Hatco HDW-2-MN Series Application guide

Nacho Chip
Drawer Warmer
REPLACEMENT
PARTS LIST
HDW-2-MN Series

Form No. HDW2MNRP-0505 2 Printed in U.S.A.
CAUTION - HOT
F
o
HATCO NACHO CHIP DRAWER WARMER HDW-2-MN SERIES
CAUTION - Use of replacement
parts other than those supplied by Hatco Corporation may result in damage to the unit or injury to personnel.
Model Designation HDW-2-MNH =Hatco
D =Drawer W=Warmer 2 =Number of Drawers M = Macho N =Nacho
20
19
19
17 13
12
5
6
18
10
11
8
7
9
114
15
3
3
319
19
18
2
20
1
2
4
16
24 Hour 7 Day Parts & Service Assistance avail- able in the United States and Canada by calling [phone].

Form No. HDW2MNRP-0505 3 Printed in U.S.A.
PARTS COMMON TO ALL HDW-2-MN MODELS
ITEM DESCRIPTION PART NO. QTY. ITEM DESCRIPTION PART NO. QTY.
1 2" (51 mm) Caster with Mounting Plate 04.16.635.00 2 2 2" (51 mm) Locking Caster with
Mounting Plate 04.16.645.00 2
3 Bolt, Caster, S.S. 1/4-20 x 1/2 05.04.201.00 16 4 Roller Assembly, Core 04.16.638.00 8 5 Motor Blower 120V, 60 Hz 02.12.001.00 1 6 Fan Guard 02.12.063.00 1 7 Thermostat Control with Bulb R02.16.039.00 1 8 Temperature Indicator 02.16.057.00 1 9 Transformer, 120-24 Volt 02.17.022.00 1
10 On/Off Rocker Switch 02.19.080.00 1
11 Thermostat Guard 04.16.754.00 2
12 Heating Element 1100 Watt, 120 Volt 02.05.415.00 1 13 Panel Cover, Rear 04.16.747.00 1 14 Power Cord and Plug Assembly R02.18.030.00 1 15 Cord Grip 02.20.269.00 1 16 Cord Grip Locknut 02.20.270.00 1 17 Top, Black Powdercoat 04.16.745.00 1 18 Panel Cover Assembly, Side 04.16.752.00 2 19 Roller Assembly, Drawer R04.16.500.00 4 20 Handle Assembly, Drawer R04.16.533.00 2

HATCO CORPORATION
P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A.
[phone] [phone]
Parts & Service Fax [phone] Int’l. Fax [phone]
www.hatcocorp.com
HATCO AUTHORIZED PARTS DISTRIBUTORS
Form No. HDW2MNRP-0505 May 2005
