Harbor Freight Tools 94737 User manual

REMOTE CONTROL
HELICOPTER
UP & DOWN ONLY
Model 94737
OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit ourWeb site at: http://www.harborfreight.com
Copyright 2006 by Harbor Freight Tools®. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
®
©
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
Due to continuing improvements, actual product may differ slightly from the product described herein.

PRODUCT SPECIFICATIONS
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures, parts list and assembly diagram.
Keep your invoice with this manual. Write the invoice number on the inside of the front
cover. Keep this manual and invoice in a safe and dry place for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep the flight area clean and well lit. Cluttered and dark areas invite acci-
dents.
2. Do not operate electrically powered toys in explosive atmospheres, such as
in the presence of flammable liquids, gases, or dust. Electrically powered
toys create sparks which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating this product.
Distractions can cause you to lose control.
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 2
ELECTRICAL SAFETY
4. Grounded tools must be plugged into an outlet properly installed and
Item Description
Electrical Requirements AC/DC Adapter Power Input: 120 VAC / 60 Hz
AC/DC Adapter Power Output: 9 VDC / 1000MA
Battery Type: 7.2 Volt / 160 mAh Ni-MH
Charger Battery Charge Time: 3 to 5 Hours
Charger Type: Class 2 Power Supply / Includes 10 “AA” Rechargeable Batteries
Helicopter Battery Charge Time: 8 Minutes
Cord Type: 22 AWG X 2C
Controller Batteries Required: “AA” (Qty. 6 Not Included)
Approximate Flight Time Per Charge 30 Seconds to 2 Minutes
Maximum Height of Flight Up to 50 Feet
Controller Maximum Operating Range Operates Up to 300 Feet From Helicopter
Dimensions 16-3/4” Long x 14-1/2” Wide x 4” High
Unit Weight (Helicopter Only) 0.3 Pound

grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs. Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the tools should electrically malfunction or
break down, grounding provides a low resistance path to carry electricity away
from the user.
5. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the
three wire grounded power cord and grounded power supply system.
6. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
7. Do not expose this product to rain or wet conditions. Water entering an
electrically powered toy will increase the risk of electric shock.
8. Do not abuse the Power Cord on the AC/DC Adapter or Charger. Never use
the Power Cord to carry these components or pull the Plug from an outlet.
Keep the Power Cords away from heat, oil, sharp edges, or moving parts.
Replace damaged Power Cords immediately. Damaged Power Cords in-
crease the risk of electric shock.
9. When operating this product outside, use an outdoor extension cord
marked “W-A” or “W”. These extension cords are rated for outdoor use, and
reduce the risk of electric shock.
PERSONAL SAFETY
10. Stay alert. Watch what you are doing, and use common sense when oper-
ating this product. Do not use this product while tired or under the influ-
ence of drugs, alcohol, or medication. A moment of inattention while operat-
ing this product may result in serious personal injury.
11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.
Keep your hair, clothing, and gloves away from moving parts. Loose
clothes, jewelry, or long hair can be caught in moving parts.
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 3
12. Avoid accidental starting. Be sure the Power Switch is off before plugging
in. Carrying electrically powered toys with your finger on the Power Switch, or
plugging in this product with the Power Switch on, invites accidents.

13. Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of the power tool in unexpected
situations.
14. Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate
conditions.
PRODUCT USE AND CARE
15. Do not force the this product. Use the correct product for your application.
The correct product will perform better and safer at the rate for which it is
designed.
16. Do not use this product if the Power Switch does not turn it on or off.
Any product that cannot be controlled with the Power Switch is dangerous and
must be replaced.
17. Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing this product. Such preventive
safety measures reduce the risk of starting the unit accidentally.
18. Store this product out of reach of children and other untrained persons.
Electrically powered toys are dangerous in the hands of untrained users.
19. Maintain this product with care. Keep this product and its accessories
clean. Properly maintained toys are less likely to malfunction and are easier
to control. Do not use this product if damaged. Tag this product “Do not use”
until repaired.
20. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect this product’s operation. If damaged,
have this product serviced before using. Many accidents are caused by
poorly maintained products.
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 4
21. Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one product may become hazard-
ous when used on another product.
SERVICE
22. Product service must be performed only by qualified repair personnel.
Service or maintenance performed by unqualified personnel could result in a risk
of injury.

