
Based on user-defined settings, the Test Stand then performs bump tests and/or calibrates the
instrument. The data collected from each test event is stored to a memory card [chapter 2.2]
and/or optional MSA Link™ Pro software application for data analysis (refer to the MSA Link Pro
end-user manual).
2.1 Power Supply
The Test Stand supplies power to the attached electronic Cylinder Holders. The Test Stand and
Multi-Unit charger are powered individually by one of the following methods:
-Power Module: Input power requirements: 100 - 240 VAC, 47 - 63 Hz
(Several different prong types are available for world-wide AC sockets).
-Optional Vehicle Module 12/24 VDC (For use in a cigarette lighter socket).
2.2 The Test Stand
The Test Stand performs the following functions:
-Bump or calibration testing per user setup.
-Records test results to the optional memory card and to an optional networked PC interface.
-Sends gas detector Instrument Periodic and/or Session datalogs to a networked PC interface.
-Provides optional instrument charging capability.
-USB key allows gas detector settings to be changed securely, with thetouch of the Test Stand
screen.
-Permits printing of test results to an instrument sticker or receipt, with the optional Receipt/
Sticker Printer.
-Sends e-mail notification of system alerts per user setup.
An LED indicator shows the status of the Test Stand:
-Green light indicates that the Test Stand hardware and software are fully functional.
-Blinking green light indicates that the Test Stand is performing the user specified test or data-
log download.
-Blinking yellow light indicates that the Test Stand is in error and cannot be used for gas detec-
tor testing. Diagnostic information is available as described on the "GX2 Status" screen on the
Test Stand and in the Troubleshooting section of this manual [chapter 6].
-Red light indicates that the last calibration or bump test failed.
NOTICE
Use of a power supply not specified by MSA will void the instrument warranty and could cause
damage to the GALAXY GX2.

MSA AUER
MSA
Introduction
GALAXY GX2 11
US
Fig. 3 Test Stand Physical Features
SD or SDHC Memory Card Slot
A memory card port is provided on the Test Stand for calibration and bump record storage. An
SD or SDHC memory card can be purchased from MSA (preferred) or from the following manu-
facturers:
-Kingston
-PNY
-SanDisk
-Lexar
-Wintec
The data on an SD or SDHC memory card is encrypted for use with MSA Link™ or the
MSA Link Pro application. The type and amount of data recorded to the memory card is contin-
gent on whether the Test Stand is networked.
Test Stand Networked to a PC
When the Test Stand is networked to a PC through the Ethernet port, test records, datalogs, and
settings will be transmitted from the GALAXY GX2 to the PC interface.
If the network connection is lost only calibration and bump records are saved to the memory card.
If the Ethernet connection is restored, the Test Stand will transmit the stored calibration and bump
records from the memory card to the PC interface.
1 Touch Screen Display 4 SD Card Port
2 Status LED 5 USB Port
3 Test Stand to Test Stand connector 6 Gas plugs
1
2
3
4
5
6
The use of MSA Link Pro via a network connection is required to download datalogs
from the instrument. Due to potentially large file sizes datalogs are not saved to the
memory card in the Test Stand.

GALAXY GX2
12
Introduction MSA
US
Test Stand is Stand-Alone
If the GALAXY GX2 is not networked to a PC interface the memory card will save each calibration
and bump test record. Incomplete records will not be saved. If networked and e-mail alerts are
configured, the Test Stand will generate an email alert once the memory card reaches 90% and
again at 99% capacity.
Once a memory card reaches full capacity, the Test Stand will be in faultand prohibit any unit from
performing tests in that bank, until corrected. The Test Stand can be configured to erase the
memory card, or the user can insert a replacement.
An optional end cap [Fig. 4] can be placed over the port to protect the memory card and all
external connections.
Fig. 4 Optional End Cap
USB Drives
Two optional USB Keys [Fig. 5] are available for purchase with the GALAXY GX2
Automated Test System:
-Digital Secure USB Key: This black key is inserted in the USB port on the Test Stand in order
to change gas detector settings. The key ensures only authorized users can change settings
on ALTAIR gas detectors; a security step in addition to the four-digit password.
-MSA Link Pro Key: This red key is used to enable the MSA Link Pro application on a single
PC. More information about this key can be found in the software product end-user manual.
Fig. 5 Digital Secure Key and MSA Link Pro Key
The memory cardshould only be removedwhen no test activityisoccurring. Eventsthat
occur while no memory card is installed will not be stored in the Test Stand.
If no memory card is used, only the most recent bump or calibration record is stored to
the Test Stand internal memory.
DUMMY!
Awaiting final plastic
- mid March

