Hardi ALPHA evo ALU-TWIN FORCE User manual

ALPHA evo
ALU - TWIN FORCE
Translation of the original
Instruction ook
67786801-100 - Version 1.03
GB - 10.2012
www.hardi-fr.com

We congratulate ou for choosing a HARDI plant protection product. The reliabilit and
efficienc of this product depend upon our care. The first step is to carefull read this
instruction book. It contains essential information for the efficient use and long life of this
qualit product.
As this instruction book covers all models, including all h draulic boom versions, please
pa attention to the paragraphs dealing with precisel our model.
This book is to be read in conjunction with the "Spra Technique" book.
The original instruction book is in French. The versions in other languages are translated from the original. In the
event of contradiction or inaccurac between the original French version and the versions in other languages, the
original French version shall prevail.
Illustrations, technical information and data in this book are to the best of our belief correct at the time of printing.
As it is HARDI-EVRARD polic permanentl to improve our products, we reserve the right to make changes in
design, features, accessories, specifications and maintenance instructions at an time and without notice.
HARDI-EVRARD is without an obligation in relation to equipment purchased before or after such changes.
HARDI-EVRARD has made ever effort in writing this instruction book to make it as accurate and complete as
possible. It ma not be held responsible for an omissions or inaccuracies.
As this instruction book covers all models, characteristics or equipment onl available in certain countries ma be
described. Pa special attention to the paragraphs concerning the model that ou own.
Published and printed b HARDI EVRARD

#
Ta le of content
1 - EC Declaration of Conformity
EC Declaration of Conformity ................................................................................................................7
2 - Safety instructions
Operator safety .....................................................................................................................................9
S mbols ........................................................................................................................................................................................................................ 9
Guidelines ................................................................................................................................................................................................................... 9
Filling and application ........................................................................................................................................................................................ 9
Usage .......................................................................................................................................................................................................................... 10
Spra er usage ........................................................................................................................................................................................................ 10
Operator's skill ....................................................................................................................................................................................................... 10
Definition of the working place ................................................................................................................................................................. 10
Responsibilities of the manufacturer and the user ........................................................................................................................ 11
Lights, working at night .................................................................................................................................................................................. 11
Driving on public roads ................................................................................................................................................................................... 11
Driving in fields ..................................................................................................................................................................................................... 11
Safet s mbols ...................................................................................................................................................................................................... 12
Regulations on the use of chemical waste ......................................................................................................................................... 12
3 - Description
General information ............................................................................................................................13
Overview .................................................................................................................................................................................................................. 13
Spra er identification plate ........................................................................................................................................................................... 14
Boom ...................................................................................................................................................15
Boom and terminolog ................................................................................................................................................................................... 15
Liquid system ......................................................................................................................................16
General information - valve s stem ......................................................................................................................................................... 16
Pump .......................................................................................................................................................................................................................... 16
Valves and s mbols ............................................................................................................................................................................................ 16
Suction valve = blue s mbols ..................................................................................................................................................................... 16
Pressure valve = green s mbols ................................................................................................................................................................ 16
Agitation valve = green s mbols .............................................................................................................................................................. 17
TurboFiller = ellow s mbols ....................................................................................................................................................................... 17
Diagram - Liquid s stem ................................................................................................................................................................................. 18
Eas Clean filter ...................................................................................................................................................................................................... 19
Ca in ....................................................................................................................................................20
Description of console ..................................................................................................................................................................................... 20
Description of console - 4-wheel drive/speed limiter ................................................................................................................. 21
HAZ boom h draulic function controls ................................................................................................................................................ 22
Steering column .................................................................................................................................................................................................. 22
General description of operator's seat ................................................................................................................................................... 23
Cabin ceiling controls ....................................................................................................................................................................................... 24
Description of driver's seat ............................................................................................................................................................................ 25
Sprayer description .............................................................................................................................26
External controls .................................................................................................................................................................................................. 26
External electrical controls ............................................................................................................................................................................ 26
TWIN air assistance ..............................................................................................................................27
General information .......................................................................................................................................................................................... 27
4 - Sprayer setup
General information ............................................................................................................................29
Unloading the spra er from the truck ................................................................................................................................................... 29
Accessories .............................................................................................................................................................................................................. 29
Precautions before putting the spra er into operation .............................................................................................................. 29
Filling the fuel tank ............................................................................................................................................................................................. 30
Spra pump ............................................................................................................................................................................................................ 30
C cloneFilter .......................................................................................................................................................................................................... 30
Fitting the nozzles .............................................................................................................................................................................................. 30
Filling the rinse tank .......................................................................................................................................................................................... 30

