Happy Beds Sherlock User manual

Sherlock Ottoman TV Bed
- All Sizes
Assembly Instructions
www.happybeds.co.uk
Important before assembly:
Health & Safety:
.
Read these instructions carefully before assembling or using the product.
Please check the contents of the boxes before attempting to assemble this product. The instructions will
have a checklist of parts and fittings.
Assemble the product as close to its intended final location/room as possible.
This product or some parts of this product will be heavy. Please use an assistant when lifting.
Please keep small parts out of reach of children.
Always use on a level, even surface.
DO NOT jump on the product or any of its parts.
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Further instructions are on the following pages.
Please keep these instructions for future reference.
Double or King Size
Super King Size

@
This product or some parts of this product will be heavy. Please use an assistant when lifting.
Never drag or push the pieces across a hard or stone floor as this will cause damage to the
joints. Use a carpet or a rug for extra care.
If you have problems assembling or have damaged or missing pieces, please contact our
customer services (details at the back of these instructions)
(Not metal)
These tools are not
necessary, but may help
to assemble the product.
Do NOT use any power
tools as this may
damage the frame.

@ happybeds
w w w . h a p p y b e d s . c o . u k
Important for Ottoman and other gas lift beds
Note:
The gas lifts are fully extended during shipment for safety. After assembly a firm
downward push will be required to overcome any resistance in the gas lifts as these
may initially stick. We suggest placing a mattress on top of the bed base to aid this and
also test the operation of your new lift-up bed by lifting and pushing down the bed base
a few times to free off the system.
Do NOT operate the lift-up mechanism without the mattress placed on the base.
The lift mechanism provides assistance with the lift of the mattress fitted to the base. It
does not lift the mattress for you. The system has been designed to effectively lift the
base system fitted with a variety of mattress weights and combinations of depths.
The gas cylinders fitted to the system may be stiff when first used or if the system has
not been operated for a period of time.
If provided, use the strap handle to lift up the mattress base using two hands. Pull the
mattress base down using two hands equally spaced from the centre of the mattress
base. DO NOT pull down on one side of the base only as this is likely to damage the base
system with potential failure of the mattress base system and lift mechanism.
Caution:
Do NOT allow children to operate the lift mechanism.
Do NOT allow children near the lift base when operating the mechanism.
Do NOT allow children in the area of the internal storage base.
Keep hands clear of the mechanism when operating the base system.
Do NOT stand inside the bed or the internal storage base.
Do NOT overload the internal storage base.
Health & Safety:
This product or some parts of this product will be heavy. Please use an assistant when
lifting.
Please keep small parts out of reach of children.
Always use on a level, even surface.
DO NOT jump on the product or any of its parts.
DO NOT use this product if any parts are missing, damaged or worn.
DO NOT use this product unless all fixings are secured.
Please keep these instructions for future reference.

No Part List Qty Box
1 1 pc
2 1 pc
3 2pc
4
5 1 pc
6 2pcs
7
Side rails
1 pc
8
1 pc
12
No Part List Qty Box
10 1 pc
11 2 pcs
Fabric hand strap
Remote control for TV Lift
Cable clips
1 pc
1 pc
1 pc
14
Mainspower lead
16
17
18 Cable ties
1
Headboard
Footboard
Metal slat frame for double or king size
“U” shaped cross bar
1
9
2 pcsGas lift pistons
4
4
4
4
“L” shape frame support brackets 2 pcs
13
4
2
Metal slat frame for super king size 1 pc
15
2
2
3 pcs 2
3 pcs 2
2
3
4
4
4
4
Angled corner brackets
Mattress stoppers
Lift mechanism
Lift mechanism
2
9
10
14
11
11
3
5
8
3
6
6
151718
16
7
4
13
12
Fabric base cover 1 pc 4
7
12

