Harbor Freight Tools 56513 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 19e
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2019 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
To ol s r eq ui r ed f o r as s em bl y a nd se rvice m ay not be in cluded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 56513
Specifications
Batteries Required 4x “AA” Batteries (for Car)
2x “AA” Batteries (for Remote)
Frequency 2.4 GHz
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Important Safety Information
1. Changes or modifications not expressly
approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
2. Follow basic safety precautions to
reduce the risk of personal injury and/
or damage to the product during use.
3. Do not allow children younger than
age 6 to use this Car. Children should
not operate without adult supervision.
4. Keep out of reach of children younger
than 3. Contains small parts that
may present a choking hazard.
5. Keep spectators and pets away. Spectators
should only watch from a safe distance.
6. Do not mix old and new batteries. Do
not mix alkaline, standard (carbon-zinc), or
rechargeable (nickel-cadmium) batteries.
Position batteries in proper polarity. Do
not use swollen or leaking batteries.
7. Do not open the Car’s housing or
modify its design. Doing so may cause
damage and/or make it dangerous.
8. Do not use if parts are loose
or damaged. If the toy has been
damaged, immediately stop using it.
9. Only use outside or in large,
enclosed area. Do not drive near open
flames, pets, or delicate furniture.
10. If you lose control of the Car,
release the switches.
11. The warnings, precautions, and instructions
discussed in this instruction manual cannot
cover all possible conditions and situations
that may occur. It must be understood by
the operator that common sense and caution
are factors which cannot be built into this
product, but must be supplied by the operator.
12. Maintain product labels and nameplates.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
Assembly
Unpacking
1. Carefully slide the cardboard
support containing the Amphibious
Car out of the packaging.
2. Remove the Remote.
3. Remove the Amphibious Car from
the cardboard. If any part does not
slide out easily, stop and clear the
obstruction before proceeding.

Page 3For technical questions, please call 1-888-866-5797.Item 56513
Installing Batteries
Remote
1. Unscrew and remove the battery
cover on the back of the Remote.
2. Insert two AA batteries (not included)
into battery compartment,
following indicated polarity.
3. Replace the Remote battery cover.
Car
1. Unscrew and remove the battery cover
from the top of the Car. See below.
2. Insert four “AA” batteries (not included)
into the battery compartment,
following the indicated polarity.
CAUTION! Replace all batteries at
one time. All batteries must be of
the same type and charge level.
3. Place battery cover on top of the Car
and slide front tabs into place.
4. Screw cover on securely.
WARNING! If cover does not attach
securely, do not use this toy.
Operation
Pairing Car to Remote
CAUTION! Keep spectators a safe distance away during use.
Note: Before each use, follow these steps to pair the Car with the Remote:
1. Ensure that both the Car and
Remote are turned off.
2. Locate power switch at the back
of the Car and turn on.
Power
Switch
3. Place Car on a flat surface and stand behind
it with the tail pointing towards you.
4. Point the Remote towards the Car and turn
Remote on. The red light will flash once,
indicating that the pairing was successful.
5. Operate the Remote’s control sticks
to make sure the Car is working.
Note: If the Remote’s red light flashes
continuously and the Car does not move,
make sure that batteries are inserted
properly. Repeat pairing process.
Note: Electronic equipment or other radio
control devices may affect the performance
of your Amphibious Car. Find an area free
of such interference when operating Car.

Page 4 For technical questions, please call 1-888-866-5797. Item 56513
Operating Car
Note: Read through this section completely and get familiar with
the controls BEFORE using Amphibious Car.
Note: Each Remote control stick corresponds to the wheels on one side of the Car.
1. To move Car forward, push both control
sticks up. To move Car backward,
push both control sticks down.
2. To steer Car to the right, press the
Left stick up. To steer Car to the
left, press the Right stick up.
3. To stop the Car, release control sticks.
4. After use, turn power switch off and dry
completely. Store indoors, away from
water, out of the reach of children.
Note: The Car is intended for use on top of still
water. Submerging the Car or waves may affect
the internal components and damage the car.
Maintenance
1. Keep the Amphibious Car clean and dry.
2. Store the Amphibious Car out
of the reach of children.
3. Properly recycle all used batteries.
Record Serial Number Here:
Note: If product has no serial number, record
month and year of purchase instead.
Note: Replacement parts are not available.
