Harris assuredcommunications X75HD User manual

Edition F
175-000248-00
/
Control Panels for X75 Systems
Installation and Operation Manual

Edition F
December 2007
Control Panels for
X75 Systems
Installation and Operation Manual

ii Control Panels for X75 Systems Installation and Operation Manual
Trademarks and Copyrights
Copyright 2007 Harris Corporation, 1025 West NASA Boulevard,
Melbourne, Florida 32919-0001 U.S.A.
All rights reserved. This product and related documentation are protected
by copyright and are distributed under licenses restricting their use,
copying, distribution, and decompilation. No part of this product or related
documentation may be reproduced in any form by any means without prior
written authorization of Harris Corporation and its licensors, if any. This
publication could include technical inaccuracies or typographical errors.
Changes are periodically added to the information herein; these changes
will be incorporated into new editions of the publication. Harris
Corporation may make improvements and/or changes in the product(s)
and/or the program(s) described in this publication at anytime.
All trademarks are the property of their respective owners.
Warranty Information
The Limited Warranty Policy provides a complete description of your
warranty coverage, limitations, and exclusions, as well as procedures
for obtaining warranty service. To view the complete warranty, visit
www.broadcast.harris.com
This publication is provided “as is” without warranty of any kind, either
express or implied, including, but not limited to, the implied warranties
of merchantability, fitness for a particular purpose, or non-infringement.

Control Panels for X75 Systems Installation and Operation Manual iii
Contents
Preface
Manual Information .............................................................................. vii
Purpose ........................................................................................... vii
Audience ........................................................................................ vii
Revision History ............................................................................ vii
Writing Conventions ..................................................................... viii
Unpacking/Shipping Information .......................................................... ix
Important Safety Instructions ...................................................................x
Servicing ...........................................................................................x
Safety Terms and Symbols ......................................................................x
Terms and Symbols Used in this Manual .........................................x
Terms and Symbols Found on the Product ..................................... xi
Important Safety Instructions ................................................................. xi
Injury Precautions ................................................................................ xiii
Certifications and Compliances .............................................................xv
EMC Standards ...............................................................................xv
Working Environments E4 and Class A ...................................... xvii
Additional EMC Information ....................................................... xvii
EU Standards ...................................................................................... xviii
Waste from Electrical and Electronic Equipment (WEEE) Directive
xix
Safety Standards .....................................................................................xx
Chapter 1: Introduction and Installation
Overview ..................................................................................................1
Product Description ..................................................................................2
Frame Mounted Control Panel ..........................................................2
X75-RCP ...........................................................................................2

iv Control Panels for X75 Systems Installation and Operation Manual
Contents
Front Views ...................................................................................... 3
Packing List ............................................................................................. 4
Installing the Control Panels ................................................................... 5
Frame-Mounted Local Control Panel .............................................. 5
Retrofit Local Control Panel ............................................................ 5
X75-RCP .......................................................................................... 6
Chapter 2: Operation via Front Panel Controls
Overview ................................................................................................. 7
Front Panel Description ........................................................................... 8
About the VFD Screen ............................................................................ 9
Using the Control Knob and Menu Control Buttons ............................... 9
Using Multi-Function Buttons ....................................................... 10
Navigating Through the Menus ..................................................... 11
Exploring the Main Menu ..................................................................... 12
Using Front Panel Control Shortcuts .................................................... 15
Video Input .................................................................................... 16
Audio Input .................................................................................... 19
Audio Proc Amp Settings .............................................................. 21
Other Shortcuts ...................................................................................... 31
ARC (Aspect Ratio Converter) ...................................................... 32
Black .............................................................................................. 36
Bypass ............................................................................................ 36
Chroma ........................................................................................... 36
FAV1 and FAV2 (Favorites1 and Favorites2) ............................... 36
Frz Mod (Freeze Mode) ................................................................. 39
Hue ................................................................................................. 40
Luma .............................................................................................. 40
Keyer .............................................................................................. 40
Memory .......................................................................................... 41
NR (Noise Reduction) .................................................................... 45
Option ............................................................................................. 46
Take ................................................................................................ 48
Timing ............................................................................................ 48
TSG (Test Signal Generator) ......................................................... 49
Chapter 3: Status and Alarm LEDs
Overview ............................................................................................... 53
Location ................................................................................................. 54