23. When servicing this product, use only identical replacement parts. Follow
instructions in the “Inspection, Maintenance, And Cleaning” section of this
manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES
1. Maintain labels and nameplates on the Helicopter. These carry important
information. If unreadable or missing, contact Harbor Freight Tools for a replace-
ment.
2. Always wear ANSI approved safety impact eye goggles when assem
bling and operating the Remote Control Helicopter. Using personal
safety devices reduce the risk for injury. Safety impact eye goggles are
available from Harbor Freight Tools.
3. Maintain a safe flying environment. Make sure there is adequate surrounding
outdoor space. Always keep the flight area free of obstructions, grease, oil,
trash, and other debris. Do not use an electrically powered toy in areas near
flammable chemicals, dusts, and vapors.
4. Avoid unintentional starting. Make sure you are prepared to begin work
before turning on the Remote Control Helicopter.
5. Do not force this product. This product will perform better and safer at
the speed and capacity for which it was designed.
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 5
6. IMPORTANT: Carefully inspect the condition of the Remote Control Helicopter
before each use, and check the product continually during use. If any damage is
noted, stop immediately and repair or replace the Helicopter.
7. The charge time for the internal Battery is 3 to 5 hours. Do not charge the
Battery for over 5 hours as damage to the Battery and/or Helicopter may result.
8. Always discontinue operating the Helicopter when its performance begins
to diminish. Severe heat is most destructive to a Battery. The more heat gener-
ated, the faster the Battery loses its power. A Battery that gets too hot can be
permanently damaged. Never over-discharge a Battery by operating the Heli-
copter even after its performance is decreasing. Never attempt to discharge the
Helicopter’s Battery by continuing to operate the unit. When the Helicopter’s
performance begins to diminish stop the unit, re-charge the Battery, and use the
fresh Battery for optimal performance.

SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 6
9. Battery leakage may occur under extreme usage or temperature condi-
tions. If Battery fluid comes in contact with skin, wash with soap and water and
rinse with lemon juice and vinegar. If the fluid comes into contact with eyes,
flush with water for several minutes and contact a physician immediately.
10. Never burn a Battery, as it can explode in a fire. Contact local
solid waste authorities for instructions on correct disposal of a Battery.
11. Do not attempt to charge a leaking Battery.
12. Make sure the Power Switch is in its “OFF” position and the unit is dis-
connected from its Charger prior to performing any inspection, mainte-
nance, or cleaning procedures.
13. Ensure the Batteries (not included) in the Controller are fully charged so you
can maintain control of the Helicopter.
14. Avoid accidental cuts. Stay away from the spinning Blades.
15. Always land the Helicopter on a flat surface to avoid the Blades hitting the
ground or other objects.
16. Fly only in open fields where your view is not obstructed.
17. This product is for outdoor use only.
18. Avoid damaging the Helicopter. Do not fly the unit near houses and trees.
19. Avoid accidental electrical shock. Always stay clear of outdoor elec-
trical power lines.
20. Never attempt to fly the Helicopter in the rain, not even a light drizzle.
21. Do not attempt to fly the Helicopter in heavy winds.
22. Allow the Helicopter to cool down for a minimum of ten minutes after every
four or five flights.
23. Do not attempt to fly the Helicopter if its Motor becomes damaged.
24. WARNING! People with pacemakers should consult their physician(s)
before using this product. Operation of electrical equipment in close proximity to
a heart pacemaker could cause interference or failure of the pacemaker.
25. WARNING! The warnings and cautions discussed in this manual cannot

cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which cannot
be built into this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
GROUNDING
WARNING!
Improperly connecting the grounding wire can result in the risk of electric
shock. Check with a qualified electrician if you are in doubt as to whether the
outlet is properly grounded. Do not modify the power cord plug provided with
the tool. Never remove the grounding prong from the plug. Do not use the
tool if the power cord or plug is damaged. If damaged, have it repaired by
a service facility before use. If the plug will not fit the outlet, have a proper
outlet installed by a qualified electrician.
GROUNDED PRODUCTS: PRODUCTS WITH THREE PRONG PLUGS
1. Products marked with “Grounding Required” have a three wire cord and three
prong grounding plug. The plug must be connected to a properly grounded
outlet. If the unit should electrically malfunction or break down, grounding pro-
vides a low resistance path to carry electricity away from the user, reducing the
risk of electric shock. (See Figure A.)
2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the product. The green wire in the cord must be
the only wire connected to the unit’s grounding system and must never be at
tached to an electrically “live” terminal. (See Figure A.)
3. Your product must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like those in the following illustration. (See Figure A.)
THIS PRODUCT
DOES NOT USE
A 3-PRONG
ELECTRICAL
PLUG 120 VOLT,
GROUNDED,
ELECTRICAL OUTLET
FIGURE A
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 7

SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 8
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Products marked “Double Insulated” do not require grounding. They have a
special double insulation system which satisfies OSHA requirements and com-
plies with the applicable standards of Underwriters Laboratories, Inc., the Cana-
dian Standard Association, and the National Electrical Code. (See Figure B.)
5. Double insulated products may be used in either of the 120 volt outlets shown in
the following illustration. (See Figure B.)
FIGURE B
THE AC/DC ADAPTER
FOR THIS PRODUCT
USES A
2-PRONG PLUG
120 VOLT,
GROUNDED,
ELECTRICAL
OUTLETS
EXTENSION CORDS
1. Grounded products require a three wire extension cord. Double Insulated
products can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a
serious drop in voltage, resulting in loss of power and possible product damage.
(See Figure C, next page.)
3. The smaller the gauge number of the wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure C.)
4. When using more than one extension cord to make up the total length, make
sure each cord contains at least the minimum wire size required.
(See Figure C.)
5. If you are using one extension cord for more than one product, add the name-
plate amperes and use the sum to determine the required minimum cord size.
(See Figure C.)
6. If you are using an extension cord outdoors, make sure it is marked with the
suffix “W-A” (“W” in Canada) to indicate it is acceptable for outdoor use.

SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 9
7. Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified
electrician before using it.
8. Protect your extension cords from sharp objects, excessive heat, and damp or
wet areas.
RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*
(120 VOLT)
NAMEPLATE
AMPERES
(
At Full Load
)
EXTENSION CORD LENGTH
25
Feet
50
Feet
75
Feet
100
Feet
150
Feet
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
* Based on limiting the line voltage drop
to five volts at 150% of the rated amperes.
FIGURE C
SYMBOLOGY
FIGURE D

OPERATING INSTRUCTIONS
1. CAUTION! Always make sure the Power Switch of the Helicopter is in its
“OFF” position and the unit is disconnected from its Charger (4) prior to assem-
bling the unit, adding any accessories, or making adjustments to the unit.
Recharging The Charger Batteries:
1. If recharging the internal Helicopter Battery within the accessory Charger (4), the
ten rechargeable Batteries (5) must be fully charged before operating the Heli-
copter. (See Figure E.)
2. When charging the ten rechargeable Batteries (5) within the Charger (4) for the
first time, and all subsequent charges, the charge time is 3 to 5 hours. Never
charge the Batteries for longer than 5 hours, as damage to the Batteries and/or
Charger will occur. (See Figure E.)
3. To charge the ten rechargeable Batteries (5), connect the plug of the AC/DC
Adapter (3) into the Charger (4) Input Port. Then connect the AC/DC Adapter to
the nearest 120 volt, grounded, electrical outlet.
4. Verify on the Charger (4) that the red charging indicator light is blinking.
If it is not blinking, check the power connection or try a different electrical outlet.
The red charging indicator light will automatically turn off when the Batteries are
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 10
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts List on page 15
are included. If any parts are missing or broken, please call Harbor Freight Tools at the
number shown on the cover of this manual as soon as possible.
CHARGER
(4)
RECHARGEABLE BATTERIES
(NOT SHOWN)
AC/DC ADAPTER
(3)
CHARGER INPUT PORT
RED CHARGING
INDICATOR
LIGHT
FIGURE E