#
Altering the track gauge ................................................................................................................................................................................. 31
T re pressures ........................................................................................................................................................................................................ 31
TWIN air assistance ..............................................................................................................................32
Adjusting the air assistance .......................................................................................................................................................................... 32
Adjusting the air speed, rules of thumb ............................................................................................................................................... 32
Angling of air and nozzle flow, rules of thumb ................................................................................................................................ 33
Water sensitive paper ....................................................................................................................................................................................... 33
Transport .............................................................................................................................................34
Transport position .............................................................................................................................................................................................. 34
Boom ...................................................................................................................................................35
Damping adjustment ....................................................................................................................................................................................... 35
Boom folding speed adjustment .............................................................................................................................................................. 35
Boom folding speed adjustment - 32-36 m boom onl ............................................................................................................. 35
5- Operation
Engine cover ........................................................................................................................................37
General information .......................................................................................................................................................................................... 37
DESCRIPTION ......................................................................................................................................................................................................... 37
Side housing .......................................................................................................................................................................................................... 37
Driving .................................................................................................................................................38
Starting up and shutting down the engine ....................................................................................................................................... 38
Forward speed selection ................................................................................................................................................................................ 39
Forward movement and braking .............................................................................................................................................................. 39
Parking brake ......................................................................................................................................................................................................... 40
Travelling in "ROAD" mode ........................................................................................................................................................................... 40
COMFORT - NORMAL - POWER driving mode .................................................................................................................................. 41
"FIELD - UPHILL - DOWNHILL" mode ...................................................................................................................................................... 41
Forward speed limitation ............................................................................................................................................................................... 42
Anti-stall device .................................................................................................................................................................................................... 43
Engine overspeed ............................................................................................................................................................................................... 43
Boom ...................................................................................................................................................44
Safet information .............................................................................................................................................................................................. 44
Folding and unfolding the LPA2 and LPA5 boom ......................................................................................................................... 44
HAZ (TWIN) boom folding and unfolding ........................................................................................................................................... 46
H draulic slanting control ............................................................................................................................................................................. 46
Alternative boom widths ............................................................................................................................................................................... 46
Boom tilt function ............................................................................................................................................................................................... 46
Boom support wheels ...................................................................................................................................................................................... 46
H draulic break-awa function .................................................................................................................................................................. 46
Boom lighting ....................................................................................................................................................................................................... 47
Electricall controlled end nozzles (optional) ................................................................................................................................... 47
TWIN air assistance ..............................................................................................................................48
General information .......................................................................................................................................................................................... 48
TWIN operation .................................................................................................................................................................................................... 48
Spraying ..............................................................................................................................................49
Safet information .............................................................................................................................................................................................. 49
Starting and adjusting the speed of the spra pump .................................................................................................................. 49
Filling the rinse tank .......................................................................................................................................................................................... 50
Filling and use of hand wash tank ............................................................................................................................................................ 50
EFC operating unit adjustment .................................................................................................................................................................. 51
Filling chemicals through the tank opening ..................................................................................................................................... 51
Filling the tank through the main tank lid ........................................................................................................................................... 51
Filling the main tank b external suction ............................................................................................................................................. 52
Filling chemicals through the tank opening ..................................................................................................................................... 54
Filling with chemicals ....................................................................................................................................................................................... 54
Agitation before re-starting spra ing ..................................................................................................................................................... 56
Quick reference - Operation ......................................................................................................................................................................... 57
Cleaning ...............................................................................................................................................58
General information .......................................................................................................................................................................................... 58