Control Panels for X75 Systems Installation and Operation Manual v
Contents
Genlock Status LED .......................................................................54
EDH Status LED .............................................................................55
TBC Status LED .............................................................................55
Autotrack Status LED .....................................................................56
M-Path Status LED .........................................................................56
Simulcast Status LED .....................................................................56
Major and Minor Alarm LEDs .......................................................57
Mem Active LED ............................................................................57
Video Input LEDs ..................................................................................58
Audio Input LEDs ..................................................................................58
Control Mode Status LEDs ....................................................................59
Chapter 4: Specifications (X75-RCP)
Overview ................................................................................................61
Dimensions and Weight .........................................................................62
Network Control ....................................................................................62
Power Consumption ...............................................................................62
Appendix A: Servicing Instructions
Overview ................................................................................................63
X75-RCP Fuse Rating and Replacement ...............................................64
Appendix B: Display Screen and Device
Setup Parameters
Overview ................................................................................................65
Display Screen Setup Parameters ..........................................................66
Scroll Mode .....................................................................................66
Display Intensity .............................................................................66
Screen Saver Timeout .....................................................................66
Screen Saver Select .........................................................................67
Shaft Direction ................................................................................67
1 Click Favorite ..............................................................................67
Backlite ...........................................................................................67
Device Setup Parameters .......................................................................68
Machine Name ................................................................................68
Device IP .........................................................................................69
Subnet Mask ...................................................................................69
Gateway ..........................................................................................69
Save IP ............................................................................................69

vi Control Panels for X75 Systems Installation and Operation Manual
Contents
Index
Keywords .............................................................................................. 71

Control Panels for X75 Systems Installation and Operation Manual vii
Preface
Manual Information
Purpose
This manual details the features, installation procedures, operational
procedures, and specifications of the local and remote control panels for
X75 systems.
Audience
This manual is written for engineers, technicians, and operators
responsible for the installation, setup, and/or operation of the local and
remote control panels for X75 systems.
Revision History
Table P-1. Revision History
Edition Date Revision History
Preliminary December 2004 Preliminary release
A January 2005 Initial release
B April 2005 Addition of SD capabilities
C June 2005 New warranty, trademarks, and
license agreement
D March 2006 Updated functionality
E January 2007 New retrofit kit information
F December 2007 Updated photos

viii Control Panels for X75 Systems Installation and Operation Manual
Preface
Writing Conventions
To enhance your understanding, the authors of this manual have
adhered to the following text conventions.
Obtaining Documents
Technical documents can be viewed or downloaded from our Web site.
Alternatively, contact your Customer Service representative to request a
document.
Table P-2. Writing Conventions
Term or Convention Description
Bold Indicates dialog boxes, property sheets,
fields, buttons, check boxes, list boxes,
combo boxes, menus, submenus, windows,
lists, and selection names.
Italics Indicates email addresses, the names of
books or publications, and the first
instances of new terms and specialized
words that need emphasis.
CAPS Indicates a specific key on the keyboard,
such as ENTER, TAB, CTRL, ALT, or
DELETE.
Code Indicates variables or command-line
entries, such as a DOS entry or something
you type into a field.
> Indicates the direction of navigation
through a hierarchy of menus and
windows.
hyperlink Indicates a jump to another location within
the electronic document or elsewhere
Internet address Indicates a jump to a website or URL
Note
Indicates important information that helps
to avoid and troubleshoot problems