fully charged. Once charged, unplug the AC/DC Adapter from its electrical
outlet. Then remove the plug of the AC/DC Adapter from the Charger.
(See Figure E.)
To Charge The Internal Battery Of The Helicopter:
1. The internal Battery of the Helicopter (1) may be charged two ways:
2. To charge the internal Battery of the Helicopter (1) using the Charger (4),
make sure the Charger’s ten rechargeable Batteries are fully charged.
(See previous section of this manual.)
4. Connect one end of the Charge Lead (6) to the Charger’s (4) Output Port.
(See Figure F.)
5. Connect the other end of the Charge Lead (6) to the Charging Input Port of the
Helicopter. The charging time for the internal Battery of the Helicopter (1) is
approximately 8 minutes. Do not overcharge. Before your first flight of the
day, charge two times. Charge only one time between flights. (See Figure F.)
6. At the end of 8 minutes charge time, unplug the Charge Lead (6) from the
Charger (4). Then unplug the Charge Lead from the Helicopter (1).
(See Figure F.)
FIGURE F
HELICOPTER
(1)
CHARGER
(4)
CHARGE LEAD
(6)
HELICOPTER POWER SWITCH
7. To charge the internal Battery of the Helicopter (1) using the AC/DC
Adapter (3), make sure the Power Switch on the Helicopter (1) is in its “OFF”
position. (See Figure G, next page.)
3. Check to make sure the Power Switch on the Helicopter (1) is in its “OFF” posi-
tion. (See Figure F.)
8. Connect the plug of the AC/DC Adapter into the Charging Input Port of the Heli-
copter (1). Then connect the AC/DC Adapter to the nearest 120 volt, grounded,
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 11

SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 12
8 minutes. Do not overcharge. Before your first flight of the day, charge two
times. Charge only one time between flights. (See Figure G.)
10. At the end of 8 minutes charge time, unplug the AC/DC Adapter from its electri-
cal outlet. Then, remove the AC/DC Adapter’s (3) plug from the Helicopter (1).
(See Figure G.)
9. The charging time for the internal Battery of the Helicopter (1) is approximately
electrical outlet. (See Figure G.)
AC/DC ADAPTER
(3)
HELICOPTER POWER SWITCH
FIGURE G
To Install Batteries In The Controller:
1. The Controller (2) requires the use of six “1.5” volt Batteries (not included) to
operate. (See Figure H.)
2. Check to make sure the Power Switch on the Controller (2) is in its “OFF” posi-
tion. (See Figure H.)
3. Loosen the Screw on the Battery Compartment Cover from the bottom of the
Controller (2). (See Figure H.)
FIGURE H SCREW
BATTERY COMPARTMENT COVER
BATTERY COMPARTMENT

