Hardi AutoSlant UC7 User manual

HARDI
AutoSlant UC7
Original
Instruction book - SW 3.3.x.x
67060600-100 - Version 1.00
GB - 04.2021
www.hardi.com

We congratulate you for choosing a HARDI plant protection product. The reliability and
efficiency of this product depend upon your care. The first step is to carefully read and pay
attention to this instruction book. It contains essential information for the efficient use and
long life of this quality product.
The original instruction book is approved and published in English. All other languages are translations of the
original. In the event of any conflicts, inaccuracies or deviations between the English original and other languages
the English version shall prevail.
Illustrations, technical information and data in this book are to the best of our belief correct at the time of printing.
As it is HARDI INTERNATIONAL A/S policy permanently to improve our products, we reserve the right to make
changes in design, features, accessories, specifications and maintenance instructions at any time and without
notice.
HARDI INTERNATIONAL A/S is without any obligation in relation to implements purchased before or after such
changes.
HARDI INTERNATIONAL A/S cannot undertake any responsibility for possible omissions or inaccuracies in this
publication, although everything possible has been done to make it complete and correct.
As this instruction book covers more models and features or equipment, which are available in certain countries
only, please pay attention to paragraphs dealing with precisely your model.
Published and printed by HARDI INTERNATIONAL A/S
Acknowledgements:
UC7 and Roll Control are trademarks of NORAC Systems International Inc., Canada
NORAC® is a registered trademark of NORAC Systems International Inc., Canada

Table of Contents
3
Table of Contents
1 - About
AutoSlant ...............................................................................................................................................5
About this Instruction Book ............................................................................................................................................................................. 5
2 - Safety Notes
Operator Safety .....................................................................................................................................7
Symbols ........................................................................................................................................................................................................................ 7
Precautions ................................................................................................................................................................................................................ 7
3 - Description
General System Info ..............................................................................................................................9
Key Features .............................................................................................................................................................................................................. 9
Types of Terminals .............................................................................................................................................................................................. 10
General System Layout ........................................................................................................................11
SmartCom Equipped Sprayers .................................................................................................................................................................... 11
JobCom Equipped Sprayers ......................................................................................................................................................................... 12
Display .................................................................................................................................................13
Navigating to the Run Screen ..................................................................................................................................................................... 13
Icon Description ................................................................................................................................................................................................... 14
Menu Structure ....................................................................................................................................16
Main Screen ............................................................................................................................................................................................................ 16
Settings Menu ....................................................................................................................................................................................................... 17
Setup Menu ............................................................................................................................................................................................................ 19
Diagnostics Menu ............................................................................................................................................................................................... 21
Understanding the AutoSlant System .................................................................................................23
General Info ............................................................................................................................................................................................................ 23
Boom Reaction Time ......................................................................................................................................................................................... 23
Ditches, Waterways and Outside Rounds ............................................................................................................................................ 23
Driving Through Ditches and Over Terraces ...................................................................................................................................... 23
Soil, Crop and Hybrid Mode ......................................................................................................................................................................... 24
Sensing Further Ahead of the Boom ...................................................................................................................................................... 24
Height Sensor Capabilities and Limitations ........................................................................................................................................ 24
4 - System Setup
Setup ...................................................................................................................................................25
General Info ............................................................................................................................................................................................................ 25
Navigating to the Setup Menu ................................................................................................................................................................... 25
Automatic System Setup .....................................................................................................................27
General Info ............................................................................................................................................................................................................ 27
Setup Procedure .................................................................................................................................................................................................. 27
Retune .................................................................................................................................................36
When to Retune ................................................................................................................................................................................................... 36
Retune Procedure ............................................................................................................................................................................................... 36
Manual Setup .......................................................................................................................................38
General Info ............................................................................................................................................................................................................ 38
Sensor Setup .......................................................................................................................................................................................................... 38
Settings Menu ......................................................................................................................................41
General Info ............................................................................................................................................................................................................ 41
Sensitivity ................................................................................................................................................................................................................. 41
Mode ........................................................................................................................................................................................................................... 41
Height ......................................................................................................................................................................................................................... 41
Headland Height ................................................................................................................................................................................................. 42
Learned Crop Height ........................................................................................................................................................................................ 42
Options Menu ......................................................................................................................................43
General Info ............................................................................................................................................................................................................ 43
Remote Switches ................................................................................................................................................................................................. 43
Disable Main Lift .................................................................................................................................................................................................. 43
Return to Height .................................................................................................................................................................................................. 44