#
Cleaning the tank and liquid s stem ...................................................................................................................................................... 59
Cleaning and maintenance of filters ....................................................................................................................................................... 59
Use of rinse tank and rinsing nozzles ..................................................................................................................................................... 60
Quick reference - Cleaning ............................................................................................................................................................................ 61
Technical residue ................................................................................................................................................................................................ 61
Using the drain valve ........................................................................................................................................................................................ 61
Transfer to external tank ................................................................................................................................................................................. 62
External cleaning - Use of External Cleaning Device (optional equipment) .................................................................. 62
Air conditioning ...................................................................................................................................63
General information .......................................................................................................................................................................................... 63
Description of air conditioning control unit ...................................................................................................................................... 63
Operation of air conditioning control unit ......................................................................................................................................... 63
Air conditioning error codes ........................................................................................................................................................................ 64
CANcockpit - rev counter .....................................................................................................................65
General information .......................................................................................................................................................................................... 65
Description of messages ................................................................................................................................................................................ 65
Partial and total hour meter ......................................................................................................................................................................... 65
Maintenance .......................................................................................................................................................................................................... 65
Engine faults ........................................................................................................................................................................................................... 66
Faults in transmission ....................................................................................................................................................................................... 66
Steering - automatic 4-wheel steering version (standard) ..................................................................67
General information .......................................................................................................................................................................................... 67
DESCRIPTION ......................................................................................................................................................................................................... 67
Travelling in 2-wheel steering ..................................................................................................................................................................... 67
Travelling in 4-wheel steering ..................................................................................................................................................................... 67
Travelling in offset 2-wheel steering ....................................................................................................................................................... 68
Steering - 4-wheel steering version with cra steering (optional) ......................................................69
General information .......................................................................................................................................................................................... 69
DESCRIPTION ......................................................................................................................................................................................................... 69
2-wheel steering mode ................................................................................................................................................................................... 69
4-wheel steering mode ................................................................................................................................................................................... 69
"CRAB" mode ......................................................................................................................................................................................................... 70
Travelling in "SLANTING" mode ................................................................................................................................................................. 70
6 - Maintenance
Lu rication ..........................................................................................................................................73
General information .......................................................................................................................................................................................... 73
Table of recommended lubricants .......................................................................................................................................................... 73
Maintenance after using for the first time ...........................................................................................74
After 10 hours ........................................................................................................................................................................................................ 74
After 150 hours ..................................................................................................................................................................................................... 74
Wheel nuts .............................................................................................................................................................................................................. 74
HAZ boom lubrication & oiling plan ....................................................................................................................................................... 75
HAZ boom lubrication & oiling plan (32-36 m) ................................................................................................................................ 76
Aluminium boom checks ............................................................................................................................................................................... 77
Regular maintenance ..........................................................................................................................78
Frequenc ................................................................................................................................................................................................................ 78
Resetting the CANcockpit ............................................................................................................................................................................. 79
Access to cabin roof .......................................................................................................................................................................................... 79
Ever 10 hours - C cloneFilter ..................................................................................................................................................................... 80
Ever 10 hours - Eas Clean filter ................................................................................................................................................................ 80
Ever 10 hours - pressure filter .................................................................................................................................................................... 81
Ever 50 hours - in-line filter for external suction ........................................................................................................................... 81
Ever 50 hours - lubrication of diaphragm pump 463 ................................................................................................................ 81
Ever 50 hours - lubrication of front and rear axle ......................................................................................................................... 82
Ever 50 hours - engine cooling ................................................................................................................................................................ 82
Ever 50 hours - checking and cleaning the engine air filter .................................................................................................. 83
Ever 50 hours - compressed air tank .................................................................................................................................................... 83
Ever 50 hours - t re pressures ................................................................................................................................................................... 83