MSA AUER
MSA
Introduction
GALAXY GX2 13
US
2.3 Ethernet Interface
Two Ethernet Interfaces are provided on the rear of the GALAXY GX2 [Fig. 6]. The ports allow
for the connection and communication distribution between multiple Test Stands. If networking to
a computer, one USB port on the Master Test Stand is used to communicate with the
MSA Link Pro software application.
Fig. 6 Test Stand Ethernet jacks
2.4 Software Options
The GALAXY GX2 functions as a standalone system, but the optional MSA Link Pro software
application can be used to network the Test Stand to a PC through an Ethernet cable. This appli-
cation provides a best-in-class user interface and data analysis toolset to quickly identify issues
or concerns that require user action.
MSA Link Pro provides the user:
-Database storage of instrument Periodic and Session datalogs.
-Automatic or customized reports from the collected data.
-Single glance notification of instruments that are overdue for calibration or bump test.
-Email notifications of GALAXY GX2 and instrument warnings and error messages.
-Single setting configuration of all GALAXY GX2 units in a bank.
No need to individually configure each Test Stand.
To learn more about installing and using MSA Link Pro, refer to the software product end-user
manual.
Users may use the free MSA Link software application and an IR dongle
[chapter 7.2]tocommunicatedirectly with their gas detector. MSA Link allows a user
to upload and download instrument settings, and download datalogs.

GALAXY GX2
14
Introduction MSA
US
2.5 Cylinder Holder (electronic)
The electronic Cylinder Holder can accommodate one test gas cylinder and includes:
Fig. 7 Cylinder Holder Physical Features
1 Light Band 2 RFID Tag 3 Internal Pressure Regulator
& Sensor
Multi-Color Light Band RFID Tag Gas
Identification Pressure Regulator & Sensor
Indicates gas bottle functionality.
-Green indicates a bottle is
completely functional, and gas
parameters are within pressure
and expiration date limits.
-Yellow indicates low calibration
gas, or gas is nearing its expira-
tion date.
-A blinking yellow light band indi-
cates a hardware problem with
the cylinder holder.
-Red indicates an empty calibra-
tion gas bottle, or that gas has
expired.
Reads the RFID tag of
the MSA test gas cylin-
der and transmits:
-the gas type
-gas concentration
-expiration date
-lot number
-cylinder part number
to the Test Stand. The
RFID tag is only availa-
bleonMSA-branded test
gas cylinders shown in
the Maintenance section
[chapter 7].
Reads the pressure of the gas
cylinder and transmits that
information to the Test Stand.
-When gas pressure drops to
approximately 99 psi
(6.89 bar) a warning will
display and the display
numbers appear yellow.
-Once pressure drops to ap-
proximately49 psi(3.45 bar)
the display numbers appear
red.
-Once pressure drops to less
than 5 psi (0.34 bar) the
Test Stand will prohibit test-
ing with that cylinder.
1
2
3

