Harken 2608 User manual

ONLINE INSTRUCTIONS
40 mm, 57 mm, 75 mm Carbo Ratchets
USA –Tel: [phone] • Web: www.harken.com • Email: [email protected]
Italy –Tel: [phone] • Web: www.harken.it • Email: techser[email protected]
Strictly follow all instructions to avoid an accident, damage to your vessel, personal injury
or death. See www.harken.com for additional safety information.
A
B
C
Glass-filled nylon sideplates: load-carrying curved bearing
races.
Machined Hardkote-anodized aluminum sheaves: strength
and corrosion resistance.
Eight-facet sheave: holds line securely.
Ratchet on/off switch: 40 mm–2608/2609/2614;
57/75 mm–all blocks.
Ratchet always on: 2610/2611.
Cam arm locking plates: Allows cam arms to be locked in more
than five positions for fair leads.
Cheek: Line-shedding, small mounting footprint and drain holes.
Common uses: Main/jib/spinnaker sheets/traveler controls/
genoa sheets/foreguys
Features
Part
No.
ABC
Max line
Ø
Maximum
working load*
Breaking
load*
Description in mm in mm in mm in mm lb kg lb kg
40 mm
2608 Single/swivel 1
9
/ 16 40 3
3
/ 8 86
5
/ 32 4
3
/ 8 10 300 136 1000 454
2609 Single/swivel/becket 1
9
/ 16 40 4 102
5
/ 32 4
3
/ 8 10 300 136 1000 454
2610 Single/swivel/471 Carbo-Cam®* 1
9
/ 16 40 3
3
/ 8 86
5
/ 32 4
1
/ 4 6 150 68 300 136
2611 Single/swivel/471 Carbo-Cam®/becket* 1
9
/ 16 40 4 102
5
/ 32 4
1
/ 4 6 300 136 600 272
2612 Triple/swivel/471 Carbo-Cam®** 1
9
/ 16 40 3
11
/ 16 94
3
/ 16 5
1
/ 4 6 750 340 1500 680
2613 Triple/swivel/471 Carbo-Cam®/becket 1
9
/ 16 40 4
5
/ 16 110
3
/ 16 5
1
/ 4 6 900 408 1800 816
2614 Cheek 1
9
/ 16 40 2
3
/ 4 70 — —
3
/ 8 10 300 136 1000 454
2619 Triple/471 Carbo-Cam®/29 mm/becket 1
9
/ 16 40 4
3
/ 4 121
3
/ 16 5
1
/ 4 6 900 408 1800 816
57 mm
2135 Single/swivel 2
1
/ 4 57 4
1
/ 16 103
3
/ 16 5
3
/ 8 10 500 227 2000 907
2136 Single/swivel/becket 2
1
/ 4 57 4
15
/ 16 125
3
/ 16 5
3
/ 8 10 500 227 2000 907
2137 Cheek 2
1
/ 4 57 3
1
/ 4 83 — —
3
/ 8 10 500 227 2000 907
2138 Single/swivel/150 Cam-Matic®* 2
1
/ 4 57 4
1
/ 16 103
3
/ 16 5
3
/ 8 10 300 136 750 340
2139 Single/swivel/150 Cam-Matic®/becket* 2
1
/ 4 57 4
15
/ 16 125
3
/ 16 5
3
/ 8 10 600 272 1500 680
2140 Triple/swivel/150 Cam-Matic®*+2
1
/ 4 57 4
1
/ 16 103
3
/ 8 10
1
/ 4 6 1500 680 3750 1700
2141 Triple/swivel/150 Cam-Matic®/becket 2
1
/ 4 57 4
15
/ 16 125
3
/ 8 10
1
/ 4 6 1800 816 4500 2041
2673 57 mm fiddle/ratchet 2
1
/ 4 57 4
5
/ 8 118
3
/ 8 10
3
/ 16 5 793 360 2380 1080
2674 57 mm/fiddle/ratchet/becket 2
1
/ 4 57 5
5
/ 8 143
3
/ 8 10
3
/ 16 5 793 360 2380 1080
2675 57 mm/fiddle/ratchet/150 Cam-Matic®2
1
/ 4 57 4
5
/ 8 118
3
/ 8 10
3
/ 16 5 793 360 2380 1080
2676 57 mm/fiddle/ratchet/150 Cam/becket 2
1
/ 4 57 5
5
/ 8 143
3
/ 8 10
3
/ 16 5 793 360 2380 1080
75 mm
2670 Single/swivel 2
15
/ 16 75 5
3
/ 8 137
1
/ 4 6
7
/ 16 12 750 341 3000 1361
2671 Single/swivel/becket 2
15
/ 16 75 6
1
/ 2 165
1
/ 4 6
7
/ 16 12 750 341 3000 1361
2672 Cheek 2
15
/ 16 75 4
1
/ 16 103 — —
7
/ 16 12 750 341 3000 1361
2694 75 mm/fiddle/ratchet 2
15
/ 16 75 6
3
/ 16 157
1
/ 2 12
1
/ 4 6 1212 550 3637 1650
2695 75 mm/fiddle/ratchet/becket 2
15
/ 16 75 7
7
/ 16 189
1
/ 2 12
1
/ 4 6 1212 550 3637 1650
2696 75 mm/fiddle/ratchet/150 Cam-Matic®*++ 2
15
/ 16 75 6
3
/ 16 157
1
/ 2 12
1
/ 4 6 900 408 3350 1020
2697 75 mm/fiddle/ratchet/150 Cam/becket 2
15
/ 16 75 7
7
/ 16 189
1
/ 2 12
1
/ 4 6 1212 550 3637 1650
*Maximum working loads and breaking loads for blocks based on cam strengths **Can be used as becket block – add 281
eyestrap +Can be used as becket block – add 137 eyestrap and (2) HFS929 panhead screws (M5X45) ++ Can be used as
becket – add 137 eyestrap
IMPORTANT: See Inspection and Maintenance
at end of manual.