#
Ever 250 hours - h draulic filter ............................................................................................................................................................... 84
Ever 250 hours - filter and lubricator (optional) ............................................................................................................................. 84
Ever 250 hours - spra er pressure gauge .......................................................................................................................................... 85
Ever 500 hours - brake s stem h draulic filter ................................................................................................................................ 85
Ever 500 hours - h draulic filters in the tank ................................................................................................................................... 85
Ever 500 hours - drainage and replacement of the oil filter .................................................................................................. 86
Ever 500 hours - bleeding water separator fuel prefilter ......................................................................................................... 87
Ever 500 hours - replacement of fuel filters ..................................................................................................................................... 87
Ever 500 hours - air conditioning compressor belt ..................................................................................................................... 87
Ever 500 hours - active carbon filter ..................................................................................................................................................... 88
Ever 1000 hours - drainage and cleaning of the h draulic tank ......................................................................................... 88
Ever 1000 hours - batter ............................................................................................................................................................................. 88
Ever 5 ears - engine coolant replacement ..................................................................................................................................... 89
Ever 1000 hours - air conditioning ......................................................................................................................................................... 89
Occasional maintenance ......................................................................................................................90
General information .......................................................................................................................................................................................... 90
463 pump valve and diaphragm replacement ................................................................................................................................ 90
Control valve c linder check/replacement ......................................................................................................................................... 90
Distribution valve seal check/replacement ........................................................................................................................................ 91
External gauge adjustment .......................................................................................................................................................................... 91
Gauge cord replacement ............................................................................................................................................................................... 91
Drain valve seal replacement ...................................................................................................................................................................... 92
Boom connectors and pipes ........................................................................................................................................................................ 92
Adjustment of 3-wa -valves ......................................................................................................................................................................... 92
HAZ oom ............................................................................................................................................93
Boom adjustment - general information ............................................................................................................................................. 93
Alignment of central and inner boom sections ............................................................................................................................... 93
TR4 - TR4R aluminium oom ...............................................................................................................94
General information .......................................................................................................................................................................................... 94
Horizontal alignment of outer sections (TR4 - TR4R) .................................................................................................................... 94
Vertical alignment of outer sections and end sections (TR4 - TR4R) ................................................................................... 95
Vertical alignment of outer sections with break-awa sections (TR4 - TR4R) ................................................................ 95
Adjustment of break-awa sections - (TR4 - TR4R) ......................................................................................................................... 95
Adjustment of parallel setting of the central frame (LPA2 frame) ........................................................................................ 96
Suspension adjustment .................................................................................................................................................................................. 96
Replacement and adjustment of anti- aw device (LPA2 frame) ........................................................................................... 96
Replacement and adjustment of dampers (LPA2 frame) .......................................................................................................... 97
Boom h draulic damper ................................................................................................................................................................................. 98
Compressed air pressure adjustment .................................................................................................................................................... 98
Air pressure adjustment .................................................................................................................................................................................. 99
Change of bulbs .................................................................................................................................................................................................. 99
Off-season storage ........................................................................................................................... 100
Off-season storage program ......................................................................................................................................................................100
Preparing the spra er for use after storage ......................................................................................................................................100
7 - Trou leshooting
Trou leshooting ............................................................................................................................... 101
Control valve DG4 .............................................................................................................................................................................................101
Spra ing ..................................................................................................................................................................................................................102
H draulic functions ..........................................................................................................................................................................................102
Transmission ........................................................................................................................................................................................................103
Mechanical incidents ........................................................................................................................ 104
Speed transducer ..............................................................................................................................................................................................104
Spra pressure gauge .....................................................................................................................................................................................104
Hydraulic incidents ........................................................................................................................... 105
General information ........................................................................................................................................................................................105
Releasing the h draulic motor brakes .................................................................................................................................................105
Transmission pump high pressure valves .........................................................................................................................................105
H draulic tank level alarm ...........................................................................................................................................................................106