4. Insert six fully charged “1.5” volt Batteries into the Battery Compartment, making
sure the correct end of each Battery is inserted into the correct pole.
(See Figure H.)
5. Close the Battery Compartment Cover, and re-tighten the Screw.
(See Figure H.)
To Operate The Helicopter:
1. Set the Helicopter (1) on a soft, grassy, flat, dry ground surface away from all
electric power lines, houses, trees, etc.
2. Turn the Power Switch of the Helicopter (1) to its “ON” position.
3. Make sure you are at least six feet away from the Helicopter (1). Then, turn the
Power Switch of the Controller (2) to its “ON” position.
4. Pull the Trigger of the Controller (2) inward to start and fly the Helicopter (1).
The Helicopter has proportional control, meaning the harder you pull the Trigger
on the Controller the higher the Helicopter will fly.
5. To land the Helicopter (1), select a soft, grassy, flat, dry ground surface. (Hard
landing surfaces may damage the Helicopter.)
6. Ease off the the Trigger of the Controller (2) slowly. Do not ease off too fast, or
the Helicopter may come down faster than anticipated and may become dam-
aged.
7. To stop the Rotor from spinning, push the Trigger of the Controller (2) outwards
to brake. You must continue to push outwards on the Trigger or the Rotor will
start spinning again.
8. Turn the Power Switch of the Controller (2) to its “OFF” position. Make sure the
Rotor of the Helicopter is no longer spinning. Then, approach the Helicopter and
turn its Power Switch to the “OFF” position.
9. When finished flying the Helicopter (1), make sure to store the unit and its acces-
sories in a clean, dry, safe location out of reach of children and other unautho-
rized people.
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 13

SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 14
INSPECTION, MAINTENANCE, AND CLEANING
1. WARNING! Make sure the Power Switches of the Helicopter and Control-
ler are in their “OFF” positions prior to performing any inspection, maintenance,
or cleaning procedures.
2. Before each use: Inspect the general condition of the Helicopter and its acces-
sories. Check for loose screws, misalignment or binding of moving parts,
cracked or broken parts, and any other condition that may affect safe operation.
If abnormal noise or vibration occurs, have the problem corrected before further
use. Do not use if damaged.
3. To clean the Helicopter and its accessories: Use only a clean cloth and mild
detergent. Do not use solvents. Do not immerse any part of this product in
liquids.
4. When storing, make sure to store the Helicopter and its accessories in a clean,
dry, safe location out of reach of children and other unauthorized people.
TROUBLESHOOTING
5. CAUTION! All maintenance, service, or repairs not mentioned in this
manual must only be performed by a qualified service technician.
Problem Possible Solution
Helicopter will not fly. 1. Make sure the Power Switch of the Helicopter and
the Power Switch of the Controller are both in their
“ON” positions.
2. Make sure to pull inward on the Trigger of the
Helicopter.
3. Make sure the internal Battery in the Helicopter is
fully charged.
4. Make sure the Batteries in the Controller are fully
charged.
Helicopter lands too hard. 1. Ease off slowly on the Trigger of the Controller.
The Charger will not accept
a charge.
1. Make sure the AC/DC Adapter is plugged into a
working, 120 volt, grounded, electrical outlet.
2. Make sure the plug of the AC/DC Adapter is
properly inserted into the Input Port of the Charger.
The internal Battery of the
Helicopter will not accept
a charge.
1. Make sure the Power Switch of the Helicopter is in
its “OFF” position.
2. Make sure the Charge Lead of the Charger (or plug
of the AC/DC Adapter) is properly inserted into the
Input Port of the Helicopter.
The Power Switch of the
Helicopter and/or Controller
does not turn the unit on or
off.
1. Immediately discontinue operating the Helicopter
and its accessories and have a qualified service
technician check out the unit.

PARTS LIST AND ASSEMBLY DIAGRAM
NOTE:
Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.
SKU 94737 For technical questions, please call 1-800-444-3353 PAGE 15
Part # Description Qty. Part # Description Qty.
1 Helicopter 1 4 Charger 1
2 Controller 1 5 1.5 Volt “AA”
Rechargeable Battery
10
3 AC/DC Adapter 1 6 Charge Lead 1
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST
AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEI-
THER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR
WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO
REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACE-
MENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISKS AND LIABILITY ARIS-
ING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACE-
MENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF
REPLACEMENT PARTS THERETO.
1
2
3
4
5