Flat washer for
M6 bolts
No Qty Box
24 pcs
24 pcs
16 pcs
3
12 pcs 3
3
3
Hardware List
HARDWARE NEEDED FOR BED ASSEMBLY (PACK A)
E
D
Spring washer for
M6 bolts
F16 pcs
G 1 pc
3
3
Allen key for
M8 bolts
B
A
C
Spring washer for
M8 bolts
Flat washer for
M8 bolts
No Qty Box
Hardware List
H
1 pc 3
12 pcs 3
J 12 pcs
K 4 pcs
L
M
2 pcs
3
3
3
2 pcs 3
Allen key for
M6 bolts
Bolt (M6x45mm) for
fitting “U” shape cross
bar to side rails(3)
Hook bracket - RH
No Qty Box
18 pcs
24 pcs
4 pcs
3
3
3
Hardware List
HARDWARE NEEDED FOR METAL SLAT FRAME ASSEMBLY (PACK B)
D
N 8 pcs 3
B
C
Spring washer for
M8 bolts
Flat washer for
M8 bolts
No Qty Box
Hardware List
P 2 pcs
Q10 pcs
R
S
T
1 pc
3
3
3
6 pcs 3
4 pcs 3
Flanged M8 lock-nut
Plastic spacer for lift
mechanisms(8& 9)
Metal connection plate
A4 pcs 3
No Qty Box
2 pcs
2 pcs
2
2
Hardware List
HARDWARE NEEDED FOR TV INSTALLATION (PACK C)
U
No Qty Box
Hardware List
1 pc
V
W
1 pc
2 pcs
2
2
2
2 pcs 2
TV Support Slide
M8 x 25mm
Bolt set
Counter-sunk screw
set (M6x12mm)
Counter-sunk screw
set (M4x12mm)
Allen key (2.5mm)
Allen key (4mm)
Hook bracket - LH
Bolts (M8x50mm) for fitting
metal slat frame (10 or 14)
to lift mechanism (8 & 9)
Bolt (M8x35mm) for fitting
side rail hook brackets to
headboard & footboard
Bolt (M6x20mm) for fitting
"L" shaped brackets (7) to
side rails (3)
Bolts (M8x20mm) for
fitting angled corner
brackets (6)
Bolt (M8x20mm) for fitting
hook brackets (L & M) to
side rails (3)
Bolts (M8x35mm) for
fitting lift mechanism
(8 or 9) to footboard (2)
Bolts (M8x65mm) for
fitting lift mechanism
(8 or 9) to headboard (1)
Spanner for flanged
M8 Lock-nuts

Step 1:
Step 2:
B
B
C
C
D
B
CD
A
BC
A
EF
K
M
M
LLL
M
Bolts (M8x35mm)
A 12 pcs
24 pcs
D
24 pcs
B
C
H
12 pcs
1 pc
M 2 pcs
L 2 pcs
Hook Bracket - LH
Hook Bracket - RH
Flat Washer for
M8 bolts
Allen key for
M8 bolts
Spring Washer for
M8 bolts
Bolts (M6x45mm)
4 pcs
H
4 pcs
E
FK
1 pc
4 pcs
Flat Washer for
M6 bolts
Allen key for
M6 bolts
Spring Washer for
M6 bolts
1
2
3
3
Bolts (M8x20mm)
5
3 3
100%

Step 3a:
Step 3b:
Bolts (M6x20mm)
12 pcs
H
12 pcs
EF
J
1 pc
12 pcs
Flat Washer for
M6 bolts
Allen key for
M6 bolts
Spring Washer for
M6 bolts
1
1
1
3
3
3
7
6
1
2
2
2
2
F
E
JFEJ
3
7
6
F
E
J
FEJ
Note: depending on your purchase, please use this hardware for:
(3a) Super King size - or for (3b) Double & King size.
Super King size
Double & King size