Ratchet blocks are hand and crew savers. The eight-sided sheave grips loaded
sheets with up to 15: 1 holding power yet allows a line to be eased instantly with
control. They allow the crew to hand hold main, jib and spinnaker sheets with
only a fraction of the effort that a regular block requires. An on/off switch allows
the ratchet to be turned off in light air to trim and ease lines more easily.
40 mm
The 2608, 2609 and 2614 have on/off switches; other 40 mm ratchet blocks are
always in ratchet mode.
57 mm (10:1 Holding Power), 75 mm (15:1 Holding Power)
All 57 and 75 mm ratchet blocks have on/off switches.
Ratchet Blocks

2614 / 2137 / 2672 Cheek Block
Position block so ratchet turns in desired direction. Flip block to change direction. Use chart below or use
block as a template. Mark holes using centerpunch. Check marks with block before drilling. Remove block
and drill holes using drill size from chart below. Bevel top of deck holes using a small knife to allow seal-
ant to mass. Place gasket under block. Through-bolt block using recommended stainless steel fasteners,
washers and locknuts.
Ratchet cheek blocks include metric panhead screws, washers and nuts. See chart below:
Block
Part No. Size
Drill Size Block Thickness (G) Supplied
Fastener x Lengthmm in mm in
2614 40 mm 3.25
1
/ 8 22
7
/ 8 M3 x 40 mm
2137 57 mm 4.25
11
/ 64 25 1 M4 x 60 mm
2672 75 mm 5.25
13
/ 64 31 1
1
/ 4 M5 x 60 mm
*Fastener length: Add deck thickness and overhang for nut and washer.
Block
Size
Part
No.
A B C D E F
in mm in mm in mm in mm in mm in mm
40 mm 2614
5
/ 64 4 1
1
/ 2 38 — —
9
/ 32 6.9 1
9
/ 16 40 2
1
/ 4 57
57 mm 2137
7
/ 32 6 1
1
/ 2 38
3
/ 8 9.4
21
/ 64 8.3 2
1
/ 4 57 3
1
/ 16 78
75mm 2672
9
/ 32 7 2 51
1
/ 2 12.7
31
/ 64 12.4 2
15
/ 16 75 4
1
/ 16 103
2614
D
B A
F
E2137, 2672
D
B
E
A
C
F
2137, 2614, 2672 G
The 3-Way U-Lock on doubles and triples allows a change
of headpost direction from front to side or allows the
block to swivel. To change headpost direction, remove
shackle, turn post, install shackle. Remove U-Lock to
allow block to swivel.
Ratchet Direction
Arrow on side of block shows direction that sheave
will spin when ratchet is switched on. Refer to arrow
when reeving block or mounting cheek block.
1
1. Cam lever up.
Block locks in
front or side
position.
2. Cam lever down.
Block turns
freely.
2
3-Way U-Lock – 2140 / 2141 / 2612 / 2613 / 2619
3-Way Cam-Lock – 2135 / 2136 / 2138 / 2139 / 2170 / 2171, 2673,
2674, 2675, 2676, 2694, 2695, 2696, 2697

Parts — 40 mm Carbo Ratchets
2608/2609 40 mm Single Ratchet
No. Description Qty Part No.
1Shackle Assembly Micro 5/32" 246
A Shackle Strap 1 HSB104
BShackle Clevis Pin 5/32 X .488 1 HSB105
C Split Ring 1 HSB24
2610/2611 40 mm Single Ratchet
w/471 Carbo Cam
1 Screw M3X30 Slotted Panhead 1 HFS888
2 Washer Cam Arm Left 1 H-26265B
3 Washer Cam Arm Right 1 H-27031B
4 Nut M3 1 HFS939
5 Cam Arm Left 1 H-46865
6 Cam Arm Right 1 H-46866
7 Nut M4 2 HFS890
8 Cam Cleat Micro Carbo 1 471
9 Micro Flairlead Black 1 424B
10 Cam Screws M4X30 Slotted
Panhead
2 HFS889
11 Cam Plate for Reversing Cam 1 H-27034B
12 Shackle Assembly Micro 5/32” 246
A Shackle Strap 1 HSB104
BShackle Clevis Pin 5/32 X .488 1 HSB105
C Split Ring 1 HSB24
2
1
4
5
6
7
8
9
10
11
12
B
A
C
Right-angle reeving dead-end on becket
For larger, printable diagrams, please see: www.harken.com.
