Harman JBL CSLM20 User manual

USER GUIDE
CSLM20
LAVALIER MICROPHONE
WITH EARPHONE

CSLM20

CONNECTING THE MICROPHONE TO
SMARTPHONES/LAPTOPS
i. Plug the 3.5mm TRRS connector into the
headphone jack of the smartphone/laptop.
Audio-out will be played from the earphone & the
lavalier microphone will be used as the default
microphone for calls.
BOX INCLUDES
i. CSLM20 lavalier microphone with earphone
ii. Carry pouch
iii. Tie-clip x 2
iv. Windshield x 2
v. TRS Adapter
i. Connect the TRS adapter to the microphone input
on the desktop (usually a pink-colored jack). In
this connection, the earphone will not work; only
the microphone can be used.
CONNECTING THE MICROPHONE TO A DESKTOP
i. The benefit of a microphone attached to the user's
clothes is that the microphone will maintain a
constant working distance independently of the
user's movements and thus ensure a constant
USING THE MICROPHONE

output level. Also, a clip-on microphone allows the
user to move about freely and keeps their
hands free.
ii. Hold the lavalier microphone firmly & attach the
tie-clip to the microphone at a point just below the
microphone body, as shown. Attach the windshield
on the microphone.
CLEANING
i. To clean the microphone case, use a soft cloth
moistened with water.
iii. Attach the microphone to the user’s upper body,
placing it as close as possible to his/her mouth.

FEATURES
i. Omnidirectional lavalier microphone with
windshield
ii. Perfect for video calls & conference calls
iii. Compatible with laptops & most smartphones
iv. Comfortable earphone for monitoring
SPECIFICATION
Polar pattern Omnidirectional
Audio frequency
bandwidth 60Hz to 18KHz
Sensitivity -30dB±3dB
(0dB=1V/Pa at 1KHz)
Max. sound
pressure level 110 dB
Output Impedance 2.2 K ohms
Length 2 Meters
Speaker Impedance 16 ±20% Ohms