Control Panels for X75 Systems Installation and Operation Manual ix
Preface
Unpacking/Shipping Information
This product was carefully inspected, tested, and calibrated before
shipment to ensure years of stable and trouble-free service.
1. Check equipment for any visible damage that may have occurred
during transit.
2. Confirm that you have received all items listed on the packing list.
3. Contact your dealer if any item on the packing list is missing.
4. Contact the carrier if any item is damaged.
5. Remove all packaging material from the product and its associated
components before you install the unit.
Keep at least one set of original packaging, in the event that you need to
return a product for servicing.
In the unlikely event that your product fails to operate properly, please
contact Customer Service to obtain a Return Authorization (RA)
number, then send the unit back for servicing.
Keep at least one set of original packaging in the event that a product
needs to be returned for service. If the original package is not available,
you can supply your own packaging as long as it meets the following
criteria:
• The packaging must be able to withstand the product’s weight.
• The product must be held rigid within the packaging.
• There must be at least 2 in. (5 cm) of space between the product and
the container.
• The corners of the product must be protected.
Ship products back to us for servicing prepaid and, if possible, in the
original packaging material. If the product is still within the warranty
period, we will return the product prepaid after servicing.

x Control Panels for X75 Systems Installation and Operation Manual
Preface
Important Safety Instructions
Review the following safety precautions to avoid injury and prevent
damage to this product or any products connected to it. Read these
instructions. Keep these instructions. Heed all warnings. Follow all
instructions.
Servicing
Only qualified personnel should perform service procedures. Refer all
servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Safety Terms and Symbols
Terms and Symbols Used in this Manual
WARNING statements identify conditions or practices that can result in
personal injury or loss of life. High voltage is present. Uninsulated
dangerous voltage within the product’s enclosure may be sufficient to
constitute a risk of electric shock to persons.
CAUTION statements identify conditions or practices that can result in
damage to the equipment or other property. Important operating and
maintenance (servicing) instructions are included in the literature
accompanying the product.
CAUTION: This icon identifies conditions or practices that can result in
damage to the equipment or other property if proper care during use and
transport is not taken.

Control Panels for X75 Systems Installation and Operation Manual xi
Preface
Terms and Symbols Found on the Product
Important Safety Instructions
Read these instructions. Keep these instructions. Heed all warnings.
Follow all instructions.
DANGER: Indicates a hazard for high voltage, fire, or personal injury
immediately accessible as one reads the marking
WARNING: Indicates a personal injury hazard not immediately accessible
as one reads the marking
CAUTION: Indicates a hazard to property, including the product, or the
need to take attention and refer to the manual
Protective ground (earth) terminal
Fuse: Replace with same type and rating of fuse
Observe precautions for handling electrostatic-sensitive devices
Do Not Use This Apparatus Near Water
Clean Only With a Dry Cloth
Do Not Block Any Ventilation Openings
Do not block any of the ventilation openings. Install in accordance with
the manufacturer’s instructions.
Keep Product Away from Heat Sources
Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
Ground the Product
Do not defeat the safety purpose of the polarized and
grounding-type plugs. A polarized plug has two blades with one wider
than the other. A grounding-type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your
safety. When the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.

xii Control Panels for X75 Systems Installation and Operation Manual
Preface
Protect the Power Cord
Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
Use With Proper Equipment
Use only with a cart, stand, tripod, bracket, or table specified by the
manufacturer or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from
tip-over.
Do Not Operate With Suspected Failures
Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as if the
power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, or the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
Use Proper Power Source
Do not operate this product from a power source that supplies more than
the specified voltage.
Install Near Socket Outlet
The equipment shall be installed near the socket outlet, and a disconnect
device shall be easily accessible.
ATTENTION:
Observe precautions for handling electrostatic-sensitive devices.
Fuse Replacement
CAUTION: For continued protection against risk of fire, replace only
with the same type of fuse.
ATTENTION: Remplacer uniquement par un fusible de même type et
calibre.