1
2
3
4
5
6
6:1 Right-Angle Reeving
Dead-end on cam
6:1 Right-Angle Reeving
Dead-end on becket
6
2
3
4
5
6
6
1
6:1
Reeving Multi-Purchase Systems
1
A
C
B
Part No.
HFS889
12
Adjust Cam Angle (Single/40 mm) Reverse Cam Cleat (Single Only)
1. Remove screws from cam.
2. Assemble as shown. Note: use plastic plate on cam
bottom.
3. Tighten screws. Do not overtighten screws.
Cam pawls should snap shut smartly.
1. Loosen cam arm locking plate screw and pull outward
to disengage.
2. Rotate cam arm to desired position.
3. Press locking plate in and tighten screw. Avoid
binding sheave, do not over-tighten screw.
5:1 Right-Angle Reeving
Dead-end on Becket
1
2
3
4
5
5
5:1 8:1
1
2
3
5
6
7
8
4
1. Remove three cam arm screws on each side.
2. Carefully note position of three screw holes in
block (see diagram).
2. Rotate cam arm to desired position and line
up cam arm holes with screw holes on block.
3. Insert screws into screw holes and tighten.
Do not overtighten screws or sheave will bind.
Adjusting Cam Angle 57 mm (Single/Triple/Fiddle), 75 mm (Fiddle)
1
2
3
4
5
6
6:1 Right-Angle Reeving
Dead-end on cam
6:1 Right-Angle Reeving
Dead-end on becket
6
2
3
4
5
6
6
1
6:1
Right-angle reeving
dead-end on cam

Parts — 40 mm Carbo Ratchets
Harken equipment is designed for minimal maintenance. However, some upkeep is required to give
the best service and comply with the Harken limited warranty.
Keep your equipment clean and free-running by frequently flushing with fresh water. Periodically
clean with mild detergent and water solution. Spin sheaves to distribute soap solution evenly.
Flush with fresh water.
Important: Exposure to some teak cleaners and other caustic solutions can result in discoloration
of part and is not covered under the Harken warranty.
Warranty
For additional safety, maintenance, and warranty information see www.harken.com or the Harken
catalog.
Maintenance
Inspect Block and Shackle Before You Sail
Frequently inspect shackles and shackle posts for signs of corrosion, cracks, or elongation. When
replacing shackles, use the correct Harken parts to maintain the proper strength. Replace line as
necessary, taking into consideration the maximum size recommendation.
WARNING! Failure to inspect and replace damaged metal parts and/or worn or frayed line
can cause block or system to break suddenly causing an accident, damage to your vessel,
personal injury or death. See www.harken.com for additional safety information.
M1005/04-26-11
2619 40 mm Triple Ratchet/29 mm/Carbo Cam
1 Nut M3 1 HFS939
2 Washer Left 1 H-26265B
3 Washer Right 1 H-27031B
4 29mm 90 Degree Fixed Block 1 352
5 Spring 1 097
6 Eyestrap, Micro 1 281
7Cam Arm Fastener M4X70
Custom 1 HFS895
8 Cam Arm 1 H-27052C
9 Cam Nut M4 2 HFS890
10 Cam Cleat, Micro Carbo 1 471
11 Micro Flairlead Black 1 424B
12 Cam Screw M4 X 30 Slotted
Panhead 2 HFS889
13 U-Lock 1 H-27808A
14 Shackle 5mm Hybrid Shallow
Bow 1 HCP1568
5
6
3
7
9
10
11
4
8
2
1
12
13 14
2614 40 mm Cheek Block
1 M3-.5X40mm Slotted
Panhead Screw
3 HFS1014
2 Gasket 1 H-34924A
3 M3 Flatwasher 3 HFS1008
4 M3 Full Nut 3 HFS939
1
2
33
44
1 Nut M3 1 HFS939
2 Washer Left 1 H-26265B
3 Washer Right 1 H-27031B
4 Cam Arm Fastener M4X70
Custom
1 HFS895
5 Cam Arm 1 H-27052C
6 Cam Nut M4 2 HFS890
7 Cam Cleat, Micro Carbo 1 471
8 Micro Flairlead Black 1 424B
9Cam Screw M4 X 30 Slotted
Panhead
2 HFS889
10 U-Lock 1 H-27808A
11 Shackle 5mm Hybrid Shallow
Bow
1 HCP1568
2612/2613 40 mm Triple Ratchet w/Carbo Cam
2
1
3
5
6
7
9
10
11
4
8