#
H draulic block - manual control and pressure adjustment .................................................................................................106
Boom damper control - manual unlocking ......................................................................................................................................106
Error messages ................................................................................................................................. 107
Transmission errors ..........................................................................................................................................................................................107
Engine errors ........................................................................................................................................................................................................108
Engine errors ........................................................................................................................................................................................................109
Electrical incidents ........................................................................................................................... 113
Location of main components .................................................................................................................................................................113
HC 9500 controller fuse .................................................................................................................................................................................113
Main circuit fuses and rela s. .....................................................................................................................................................................113
Fuse test ..................................................................................................................................................................................................................115
Side lights fuses ..................................................................................................................................................................................................115
Cabin fuses ............................................................................................................................................................................................................115
Engine - cabin - REGULOR 6 fuses ..........................................................................................................................................................115
Lighting ...................................................................................................................................................................................................................116
8 - Technical specifications
Features ............................................................................................................................................ 117
Technical specifications ................................................................................................................................................................................117
T re pressure ........................................................................................................................................................................................................118
Boom width ..........................................................................................................................................................................................................119
Component identification plates ............................................................................................................................................................119
Nitrogen accumulators .................................................................................................................................................................................120
H draulic pressure ............................................................................................................................................................................................120
Air conditioning .................................................................................................................................................................................................120
Materials and recycling .................................................................................................................... 121
Rec cling ................................................................................................................................................................................................................121
Boom hydraulic systems ................................................................................................................... 122
Boom h draulic - Y ...........................................................................................................................................................................................122
Boom h draulic - Z ...........................................................................................................................................................................................122
Boom h draulic - LPA3 ..................................................................................................................................................................................123
Boom h draulic - LPA2 ..................................................................................................................................................................................124
Boom h draulic - TR5 ......................................................................................................................................................................................125
Index
Index ................................................................................................................................................. 127

#

7
1 - EC Declaration of Conformity
EC Declaration of Conformity
The Manufacturer:
HARDI-EVRARD
43 rue du Cuivre-BP 59
77542 SAVIGNY-LE-TEMPLE CEDEX
FRANCE
declares that the following equipment:
•Conform to all of the relevant provisions of the Machiner Directive 2006/127/EC of 21 October 2009 amending
Directive 2006/42/EC with regard to machiner for pesticide application.
•Conform to the provisions of Council Directive 2004/108/EC (EMC).
•Compl with the provisions of Appendix I provided in article R.4312-1 appearing at the end of title 1, book III of the
fourth section of the French Labour Code, amended b Decree No. 20011-1480 of 9 November 2011 related to work
equipment and personal protective equipment.
Managing Director
HARDI-EVRARD
ALPHA 3500 evo and ALPHA 4100 evo self-propelled sprayers

1 - EC Declaration of Conformity
8

9
2 - Safety instructions
Operator safety
Sym ols
These s mbols are used throughout this book to draw the reader's attention to certain points. This is the meaning of the
four s mbols.
€
This s mbol means DANGER. Be ver alert as our safet is at risk!
±
This s mbol means WARNING. Be ver aware as our safet ma be at risk!
µ
This s mbol means ATTENTION. This guides ou towards better, easier and safer use of our spra er!
÷
This s mbol means NOTE.
Guidelines
Before using the spra er, read the following recommendations and the safet instructions:
€
Read this instruction book carefull before using the equipment. It is equall important that other operators of this
equipment also read this book.
If an parts of this instruction book remain unclear after reading it, contact our retailer for further information before
using the spra er.
€
Local legislation ma require operators to have a certificate of competence in the use of the equipment. Respect the
applicable local legislation.
€
The driver's seat is the intended working place during operation.
€
Wear protective clothing. Clothing ma differ according to the plant protection chemicals used. Respect the
applicable local legislation.
After spra ing, the operator should have a wash and change his clothes. Clean an equipment that ma have become
soiled.
€
Do not eat, drink or smoke during the use and maintenance of our spra er.
In case of poisoning, immediatel seek medical advice or call the emergenc service indicated on the packaging of
the products used.
Filling and application
€
No persons are allowed in the operational area of the spra er. Take care not to harm people or surroundings when
manoeuvring the spra er, especiall when reversing.
€
Slow down when driving on uneven terrain as the spra er ma become unbalanced and overturn.
€
Keep children awa from the spra er.
€
Do not attempt to enter the tank.
€
Do not go under the machine unless it is secured. The boom is secure when placed in the transport brackets.
€
For further information, see the Spra Technique book.