Control Panels for X75 Systems Installation and Operation Manual xiii
Preface
Injury Precautions
WARNING!
To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture.
AVIS! Risque de choc électrique. Ne pas ouvrir.
Caution
Risk of Electric Shock
Do Not Open
WARNING!
Potentially lethal voltages are present within this product’s frame during
normal operation. The AC power cord must be disconnected from the frame
before the top panel is removed. (In frames with multiple power supplies,
remove ALL power cords.) Power should not be applied to the frame while
the top is open, unless properly trained personnel are servicing the unit.
[Poland] Przod zdjeciem pokrywy wyciagnac wtyczke z gniazda
sieciowego.
Use Proper Power Cord
To avoid fire hazard, use only the power cord specified for this product.
Connect to an Earthed Mains Socket-Outlet
The apparatus must be connected to an earthed socket-outlet.
United Kingdom:
WARNING: This appliance must be earthed.
Norway:
Apparaten må tilkoples jordat stikkontakt.
Finland:
Laite on liitettää suojamaadoitus-koskettimilla varustettuun pistorasiaan.
Sweden:
Apparaten skall anslutas till jordat uttag.
Do Not Operate Without Covers
To avoid electrical shock or fire hazard, do not operate this product with
covers or panels removed.
Do Not Operate in Wet/Damp Conditions
To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture
Do Not Operate in an Explosive Atmosphere
To avoid injury or fire hazard, do not opeate this product in an explosive
atmosphere.

xiv Control Panels for X75 Systems Installation and Operation Manual
Preface
Avoid Exposed Circuitry
To avoid injury, remove jewelry such as rings, watches, and other metallic
objects. Do not touch exposed connections and components when power is
present.
Isolate IT Power System Connection
CAUTION: IT power system shall be isolated from earth, except that one
point may be connected to earth through an impedance or a voltage limiter.
The parts of the equipment required to be earthed shall be connected to
earth electrodes at the user’s premises. Protective earthing shall be provided
either directly to the equipment or into the mains supply building
installation.
Preventing Electrostatic Discharge
CAUTION: Electrostatic discharge (ESD) can damage components in the
product. To prevent ESD, observe these precautions when directed:
Use a ground strap. Wear a grounded wrist strap to discharge the static
voltage from your body while installing or removing sensitive components.
Use a safe work area. Do not use any devices capable of generating or
holding a static charge in the work area where you install or remove
sensitive components. Avoid handling sensitive components in areas that
have a floor or benchtop surface capable of generating a static charge.
Handle components carefully. Do not slide sensitive components over
any surface. Do not touch exposed connector pins. Handle sensitive
components as little as possible.
Transport and store carefully. Transport and store sensitive
components in a static-protected bag or container.
CAUTION: To completely disconnect this equipment from the AC Mains,
disconnect the power supply cord plug from the AC receptacle.
CAUTION: Do not expose this equipment to dripping or splashing and
ensure that no objects filled with liquids, such as vases, are placed on the
equipment.

Control Panels for X75 Systems Installation and Operation Manual xv
Preface
Certifications and Compliances
This product has been tested and found to comply with the following
EN, IEC, FCC, UL, ICES, and CSA standards, per the provision of the
Electromagnetic Compatibility Directive 89/336/EEC of 3 May 1989 as
amended by 92/31EEC of 28 April 1992 and 93/68/EEC, Article 5 of 22
July 1993, and the Low Voltage Directive 73/23/EEC of 19 February
1973 as amended by 93/68/EEC.
EMC Standards
EMC
Standard Description
EN55014 Limits and methods of measurement of radio disturbance
characteristics of electric motor-operated and thermal
appliances for household and similar purposes, electric
tools and similar electric apparatus.
EN55022 Limits and methods of measurement of radio disturbance
characteristics of information technology equipment,
Class A.
EN55103-1 Electromagnetic compatibility—Product family standard
for audio, video, audio-visual and entertainment lighting
control apparatus for professional use, Part 1: Emission,
Environment E4.
EN55103-2 Electromagnetic compatibility—Product family standard
for audio, video, audio-visual and entertainment lighting
control apparatus for professional use, Part 2: Immunity,
Environment E4.
EN61000-3-2 Limits for harmonic current emissions (equipment input
current less than or equal to 16 A per phase).
EN61000-3-3 Limitations of voltage fluctuations and flicker in low
voltage supply systems for equipment with rated current
less than 16 A.
EN61000-4-2 Electrostatic discharge requirements “ESD” 2 kV CD,
4 kV AD.

