Harken 253 Lazy Jack Kit User manual

INSTRUCTION MANUAL
253 Lazy Jack Kit
Boats 27 – 37 ft.
(8.2 – 11.3 m)
Mainsail luff length
32 – 42 ft. (10 – 13 m)

2
Parts List
2 Wire assemblies including blocks and mast tangs
1 62' (19 m) length of
5
/ 16 " (8 mm) line with eye splice
3 Stainless steel eyestraps
1 Carbo cheek block
1 4" (101 mm) aluminum cleat
15 10-32 x
3
/ 8 " (10 mm) truss head machine screws (includes 3 extra)
15
3
/ 16 " (4.76 mm) stainless steel rivets (includes 3 extra)
3 #10 x 1
1
/ 4 " (32 mm) self-tapping screws (includes 1 extra)
3 10-32 x
3
/ 4 " (19 mm) trusshead machine screws (includes 1 extra)
3 #10 x
3
/ 4 " (19 mm) trusshead self-tapping screws (includes 1 extra)
Tools Required
Marker or pencil
5
/ 32 " (4 mm) drill bit
Center punch Phillips/slotted screwdriver
Hammer Tape measure (long enough to measure luff length)
Electric drill Pliers or vice grips
Drill, Tap and Screw Method:
1 – slotted screwdriver
1 – 10-32 tap and handle
1 –
5
/ 32 " (4 mm) drill bit
Rivet Gun Method: Stainless steel rivets require a heavy-duty rivet gun.
It may be necessary to rent a rivet gun if you do not have a heavy-duty model.
1 –
13
/ 64 " (5 mm) drill bit
Topping Lift
To avoid snagging the mainsail on the Lazy Jacks when raising sail, the boat
must be equipped with a topping lift or vang that holds boom lifted.
Altering Sail Cover
Take your sail cover to a sailmaker to have slits cut in the cover for the Lazy Jacks.
Slits should have Velcro or snap closures to make it easy to cover the mainsail.
Mark your cover after installation so the slots can be positioned correctly.
Determining the Location of Mast Tang
Measure the mainsail luff length or find the “P” dimension of the mast. Find this
measurement in the left column below and circle the number in the right column.
See drawing, page 3.
7.89 m ——25'11" —10.97 - 11.11 m —36'7" to 37'
7.79 m 8.96 m29'5"25'7" 12.47 - 12.60 m10.82 - 10.96 m 41'7" to 42'36'1" to 36'6"
7.66 m 8.86 m29'1"25'2" 12.32 - 12.46 m10.67 - 10.81 m 41'1" to 41'6"35'7" to 36'
7.56 m 8.73 m28'8"24'10" 12.17 - 12.31 m10.52 - 10.66 m 40'7" to 41'35'1" to 35'6"
7.46 m 8.63 m28'4"24'6" 12.02 - 12.16 m10.37 - 10.51 m 40'1" to 40'6"34'7" to 35'
7.36 m 8.53 m28'24'2" 11.87 - 12.01 m10.22 - 10.36 m34'1" to 34'6"
7.26 m 8.43 m27'8"23'10" 11.72 - 11.86 m
10.07 - 10.21 m 39'1" to 39'6" 33'7" to 34'
7.13 m 8.33 m27'4"23'5" 11.57 - 11.71 m9.92 - 10.06 m 38'7" to 39'33'1" to 33'6"
7.03 m 8.20 m26'11"23'1" 11.42 - 11.56 m9.77 - 9.91 m 38'1" to 38'6"32'7" to 33'
6.93 m 8.10 m26'7"22'9" 11.27 - 11.41 m9.62 - 9.76 m 37'7" to 38'32'1" to 32’6"
The tang location
measured from the
top of boom is:
6.85 m
The tang location
measured from the
top of boom is:
8.00 m26'3"22'6"
Chart A
If the mainsail luff length or
“P” dimension measures:
11.12 - 11.26 m9.47 - 9.61 m 37'1" to 37'6"
Chart A
If the mainsail luff length or
“P” dimension measures:
31'7" to 32'
40'1" to 40'6"