MSA AUER
MSA
Introduction
GALAXY GX2 15
US
2.6 Optional Printer
The Printer can print calibration and bump result receipts and calibrations stickers for gas detec-
tors [Fig. 7]. The Receipt/ Sticker Printer uses a USB cable to connect to the port of the farthest
right Test Stand [Fig. 3].
Labels are available in two formats [chapter 7.2]:
-Format #1: Calibration Sticker only (2 cm x 2 cm square label).
-Format #2; Receipt and Sticker combined.
Fig. 8 Optional Printer
2.7 Optional Multi-Unit Charger
There are two configurations of the optional Multi-Unit Charger (MUC). The ALTAIR 4/4X MUC
cansimultaneously chargeup to fourALTAIR4/4Xgasdetectors.SimilarlytheALTAIR5/5X MUC
can charge four 5/5X gas detectors. Each Multi-Unit Charger contains its own power supply and
does not connect electrically to the Test Stand. The housing is designed to physically connect to
each other, whether bench-top or wall-mounted (if desired).
The light indicators on the Multi-Unit Charger are defined as follows:
-Red indicates that the unit is charging
-Green indicates that the unit is fully charged or no unit is inserted.
There can be as much as a 10 minute window between when the instrument battery indicator
shows charged and the Multi-Unit charger status indicator changes. The instrument indicator is
the most accurate and will indicate the true charge state of the battery.
DU
MM
Verify the Multi-Unit Charger indicator lights red when an instrument is inserted. A fully
chargedinstrumentwillmomentarilyflash red and the indicator will light green.Ifthe red
light does not engagethe instrument may notbe seated properly on the charging prong.
Instruments whose battery is completely discharged will be need to trickle-charge
prior to normal charging operations.Such instruments will show a green LED during the
trickle-charge period until normal charging is initiated, at which time the red LED will be
active.

GALAXY GX2
16
Introduction MSA
US
Fig. 9 Multi-Unit Charger (Altair 4/4X and 5/5X only)
2.8 Special Conditions for Use with Reactive Gases
If using a Test Stand and Cylinder Holder for calibrating or bump testing a gas Detector config-
ured with a chlorine or ammonia sensor:
-Place the chlorine or ammonia gas cylinder in the Cylinder Holder closest to the Test Stand.
-Only one reactive gas Test Stand is allowed in a bank.
-If connecting other Test Stands to the right of the reactive stand, plug the reactive gas outlet
port with a white gas plug before mating the next Test Stand. Otherwise, inaccurate calibration
could result on the reactive sensor.
-Before the first use with reactive toxic gas, condition the regulator and Test Stand with the gas,
by running the calibration twice in sequence. If using chlorine, perform this procedure daily be-
fore use.
If not using GALAXY GX2 Cylinder Holders:
-Use a dedicated pressure regulator on the reactive toxic gas cylinder (for chlorine or ammonia,
use P/N 10034391). Label the pressure regulator "FOR CHLORINE USE ONLY" or
"FOR AMMONIA USE ONLY", as applicable (label stickers are provided with regulator).
-Use the shortest possible tubing running from the reactive toxic gas pressure regulator to the
Test Stand's "CYLINDER 1" port.
-Before the first use with reactive toxic gas, condition the regulator and Test Stand with the
gas by running the calibration twice sequentially; for chlorine, perform this procedure daily be-
fore use.
-Many gases have a cross-sensitivity to other gases. Ensure that test cylinder gases do not
contain other interfering gases.
Do not use the GALAXY GX2 to calibrate or bump a gas detector with a chlorine dioxide (ClO2)
sensor.

MSA AUER
MSA
Installation
GALAXY GX2 17
US
3 Installation
The GALAXY GX2 is a simple to install system that can be desktop or wall mounted. Setup re-
quires simple tools and just a few minutes of time.
Carton Contents
The GALAXY GX2 system will be shipped with the following:
-Test Stand (including gas plugs, barbs and fresh air filter)
-Power Supply (if ordered)
-Spare Parts Kit (gas tubing barbs and plugs)
-Ethernet Cable (short cable for connection between Test Stands)
-Product CD
-Quick Start Guide
-Screen Protector (installed on the display screen)
Tools Needed
-Phillips head (cross-head) screwdriver.
As stated in the Introduction, the GALAXY GX2 is designed for the connection of up to 10 Test
Standsand fourCylinderHolders [Fig. 10].Test Stands mustbeassembled sequentiallyon the
right-hand side of the first. Cylinder Holder(s) must be installed on the left-hand side of the first
Test Stand for best gas flow into all Test Stands.
Fig. 10 Test Stands and Cylinder Holders properly installed in a bank
Test gas cylinders containing Chlorine or Ammonia must be installed according to the
directions in the Special Conditions for Use with Reactive Gases section
[chapter 2.8].
When installing the GALAXY GX2, please consider the environmental needs of your
facility. If the customer desires, the GALAXY GX2 can be used in a ventilated area to
assist in disbursing the test gas exhaust.