2 - Safety instructions
10
Usage
€
Carr out a pressure test with clean water prior to filling with chemicals. Never dismantle the hose while the spra er
is in operation.
DANGER! Do not exceed the maximum recommended rotation speed of the pump.
€
Rinse and wash the equipment after use and before servicing.
€
Never service or repair the equipment while it is operating. Alwa s replace all safet devices or shields immediatel
after servicing or repair.
€
Disconnect the electrical power before servicing and depressurise the equipment after use and before servicing.
€
If an arc welder is used and connected to an part of the spra er, disconnect the power leads from the batter before
welding. Remove all inflammable or explosive material from the welding area.
€
The External Cleaning Device should not be used if important parts of the equipment have been damaged, including
safet devices, high pressure hoses etc.
€
Take all precautions to avoid the risks related to unintentional contact with overhead power lines. A sticker placed
near the operator's seat warns of the risk of contact with overhead power lines.
Sprayer usage
This HARDI EVRARD self-propelled spra er is exclusivel intended for use in farming work, i.e. the application of plant
protection chemicals and liquid fertilisers.
An other use is considered contrar to normal usage and is therefore forbidden.
Operator's skill
The machine should be used and maintained b people who are aware of its special use and safet characteristics.
Before using our machine, familiarise ourself with all the commands. When working it will be too late to do so.
Ensure that ou have the skills required for protecting crops and the environment, and for handling and spra ing plant
protection chemicals. For more information about personal and environmental protection, see the SPRAY TECHNIQUES
book.
Definition of the working place
Never leave the operator's seat when the machine is moving.
The following is considered as the working place:
1. the outside area where the valves are located that can be handled during tank filling and liquid preparation operations
2. the operator's seat
3. the access ladder and the footboard for accessing the tank opening
A. Clean Zone engine
cabin access ladder and gangwa
operator's seat
access to main tank
B. Work zone liquid s stem valves
filling with plant protection chemicals
external connectors (filling - transfer)
C. Spra ing zone spra ing boom and nozzles
boom h draulic controls
EVRARD
HARDI
GROUPE
AC B

2 - Safety instructions
11
Responsi ilities of the manufacturer and the user
•Compl with all recommendations for installation, carr ing out adjustments, maintenance and repair contained in this
instruction book.
•Use onl original spare parts and accessories conforming to the manufacturer's recommendations.
•Do not modif or have our machine and its accessories modified b someone else (mechanical, electrical, h draulic
and pneumatic characteristics) and, more generall , the parts of the machine affecting user safet , without first
requesting written agreement from the manufacturer.
•Failure to respect these rules ma make our machine dangerous. In the event of damage or injur , HARDI EVRARD
shall not be held liable in an wa .
Lights, working at night
If there is insufficient light for working at night, the spra ing boom should be equipped with boom lights. For more
information on this equipment, contact our HARDI EVRARD retailer.
Driving on pu lic roads
When driving on public roads where the highwa code and an other regulations appl , these must be observed,
particularl regarding mandator equipment such as lights, indicators, hazard lights etc.
You should be aware of the vehicle's size and weight, particularl the overall width and height. For more information, see
section “Technical specifications” on page 117.
µ
ATTENTION! In all circumstances, ou should adapt to road driving, particularl b reducing our speed on bends, on
meeting or being overtaking b another vehicle, depending on the state of the road surface and how full the tank is.
Driving in fields
It is advisable to pa a lot of attention to the risks of overturning, especiall in 4-wheel drive mode and when travelling at
speeds of more than 15 km/hr.
µ
ATTENTION! As a general rule:
•Adapt our speed and driving to suit the terrain ou are driving on.
Be aware and take care!
•In all circumstances and particularl on uneven and sloping terrain,
drive the machine at a low speed, especiall on bends and avoid
sudden changes of direction.
•Do not brake or start up suddenl when going up or down a slope,
bearing in mind the variable volume of liquid in the spra er tank.
±
WARNING! Boom manoeuvres should be carried out with the
engine shut down and on flat ground. Ensure that there are no
obstacles nearb (electricit lines, people, poles etc.).