3
Installing Mast Tang and Wire Assembly
If you are installing the system with the mast up, you will need to take up the follow-
ing parts in the bosun's chair or send them up with a messenger line. (Follow all pre-
cautions to insure the safety of the person aloft. Make sure no one is standing where
they could be hit with dropped tools.)
WARNING! When drilling through mast, do not let drill bit contact the halyard that
is holding you aloft! This may cause the halyard to fail. Limit depth.
Tape measure Screw Method
Port and starboard templates (attached to pg. 3) Drill with 5/32" (4 mm) drill bit
Tape for template #10-32 Tap and handle
Tang assembly including wires and blocks Slotted screw driver
Hammer 10-32 x
3
/ 8
" (10 mm) Trusshead
Center punch machine screws
Rivet Method
Drill with 13/64" (5 mm) drill bit
Rivet gun and rivets
Note: before going up the mast, insert the middle screw or rivet into the tang.
Squeeze the top and bottom of the tang together to insert the screw or rivet. It
may be necessary to use a pliers or vice grips.
Measure up from the top of the boom to the height from chart A (page 2).
Moveable Gooseneck - If the gooseneck is capable of moving up and down, measure
from the top of the boom when the boom is positioned in its normal sailing position.
Mark the mast at this point.
Tape the template to the side of the mast so the middle hole is even with your mark.
Line the template up so the vertical line is parallel to the side of the mast. See drawing
below.
Use a center punch to mark three tang holes. Remove template and drill three holes:
Screws 5/32" (4 mm) and Tap #10-32 Rivets 13/64" (5 mm).
Attach tang starting from center hole.
Mast Tang
Assembly
Installing
Mast Tangs
Measurement
from
Chart A
Top View
Tangs installed
on widest part
of mast

4
Stringing the Control Lines
Decide whether the adjusting block and cleat
will be on port or starboard. The end of the line
without the eye splice will be on the side of the
boom where you will adjust the Lazy Jacks –
the side where you will install the cleat.
With the middle of the control line draped
under the boom, pass the ends of the line
up and run each end of the line through
the blocks that are suspended from
the wire. Run line through the
blocks from stern to bow as
shown in the diagram below.
Eye Splice
This will be adjusting side
*Note: You may want to check sail containment before drilling holes in the boom.
To do this, put sail on, tape the boom hardware in place, reeve lines through system
and lower sail. Move if necessary.
9'11" (3.023 m)4.67 - 4.81 m 3'6" (1.067 m)15'7" to 16'
9'8" (2.946 m)4.52 - 4.66 m 3'4" (1.016 m)15'1" to 15'6"
9'4" (2.845 m)4.37 - 4.51 m 3'3" (991 mm)14'7" to 15'
9' (2.743 m)4.22 - 4.36 m 3'2" (965 mm)14'1" to 14'6"
8'8" (2.642 m)4.07 - 4.21 m 3' (914 mm)13'7" to 14'
8'4" (2.540 m)3.92 - 4.06 m 2'11" (889 mm)13'1" to 13'6"
8'1" (2.464 m)3.77 - 3.91 m 2'10" (864 mm)12'7" to 13'
7'9" (2.362 m)3.62 - 3.76 m 2'8" (813 mm)12'1" to 12'6"
7'5" (2.261 m)3.47 - 3.61 m 2'7" (787 mm)11'7" to 12'
7'1" (2.159 m)3.32 - 3.46 m 2'6" (762 mm)11'1" to 11'6"
6'10" (2.083 m)3.17 - 3.31 m 2'4" (711 mm)10'7" to 11'
6'6" (1.981 m)3.02 - 3.16 m 2'3" (686 mm)10'1" to 10'6"
6'2" (1.880 m)2.87 - 3.01 m 2'2" (660 mm)9'7" to 10'
5'10" (1.778 m)2.72 - 2.86 m 2'1" (635 mm)9'1" to 9'6"
Boom Cradle
Strap Location
5'6" (1.676 m)
“E” Dimension or Sail Foot Length
2.57 - 2.71 m
Cheek Block and
Deadend Location
1'11" (584 mm)8'7" to 9'
Chart B – Location of Boom Hardware*
Determining the Location of Boom Hardware
Measure the mainsail foot length or find the E dimension of the mast. Find
this measurement in the left column below and circle the corresponding
numbers in the right column. Put a mark on each side of the boom at
each measurement. See drawing, page 5.

Sheave Side of Block is Towards Cleat
Measurement from Chart B
5
Installing Cheek Block
Hold cheek block on the side of the boom so aft end of block is even with forward
mark. Use cheek block as a template to mark holes and use center punch to start
holes. Use
3
/ 4 " (19 mm) long trusshead machine screws or self-tapping screws.
Do not drill holes for rivets.
DRILL HOLES: Machine Screws 5/32" (4 mm) and Tap #10-32;
Self-Tapping Screws 5/32" (4 mm)
Note: Position cheek block so sheave side of block is towards cleat. Refer to the two
diagrams on page 6. In most cases cleat will be mounted forward of cheek block near
forward end of boom. If there is other hardware in the way, mount cleat aft of block.
Screw block to boom.
Mounting Adjusting Cleat
Mount cleat near forward end of boom so Lazy Jacks may be easily adjusted. Before
mounting cleat, swing boom out as far forward as it will go to make sure cleat does
not hit mast. If you have a single line reefing or other obstruction forward of block,
mount cleat aft of block as pictured on page 6. Use cleat as a template to mark holes
and use center punch. Do not drill holes for rivets!
Drill size for screws - 5/32" (4 mm)
Use supplied flat head self-tapping sheet metal screws.
Note: If you have internal boom control lines, cut off the ends of the self tapping
screws and round off tip to avoid snagging internal lines. First drive screws into
boom to cut threads.
Installing Dead End Eyestrap
Use the eyestrap as a template to mark holes and start holes using a center punch.
DRILL HOLES: Screws 5/32" (4 mm) and Tap #10-32 Rivets 13/64" (5 mm)
Important: Put eyestrap through line eye splice before fastening to mast.
Use
3
/
8 " (10 mm) long screws or rivet eyestrap and line to boom.
Top View - Fittings Mounted to Side of Boom

