ASSEMBLY & OPERATING INSTRUCTIONS
91735
TOY BOX
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web Site at www.harborfreight.com
Copyright©2004 by Harbor Freight Tools®. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
For technical questions and replacement parts please call 1-800-444-3353.
®

SKU 91735 For technical questions, please call 1-800-444-3353. Page 2
THANKYOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please
complete the owner’s record below:
Model______________ Serial No._____________ Purchase Date_______________
SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the
entire manual to become familiar with the unit BEFORE you begin assembly.
Technical Specifications
Construction: Pine wood, Cotton cover with foam cushion
Overall Dimensions: 13-1/2” x 20” x 11-1/4”
Maximum Weight Capacity: 11 Lbs.
Safety Warnings and Precautions
WARNING:When using product, basic safety precautions should always be followed to
reduce the risk of personal injury and damage to equipment.
Read all instructions before using this product!
1. Keep play area clean. Cluttered areas invite injuries.
2. Observe play area conditions. Keep play area well lit.
3. Store idle equipment. When not in use, the Toy Box must be stored in a dry location to inhibit
damage from moisture and salt air.
4. Check for damaged parts. Before using the Toy Box, any part that appears damaged should
be carefully checked to determine that it will operate properly and perform its intended function.
Check for any broken or damaged parts and any other conditions that may affect its operation.
Replace or repair damaged or worn parts immediately.
5. Small children should be supervised by responsible adults. Children must not climb on,
sit on, stand on, play inside or get on top of theToy Box.
6. There are certain applications for which thisToy Box was designed. Do not modify this Toy
Box and do not use this Toy Box for a purpose for which it was not intended.
7. Use eye and ear protection. Always wear ANSI approved impact safety goggles when
assembling this product.
Warning: The warnings, cautions, and instructions discussed in this instruction
manual cannot cover all possible conditions and situations that may
occur. It must be understood by the operator that common sense and
caution are factors which cannot be built into this product, but must be
supplied by the operator.

SKU 91735 For technical questions, please call 1-800-444-3353. Page 3
Assembly
Your Toy Box will require complete assembly. It is important that you read the entire manual to
become familiar with the product BEFORE you use the Toy Box. Before assembling the Toy Box be
sure that you have all parts described in the Parts List and Assembly Diagram located on the last
pages of this manual.
1. Slide the Side Wall (1) into the slot in the corner brace of the Main Wall (2). Make
certain it is square with the Main Wall (2). Secure it in place by screwing a Wood Screw (3)
into each pre-drilled hole in the top, middle and bottom of the corner brace of the Main
Wall (2). Repeat for the second Side Wall (1). Make certain to leave one Main Wall (2)
unattached.
Wood Screw (3)
Side Wall (1)
Corner Brace
Figure 1
Main Wall (2)
2. Turn the Box so it sits on the Main Wall and slide the Floor (4) down into the grooves on the
bottom of the Side Walls (1). Make certain that the Floor (4) slides all the way down into the
groove in the MainWall (2)-see Figure 2.
Floor (4)
SideWall (1)
Main Wall (2)
Figure 2
3. Slide the remaining Main Wall (2) onto the Side Walls (1). Make certain that the bottom
Floor (4) slides into the bottom groove on the Main Wall (2). Make certain that the Main
Wall (2) is square and that each piece is securely fitted into the slots. Tighten it in place by
screwing a Wood Screw (3) into each pre-drilled hole in the top, middle and bottom of the
corner brace of the Main Wall (2).
4. Place the Top (5) onto the assembled Toy Box.

SKU 91735 For technical questions, please call 1-800-444-3353. Page 4
Unpacking
When unpacking your Toy Box, check to make sure the following parts are included. If any parts are
missing or broken, please call HARBOR FREIGHTTOOLS at 1-800-444-3353.
Parts List
Part # Description Quantity
1 Side Wall 2
2 Main Wall 2
3 Wood Screw 12
4 Floor 1
5Top1
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER
THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS
QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT,
THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR
HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
1
2
3
4
Top (5) not shown
Assembly Diagram
The Parts List is shown for identifying all components. Replacement parts are not available.