Step 4a:
Step 4b:
Headboard Bolts
(M8x65mm)
1 pc
N
8 pcs
C
H
T
8 pcs
4 pcs
Flat Washer for
M8 bolts
Spring Washer for
M8 bolts
Footboard Bolts
(M8x35mm)
A
B
4 pcs
8 pcs Allen key for
M8 bolts
Plastic spacer for lift
mechanisms(8& 9)
B
N
N
N
N
CTB
CA
2
1
8
8
9
9
B
CT
B
CA
1
2
Note: depending on your purchase, please use this hardware for:
(4a) Super King size - or for (4b) Double & King size.
Super King size
Double & King size

1
3
4
B
C
D
P
B
C
D
P
Step 5:
Step 6:
1 pc
P
4 pcs
CH
2 pcs
Flat Washer for
M8 bolts
Spring Washer for
M8 bolts
Super King Size
Bolts (M8x20mm)
D
B4 pcs
4 pcs
Allen key for
M8 bolts
Lift and turn bed on its side and with
assistant holding bed upright for safety,
attach fabric base cover (4) using the
velcro tape, to bottom of side-rails,
headboard & footboard.Make sure
fabric is fixed evenly all round.
Metal connection
plate
10
14
14
11
10
i. Carefully open the frame.
ii. To top of slat frame, fit two
connection plates (P). Using four sets
of bolts (D), spring washers (B) & flat
washers (C), screw into the threaded
inserts on top of the frame.
iii.Push x2 Mattress Stoppers (11)
into metal frame, they should go
all the way through the upper &
lower metal sections.
Double or King Size

x5
Press the “UP” button to raise the TV lift.
Step 7:
Step 8:
15
16
Connect mains power lead (15)
to your wall socket - for safety
this must be an earthed power
supply.

Note: For illustration purposes only, TV connections may vary.
Tip:
Before fitting the TV, push cables through each
duct from the top choosing the best side to use
depending on where the connection ports are
on back of your TV.
Never cross cables from one side of the
footboard to the other unless cable is threaded
under the TV supports, in front of the TV Lift.
10mm
Max TV Height
575mm
Height of TV is normally pre-set - follow this guide if it needs to be changed.
V
Step 9:
Step 10:
Media Cable are
not supplied
TV Power Lead
supplied with your TV
W
i. Loosen the two bolts.
Measure the height of the TV.
Adjust the lid lifter column adding 10mm to
height of the TV.
Re-tighten the two bolts.
ii. The upper part of each TV support slides
to hold front of TV in place, see step 12.

UU
V
10mm
100%
i
ii
V
Stand TV vertically in position.
Each slider (W) should be set to just touch
the front bezel.
To make sliding each support easier, lift
respective end of the TV a small amount.
Once set, lightly push
down on top of centre
of the TV and tighten
the two Vesa bolts
100% , these should
be in the centre of the
long holes as shown.
Step 11:
Step 12:
2 pcs
2 pcs
U
2 pcs
M8 x 25mm
Bolt set
Counter-sunk screw
set (M6x12mm)
Counter-sunk screw
set (M4x12mm)
1 pc
V
1 pc
Allen key (2.5mm)
Allen key (4mm)
1 pc
V
1 pc
Allen key (2.5mm)
Allen key (4mm)
If your TV is supplied with Vesa bolts, please use those in preferance to our selection.

Note: For illustration purposes only, TV connections may vary.
TV Power Lead
supplied with your TV Keep all leads tight, peel
off cover from cable clips
& adhere to back of TV.
Press the “DOWN” button
to lower the TV lift.
16
x5
Step 13:
Step 14:
17
18
KEEP ALL CABLES
TIGHT BY USING CLIPS
& TIES PROVIDED.

