PRV90
TABLE OF CONTENTS
Table of Contents ------------------------------------------------------------------ pg 1
Product Description -------------------------------------------------------------- pg 2
Front Panel Layout -------------------------------------------------------------- pg 3
User Operation ------------------------------------------------------------------- pg 4
General -------------------------------------------------------------------------- pg4
Radio --------------------------------------------------------------------------- pg 4
Auxiliary Input --------------------------------------------------------------- pg 4
USB ----------------------------------------------------------------------------- pg 5
Bluetooth ----------------------------------------------------------------------- pg 5
Installation ------------------------------------------------------------------------ pg 6
Wiring ------------------------------------------------------------------------------ pg6
Troubleshooting ------------------------------------------------------------------ pg 7
Installation Bulletin --------------------------------------------------------------- pg 8
1

ProductDescription
This radio is another forward thinking [product from Infinity by Harman. Other Hannan
brands include JBL, JBLProfessional, AKG, Mark Levinson, Hannan Kardon, and
Revel. Harman was purchasedbySamsung in 2016. Prospec Electronics is Harman's
exclusive distributor to OEM's in the marine, side by side, golf car, and hot tub
industries .Ourproducts range from mechless receivers, amplifiers, subwoofers,
speakers, and other accessories. Prospec is located in Mount Pleasant, S.C., a stone's
throw away from Charleston, S.C. Should you need our expertise, please do not hesitate
to give us a call. We're all aboutthe music andthis music should resonate from
components verifiedto complementyour hard earned off road purchase.
The PRV90 incorporates the following features:
\• AM/FM
0 BluetoothAudio Streaming
i' USB input (for USB drives only)
,.-.- .. ,- Auxiliary input
e Waterprooffaceplate
C, 40Wx 4 amplifier
0 U.S. and Europeantuning
~ii Chargingthrough USB
2

Front Panel Layout
PRV-90
+
~
POWER
Power On/Off button.
Short push for the first time to turnthe unit on.
With unit poweredon, short push for MUTE feature.
Press and hold for morethan2 secondstoturn the unit off.
MODE Mode Function.
SEL Switches amongstRadio, USB andAuxiliary mode.
SELstands for SELECT.
BAND
In Radio mode, this works Band Function. I
Ml
In MP3 playingmode, it works Play /Pausefunction.
VOL+
Volume Increase.
VOL-
Volume Decrease.
... Track Down / Tune Down/ Rever se
..
TrackUp / Tune Up / Fast Forward.
3

General Operation
A. SEL button
Press and hold this button to enter into SELECT function, then repeatedly short push
in succession to access the following menu options: Bass, Treble, Balance, Fader,
Loud, EQ, Beep, Initial Volume, Area. Press the VOL+ or VOL- to adjust the options.
-LOUD. Choose between Loud ON or OFF.
- EQ. Choose between Classic, Pop, Rock, Jazz and EQ off.
-Beep. Choose between Beep ON, Beep 2ND, Beep OFF. Beep ON will result in
a sound at the press of every button; Beep 2ND will result in the beep
sound once the button is long pressed; Beep OFF results inthe beep sound off
completely.
-Initial Volume. Refers to the loudness level upon start of the receiver.
-AREA. Choose betweenUSA and Europe.
(<J1~>
Radio Operation •
A. Press Ml button (BAND function) to access FM and AM. There are three FM bands
andtwo AM bands.
B. Tuning. A short press of the T or A button results ina search of the station and
stoppage at station of next sufficient signal strength. A long press results in manual
tuning mode, allowing you to search one odd digit frequency at a time. (Itwill revert
back to AUTO tune mode without operation in 5 seconds.)
AuxiliaryInputMode ,-.. ••
A. Press the Mode button until "AUX"appears on the LCD screen. ,.
B. The use of auxiliary mode allows youto play the portable music cle ·1 ice through
the headphonejack. ·
Note: An additional accessory/adaptor must bepurchased in order for this to happen.
Prospec's part, SEAMINI2, or SEAUSBMINI36 fulfills this option.
4