GALAXY GX2
18
Installation MSA
US
This manual provides steps for desktop and wall mounting. The following sections describe the
proper installation for various GALAXY GX2 configurations:
-Connect Units in a Bank (Test Stands and Cylinder Holders) [chapter 3.1]
-Connect a Test Gas Source Without a Cylinder Holder (optional) [chapter 3.2]
-Network Test Stands (optional) [chapter 3.3]
-Removing Gas Seal for Certain ALTAIR and ALTAIR Pro Instruments [chapter 3.4]
-Desktop Mounting [chapter 3.5]
-Wall Mounting [chapter 3.6]
-SD or SDHC Memory Card Option [chapter 3.7]
3.1 Connect Units in a Bank
(1) On the left-hand side of the Test Stand, ensure all five barb fittings are in place and straight-
ened before connecting a Cylinder Holder or another Test Stand.
(2) Press the two units together until the barb fittings are fully inserted and the screw holes in
the flange align.
(3) Insert one of the supplied screws into the front and two screws into the back of the flange.

MSA AUER
MSA
Installation
GALAXY GX2 19
US
(4) If connecting multiple Test Stands, remove the white gas plugs [Fig. 3] from all units ex-
cept the farthest right Test Stand. If using ammonia or chlorine test gas, read the restriction
found under chapter 2.8 “Special Conditions for Use with Reactive Gases” regarding the
white plugs.
(5) Continue adding Test Stands to the right and Cylinder Holders to the left [Fig. 10].
3.2 Connect a Test Gas Source Without a Cylinder Holder
If high-pressure, high-capacity test gas cylinders are preferred, an optional demand regulator
(p\n 710289) is available for cylinders with pressure less than (<) 3000 psi. Testing from an inde-
pendent gas source will require additional setup effort, as described in the Cylinder Configuration
section [chapter 4.7].
(1) On the left-hand side of the Test Stand, ensure all five barb fittings are in place and straight-
ened.
(2) Place the user-supplied regulator onto the gas cylinder and secure a length of tubing onto its
outlet.
(3) Securely fit the end of the tubing over the appropriate barb fitting on the GALAXY GX2.
3.3 Network Test Stands
Test Stands that are banked together should be connected through the provided Ethernet cable.
The Master Test Stand is the one located on the furthest right of the bank.
(1) Insert the short Ethernet cable into the left side jack of each Test Stand (1) and connect it to
the right side jack of the neighboring unit (2) [Fig. 11].
ZOne interconnect Ethernet cable is included with each Test Stand.
When connecting two or more Test Stands ensure the white plugs are secured on the
right side of the farthest right unit to prevent gas leakage.

GALAXY GX2
20
Installation MSA
US
Fig. 11 Test Stand Ethernet connections
(2) If connecting the bank to a computer with the MSA Link Pro software, use a customer-
supplied ethernet cable and connect via the Master Test Stand ethernet port #1 shown
above.
3.4 Removing Gas Seal for Certain ALTAIR and ALTAIR Pro Instruments
All ALTAIR/ALTAIR Pro Test Stands will be shipped with a black rubber base seal and a green
rubber gas seal. The green seal is used only for ALTAIR H2S and ALTAIR CO instruments.
The seal should be removed and stored for ALTAIR O2and all ALTAIR Pro instruments.
Fig. 12 Altair and Altair Pro Inlet Seals
1 MSA Link Pro port 2 Test Stand to Test Stand port
2
1
DUMMY!
Will be replacing this
photo - mid March