Double & King Size
Double & King Size
Super King Size
Super King Size
Step 15a:
Step 15b:
Q 6 pcs
R 1 pc
Flanged M8 lock-nuts
for gas-lift piston
Spanner for flanged
M8 lock-nuts
C 12 pcs
B 6 pcs
Flat Washer for
M8 bolts
Spring Washer for
M8 bolts
H 1 pc
Allen Key for
M8 bolts S 6 pcs
Bolts (M8x50mm)
S
C
B
C
Q
10
14
13
13
14
Fit the bolt sets
but please do not
tighten fully yet.
Note: Please choose which side of the slat frame to lift up to reach into the storage area
then, depending on your purchase, please use this hardware for the Double, King or
Super King size bed: (15a) lift from LEFT OR (15b) LIFT FROM RIGHT.
LIFT FROM LEFT SIDE
MAKE SURE MATTRESS STOPPERS
AND HAND STRAP ARE ON THE
CORRECT SIDES AS SHOWN
10 or 14
Fit the bolt sets but please
do not tighten fully yet.
LIFT FROM RIGHT SIDE
MAKE SURE MATTRESS STOPPERS
AND HAND STRAP ARE ON THE
CORRECT SIDES AS SHOWN
10
S
C
B
C
Q
10 or 14

Step 16:
Step 17:
WARNING: ONLY USE THE HANDLE TO LIFT &
LOWER THE BED FRAME TO
AVOID TRAPPING FINGERS!
SAFETY WARNING
PLEASE DO NOT ALLOW CHILDREN
OR PETS INSIDE THE STORAGE AREA.
SAFETY WARNING
PLEASE BE CAREFUL WHEN LIFTING.
ONLY LIFT WITH MATTRESS ON TOP.
TO BE OPERATED BY ADULTS ONLY.
TO AVOID ACCIDENTS
TO ACCESS THE STORAGE AREA THE OTTOMAN FRAME
MUST BE FULLY OPENED AND THEN FULLY CLOSED AFTERWARDS
R 1 pc
Spanner for flanged
M8 lock-nuts
H 1 pc
Allen Key for
M8 bolts
Carefully lay frame down. Make sure there is an
even gap each side of about 8mm, as in the sketch.
8 mm
Q4 pcs
Flanged M8 lock-nuts
Q
Q
12
Hold frame securely then tighten
all six bolt sets 100% using
spanner (R) & Allen key (H).
Fit the pistons (12) sliding the
stems (x) over the axles (y).
Tighten lock nuts (Q) with
spanner (R) but please DO NOT
over-tighten, a small gap needs
to be left so stems can move
freely - if too tight the frame will
be hard to lift so this is important.
SMALL GAP
y
x
R 1 pc
Spanner for lock-nuts
Please read warnings carefully
Note: Be very careful
what you store under
the bed - the top of an
item, like a box or a
suitcase, must not
touch the slats or they
may be damaged.
Maximum storage
height is 240mm.

@happybeds
w w w . h a p p y b e d s . c o . u k
Important for Ottoman and other gas lift beds
Please follow these final steps to ensure the best experience with your new bed
•Please ensure the pistons are fitted to the bed frame.
•Please place the mattress on top of the bed frame.
•Standing at the foot of the frame (looking at the headboard) open the base and the press
quite forcefully down on the mattress - please do not attempt to do this without the
mattress being in place.
•Please do not pull on the strap handles.
•Please note as the pistons are full of gas - you will need to press heavily to release the
compressed gas.
•Once done the pistons should start operating as normal.

www.happybeds.co.uk
General Care & Maintenance
Please dispose of all packaging safely.
Wipe clean with a slightly damp cloth.
Avoid the use of all household cleaners and abrasives.
Periodically check all screw & fixings to ensure they are secure.
When moving your product, carefully lift into place. Never drag or push the product across the floor as
this will cause damage to the joints. If the product is used on hard flooring, such as wood or laminated
floor, you must place some protection under the legs to stop the product from moving. If this is not
adhered to, it could result in failure to the product that will invalidate the warranty.
For more information on cleaning and product care visit:
https://www.happybeds.co.uk/help-and-advice
In the unlikely event that you have problems putting this product together or have damaged or
missing parts, please contact us by visiting:
https://www.happybeds.co.uk/customer-service
Notes