2 - Safety instructions
12
Safety sym ols
Safet s mbols show the different locations of the spra er that present risks for our safet . These s mbols should be
respected b all people working on or near the machine.
The safet s mbols should alwa s be clean and readable. Worn or damaged labels must be replaced with new ones. Contact
our local dealer for new labels.
÷
NOTE! The list of warnings presented below ma var according to the function of the equipment.
Regulations on the use of chemical waste
For further information on using waste, see section "Environmental Protection" in the SPRAY TECHNIQUES book.
Not for drinking!
Filling the rinsing tank with clean water
Point d'ancrage !
SService!
Shut off engine and remove ignition ke
before performing maintenance or repair.
isk of falling!
Do not ride on platform or ladder during use..
SService!
Tighten with torque according to instruction
book.
Risk of burn!
Sta clear of hot surfaces
Risk of injur !
Keep hands awa .
RRisk of crushing!
Sta clear of raised unsecured loads.
Risk of injur !
Do not open or remove safet shields while
engine is running.
.Handling chemicals!
Carefull read the information about chemical
preparation before operating the machine.
Observe the instructions and safet
instructions when operating
Risk of electrocution!
Keep sufficient distance awa from electrical
power..
Risk of injur
Do not enter in the tank
Handle!
Use the cabin access ladder.
.Service!
Tighten with torque according to instruction
book
DANGER !

13
3 - Description
General information
Overview
1. Main tank lid 8. External controls
2. Main tank 9. Clean water tank
3. Central boom frame 10. Cabin access gangwa
4. Rear damper 11. Cabin access ladder
5. Multi-wa suction valve 12. H draulic motors
6. Agitation valve 13. Engine cover
7. Multi-wa valves - pressure (SmartValve) 14. GPS receiver
4
5
6789
1 2 3
101112
13
14

3 - Description
14
Sprayer identification plate
A manufacturer's plate is fixed to the right-hand side of the chassis. It
indicates the following elements:
•Serial number.
•T pe and variant.
•Year of manufacture.
•Empt weight and maximum authorised total weight.
•Axle weight 1 (front axle).
•Axle weight 2 (rear axle).
•Date and place of receipt of spra er.
•Cold marking on chassis (Serial No. - T pe- Variant).
µ
ATTENTION! The identification plate is regulator , it should alwa s be in place on the spra er. For all information about
the machine, please quote the serial number of the spra er.
Other identification plates are attached to the machine components, see section “Component identification plates” on
page 119.
Marque : EVRARD
Année fabrication
Masses maximales admissibles
Essieu 1/attelage
Essieu 2
Essieu 3 kg
kg
kg
N° de série
kg
kg
kg
Type Variante Version
PV
PTAC
PTRA
Réceptionné le
par la DRIRE
HARDI-EVRARD
62990 BEAURAINVILLE
54200
2008
6900
6900
8840
13440
28/09/09
OUTREAU
AH12 - ALP414MS18129
54200 - AH12 - ALP414MS18129