Table of Contents
4
Main Lift Trigger ................................................................................................................................................................................................... 44
Remote Auto Trigger ........................................................................................................................................................................................ 44
Minimum Boom Height .................................................................................................................................................................................. 45
Features ...............................................................................................................................................46
High Oil Temp Alarm Toggle ....................................................................................................................................................................... 46
Temperature Compensation Toggle ...................................................................................................................................................... 46
5 - Operation
Typical Operation ................................................................................................................................47
Run Screen .............................................................................................................................................................................................................. 47
Minimum Boom Height .................................................................................................................................................................................. 48
Settings ................................................................................................................................................49
General Info ............................................................................................................................................................................................................ 49
Sprayer Switches .................................................................................................................................50
General Info ............................................................................................................................................................................................................ 50
Slant Switches ....................................................................................................................................................................................................... 50
Main Lift Switch .................................................................................................................................................................................................... 50
6 - Maintenance
Service Info ..........................................................................................................................................51
General Info ............................................................................................................................................................................................................ 51
Before Each Day ................................................................................................................................................................................................... 51
At the End of the Season ................................................................................................................................................................................ 51
Cleaning Ultrasonic Height Sensors ........................................................................................................................................................ 52
Lubrication of the Sprayer ............................................................................................................................................................................. 53
7 - Fault Finding
Typical Failures ....................................................................................................................................55
General Operation .............................................................................................................................................................................................. 55
Sensors ....................................................................................................................................................................................................................... 55
Height Control Module ................................................................................................................................................................................... 56
Hydraulics ................................................................................................................................................................................................................ 57
Boom Stability ....................................................................................................................................................................................................... 57
8 - Technical Specifications
Specifications ......................................................................................................................................59
System Specifications ....................................................................................................................................................................................... 59
Fuses ........................................................................................................................................................................................................................... 59
Index
Index ....................................................................................................................................................61

5
1 - About
AutoSlant
About this Instruction Book
This instruction book is written for the use with certain possible display choices. Depending on the choice of display, the
AutoSlant is controlled via:
•Universal Terminal (UT) interface on HC 8700, HC 9700 displays.
•Universal Terminal (UT) interface on HC 8600, HC 9600 displays.
•Virtual Terminal (VT) interface on HC 8500, HC 9500 displays.
•Other similar ISOBUS displays.
•PULSE™ display.
Because of the physical size of controllers, some buttons and dialogue boxes will appear with a bit different layout. But as
menus and functions are identical, we have chosen to illustrate this book with Universal Terminal (UT) interface as on the
HC 9600 display.

1 - About
6

7
2 - Safety Notes
Operator Safety
Symbols
These symbols are used thorough the book to designate where some sort of extra attention has to paid for the reader. The
four symbols have following meaning.
€This symbol means DANGER. Be very alert as your safety is involved! The DANGER symbol indicates a high risk for an
immediate death or serious physical injury, if the instruction is not followed.
±This symbol means WARNING. Be alert as your safety can be involved! The WARNING symbol indicates a medium risk
for immediate death or serious injury, if the instruction is not followed.
μThis symbol means ATTENTION. This indicates an obligation to special behaviour or an activity required for proper
sprayer handling.This instruction will help you to avoid faults on the sprayer or disturbance to the environment.
÷This symbol means NOTE. This indicates handling tips and particularly useful information. This instruction will help
you to use all the functions of your sprayer in the best way possible for a better, easier and more safe operation.
Precautions
Note the following recommended precautions and safe operating practices before using the sprayer.
General Info
€Read and understand this instruction book before using the equipment. It is equally important that other operators
of this equipment read and understand this book.
If any portion of this instruction book remains unclear after reading it, contact your HARDI dealer for further
explanation before using the equipment.
€Local law may demand that the operator is certified to use spray equipment. Adhere to the law.
€Tractor drivers seat is the intended working place during operation.
€Wear protective clothing. Clothing may differ depending on chemical being sprayed. Adhere to the local law.
Wash and change clothes after spraying. Wash tools if they have become contaminated.
€Do not eat, drink or smoke while spraying or working with contaminated equipment.
In case of poisoning, immediately seek medical advice. Remember to identify chemicals used.
AutoSlant Precautions
€Under no circumstances should any service work be performed on the machinery while the AutoSlant system is in
the automatic mode.
€Always ensure that the AutoSlant system is powered down or in manual mode:
•Before leaving the operator’s seat.
•While the machine is not moving.
•When transporting the machine.
Before working on any part of the booms:
•Set the AutoSlant system to manual mode.
•Turn the sprayer engine off.
Do not operate this system before:
•Reading and understanding this instruction book.
•Thoroughly understanding the machine operation.