USB Operation ~
Note: USB slot is for USB flash drives only. For play of other brands of media, please use the
auxiliary input or Bluetoothoptions.
A. Insert a USB flash drives into the USB slot. *Songs must be of the mp3 or wma format.*
B. Ill-II button. Press to pause the track. Press again to resume play.
C. T and ..A. button(Track Up/ Track Down)
Shortpress Track Up or Track Down button to select the next or previous track.
Press and hold Track Up or Track Down button to fast forward or rewind the
current trackrespectively.
Bluetooth Operation 0
Your media device must incorporate the Bluetooth option in order to stream music.
A. First, make sure you are in the BT mode.
B. While in BT mode, press and hold BAND button until PAIRING appears.
C. Next, go to settings on the Bluetooth device and turn the Bluetooth option to "on".
Pick the "PRV-90" option on your Bluetooth enabled device
If your stereo does not immediately pair, press BAND. This will allow the pairing
process to finalize. A higherpitch frequency noise will alert you to the
connection/success!The display will also read "CONN OK" (connection ok).
D. To disconnect your device, press and hold BAND button. "DISCONN" will aypear
letting you know you have successfully disconnected. ·
E. While BT Music playing, push Ml to Pause playback.
Cleaning Note: Do not use a pressure washer
or chemicals to clean this faceplate. Use a
sponge, soap, and water.
5

Installation
A mounting gaskethas been added inside the package for convenience. Trace along the
outside edge and this will be yourcutout.
Mounting Illustration
1. Do not install beneath cup holders 2. See important installation instructions on
6
page 8.
Rear of the Audio Unit
◊
L-----C=:J (ANT JACK)
(BACK.UP B+ ) - OiCl-~:,___J
(GROUND) ____ _,.,,._.,__.
GRAY
( FRONT LEFT )
GRAY/BLACK
VIOLET
(REAR LEFT)
VIOLET/BLACK
RED (AUX)
WHITE
(USB)
(FRONT RIGHT)
( REAR RIGHT)

Troubleshooting
*Note: In many respects, a stereo acts much like a computer and occasionally requires a
reboot. In the unlikely event of product malfunction, a reset can usually fix the issue.
Reset Function: With the unit powered off, press SEEK DOWN then SEEK UP in
succession three times in a row. Once this occurs, the display will read SYS CLR,
indicating a successful reset.
Issue Cause Solution
No power
1. Incorrectwiring
1. Double check wiring
2. Fuse is blown
2. Replace fuse
3. Low batteryvoltage 3. Check voltage
of vehicle battery
with multimeter. Voltage must
be at least 11 V.
No Sound
1. Speakerconnection
1. Double check connections.
came loose
2. Bad speaker 2. Replace
bad speakerwith known
good speaker and connect.
3. Output blown
3. Send unit in forrepair.
4. Volume too low on
4. Increase volume of media device
media device
No Reception
1. Antenna not firmly 1. Insert.firmly
seated in socket
USB stick not 1. File must be a mp3 1. Convert format to mp3 or wma.
reading
orwma file \
While in Bluetooth mode:
No Connection 1. You are not connected 1. Choose"PRV90"
to the "PRV90"
address on your
portable media
device.
2. Out of range 2. Bringportable mediadevice closer
' to the receiver. Device needs to
be
within 30'.
3. The connection is 3. Ask the person who first paired to
already in use . drop out.
7

INSTALLATION BULLETIN
To avoid possible water ingress into wire harness area, route the harness
in the downward direction as shown below on the left . Do not route the
harness in the upward direction as shown on the right.
Installation Instructions
8
NO.
PART DESCRIPTION
1 RADIO
2
MOUNTING PLATE
3 MOUNTING STUDS
4 JAMB NUTS
5 MOUNTING BRACKET
6
SPRING WASHER
7
OUTER NUTS
Instructions:
1. Install jamb nuts (4) loosely on mounting
studs (3), so they will not touch mounting
brackets (5) when installed.
2. Slip mounting bracket(5) on and make
flush with mounting surface (2).
DO NOT TIGHTEN
3. Snug spring washer(6) and outernuts (7)
against mountingplate (2).
DO NOT TIGHTEN
4. Po sition jamb nuts (4) approximately
1/16" from mountingbracket.
5. Tighten outer nuts (7) completely.