3 - Description
15
Boom
Boom and terminology
The TWIN FORCE booms have a stable and robust parallelogram lift and are pendulum suspended. There are two versions:
HAY and HAZ.
The TWIN blowers are driven b h drostatic transmission integrated into the self-propelled vehicle. The blower speed can
be adjusted b increments from the cabin.
The 18-30 m HAY boom is pendulum suspended and has 4 h draulic rams. The raising/lowering and folding/unfolding
functions are operated via the spra er h draulics.
The 18-30 m HAZ boom is pendulum suspended and operates h draulicall . All functions are operated b direct acting
h draulics (D.A.H.). The boom is also equipped with an individual slanting boom control and h draulic locking of the
suspended pendulum.
The 32-36 m HAZ boom is pendulum suspended and operates h draulicall . The boom is also equipped with an individual
slanting boom control and h draulic locking of the suspended pendulum.
The end sections of all booms are break-awa sections.
Booms are available in 18, 20, 21, 24, 27, 28 and 30 m widths. For 4400 and 6600-litre spra ers, the boom is also available in
32, 33 and 36 m widths. All booms can be folded awa into 2 sections.
The boom can also be used half-folded. Half folded widths are as follows:
For 2-folded booms the terminolog is as follows:
A. Break-awa section
B. Outer section
C. Intermediate section
D. Central section
Full working width 1/2 folded
18 metres 12 metres
20 metres 12 metres
21 metres 12 metres
24 metres 12 metres
27 metres 14 metres
28 metres 14 metres
30 metres 15 metres
32 metres 17 metres
33 metres 17 metres
36 metres 18 metres
A B C
D

3 - Description
16
Liquid system
General information - valve system
All of the spra functions are operated via centrall situated valves with colour coded pictorial s mbols for eas operation.
Pump
The 6-diaphragm pump has a simple design. The diaphragms and valves are eas to access, the isolate the moving parts
from the liquid. The ALPHA Evo self-propelled vehicle ma be equipped with the model 463-10 or 463-12 with respective
flow rates of 276 l/min and 322 l/min.
Valves and sym ols
The valves are identified b coloured s mbols according to their function. The correspond to the different possible
functions of the valves, thus facilitating their use. A function is activated b turning the handle towards the desired function.
Suction valve = lue sym ols
Turn the handle so the s mbol for the required function is pointing
towards the indicator. The valve is closed when the handle is not
pointing towards a s mbol.
Pressure valve = green sym ols
Turn the handle so the s mbol for the required function is pointing
towards the indicator.
Suction in
main tank
Suction in
rinse tank
External
suction
Spra
pressure Tank rinse
Fill with
chemicals
Direct filling

3 - Description
17
Agitation valve = green sym ols
With the adjustable agitation valve it is possible to combine spra ing with a low volume rate at high pressure with agitation
at the same time. This is continuousl controlled b the agitation valve.
The valve is marked with an arrow on the disc, which indicates the amount of liquid that passes through the valve. If the
valve handle is turned to the right, there is less agitation in the tank. Conversel if the handle is turned to the left, the volume
is higher and there is maximum agitation in the tank.
Tur oFiller = yellow sym ols
The filler is situated in the working zone on the spra er's left side. To use
it, lift the handle fig. 1 gentl and pull it to drop the TurboFiller to the
lower position.
After use, raise the TurboFiller to its high position again, making sure that
it locks.
±
WARNING! The handle should be held all the time while the TurboFiller is being lowered.
Adjustable
agitation External
cleaning
Mixing the
liquid Rinsing the
TurboFiller
Rinsing the
containers
1
2

3 - Description
18
Diagram - Liquid system
1. Suction SmartValve
2. Pressure SmartValve
3. Agitation valve
4. Suction line filter
5. Filler valve
6. Spra pump
7. Main tank
8. Eas Clean suction filter
9. Rinse tank
10. Injector
11. C cloneFilter
12. Section valve
13. Chemical filler
14. Safet valve
15. Tank injection entrance
16. Tank rinsing nozzles
17. Agitation
18. C cloneFilter return
19. Spra section valve returns
20. Rinse tank valve connector
21. Pressure control valve
22. One-wa valves
23. Drain valve
24. Drainage connector
25. Flow transducer
26. Suction connector
27. Transfer connector
28. External spra washer
29. Chemical filler cleaning valve
30. Vortex nozzle valve
31. Container rinsing valve
2
21
1
3
8
6
7
22
22
22
22
22
27
4
5
13
27
28
29
30
31
23
17
20 26
16 18
15
14
10 22
22
12
9
19
24
22
25
11