2 - Safety Notes
8

9
3 - Description
General System Info
Key Features
The AutoSlant includes the following features:
Automatic Software Setup
•The automatic system setup calibrates the software specifically for the sprayer in an easy manner. This provides the
maximum performance for the sprayer.
Height Sensors
•The height sensors use an ultrasonic signal to measure the distance to the ground or crop canopy.
•Three height sensors used. A sensor is mounted to the outer part of each boom tip, and another sensor is mounted to
the centre section.
Smart Sensor Technology
•Non-contact Sensing:
•Sensing is done using ultrasonic sensors which means no parts of the AutoSlant system come in contact with
the ground.
•Using a non-contact system means there will be no additional forces put on the boom, which could cause
damage to the sprayer boom.
•The ultrasonic signals can distinguish the difference between the ground and standing crop or field residue.
•Choose between soil, crop or hybrid mode for the boom height control.
Modules
•There is one module included: a Height Control Module.
•The Height Control Module status is indicated by a number of LED’s. Shortly after power-up, the module should
present a green light, indicating the module is functioning and ready.
Improved Reliability
•The AutoSlant system is installed in a way to leave the sprayer hydraulics operational. This means that if a cable is
damaged or a AutoSlant component is failing the sprayer remains functional.

3 - Description
10
Types of Terminals
The AutoSlant software can run with 2 main types of display Terminals.
ISOBUS Terminals With Buttons
ISO Terminals with physical function buttons, e.g. the shown Massey
Ferguson terminal.
•Conventional or touch screen and physical buttons.
•Function buttons are graphical but are operated by physical
buttons on the terminal.
•The AutoSlant software runs as a Universal Terminal (UT) into the
terminal software.
ISOBUS Terminals Without Buttons
HARDI HC 8600/8700, HC 9600/9700 or similar ISO terminals with
touchscreen interface. The HC 8600 is shown here.
•Touchscreen and no buttons (except ON/OFF).
•Function buttons are graphical and operated by pressing the
touch screen.
•The AutoSlant software runs as a Universal Terminal (UT) into the
Terminal software.

3 - Description
11
General System Layout
SmartCom Equipped Sprayers
Lift Sprayer
Trailed Sprayer
A. Display Terminal.
B. Cable to PDU Box.
C. PDU Box for SmartCom.
D. Height Control Module (HCM1).
E. Left Outer Sensor.
F. Bus Terminator.
G. Cable to Boom Sensors.
H. 3-way Coupler.
I. Right Outer Sensor.
A
B
CD
EF
G
G
HI
F
A
BCD
E
H
I
F
G
G
F

3 - Description
12
JobCom Equipped Sprayers
Trailed Sprayer
Self-propelled Sprayer
A. Display Terminal.
B. Cable to JobCom Box.
C. JobCom Box.
D. Cable to Height Control Module (HCM1).
E. Height Control Module (HCM1).
F. Left Outer Sensor.
G. Right Outer Sensor.
H. Bus Terminator.
I. Cable to Boom Sensors.
J. 3-way Coupler.
A
B
C
D
F
G
H
J
E
I
I
H
A
B
C
D
F
G
H
H
E
J
I
I