xvi Control Panels for X75 Systems Installation and Operation Manual
Preface
Per the provision of the Electromagnetic Compatibility Directive 89/
336/EEC of 3 May 1989, as amended by 92/31EEC of 28 April 1992
and 93/68/EEC, Article 5 of 22 July 1993, these devices are for
professional use only and comply with Part 15 of FCC rules. Operation
is subject to the following two conditions:
1. These devices may cause interference to Radio and TV receivers in
residential areas.
2. These devices will accept any interference received, including
interference that may cause undesired operations.
Changes or modifications not expressly approved by the manufacturer,
the party responsible for compliance to the FCC Part 15 Rule, could
void the user’s authority to operate this equipment legally in the United
States.
These devices do not exceed the class A limits for radio noise emissions
from digital apparatus as set out in the interference standard entitled
“Digital apparatus”, ICES-003 of the Canadian Department of
Communications.
EN61000-4-3 Radiated radio-frequency electromagnetic field
immunity test 1V/m {1 kHz 80% AM, 80-1000 MHz}.
EN61000-4-4 Electrical Fast transient requirements “Burst”, 0.5 kV
Sig. & Ctrl. Lines 0.5 kV a.c. & d.c. Power line, 0.5 kV
functional earth.
EN61000-4-5 Surge Immunity test 0.5 kV a.c. Power line.
EN61000-4-6 Immunity to conducted disturbances induced by radio
frequency fields 1 V rms 0.15-80 MHz Sig. & Ctrl.
Lines, 3 V rms 0.15-80 MHz d.c. Power line, 1V rms
0.15-80 MHz a.c. Power line, 1V rms 0.15-80 MHz
functional earth.
EN61000-4-11 Voltage dips, short interruptions and voltage
variations-immunity tests.
EMC
Standard Description

Control Panels for X75 Systems Installation and Operation Manual xvii
Preface
Working Environments E4 and Class A
This product is intended for professional use in a controlled EMC
environment such as a purposely-built broadcast studio.
Additional EMC Information
This device is for professional use in a controlled EMC environment,
such as purpose-built broadcast studios.
EMC regulations require that the radiation emitted from this unit does
not exceed certain limits. These limits are only met when the front panel
is closed and the two thumb screws are secured.
Compliance to the EMC regulations is also dependent on the use of
suitably shielded (screened) cables. Coax cables should be of the
double-shielded (screened) variety. Unused BNCs should be fitted with
75Ωterminations.
All audio cables should be screened with the shield (screen) making
good contact with the metallic parts of the cable connectors.
D-type connectors used with this unit should always have metallic
shells with the shield (screen) of the cable mechanically bonded to the
metal shell. It is further recommended that the D-type cable connectors
be of the “dimple” variety. These connectors make a better contact and
consequently improve EMC performance.

xviii Control Panels for X75 Systems Installation and Operation Manual
Preface
EU Standards
Restriction on Hazardous Substances (RoHS) Directive
Directive 2002/95/EC—commonly known as the European Union (EU)
Restriction on Hazardous Substances (RoHS)—sets limits on the use of
certain substances found in electrical and electronic equipment. The
intent of this legislation is to reduce the amount of hazardous chemicals
that may leach out of landfill sites or otherwise contaminate the
environment during end-of-life recycling. The Directive took effect on
July 1, 2006, and it refers to the following hazardous substances:
• Lead (Pb)
• Mercury (Hg)
• Cadmium (Cd)
• Hexavalent Chromium (Cr-V1)
• Polybrominated Biphenyls (PBB)
• Polybrominated Diphenyl Ethers (PBDE)
According to this EU Directive, all products sold in the European Union
are fully RoHS-compliant and “lead-free.” (See our website for more
information on dates and deadlines for compliance.) Spare parts sup-
plied for the repair and upgrade of equipment sold before July 1, 2006
are exempt from the legislation. Equipment that complies with the EU
directive are marked with a RoHS-compliant emblem, as shown in
Figure 1.
Figure P-1. RoHS Compliance Emblem