6
Using Shock Cord to Pull Lazy Jacks Outward
We recommend shock cord to hold Lazy Jacks open to make it easier to raise sail.
1. Attach shock cord to the end of the lower spreaders. Hog rings work well for this
purpose. Use rigging tape over hog rings.
2. Temporarily tie other end of shock cord to Lazy Jacks at a length that holds Lazy
Jacks out, yet will not be too short and damage spreaders when boom is swung out.
3. Test length by swinging boom all the way out. If necessary, lengthen shock cord
before permanently attaching to Lazy Jacks.
Mounting Cradle Straps (Make sure you’ve checked sail containment before mounting eyestraps.)
Pull aft line towards end of boom until line intersects with mark you have made as
indicated in chart B. The eyestrap will be located aft of mark. See below.
DRILL HOLES: Screws 5/32" (4 mm) and Tap #10-32 Rivets 13/64" (5 mm)
Make sure line is inside eyestrap before riveting. Use
3
/ 8 " (10 mm) long screws or
rivet eyestrap in place.
Boom Cradle Strap Location From Chart B
Alternate cleat location – sheave side of
cheek block is towards cleat
From Chart B
Shock Cord

7
Conventional Sail Slugs
If using conventional sail slugs, make sure slugs are free to move below the gate.
Use mast gate plates so sail slugs stay in the mast groove. Contact your rigger.
Adjusting Lazy Jacks
The Lazy Jack may be set to proper tension at dock. Raise mainsail and make sure
adjusting line is uncleated at boom. Tighten mainsheet as tight as it will go to find
maximum distance that boom will be lowered while under sail. Next tighten adjusting
line and slack it off 2" (50 mm). The system should be set at a reasonable tension
so it will not interfere with sail shape, yet will contain the sail when lowered onto
the boom. Some further adjustment may be necessary.
Using Your Lazy Jacks - Precautions
Before sailing, make sure Lazy Jacks will not catch on spreaders. While at dock,
swing boom out so sail is against spreader tips. Try lifting boom and shaking to see if
Lazy Jack lines are apt to swing behind spreaders. When first sailing with Lazy Jacks,
look aloft while sailing downwind to see if Lazy Jacks catch behind spreaders. If they
get snagged while sailing, release snagged Lazy Jacks from behind spreader before
bringing mainsail in towards center. If this is not done, you risk breaking spreaders
as mainsheet is tensioned and mainsail moves toward the centerline.
If Lazy jacks are prone to snagging spreader tips, there are 2 solutions. The easiest is
to rig shock cords to pull Lazy Jacks forward out of way of spreader tips. Rig a length
of shock cord on each side of sail. Dead end shock cord at or near gooseneck and
run it up to blocks which are suspended from wires.
If this does not help, you will need to reposition Mast Tangs so they are lower on
mast and do not interfere with spreader tips.
Raising Sail
When hoisting sail, check to make sure the sail does not get caught in the Lazy Jacks.
The headboard or battens may catch between the mast and the Lazy Jacks or jam in
the angle between the lines. If the halyard is forced, this could result in a broken bat-
ten, ripped sail or damaged Lazy Jack. To avoid this, look aloft as you raise the main-
sail and stop if the sail gets caught. Also, make sure the boat is facing head-to-wind.
The sail is less apt to catch on the Lazy Jacks if the topping lift is used and the Lazy
Jacks are somewhat loose. This way they will deflect out of the way easier when the
sail makes contact with them.

4059/2-02
1251 E. Wisconsin Ave.
Pewaukee, WI 53072 USA
Tel: [phone] • Fax: [phone]
Website: www.harken.com
Email: [email protected]
Harken Italy S.P.A.
Via Della Cerca, 12/14
22070 Lurago Marinone, Como, Italy
Tel: [phone] • Fax: [phone]
Email: [email protected]
Harken France
ZA. Port des Minimes
11 Place du Petit Hunier
17000 La Rochelle, France
Tel: [phone] • Fax: [phone]
Email: [email protected]