3 - Description
13
Display
Navigating to the Run Screen
To navigate to the AutoSlant run screen:
1. At your terminal, go to the NORAC UC7 universal terminal.
÷NOTE! The method to enter the NORAC UC7 universal
terminal may differ depending on the controller terminal
used.
2. Press the check button “V” to accept the Liability Notice
Screen and enter the AutoSlant work screen.
μATTENTION! The liability notice needs to be accepted
before you can operate the AutoSlant from:
•The widget on the HC 8700/9700 terminal.
•From the work screen on the HC 8500/9500 or HC
8600/9600 terminals.
3. The run screen appears.
÷NOTE! To view Run Screen functions, refer to “Run Screen”
on page 47.
NORAC UC7 Liability Notice
By pressing the [F] button you
acknowledge that you have read and
understand the operator’s manual and
assume responsibility for safe
installation and operation of this
system. Safe operation includes, at
a minimum, maintaining appropriate
speed, having an operator present in
the cab when in AUTO or MANUAL mode,
and manually overriding the system
if necessary.

3 - Description
14
Icon Description
The following table illustrates and describes the icons used in the display.
÷NOTE! These icons may look different depending on the type of display you have.
Icon Name Description
Check Confirms selection or completion of a step
Next Navigates to the next page
Previous Navigates to the previous page
Home This button always returns directly to the Run Screen
Manual Mode (Active) Green button indicates the system is in Manual Mode
Manual Mode (Inactive) Changes to Manual Mode when the system is in Automatic Mode
Automatic Mode (Active) Green button indicates the system is in Automatic Mode
Automatic Mode (Inactive) Changes to Automatic Mode when the system is in Manual Mode
Settings Navigates to the Settings screen
Cancel Cancels current selection or operation
Setup diagnostics View the automatic setup diagnostic screen (PULSE™ only)
Error Indicates when there is an error
Setup Navigates to the Automatic/Manual setup screen
Options Navigates to the Options screen
USB update Navigates to the USB screen for software update
Advanced Settings Navigates to the Advanced settings

3 - Description
15
Activation The activation code can be entered here
Automatic Setup Starts an Automatic setup
Retune Starts a Retune
Boom Geometry Test Starts a boom geometry (push) test
Sensor Setup/Diagnostics Navigates to the Manual sensor setup or Sensor diagnostics screens
Valve Setup/Diagnostics Navigates to the Manual valve setup or Hydraulic diagnostics screens
Switches Navigates to the input map for Manual remote switches screen
Versions Navigates to the UC7 modules versions screen
Other Information Navigates to the valve temperature and scale factor screen
Move to Next VT Move the UC7 screen to a different VT
Icon Name Description

3 - Description
16
Menu Structure
Main Screen
See “Settings Menu” on page 18.
See “Diagnostics Menu”on page 22.
Settings
Sensitivity
Mode
HEIGHT
Hybrid
Settings
Headland height
Terrain height
Learned crop height
Off
Diagnostics

3 - Description
17
Settings Menu
Setup and Options Menus
Settings
Setup
Options
Options
Options
Remote switches
Disable main lift
Return to height
Main lift trigger
Remote auto trigger
Off
Headland mode - Main
Minimum boom height
See “Setup Menu” on page 20.

3 - Description
18
USB, Advanced and Activation Menus
Enter Password
Settings
Advanced
Enter Password
System update
Activation
Advanced
Flash Data Editor
Default
Select an update file and then press
[F]

3 - Description
19
Setup Menu
Automatic Setup, Retune and Boom Geometry Test Windows
Setup UC7 ReTune
By pressing [F] you acknowledge that
you have read the automatic setup
instructions in the operator’s
manual and assume full
responsibility for the safe
operation.
UC7 Automatic Setup
By pressing [F] you acknowledge that
you have read the automatic setup
instructions in the operator’s
manual and assume full
responsibility for the safe
operation.
Boom Geometry Test
UC7 System Check
Press [F] to resume
Height Sensors:
Position Sensors:
Proper UC7 system components
connected

3 - Description
20
Sensor and Hydraulics Windows
Setup
Valves Valves
Sensors
